E-line ELI?EVC User manual





USERMANUAL




Indoor/OutdoorIRVandalDome
ELI‐EVC


eLineTechnology.com


CAMERAELI‐EVC/ELI‐EEVCUSERMANUAL eLineTechnology.com

Page|2

TableofContents
PRODUCTDESCRIPTION.......................................................................................................................3
FEATURES...............................................................................................................................................3
MODELS.................................................................................................................................................3
SAFETYINFORMATION.........................................................................................................................3
FCCSTATEMENT...................................................................................................................................4
PRODUCTCOMPONENTS.....................................................................................................................4
BOXCONTENTS.......................................................................................................................................4
ADDITIONALMATERIALSNEEDEDFORINSTALLATION.......................................................................................5
PRODUCTDIAGRAMS................................................................................................................................5
INSTALLATION.....................................................................................................................................5
MOUNTING............................................................................................................................................5
CONNECTIONS.........................................................................................................................................6
ADJUSTINGTHECAMERA...........................................................................................................................7
FOCUSING..............................................................................................................................................7
ON‐SCREENDISPLAY(OSD)SETTINGS..........................................................................................................8
SPECIFICATIONS...................................................................................................................................9
TROUBLESHOOTING.............................................................................................................................9
WARRANTYREPAIR/REPLACEMENTS.................................................................................................10

©2012eLine.Allrightsreserved.eLineprovidesnowarrantywithregardtothismanualandreserves
therighttomakeanymodificationtothismanualwithoutnotice.


CAMERAELI‐EVC/ELI‐EEVCUSERMANUAL eLineTechnology.com

Page|3

ProductDescription
Indoor/OutdoorIRVandalDome
Congratulationsonyourpurchaseofthisproduct.Thisanalogsurveillancedomefeaturesadvanced
functionsinacompactbodyandissuitedfortight,indoororoutdoorenvironments.Thecamerautilizes
advancedSonyimagesensortechnologyproducinghighdefinition,realisticcolor.
Features
Indoor/outdoorvandaldomehousing
InfraredLEDsfornightvision,20Mto30Mrange(modeldependent)
3‐Axisbracketforversatilepositioningofthelens
12VDC
Additionalfeaturesbasedonmodel
Models
ModelNumberResolutionLensFeatures
ELI‐EVC‐48‐4IR480TVL3.6mmFixed20MIRRange,Low
Illumination
ELI‐EVC‐60‐4IR600TVL3.6mmFixed20MIRRange,Low
Illumination,DWDR,
OSD, DNR
ELI‐EVC‐65‐312IR650TVL2.8~12mmVarifocal30MIRRange,Low
Illumination,DWDR,
OSD, 3D DNR, Sense-
UP
SafetyInformation
1. Readtheseinstructions.
2. Heedallwarnings.
3. Followallinstructions.
4. Cleanonlywithdrycloth.
5. Donotblockanyventilationopenings.
6. Donotinstallnearanyheatsourcessuchasradiators,heatregisters,stoves,orotherapparatusincludingamplifiers)
thatproduceheat.
7. Onlyuseattachments/accessoriesspecifiedbythemanufacturer.
8. Payattentiontothepowerrequirements.
9. Stopoperationimmediatelywhensomethingiswrongwiththeproduct.Ifsmokeorthesmellofsmokecomesfrom
theproduct,continuedusewillresultinfire,injury,ordamagetotheproduct.
10. Turnthepoweroffimmediatelyandcontactqualifiedservicepersonnelforservice.
11. Besuretoturnoffthepowerbeforewiring.Failuretoobservethismaycauseelectricshock.Ashortcircuitorwrong
wiringmaycausefire
12. Thisproducthasnopowerswitch.Turnthepoweroffwhencleaningtheproduct.
13. Whencontinuouslyviewingabrightlightsourcesuchasaspotlight,thecolorfilteroftheCCDmayhavedeteriorated
anditmaycausediscoloration.Evenwhenchangingthefixedviewingdirectionaftercontinuouslyviewingaspotlight
foracertainperiod,thediscolorationmayremain.

CAMERAELI‐EVC/ELI‐EEVCUSERMANUAL eLineTechnology.com

Page|4

14. Keepthecameracableawayfromthelightingcable.Failuretoobservethismaycausenoise.
15. WhenthecameraisusednearaTV/radioantenna,strongelectricfield,ormagneticfield(nearamotorora
transformer),imagesmaybedistortedandaudiblenoisemaybeproduced.Insuchacase,routethecameracable
throughspecializedsteelconduittubes.
CAUTION:TOREDUCETHERISKOFELECTRICSHOCK,DONOTREMOVECOVER(ORBACK).NOUSERSERVICEABLEPARTS
INSIDE.REFERSERVICINGTOQUALIFIEDSERVICEPERSONNEL.
FCCStatement
THISDEVICECOMPLIESWITHPART15OFTHEFCCRULES.OPERATIONISSUBJECTTOTHEFOLLOWINGTWOCONDITIONS:
1. THISDEVICEMAYNOTCAUSEHARMFULINTERFERENCE,AND
2. THISDEVICEMUSTACCEPTANYINTERFERENCERECEIVED,INCLUDINGINTERFERENCETHATMAYCAUSEUNDESIRED
OPERATION.
Thisequipmentgeneratesandusesradiofrequencyenergy,andifnotinstalledandusedproperly,thatis,instrictaccordance
withthemanufacturer’sinstructions,itmaycauseinterferencetoradioandtelevisionreception.Ithasbeentypetestedand
foundtocomplywiththelimitsforremotecontroldevicesinaccordancewiththespecificationsinSub‐PartsBandCofPart15
ofFCCRules,whicharedesignedtoprovidereasonableprotectionagainstsuchinterferenceinaresidentialinstallation.
However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescause
interferencetoradioortelevisionreception,whichcanbedeterminedbyunpluggingtheequipment,trytocorrectthe
interferencebyoneormoreofthefollowingmeasures.
Reorienttheantennaoftheradio/TVexperiencingtheinterference.
Relocatetheequipmentwithrespecttotheradio/TV.
Movetheequipmentawayfromtheradio/TV.
Plugtheequipmentintoanoutletonadifferentelectricalcircuitfromtheradio/TVexperiencingtheinterference.
Ifnecessary,consultyourlocaldealerforadditionalsuggestions.
NOTE:Modificationstothisproductwillvoidtheuser’sauthoritytooperatethisequipment.
ProductComponents
BoxContents
DomeCamera
QuickStartUserGuide
MountingScrews


CAMERAELI‐EVC/ELI‐EEVCUSERMANUAL eLineTechnology.com

Page|5

AdditionalMaterialsNeededforInstallation
Tapeforprotectingconnections
Powersupply12VDC350mA
ProductDiagrams


Installation
Mounting

1. Unscrewthemountingbasefromthecamerabytwistingthemountingringcounter‐clockwise.
Thisreleasesallfourpartsofthedome(base,ring,hood,andcamera).Carefullyremovethe
basefromtheotherparts.


CAMERAELI‐EVC/ELI‐EEVCUSERMANUAL eLineTechnology.com

Page|6

2. Usethemountingbaseasaguidetomarkthelocationsforscrewandcablemanagementholes
onthemountingsurface.Drillastarterholeateachmarkedlocation.Drillacablemanagement
holeinthecenteratleast14mmindiametertopermitthecamera’scabletobeinserted
throughthemountingsurface.Ifnecessary,insertdrywallanchorsintothescrewholes.
3. Placethemountingbaseintolocation.Insertascrewthrougheachofthescrewholesinthe
baseandintothemountingsurfaceandthentighteneachscrewuntilthebaseissecure.
4. Feedthecamera’scablethroughtheaccesshole;positionthedomeontothemountedbase,
andtwistthemountingringclockwisetosecureloosely.Thiswillallowyoutoadjustthe
positionofthehoodandthecamera.Afterthecamerahasbeenadjusted,tightenthemounting
ringsecurely.
Caution:Oncepowerissupplied,donotremovethecamerafromthemountingbaseduetoriskof
electricalshock.
Connections
1. UseaBNCconnectortoconnectthecamera’sVIDEOOUTtothemonitor’s(orDVRs)VIDEOIN.
Usethefollowingrecommendationsforcabletypesanddistances:
MaximumCableLength
TypeofCoaxialCableRG‐59/URG‐6/URG‐11/URG‐15/U
RecommendedMax
CableLength
250M
825ft
500M
1650ft
600M
1980ft
800M
2640ft

2. ThepowerisDC12V(+/‐10%)/350mA.Usethefollowingrecommendationsforcabletypes
anddistances:
12VDCRecommendedWireSizeandResistance(68°F)
CopperWireSize
(AWG)
#24
(0.22mm2)
#22
(0.33mm2)
#20
(0.52mm2)
#18
(0.83mm2)
Resistance(Ω/m)0.0780.0500.030.018
Resistance(Ω/ft)0.0240.0150.0090.005
Usetheformulabelowtocalculatethepowercordandpowersupply.“L”,“R”,“VA”,“I”shallsatisfytheinequalitybelow:
10.8VDC≤VA‐2(RxIxL)≤16VDC
L=Cordlength(morft)
R=Resistanceofcopperwire(Ω/morΩ/ft}VA=DCoutputvoltageofpowersupplyunit
I=DCcurrentconsumption(A).

3. Connectpowersupplytothecamera’sPOWERINterminal.

CAMERAELI‐EVC/ELI‐EEVCUSERMANUAL
eLineTechnology.com

Page|7


AdjustingtheCamera
1. Toadjustthecameraangle,loosenthemountingringjustenoughtomovethecamerabutnot
toomuchastomakethemountunsecure.
2. Afterthelensandthehoodareintoposition,tightenthemountingring.
Focusing
Onmodelswithavarifocallens,youmayadjustthefocusandzoomby turning the screws on the sides of the
camera.

1. Thescrewontheleftwilladjustthelensfocus.
2. Thescrewontherightwilladjustthelenszoom.
3. Focustothedepthoffieldthatismostimportant.

CAMERAELI‐EVC/ELI‐EEVCUSERMANUAL eLineTechnology.com

Page|8

On‐ScreenDisplay(OSD)Settings
OntheOSDcontroldeviceonthecable,hitthecenterbuttontoactivatetheOSDsettings.Themenuas
belowwillappear.Usethebuttonbymovingup/down/left/rightanddepressingas‘Enter’tochange
OSDsettings.ForfurtherdefinitionofeachsettingseetheeLinewebsiteunderSupport.
http://www.elinetechnology.com.
LensELCDC
ExposureHBLCD‐WDRBLCHLI/D‐WDR
AGCOFFLOWMIDDLEHIGH
3DDNROFFLOWMIDDLEHIGH
SENSE‐UPAUTOOFFX2X4X8X16X32X64X128
X256X512
EXIT
COLORWBMODEATWMANUALAWC>PUSHAWC
R‐Y‐GAINO‐256
B‐Y‐GAIN0‐256
EXIT
DAY&NIGHTD&NMODEAUTOCOLORB&WEXT
FUNCTIONMIRRORONOFF
SHARPNESS0‐30
LSCON(0‐30)OFF
MOTIONMOTIONONOFF
AREASEL.TOPBOTTOMLEFTRIGHT
SENSITI0‐30
DISPLAYOFFICONTRACE
HOLDTIME0‐15Unit:sec
ALARMONOFF
EXIT
PRIVACYMASK1‐MASK8ONOFF
SETUPTITLEOFFON:64characters
DPCOFFMANUAL:WHITETHR0‐255BLACK
THR0‐255
DPCLEVEL0‐255
OLPF650850
MONITORCRTLCD
GAMA0.450.601.0USER
EXIT
SYSTEMCAMERAID0‐255
COMMUNIPROTOCOL:PELCO‐D
BAUDRATE:240048009600bps
RETURN
LANGUAGECHINESEENGLISH
EXIT
EXITFACTORYSET
SAVE&EXIT
EXIT



CAMERAELI‐EVC/ELI‐EEVCUSERMANUAL eLineTechnology.com

Page|9

Specifications

FeatureSpecification
MinimumIllumination 0.001Lux/0Lux(withIRLEDON)
S/NRatio Morethan50dB
ScanningSystem 2:1Interface
SynchronousSystem Internal,Negativesync
AutoElectronicShutter NTSC:1/60s~1/100,000s/PAL:1/50s~1/100,000s
GammaCharacteristic 0.45
IRDistance ModelDependent
20Meters(withȼ5x24pcsInfraredLED)
30Meters(withȼ5x36pcsInfraredLED)
VideoOutput 1Vpp.75Ω
AutoGainControl Auto
Power/Current ModelDependent
DC12V(+/‐10%)350mA–FixedLens
DC12V(+/‐10%)500mA–VarifocalLens
Dimension ModelDependent
94(C)x69(H)mm–FixedLens
131(C)x93(H)mm–VarifocalLens
Weight ModelDependent
400g–FixedLens
800g–VarifocalLens
StorageTemperature ‐20°~60°CRH95%Max
OperatingTemperature ‐10°~50°CRH95%Max

Troubleshooting
Nopictureafterprovidingpower
Checkthepowerconnectiontothepowersupplytothepoweroutletforconnectivity.
Checkthepowersupplyvoltage.
Checkallconnectingcableandmonitorsforlooseconnections.
Checkthemonitorsettings
Thepicturehasinterferenceorripples
Thismaybecausedbythepowersupply’sarc,poorqualitycable,toolongcable,orimproper
groundconnection.
Thepicturebackgroundcolorchangescontinuously
Afluorescentlight’selectromagneticfieldmaycausecolorroll.Reducethenumberof
fluorescentlightsorincreasethedistancebetweenthecameraandthelightstoreducethis
effect.Useofapowersupplywithexternalsyncmaysolvetheproblem.


CAMERAELI‐EVC/ELI‐EEVCUSERMANUAL eLineTechnology.com

Page|10

BlurredImage
Checkthedomecoverfordirtorimperfections
Checkthefocustomakesureadjustedcorrectly
Checkthelensofthecameratomakesureitisclean.Onlyuseadry,cleanlensclothtoclean
thelens.Nevertouchwithyourfingers.
WarrantyRepair/Replacements
Subjecttothetermsofthelimitedwarrantyineffectatthetimeofpurchase,e‐Linewillrepairor
replaceaproductthatfailstomeetthetermsprovided,withintheproduct’swarrantyperiod.eLine
reservestherighttoreplaceanyproductunderwarrantywithnew,refurbishedorremanufactured
product.ForproductpurchaseddirectlyfromeLinebyadealeroranintegrator,thewarrantyperiod
startsfromeithera)thedateofshipmentfromeLine’sfacility(pointoforigin)orb)themanufacturer’s
datecode(iftheshipmentdateisunknown).Exceptforsoftwareproducts(whichshallbetreatedasif
purchaseddirectlye‐Lineforpurposesofdeterminingthestartofthewarrantyperiodassetforthinthe
immediatelyprecedingsentence),forproductpurchasedfromanauthorizedeLinedistributorbya
dealeroranintegrator,thewarrantyperiodstartsfromthedatetheproductispurchasedbythedealer
orintegrator.Warrantyperiodsvarybasedonproductcategoryandtypeofequipment,asshownin
Table1entitled“ProductWarrantyPeriods”below.
Wewillreturnequipmentorshipreplacementequipmentviathesameincomingshipmethodatno
additionalcharge.Ifyourequestadifferentreturnshipmethod,wewillchargeforthefullshippingcost.

ProductWarrantyPeriods
Table1listswarrantydurationsformosteLineequipment,sortedbycategory.Warrantyperiodsstartas
setforthundertheheading“WarrantyRepair/Replacements”above.Foritemsthatdonotappearin
Table1,contactCustomerServiceoryoursalesrepfortheapplicablepolicy.
ProductTypeProductWarrantyExceptions
eLineCloudCameras2yearsPTZCameras–1year
OthereLine2years ‐‐‐‐

Forhelpormoreinformationonsetup,pleasevisithttp://elinetechnology.com
OrcontacteLinesupportprovidedby2DElectronicsat303.938.1133[e-mail]
eLine,1070W124thAveSuiteB‐100,Westminster,CO80234
