Lightolier Brisa FB9314UDA User manual

Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • 0907
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Brisa™Linear Bow Surface Mount FB9314UDA
Page 1 of 1 Wall/Ceiling Mounted T5 Fluorescent ADA Compliant
Features
1. Housing Sides and ends: Die-cast aluminum.
2. Back Pan: Stamped 18ga. (0.048”) sheet metal.
3. Diffuser: Bowed opal glass or opal acrylic
4. Optics: Internal white acrylic diffuser covers slots on housing sides
and ends.
Mounting
Fixture Mounts directly to 4" octagonal junction box.
Electrical
5. Ballast-Fixture: Has (1) 1-lamp ballast and (1) 2-lamp ballast, allowing for
separate switching.
A. Dali Dimming 120V-277V 1 Lamp 2 Lamp
Voltage 120V 277V 120V 277V
Total Input Watts 18W 18W 35W 35W
Max. Line Current (Amps) 0.15A 0.07A 0.28A 0.13A
Power Factor >0.98 >0.98 >0.98 >0.98
THD <10% <10% <10% <10%
Min. Starting Temp 50°F, -10°C 50°F, -10°C
Dimming Range 100%-1% 100%-1%
6. Luminaire-Ballast Disconnect: Meets NEC 410.130(G)
and CEC Disconnect Requirements.
Lampholders
Fluorescent: Mini Bi-Pin, G5 Base
Lamping (by others)
General Electric Osram/Sylvania Philips
(1) 14W T5 Linear Fluorescent
F14W/T5/*/ECO FP14/* F14T5/*/ALTO
*Manufactures Color Temperature Designation
Finish
Satin Aluminum
Labels
cULus Listed. Suitable for Damp Locations.
Fixture Ordering Information
Catalog No. Description Finish Wattage Volts Lamp
FB9314UDA Linear Bow Surface Mount Dali Dimming Satin aluminum 14W 120-277V (3) T5
Diffuser Ordering Information
Catalog No. Description Finish Dimensions (Nominal)
FBA9 Acrylic Bow Diffuser Opal 9" X 24"
FBG9 Glass Bow Diffuser Opal 9" X 24"
25 5/16”
[643mm]
7 15/16”
[202mm]
2
3 1 5
4
9 5/16”
[237mm]
2 13/16”
[71mm]
1
