Installation Instructions
Vault w/ visor C-Scroll w/ visor Roundel w/ visor
These installation instructions are valid with the above metrix styles
Mounting Plate Dimensions In [mm]
Lamping Size Chart
(lamps provided by others)
Warning : Before starting any work ensure
that all sources of power are turned off. ll
work must meet local/national codes and be
performed by a certified electrician. Do not
mount fixtures vertically.
Large, INDOOR
YR (30 1/2")
(Yoke mount, Remote ballast)
Visor an Non-Visor
Sheet 2 of 2
ADY071446 Rev A (ECN070295)
C
L
325.9
32
12 "
27
23.2
29 "
32
346.9
"13 32
21
651.7
"25 32
21
114.3
"4 2
1
57.2
"2 4
1173.5
"6 32
27
14 15
16 "
379.3
Mounting dimensions are for 30 1/2"(774.7mm) large YR indoor only
FIXTURE SIZE
(inches/ m m )
WATTAGE # OF
LAMPS LAMP TYPE LAMP DESCRIPTION
LAMP
(not to scale)
30
1/2
/ 774.7 36 W 1 T5 Twin Tube
30
1/2
/ 774.7 40 W 1 T5 Twin Tube
30
1/2
/ 774.7 50 W 1 T5 Twin Tube
30
1/2
/ 774.7 55 W 1 T5
30
1/2
/ 774.7 36 W 2 T5 Twin Tube
30
1/2
/ 774.7 40 W 2 T5 Twin Tube
30
1/2
/ 774.7 50 W 2 T5 Twin Tube
30
1/2
/ 774.7 55 W 2 T5 Twin Tube
30
1/2
/ 774.7 250 W 2 ET18 Metal Halide
30
1/2
/ 774.7 400 W 2 ET18 Metal Halide
30
1/2
/ 774.7 900 W 1 T3 Halogen(Double Ended)
30
1/2
/ 774.7 1000 W 1 T3 Halogen(Double Ended)
