E-line ELI-SIP-NVR4-POE User manual

Product Made in China under ISO9001 & ISO1400 standards
Manual Printed in China v1.0
NETWORK VIDEO RECORDER
01.BSM.13.2000006
Connect
Auto Detect
Record

i
About this document
Purpose
This document is for Network Video Recorders, including the product features,
hardware installation, network access, network configuration, daily maintenance, and
troubleshooting.
Intended Audience
This document is intended for:
Technical support engineer
Maintenance engineer
Symbol Conventions
This symbol may be founded in this document are defined as follows:
Symbol
description
Alerts you to a high risk hazard that could, if not avoided.
Alerts you to a medium or low hazard that could, if not
avoid, result in moderate or minor in injury.
Alerts you to a potentially hazard situation that could, if not
avoid, result in damage, data loss, performance
deterioration, or unanticipated results.
Provide a tip that may help you solve a problem or save
time.
Provides additional information to emphasize or
supplement important points in the main text.
Special Notices
When using video surveillance products, comply with applicable statutory and
regulatory requirement to enable and maintain legal surveillance device. It is illegal for
company or person to install surveillance devices in an office to monitor employees
outside scope of local law, or use surveillance devices to invade other people’s privacy
with illegal purposes.
ii
Contents
About this document................................................................................................... i
1 Preface........................................................................................................................ 1
1.1 Important note................................................................................................................ 1
1.2 About this manual........................................................................................................... 1
1.3 Check the installation environment................................................................................ 2
2 Specification ............................................................................................................. 3
3 NVR Networking solutions ................................................................................... 5
4 Installation ................................................................................................................ 6
4.1 Hard disk recommended................................................................................................. 6
4.2 Days recorded................................................................................................................. 6
4.3 Installation...................................................................................................................... 6
4.4 Front panel description................................................................................................... 8
4.5 Rear panel description.................................................................................................... 9
4.6 First boot ...................................................................................................................... 10
4.7 Shutdown ......................................................................................................................11
4.8 Displayer resolution adjustment................................................................................... 12
4.9 Add Network cameras .................................................................................................. 14
4.10 Login.......................................................................................................................... 14
5 Quick configuration .............................................................................................. 16
6 Live video ................................................................................................................ 21
7 Playback................................................................................................................... 25
7.1 Recording playback...................................................................................................... 25
7.2 Recording backup......................................................................................................... 26
8 Alarm searching ..................................................................................................... 30
9 Setup ........................................................................................................................ 32
9.1 NVR setup.................................................................................................................... 32
9.2 Camera management.................................................................................................... 45
10 Web Browser Access NVR ................................................................................. 46
10.1 Login.......................................................................................................................... 46
10.2 Operation Read........................................................................................................... 47

iii
10.3 Live Video.................................................................................................................. 49
10.4 Playback..................................................................................................................... 50
10.5 Alarm Search.............................................................................................................. 52
10.6 NVR setup.................................................................................................................. 52
10.7 Network Camera setup............................................................................................... 53
11 NVRClient Access NVR ..................................................................................... 54
11.1 Start and Run.............................................................................................................. 54
11.2 Login .......................................................................................................................... 54
11.3 System main interface ................................................................................................ 55
11.4 System Management .................................................................................................. 55
11.5 Live Video and Playback............................................................................................ 59
12 F.A.Q....................................................................................................................... 61
1
1 Preface
1.1 Important note
Thank you for choosing our Network Video Recorder (NVR). Please read this user
manual carefully before using NVR.
Network Video Recorder (NVR) is a complicated system equipment. For avoid any
fault caused by installation, debugging, operation and environment causes, please read
below important note:
Read this manual carefully before installation.
In view of the different brands and models of hard disk in the current market, we
recommend using SEAGATE and WESTERN Digital with high stability and high
performance-price ratio.
Never open the device cover and dissemble the device by nonprofessional person,
otherwise may cause damaging and electric shocking.
Video data lost caused by installation, configuration, improper operations, and hard
disk error is born by the buyer.
1.2 About this manual
Before you use this manual, please read below declarations carefully:
This manual is intended for NVR user.
This manual content is suitable for NVR.
This manual gives example to explain NVR operation details and performance
index.
Before using NVR, please read this manual carefully and follow the steps to install
and use.
For any questions during using the NVR, contact service center. The device may be
upgraded without prior notice.

2
1.3 Check the installation environment
Installation environment
Before installing the device, checking the environment according to the
Table 1-1 Installation environment check items
Check item
standard
Moisture-resistant
The relative environment humidity must be in the range from
5% to 95%. If the humidity is higher than 95%, a dehumidifier
must be installed, such as an air conditioner with the
dehumidification function or a dedicated.
Dehumidifier. In addition, water seepage, water dropping, and
dew forming and not allowed.
Dustproof
If the office block is near the source of dust, such as the
colliery, country install for the offices, and anti-burglary and
fireproofing doors must be installed for the equipment room.
Lightproof
The device must be installed in the environment that is not
shined by a strong light, delaying the aging of the device
enclosure.
Installation notice
During the installation, please notice:
NVR power input voltage is DC12V（±5%）and DC48V（±5%）for POE. The supply
voltage must meet the input voltage, can’t be higher or lower.
NVR installation should be kept horizontal.
NVR installation should avoid direct sunlight, and keep away from heat and high
temperature environment.
Make sure connects NVR with other equipment’s normally.
Install the Hard Disk when use NVR first time.
NVR can automatically identify the hard drive capacity, support current market
mainly models. But for NVR work stable we advise to use good brand hard disk.
Others
Please use a soft and dry cloth to clean NVR, do not use chemical solvents.
Don’t put other things on NVR.
NVR is standard of electromagnetic radiation, no harm to human body.
3
2 Specification
System
CPU
Industrial embedded CPU
Operating system
Embedded Linux 2.6
Features
Embedded CMS system, fully functional friendly interface, easy to use;
Original "quick configuration" feature that enables NVR configuration and
management operations easy to get started.
Original "camera private network enables Plug-and-play camera access auto detection
and schedule setup for fast rapid use.
Real-time fault alarm mechanism to timely reporting of hard disks, networks, fault
information, such as camera disconnection; Embedded WebServer using Flash
technology to support common browsers real-time monitoring and playback.
Video
Record Info
4ch recording ,Maximum recording Bandwidth is 18Mbps
Support resolution:1080P,720P,D1
Ability to decode
H.264 (ISO / IEC 14496-10) high profile 4.2
4ch up to 1080Pplayback
Real-time video
Single screen: 1x1080p\/720p/D1 with tour
Quad display of 1080p / 720p / D1 resolutions
Split screen 1/4//6/8/9/16 for D1 resolutions
Output
DVI-I interface to transition through the first converted to VGAor HDMI output.
Supplied with DVI to VGA converter. And DVI to HDMI converter.
Storage

4
HDD
Two external-swappable hard disk , maximum 2x4TB hard drive supported
Audio
In / Out
3.5mm linear audio output
Audio formats
G711_A，G711_U
Network
Transmission control
Embedded network bandwidth adaptive flow control technology.
Interface
1 RJ45 10M/100M network port ;4 RJ45 10M/100M ports with POE
Web
Webserver supported with Flash technology for and popular browsers in real-time
monitoring and video playback, and system configuration.
Network protocol
RTP/RTCP, TCP/UDP, HTTP, DHCP, DNS Client, RTMP for Flash Video
Characteristic
Temperature
Ambient temperature: 0 °C -45 °C, using industrial grade microprocessor, intelligent
heating and cooling
Humidity
00% to 90%
Power consumption
Low-power design, motherboard max power consumption 8W; with 2 3T hard disk
increases 40W power consumption.
Power input
DC12V/5A
DC48V/1.04A ;
Thermal
The main chip heat sink, plus intelligent temperature controlled fans.
Size
Chassis：215mm x 150mm x 100mm（L x W x H）
Weight
3.6Kg No HDD installed.
USB
2x USB2.0 interface, respectively as a backup and USB mouse.
5
3 NVR Networking solutions
This the NVR has 5 Ethernet ports, one is RJ45 without POE, others is POE supported
ports. 4 POE ports connecting device distance less than 100 meters.
POE port
POE ports can connect IP cameras by POE power supply ,so Camera can connect the
NVR directly and NVR will add the camera automatically that connecting by POE and
default recording 7*24 hours .Note the POE only support IEEE802.3af standard .
10M/100M RJ45 Internet port
For connecting the Internet or local network, And NVR need to search the camera by
manually.
The camera dedicated network topology shown in Figure 3-1
Figure 3-1 camera dedicated network

6
4 Installation
4.1 Hard disk recommended
Given the current market of different brands, the uneven quality of the different models
of hard, recommended to use Seagate or Western Digital brands which are designed for
security/server applications offering 24x7 reliable operation.
4.2 Days recorded
Table 4-1 video storage time
HDD capacity
Video stream
Cameras
Days recorded
2x4TB
D1 1.5Mbps
4
129
2x4TB
720p 3Mbps
4
64
2x4TB
1080p 4.5Mbps
4
43
Suggestion: To use two hard disk for reduce the risk of loss
4.3 Installation
The hard specific installation steps are as follows：
Step 1 Remove the hard disk box, shown in Figure 4-2 specific operation.
Figure 4-2 to take the hard disk
box
7
Step 2 Fixed hard disk as shown in Figure 4-3, using supplied screws.
Figure 4-3 fixed hard
Step 3 Insert the hard disk box, shown in Figure 4-4 specific operation.
Figure 4-4 insert hard
-

8
Operation instruction
4.4 Front panel description
Figure 4-5 shows the front panel of the Network Video recorders. Table 4-1 shows the
description of front panel.
Figure 4-5 Front panel
Table 4-1 Front panel description
No.
Name
Description
1
Power indicator
ON-OFF key
Open, close NVR, NVR is turned on the power light is
solid red, power light off means NVR Close.
2
Network LAN
LED
LAN normal solid Green status., Data transmitting
flashing status
3
USB interface
For connecting external mouse, keyboard, mobile hard
disk.
4
HDD data LEN
HDD read and write ,Blue LED flashing
5
HDD Rack
To fix the HDD
9
4.5 Rear panel description
Figure 4-6 shows the rear panel of the Network Video recorders. Table 4-2 shows the
interface of rear panel.
Figure 4-6 Rear panel
Table 4-2 Real panel description
No.
Name
Description
1
POE port
Poe power supply port
2
FANS
When power on Fans ON
3
Power Input
DC12V,5A power input (Supplied)
4
Switch
For switching HDMI or VGA output ,default is
VGA output
5
Network Interface
Headphones, stereo audio device. RJ45 100Mbps
network interface. (WAN Connection)
6
DVI Output
Video output interface, VGA or HDMI output. VGA
uses supplied DVI –VGA converter interface.
7
Audio output
Audio output.

10
No.
Name
Description
8
RST button
Restores the factory default settings. 5 second holds
9
GND connect
GND connect
10
DC48V Power
interface
DC48V.1.04A power input
4.6 First boot
Make sure that the right of access to power NVR.
Ensure correct display HDMI or VGAinterface connection is set from switch
If the front panel of the power indicator lamp does not flash please plug in the power
cable .Enable the power switch, NVR start running. If the front panel power indicator
lamp flashing Red light, please put the switch at front panel to start device. Note: If
want to use POE power supply, please plug in the DC48V power adapter.
After the device starts, the power light is solid red device starts after the self-test, and
the test results are displayed on the screen. Show in Figure 4-7. Entire boot process
takes about two minutes.
Figure 4-7 Device power on
11
When an exception occurs when the device self-test, this interface will stay in the lower
right of the screen, you can choose to continue or shutdown. If you choose to continue,
the device will continue to start, until the device login screen is shown.
NVR hard drive has rigorous testing, if fails, the reasons may include the following：
Unformatted new hard disk. Go to quickly configure the hard disk is formatted。
Formatted hard drive, the NVR supported file systems do not match。
Hard disk is damaged。
4.7 Shutdown
If the equipment is not load, long press the PWR button on the front panel for more
than three seconds, the device will shut down, solid red becomes off after a
successfully shut down.
Shutdown process, the system prompts are off, do not cut off the power。
Equipment running directly through the rear panel power off switch, cut off the
power or unplug the power cord should be avoided.
In some circumstances, the power supply is not normal, will lead to the NVR not to
work properly, serious damage can occur to the NVR. In this environment, it is
recommended to use regulated power supply, or a backup AC source.
If the device is logged into the main interface, you can click the top right
Button or long press the PWR button on the front panel for more than three seconds
will bring up the shutdown interface, shown in Figure 4-8 Interface.

12
Figure 4-8 Shutdown interface
4.8 Displayer resolution adjustment
NVR support resolutions with VGA 1024*768, VGA 1280*1024, VGA1600*1200,
HDMI720P, HDMI1080P, you can select the proper resolution according your
displayer.
For display using VGA set to 1024*768 or VGA 1280*1024. When using HDMI input we
advise to use HDMI 1080P.
Adjustment Steps:
Step 1 Click Change on login interface and find the adjustment interface shown in Figure 4-9.
13
Figure 4-9 Adjust displayer
Step 2 Choose the type of resolution in the resolution of the drop-down box.
Device will automatically switch to the selected resolution and show the dialog for Yes
or Cancel.
If no operate in 10 seconds, displayer will back to previous resolution.
If select Yes then will switch to the selected resolution.
If select cancel display will not save the configuration and back to previous
resolution.
Step 3 Adjust display.
If displayer couldn’t show the full screen (at the corners can’t see ) then we need to
adjust the displayer (we advise to auto adjust first)
1. Click Adjustment button at lower right corner.
2. In the step of the drop-down box to choose the adjustment step.
Step: The moving distance when adjust screen each times , the greater number the
more moving distance, you can select the larger step sizes to adjust sketchy, and
then select the smaller step tuning.
3. Use UP, DOWN, LEFTRIGHT button to adjust the screen.
Step 4 Click the configuration interface to close.
Exist displayer interface
Back to Login interface

14
4.9 Add Network cameras
This NVR allow to connect maximum 4 pcs network cameras.
NVR maximum support to connect 4 pcs 1080P/720P/ D1 resolution
When Add HD IP camera, it can be added by reduction the number of channel or
the camera baud rate.
Detail Specifications please refer to Specifications
Add Network camera
Method1: Add the camera by manually.
Discover the network camera we can discover by broad cast, IP segment search, and pointed
IP search. Network camera have to be pointed IP first and stay with a same sub network
segment.
Method2: Add camera by POE ports .
4.10 Login
Login to the equipment using the following steps：
Step 1 In the login screen shown in Figure 4-10, enter a user name, password.
15
Figure 4-10 Login screen
Step 2 Click Login.
Enter the main interface.

16
5 Quick configuration
Quickly configure some common functions together to facilitate the configuration
management of the NVR. It provides:
The NVR network configuration, disk management, date and time configuration, the
search network camera, video configuration; fast configuration of the features of the
camera network configuration stream configuration, motion detection configuration.
Enter the rapid configuration interface, as shown in Figure 4-11
Figure 4-11 Fast configuration interface
The rapid configuration interface description.
Area 1：NVR Basic information and time synchronization functions.
NVR Basic information configuration.
The NVR can set the name, date and time.
Synchronization time of the network cameras. You can select the manual mode or
automatic mode.
17
When the manual mode is selected, click Button for time synchronization.
Select automatic synchronization mode, time synchronization automatically by
NVR, this means all cameras will have internal times set to match NVR time.
Area 2：Manage cameras certification account.
Can only certification through the camera to normal use, be sure to add the correct
camera certification before adding the camera, the camera certification account list of
account numbers and passwords, this is not same as NVR account users.
Certification account used to log on to the network cameras, for search network camera
login authentication. Only certified network cameras can be added to NVR system.
Systems have a default account admin password admin; you can click Icon to
add a network camera certification account.
Click to select account to be deleted from list.
Area 3：NVR network configuration。
NVR default factory IP address: network 1:192.168.0.121
The basic network configuration can configure the IP address, subnet mask, default
gateway, DNS address and other parameters. Real-time display of the network
connection status and speed. 8.1.5 Network specific parameters, see "Network
Video Recorder User Manual.
Network support the cameras dedicated network function, factory default enables
this feature.
The Camera network is the only network cameras and NVR, there is no other network
equipment network。
Area 4：Hard disk management。
Format the hard disk will cause video loss, please use this feature with caution。
Power until off to remove the hard drive, use the software to control this process as
below otherwise it may cause damage to the hard disk recordings.
Hard disk management for hard disk management NVR：
Format hard disk. Click the Format button, pop-up prompts, choose to format.
Capacity. Note: 4T formatted hard disk takes about 10 minutes to complete.
Load or unload HDD. Please uninstall the need to pull out the hard disk.

18
Modify hard disk group.
(Normal, abnormal, unformatted drive or does not exist) to view the status of the
disk.
View the disk space and the total space.
Area 5：Select Network Camera
NVR will automatically search for the network cameras.
When the number of network cameras is not more than 4 units, NVR automatically
add the management list.
When the number of network cameras of more than 4 units, NVR automatically
randomly add 4 units to manage, and prompted a warning, as shown in Figure 4-12.
Figure 4-12 Device DiscoveryTips
You must on the NVR management of equipment selection, click ignore NVR
management network camera, click, pop-up camera selection screen shown in Figure
4-13.
Figure 4-13 Device DiscoveryTips
Click the Apply button to complete the network camera selection.
Area 6：Configure network camera.
You can view the status of the network camera, set the name of the network cameras,
IP address, video strategy, stream parameters, and motion detection parameters.
View the status of network cameras, status: online, not online, account errors.
Online equipment, you can click Real-time video preview.
19
Modify the name of the network camera.
Enter the desired name of the device corresponds to the name of the bar, you can
modify the name of the camera.
Modify the IP address of Network Camera.
4. Click to modify the IP address, network cameras IP Settings dialog box pops up
5. Set the network camera IP specific operation methods and procedures, see the
"Network Video Recorder User Manual in 8.1.5 Network.
Set video strategy.
1. Video strategy information, click on the desired modifications configuration dialog
pop-up video strategy；
2. Specific methods of operation and the steps set video strategy see 8.1.7 Video
Network Video Recorder User Manual.
Set the device stream.
3. Click stream information required to modify the pop-up the stream configuration
dialog box shown in Figure 4-14 will show.
Figure 4-14 stream quick configurations
4. Applied to all of the same device switch stream is set to open, click the Apply
button will automatically set the current parameter to all devices with the same
resolution parameters.
Set to detect alarm.

20
5. Click the desired modification motion detection, motion detection alarm dialog
pops up.
6. If the motion detection alarm, you must set the arming time and detection area.
21
6 Live video
Input the username and password, click login.
Enter the live video interface, which looks like Figure 4-15.
Figure 4-15 Live video interface
g
In the live video interface, you can select the camera from the left list to the live video
channel to do the below operates:
Live video
Alarm log tracking
Monitor the recording status
PTZ Control
Audio monitor
Full screen automatically
Video mark
Sensor configuration

22
Decoding ability
This system decoding ability is 6 channels D1 or 1 channel 720p or 1 channel 1080p. If
it is over loaded, then it will print out “Decoding ability not enough” on the screen
showing area.
Intelligent adaptive mechanism of stream frame rates
This system provides the intelligent adaptive mechanism of stream frame rates.
When you are selecting the camera to watch the live video, the system will select the
suitable stream according to system’s own decoding ability and live video windows.
Always make the system working with best performance.
If you need to change the streams manually, you need right click the screen to call the
menu, then we will be able to see all the available streams in current camera. And after
we switched the streams, by the bottom line of the live video window we will see the
stream information.
Live video interface introduction as Figure 4-15.
Table 4-3 Live video interface introduction
Items
Name
Content
1
Top menu
Click Live video, Recording playback, Alarm search and
Quick setup to enter the responding interface.
Click icon to check the HDD information.
Click icon to enter the recording backup interface.
Click icon to lock the interface.
2
Channel
Layout
When you are watching the live video, we can select the 1
screen, you can select 1 display, four display, six display
layout and other layout mode. After we selected the layout
mode, we can move the camera from the left list to the
layout screen, then click save button to save the layout.
There exist two option ”Shared layout” ”May layout”, this
system also support |”Wheel guard”mode, we can
configure the wheel guard mode in system management and
live video layout.
3
Camera
List
In the camera list it listed all the cameras in the system.
means normal, means offline, means
unverified.(username or password is not correct)
4
Alarm
informatio
n
In this area will display the alarm information include
motion detection and I/O input alarm. This information area
will only display recently latest 20 alarm information. Click
to clear the information.
23
Items
Name
Content
5
Bottom
menu
Click 、and icon, we can try to hide or
display the layout list, alarm list and alarm information.
：Play live video button.
：Close live video button.
：Mark tag button, you can mark the tag during the live
video, it will helps to track the video fragment in recording
playback.
：Click this button will call , we
can select which one want to display according to the
requirement.
：PTZ menu button, click will call the PTZ control
menu.
6
Live
video
Display the live video, and configure the sensor settings.
If you need to change the streams manually, we can right
click the menu, it will list out all the streams which is
available for current device. After we selected one of them,
it will also display the stream information at the bottom
side.
Full screen automatically
Click button, it will be available to choose whether enable the full screen
function, also the time delay for full screen showing. When this function is enabled, if
we didn’t do any actions during the delay time period, then it will go to the full screen
mode immediately. When it is in full screen mode, after you moved the mice to the
bottom line it will give out the tool bar, click the icon in tool bar we can exit the
full screen mode. Then you click can go to the full screen mode manually again.
PTZ control
Click button, call the PTZ control menu, as Figure 4-16 showing. In this interface
you can adjust pan, zoom, preset, trajectory, scanning, infrared light, north, timer
settings etc.

24
Figure 4-16 PTZ Control menu
PTZ Control menu only can be cooperate with IPS Dome and Ext PTZ platform.
Click button to close the PTZ configuration menu.
Click button to exit the PTZ control menu.
Live video fast operation
Right lick mice to call Figure 4-17 interface, call the menu “Showing title, Showing
stream info, Enable audio, Stream switch, Sensor configuration etc.”
Figure 4-17 Live video monitor menu
25
7 Playback
7.1 Recording playback
Recording playback will play back the video which is recorded in local HD. Like
Figure 4-18 showing.
Figure 4-18 Local playback
Playback operations steps.
Step 3 Choose the camera which you want to playback.
Click one from the list at left side, icon means this camera has been selected,
icon means camera has not been selected.
Step 4 . Date selection.

26
You can select the date period at the calendar. Click icon 、to switch month,
click 、to switch year. Means selected date. When it is green marked
means this day have recording files, otherwise there is none recording in that day.
Step 5 Recording show.
After selected the device and date, at the bottom area of the live video area it will
display the recording status. The scale on the time axis showing the recording time
period, blue marked means the current playback video time. The playback video will be
displayed above the time axis, blue marked means retain video, red marked means
alarm video, yellow means label video, green means normal video.
: You can input the time. After
clicked , the playback video will jump to the pointed time.
: After the time zone, you can select the time interval:
15 minutes, 30 minutes, 1 hour, 4 hours, 8 hours, 12 hours, 1 day.
When 1 hour is selected, then the time period between two blue tagging means 1 hour.
Step 6 Playing Playback
After selected the camera and date, you can start playing playback, click button
to start play.
Figure 4-19 Control tool bar
From left to right are: Play, Pause, rewind 10 seconds, single frame playing, rewind,
fast forward and full screen button.
During the playback, you can try to move the mice to control the playback processes, click
to switch to the full screen mode.
-
7.2 Recording backup
Step 7 Configure the backup path.
Click button to call the backup interface, click button to call the backup
path configuration interface like Figure 4-20.
27
Figure 4-20 Backup path browser
In the backup path, it is displaying the current backup path, if it is none, then you need
to select one, in the below list it is showing all the available storage path. This NVR
support two kinds of the storage method: Network storage device (NAS) and USB
storage device (U disk or Removable HDD).
Network storage device
7. Double click the Add network disc, or right click the menu to call the Add network
disc interface. Like Figure 4-21.
Figure 4-21 Add network disc
8. Input the IP address, path, account and password, click Add button.
9. Check the network disc status. The status list: OK, connect fail, unavailable. Only
when status is OK it means the network disc can be used for backup normally.

28
10. Double click go into the network disc path list, select the backup path, click ok
button save and exit.
USB Storage device
1. Insert U disk or removable HDD to the USB interface.
2. NVR will detect the USB storage device automatically, after detected successfully,
it will showing USB storage device.
3. Right click menu to select unmounts or formatting options on the U disk.
4. Double click into the USB storage device path list, select the backup path, click OK
button and exit.
Step 8 Configure the backup file options.
Backup file large size, we can define the maximum size of individual file.
Create the subdirectories, can be specified create the directories based on the
network cameras IP or ID.
Whether to combine video clip, you can specify whether to make two
discontinuous video merged into one file.
Step 9 Select backup recording
Method one: We can select the recording and backup during the playback processes.
Recording backup control bar as Figure 4-22 showing:
Figure 4-22 Recording backup control bar
11. Click the Start button to start selecting the recording segment.
12. Select the recorded files, keep pressing mice left button move to left or right side to
high light the files which you want to make the backup.
13. .Click Stop button to stop the selection. (You can also click cancel button to cancel
the current selected video segment.)
Click backup to start the recorded files backup.
Method two: In alarm searching, when we are playing the playback alarm triggered
video, we can click backup to make the backup files.
Step 10 View backup file progress
You can check the backup status in backup interface, means backup is in
processing, means wait for backup, means backup stopped, means backup
failed, means backup finished.
Step 11 Backup file searching
Enter the backup directory folder, you can check all the backup files like
Enter the backup path folder to check the backup files. Like Figure 4-23.
29
Figure 4-23 File search

30
8 Alarm searching
In alarm searching interface we can search the alarm recording.
Operation steps
Step 12 Click button enter into the alarm management interface like
Figure 4-24 showing.
Step 13 You can select the camera which you want to search the alarm information from left
list. Means this camera have alarm information.
Step 14 We can select the alarm type at the Type drop-down menu.
Figure 4-24 Alarm searching interface.
Step 15 Date selections.
You can choose the date period which you want to search in the calendar area.
Click 、to switch the month, click 、to switch month. Means the
date which has been selected. If it is red color then it means in that day it have the
alarm trigger recording.
Step 16 Recording show.
31
After we selected the device and date, we can try to play the alarm recording files
below type area.
Step 17 Alarm triggers recording play.
Select the alarm trigger recording files, click button to start playing.
Step 18 Alarm recording backup
Select the recorded files and click backup button to make backup files.

32
9 Setup
Setup includes NVR setup and camera setup. NVR setup for NVR configure and
camera setup for cameras configure.
9.1 NVR setup
Click NVR setup in upper right to inter the NVR configure interface show in Figure
4-25.
Figure 4-25 NVR setup
9.1.1 Device information
When inter NVR setup interface, we can see the system information show in Figure
4-25 .
Device information includes:
Device ID
Device Name
Manufacturer ID
Manufacturer Name
33
Hardware Version
Channel Qty
Disk Qty
Only Device Name can be edit, other parameters can’t be edit.
When device update the device info will auto update as well and will keep same step
with the software version.
9.1.2 Device Management
User and search, add, delete cameras through device management.
Select NVR setup->Device Management，
Enter the camera management interface, like Figure 4-26 showing; it will list all the
cameras which has been connected with NVR, and also some basic information of
them.
Figure 4-26 Device Management interface
Search and add cameras.
The steps of search and add cameras like below:
Step 19 Click the add button to call the camera searching interface like Figure 4-26 .
Step 20 Add the cameras according to the IP segment or something specific.
Add IP address
14. Click Add button in IP address, to call the IP adding interface as Figure 4-27.

34
Figure 4-27 Add IPsection.
15. Input the Begin IP address and End IP address and Port number.
16. Click Apply to finish the operation.
17. This system will search the IP cameras in such an IP segment automatically, and
display the searching result below.
Add manually
18. Click button, to call the add cameras interface like Figure 4-28
showing.
Figure 4-28 Add cameras manually
19. Input the IP address and Port number.
20. Click OK button to finish the operation.
21. If such camera is available, then the adding result will display below.
35
Step 21 Click button to call the interface as Figure 4-29.
Figure 4-29 Add camera management
Step 22 Select the cameras which you want to add from the left part list click to
finish the operation. Click.
To cancel the adding operation.
Click OK button to finish the operation.
9.1.3 System alarming
Select Setup>System warning> system warning
Enter the system warning like Figure 4-30 showing.
