Task Li htin PristineHW Series
Pa e 1 of 2 For Hard Wirin 22" Len th, 1 Lamp T2 Linear
Features
• Architecturally pleasin rounded slim profile only 3/4" deep x 4-3/4" wide.
• Provides median foot candle level of 55 on 2' x 5' desk top.
• Prismatic acrylic spread lens.
• Flush push button switch.
• Easy access wirin compartment for hard wirin .
• Can be hard wired from top or back.
• Electronic pro ram start <10 THD ballast.
• Lamp T2 13W, CRI=80, color temperature 3500K,
lamp is included.
• Flat white polyester enamel finish.
• Meets New York City requirements for task li htin .
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier a Genlyte Thomas Company www.li htolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the ri ht to chan e details of desi n, materials and finish.
Copyri ht 2007 Li htolier Section 5/Folio H150-17
Features Dimensions
Alum num
Reflector
4-3/4" (121mm)
22" (559mm)
12" (305mm)
5-1/16"
(132mm)
4-3/4"
(121mm)
3/4"
(19mm)
TM
Architecturally pleasing rounded slim
profile only 3/4" deep x 4-3/4" wide.
1-1/4"
(32mm)
6" (153mm)
8"
(203mm)
T2 Lamp
6-3/16" (161mm)
2 ~ 7/8" K/O
2 ~ 7/8" K/O
3" (76mm)
Center L ne
1-1/4" (32mm)
Easy access wiring
compartment
03/07

Task Li htin PristineHW Series
Pa e 2 of 2 For Hard Wirin 22" Len th, 1 Lamp T2 Linear
Lightolier a Genlyte Thomas Company www.li htolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the ri ht to chan e details of desi n, materials and finish.
Copyri ht 2007 Li htolier Section5/Folio H150-17
Job Information Type:
Ordering Information
Explanation of Catalo Number. Example: PC2W13T2120PTHW
Options/Accessories
Dimming: Consult factory.
Specifications
Materials: Chassis parts are d e-formed cold rolled steel.
Wiring Compartment s 16 gauge cold rolled steel.
Lens: R bbed acryl c.
Reflector: Alum num.
Lamp: T2, 13 watt CRI=80, color temperature 3500K. (Included)
Finish: Cavity–Flat wh te baked enamel, 86% reflectance. Rust preventat ve
undercoat ng.
Chassis exterior–Flat wh te baked enamel.
Electrical: Thermally protected class “P” ballast C.B.M. approved, sound rated
A, <10 THD, non PCB.
Labels: UL and ULc L sted.
PC
Pristine
Series:
Task Li htin
2
Length:
2=22"
W
Finish:
White
13
Lamp:
13 Watt
T2
Lamp Type:
T2=835K
installed
with fixture
120
Voltage:
120
PT HW
Hard Wiring
Compartment
Ballast:
PT = Elec. Pro ram
Start <10 THD
for Linear
T2 Lamp
17-1/2"
(445mm) 6"
6"
6"
6"
6"
6"
6" 12" 12" 12" 12" 6"
60"
25 55 66 55 25
28 72 95 72 28
30 72 94 72 30
10 21 46 21 10
15 26 38 26 15
Pristine Footcandle Readings
TM
Bac Wall
Des Top
