E-T-A ControlPlex EM12D-TIO User manual

User Manual ControlPlex®
EM12D-TIO Intelligent Supply Module

2
1 Table of contents
1 Table of contents 2
2 General information 6
2.1 Safety instructions 6
2.2 Qualified personnel 6
2.3 Use 6
2.4 Delivery state 6
3 General description 7
3.1 Design of the entire system 8
3.2 Dimensions of the EM12D-TIO intelligent supply module 9
3.3 Status indication and terminals 9
3.3.1 Terminals for voltage supply and IO link connection 9
3.3.2 Connector socket for the IO link Master®, connector socket X81 10
3.3.3 LED »CE/CM« 10
3.4 Representations of the manufacturing date, the Device ID and revision
status of the software 10
4 Mounting and installation 11
4.1 Mounting of the system 11
4.2 Wiring and connection of the EM12D-TIO intelligent supply module 11
4.2.1 Supply by means of IO link connector X81 COM 12
4.2.2 Connection EM12D-TIO intelligent supply module (-X81) 12
5 Operating modes and signalling 13
5.1 Operating mode: (system start) 13
5.2 Operating mode: (critical failure) 13
5.3 Operating mode: (non-critical failure) 13
5.4 Operating mode: (independent operation) 13
5.5 Operating mode: (faultless operation) 13
5.6 Signalling of operating modes on EM12D-TIO supply module 14
5.7 Signalling of operating conditions on REX12D circuit protector 14
6 Basic functions of the entire system 15
6.1 Internal cycle times 15
6.2 Hot swap of circuit protectors 15
6.3 Communication via port configuration tool 15
7 Types of communication 16
7.1 SIO mode, group signal at PLC input 16
7.2 Model of the EM12D-TIO intelligent supply module 16
7.2.1 Models for the operation of 32 channels 16
7.2.2 Models for the operation of 16 channels 16
7.2.3 Population errors 16
7.2.4 Error device addressing 16
7.3 IODD file 17
7.4 Software versions of EM12D 17
8 Cyclical I/O data 18
8.1 Data model for max. 16 channels 18
8.1.1 Data from IO link master to EM12D-TIO (16 channels) 18

3
8.2 Data model for max. 32 channels 22
8.2.1 Data from IO link master to EM12D-TIO (32 channels) 22
9 Non-cyclical I/O data 27
9.1 Identical data model for max. 16 channels and 32 channels 28
9.1.1 System commands IO link EM12D-TIO (index 2) 28
9.1.1.1 Store adjustments in master (data storage) 28
9.1.1.2 Reset to factory settings 28
9.1.1.3 Reset statistical information 28
9.1.2 Device information IO link EM12D-TIO (Index 19, 21, 22, 23) 28
9.1.2.1 Device type (Index 19) 28
9.1.2.2 Serial number (Index 21) 28
9.1.2.3 Hardware version (Index 22) 28
9.1.2.4 Software version (Index 23) 28
9.1.2.5 Application Specific Tag 28
9.1.2.6 Device Status 28
9.1.2.7 Extended Device Status 29
9.1.2.8 Process Data Input 29
9.1.2.9 Process Data Output 29
9.2 Data model for max. 16 channels 30
9.2.1 Configuration data of the EM12D-TIO intelligent supply module 30
9.2.1.1 Internal cycle time 30
9.2.1.2 Configure controllability of the channels with 16 channels
(PLCLock Index 199) 30
9.2.1.3 Configuration data of the EM12D-TIO intelligent
supply module (Index 200) 31
9.2.2 Diagnostic information of the EM12D-TIO intelligent
supply module (Index 300) 32
9.2.3 Parameters of channel for 16 channels 33
9.2.3.1 Current rating for 16 channels 33
9.2.3.2 Limit value load current for 16 channels 33
9.2.4 Diagnostic information channel with 16 channels 34
9.2.5 Load voltage channel for 16 channels 35
9.2.6 Extended diagnostic messages (dynamic info) channel
for 16 channels 35
9.2.6.1 Error memory for 16 channels 35
9.2.6.2 Trip counter for 16 channels 36
9.2.6.3 Reason for trip for 16 channels 36
9.2.7 Action commands channel for 16 channels 36
9.2.8 Device information channel for 16 channels 37
9.2.8.1 Device type for 16 channels 37
9.2.8.2 Hardware version for 16 channels 37
9.2.8.3 Software version for 16 channels 38
9.2.8.4 Serial number for 16 channels 38
9.2.9 Statistical information for 16 channels 39
9.2.9.1 Minimum current for 16 channels 39
9.2.9.2 Maximum current for 16 channels 39
9.2.9.3 Mean value current for 16 channels 40
9.2.9.4 Minimum voltage for 16 channels 40
9.2.9.5 Maximum voltage for 16 channels 40
9.2.9.6 Mean value voltage for 16 channels 41

4
9.3 Data model for 32 channels 42
9.3.1 Configuration data of the EM12D-TIO intelligent supply module 42
9.3.1.1 Configure controllability of the channels with 32 channels
(PLCLock Index 199) 42
9.3.1.2 Configuration data of the EM12D-TIO intelligent
supply module (Index 200) 43
9.3.2 Diagnostic information of the EM12D-TIO intelligent
supply module (Index 300) 44
9.3.3 Parameters of channel for 32 channels 45
9.3.3.1 Current rating for 32 channels 45
9.3.3.2 Limit value load current for 32 channels 45
9.3.4 Diagnostic information channel for 32 channels 46
9.3.5 Load voltage channel for 32 channels 47
9.3.6 Extended diagnostic messages (dynamic info) channel
for 32 channels 47
9.3.6.1 Error memory for 32 channels 47
9.3.6.2 Reason for trip for 32 channels 48
9.3.6.3 Reason for trip for 32 channels 48
9.3.7 Action commands channel for 32 channels 48
9.3.8 Device information channel for 32 channels 49
9.3.8.1 Device type for 32 channels 49
9.3.8.2 Hardware version for 32 channels 50
9.3.8.3 Software version for 32 channels 50
9.3.8.4 Serial number for 32 channels 52
9.3.9 Statistical information for 32 channels 52
9.3.9.1 Minimum current for 32 channels 52
9.3.9.2 Maximum current for 32 channels 53
9.3.9.3 Mean value current for 32 channels 53
9.3.9.4 Minimum voltage for 32 channels 54
9.3.9.5 Maximum voltage for 32 channels 54
9.3.9.6 Mean value voltage for 32 channels 53
10 Appendix 56
10.1 List of pictures 56
10.2 Technical data 57

5

6
2 General information
2.1 Safety instructions
This manual points out possible danger
for your personal safety and gives
instruction how to avoid property damage.
The following safety symbols are used to
draw the reader's attention to the safety
instructions included in this manual.
Danger!
Danger to life and limb unless the following
safety precautions are taken.
Warning
Danger to machinery, materials or the
environment unless the following safety
precautions are taken.
Note
Information is provided to allow a better
understanding.
Caution
Electrostatically sensitive devices (ESD).
Devices must exclusively be opened by
the manufacturer.
Disposal guidelines
Packaging can be recycled and should
generally be brought to re-use.
2.2 Qualified personnel
This user manual must exclusively be
used by qualified personnel, who are able
– based on their training and experience –
to realise arising problems when handling
the product and to avoid related hazards.
These persons have to ensure that the
use of the product described here meets
the safety requirements as well as the
requirements of the presently valid
directives, standards and laws.
2.3 Use
The product is part of a continuous
enhancement process. Therefore there
might be deviations between the product
in hand and this documentation. These
deviations will be remedied by a regular
review and resulting corrections in future
editions. The right to make changes
without notice is reserved. Error and
omissions excepted.
2.4 Delivery state
The product is supplied with a defined
hardware and software configuration.
Any changes in excess of the documented
options are not permitted and lead to
liability exclusion.

7
3 General description
The requirements regarding modern
machinery and equipment are constantly
growing. System transparency, remote
maintenance and remote access are
getting more and more important in
international competition. Early notification
in the event of any disturbances and a
fast response to current problems will
increase system availability, save costs
and improve the overall stability of the
production process.
E-T-A provides the ideal solution for
machine and panel builders with the
intelligent protection system comprising
the REX12D circuit protector and the
intelligent EM12D-TIO supply module. The
system combines the well-proven quality
of DC24V overcurrent protection with
the communication options of the IO link
system. It allows complete transparency
of the DC24V power supply and provides
all necessary information for a reliable
production process in this plant sector.
Part of the information is the permanent
transmission of status indication regarding
each channel of the individual circuit
protector. In addition the present load
current of the channel on the selected
circuit protector is transmitted to the IO
link master.
A parameterisable limit value allows
creation of a warning threshold which
advises the user of changing system
conditions.
Any number of the only 12.5 mm wide
modules can be mounted side by side.
They feature push-in technology with
press release buttons and allow no-tool
time-saving and maintenance-free wiring.
The supply module is designed for DC
24 V and 40 A and accommodates max.
10 mm² with wire end ferrule as a plus (+)
supply. On the load output side the circuit
protector can be wired with 2.5 mm².
It is exactly tailored to the needs of
machine and panel builders. And what
is more: no additional accessories are
required when connecting the individual
components electrically and mechanically.
This helps save time and money!

8
3.1 Design of the entire system
The EM12D-TIO intelligent supply module is the centre of the
ControlPlex®system. It collects all information of the REX12D
electronic circuit protectors and forwards it to the superordinate
IO link master and thus to the superordinate control unit.
The IO link interface to the superimposed IO link master is
realised with a 3-wire cable. It allows connection of the required
IO link master to the ControlPlex®system, thus enabling display
and analysis of the individual measuring values as well as
diagnosis and control of the individual channels of the electronic
circuit protectors. This enables the user to have unrestricted
access to the safety-relevant functions even in the event of
an interruption. Any occurring failures will be detected quickly
and can be remedied without delay. The ControlPlex®system
effectively reduces system downtimes and significantly increases
the productivity.
fig. 1: System overview
4230-T110
100-240 V AC
24 V DC/10 A
EM12D-
TIO-xxx
DC24V
40A
Port1
Master
AC
CPU
DC24V
REX12D-
TA2-100
DC24V
REX12D-
TA2-100
2A
2A 4A
4A
DC24V
REX12D-
TA2-100
6A
6A
COM COM COM

9
3.2 Dimensions of the EM12D-TIO intelligent supply module
3.3 Status indication and terminals
3.3.1 Terminals for voltage supply and IO link connection
The operating voltage of the device is 24 V DC. Faultless operation of the device is
ensured in a voltage range of 18 V to 30 V. The max. current of the supply module is 40 A.
Using a supply voltage outside the indicated operating range can cause
malfunctions or destruction of the device.
fig. 2: EM12D-TIO
fig. 3: Status indication and terminals EM12D-TIO
EM12D-
TIO-xxx
L+
C/Q
L-
X81
OV
DC24V
40 A
LINE +1
LED CE/CM
connector
3-pole
snap-on socket for
rail EN 60715-35x7.5
label e.g. from
Phoenix Contact
ZBF-12 GERMANY
91,5
80
7,5
98
12,4
EM12D-
TIO-xxx
L+
C/Q
L-
X81
0V
DC24V
40 A
LINE +1
X
81 COM
IO link master
interface
socket 1 (L+)
socket 2 (C/Q)
socket 3 (L-)
0 V DC
LINE+ DC 24 V
max. 40 A
LED CE/CM
GERMANY
connector
3-pole

10
Use of the terminals for applications not provided for in the operation manual or improper connection can lead to mal-
function or destruction of the device.
The EM12D-TIO intelligent supply module is supplied with voltage both via the supply terminals LINE+ and 0 V and via
X81 COM. The voltages are decoupled reciprocally.
3.3.3 LED »CE/CM«
The LED CE/CM shows the status of the communication unit. Available LED colours are red, green and orange. For further details
please see fig. 9. Illustration of operating modes.
3.4 Representations of the manufacturing date, the Device ID and revision status of the
software
1. supply voltage IO link L +24V
2. data line IO link C/Q (to IO link master)
3. supply voltage IO link L-
3.3.2 Connector socket for the IO link Master®, connector socket X81
This connector socket serves for connecting the EM12D-TIO
intelligent supply module with the superordinate IO link master.
Connection of the device with the master is realised with a
one-to-one wiring mode. Preferably the connection should be
a typical sensor cable 3-pole with a cross section of 0.25 mm²
to 0.5 mm² (e.g. FD Li9Y11Y or LifYY). The cable does not have
to be shielded specially. The cable length between the IO link
master and the IO link device must not exceed 20 m.
fig. 4: IO link connection
fig. 5: marking of date code
date code
Device ID
revision status of firmware
Entrance Module
EM12D-TIO-000-DC24V-40A
E-T-A
D-90518 ALTDORF
Made in Germany • xxxx • xxxxx • x
GERMANY
LOAD+ 2.1 (2.2)
COM
ADDR
LINE+1
EM12D-T
max. 16 channels
REX12D-T
0 V
IO-Link

11
EM12D-
TIO-xxx
L+
C/Q
L-
X81
0V
DC24V
40 A
LINE +1
0 V terminal
push-in PT 2.5
0.14 mm2... 2.5 mm2
wire stripping length
8 mm ...10 mm LINE+ terminal
Push-in PT 10
0.5 mm2...10 mm2
wire stripping length
18 mm
IO link connection
X81 COM
4 Mounting and installation
4.1 Mounting of the system
The preferred mounting position of the EM12D-TIO is horizontal.
4.2 Wiring and connection of the EM12D-TIO intelligent
supply module
fig. 6: Mounting position
fig. 7: Terminals EM12D-TIO
GERMANY

12
4.2.1 Supply by means of IO link connector X81 COM
Voltage ratings: DC 24 V (18 ... 30 V)
Terminal L+: IO link®DC +24 V (line +)
Terminal C/Q: Data cable IO link® (COM)
Terminal L-: IO link®GND
When wiring and connecting to the bus system IO link, the installation and wiring regulations of the PROFIBUS User Organisation
(PNO) have to be observed.
The EM12D-TIO intelligent supply module is supplied with voltage both via the supply terminals LINE+ and 0 V and via
X81 COM . The voltages are decoupled reciprocally.
4.2.2 Connection to EM12D-TIO intelligent supply module (-X81)
Use of the terminals for applications not provided for in the operation manual or improper connection can lead to
malfunction or destruction of the device.
X81 COM: connection to IO link bus system
cable length: max. 20 m
typically: FD Li9Y11Y or LifYY max. 0.5 mm² (sensor line)
connector 1: supply voltage IO link L +24V
connector 2: data line IO link C/Q (to master)
connector 3: supply voltage IO link L-
fig. 8: IO link connector

13
5 Operating modes and signalling
5.1 Operating mode: (system start)
When applying the supply voltage, the EM12D-TIO intelligent
supply module will be initialised. The device will carry out
implemented programme memory tests and self test routines.
During this time a communication via the interfaces is not
possible.
5.2 Operating mode: (critical failure)
If a failure is detected during the self test routines, the EM12D-TIO
intelligent supply module will change into operating mode »Critical
Failure«. In the event of a critical failure, the device will also
change into this operating mode. This operating mode can only
be discontinued by way of re-starting the device and it prevents
the data exchange via the interfaces. If the EM12D-TIO intelligent
supply module is in this operating mode, no communication is
possible with the superordinate control unit. The electronic circuit
protectors cannot be controlled by it and remain OFF.
5.3 Operating mode: (non-critical failure)
If there are invalid or no configuration data at all available in
the EM12D-TIO intelligent supply module, it will change into
the this operating mode. This operating mode only allows
restricted non-cyclical data exchange. Cyclical data exchange
is prevented. This operating mode will be left upon receipt of
the correct module and slot parameters and configuration data.
The circuit protectors remain OFF.
5.4 Operating mode: (independent
operation)
If no connection to the superordinate control unit is recognised
after the supply voltage was applied, the module will change
into the operating mode »independent operation«. Thus the
parameters stored in the EM12D-TIO will be transmitted to the
electronic circuit protectors. If there is a connection between the
EM12D-TIO and the superordinate IO link master and there is no
critical failure, the operating mode »independent operation«will
be quitted. Should the connection between the EM12D-TIO and
the superordinate control unit be interrupted during operation,
the EM12D-TIO will automatically change into the operating
mode »independent operation«.
By means of the non-cyclical parameter, the behaviour of the
EM12D-TIO can be defined in the event of an interruption of the
superordinate IO link master. Either the condition of the circuit
protector is frozen (FREEZE) or all circuit protectors are switched
off (UNFREEZE).
Should the connection between the EM12D-TIO and the
superordinate IO link master be interrupted and the non-cyclical
parameter unfreeze be set, all circuit protectors will be switched
off before changing into the operating mode »independent
operation«.
Should the connection between the EM12D-TIO and the
superordinate IO link master be interrupted and the non-cyclical
parameter »FREEZE«be set, the condition of the circuit protectors
will remain unchanged before changing into the operating mode
»independent operation«.
Should the connection between the IO link device and the
superordinate IO link master be restored after a previous
interruption, the EM12D-TIO will automatically change into the
operating mode »faultless operation«.
5.5 Operating mode: (faultless operation)
If there is no fault and a connection is in place to the superordinate
IO link master, the EM12D-TIO will change into the operating
mode »faultless operation«.
The parameters will be transmitted from the superordinate IO
link master to the EM12D-TIO and be saved there. Subsequently
they will be forwarded to the electronic circuit protectors. The
configuration data and the parameters will be exchanged as
non-cyclical data between the IO link master (superordinate
control) and the EM12D-TIO.

14
Operating mode Indication of operating mode IO link communication
independent operation blinking green not connected
faultless operation green connected
critical failure detected red not connected
uncritical failure detected orange connected
uncritical failure detected flashing orange not connected
system start (1 second) orange not connected
operating condition LED for signalling condition of
load output
channel switched off by momentary
switch
dark OFF
channel ON by momentary switch
and OFF by IO link
orange OFF
channel ON by momentary switch
and IO link
green ON
selected threshold value exceeded blinking green/orange ON
overload detected orange ON
trip by short circuit
or overload
red OFF
low voltage detected red OFF
5.6 Signalling of operating modes on supply module EM12D-TIO
The different operating modes of the EM12D-TIO are indicated as follows:
5.7 Signalling of operating conditions on REX12D circuit protector
The different operating modes of the REX12D are indicated as follows:
fig. 9: Operating modes of the EM12D-TIO
fig. 10: Signalling of operating conditions of REX12D circuit protector

15
fig. 11: Cycle time of the system
6 Basic functionalities of the entire system
6.1 Internal cycle time
The cycle time via the ELBus®is 340 ms. During the aforementioned period, the status and the load current of each circuit protector
are cyclically transmitted to the EM12D-TIO intelligent supply module.
6.2 Hot swap of circuit protectors
The electronic REX12D circuit protector can at any time be mounted side by side with a supply module or an existing system.
By closing the connector arm, a voltage supply of the device is available. Also, the device is connected to the internal ELBus®.
Opening the connector arm is only permitted in the OFF condition. Opening under load can damage the device or cause
undefined system conditions.
After plugging in a circuit protector, it will automatically be identified and parameterised if parameters are available for the slot in
question. During this procedure the cyclical data will be marked as unvalid for a short period of time.
6.3 Communication via port configuration tool
The port configuration tool is made available by the manufacturer of the IO link master.
It allows direct access of the IO link master to the IO link device EM12D-TIO. Thus it is possible to parameterise the individual
devices, indicate the status and receive diagnostic information.
If the slot parameters are changed, the change will be signalled to the superordinate control unit via the IO link master. The user
will thus be able to process these changes in his control unit accordingly.
The cycle times indicated refer to REX12D units from index I onwards.
Cyclical Data 16 x 15 ms = 240 ms Non-cyclical Data 100 ms

16
7 Communication types
7.1 SIO mode, group signal at PLC input
Commencing with revision F, the SIO mode is available in the supply module.
It is possible to connect the EM12D-TIO directly to a PLC input. In this case, it is not the IO link information that is going to be
transmitted, but only the group status signal.
The data line IO link C/Q to X81 carries a high signal if no circuit circuit protector has tripped. As soon as a circuit protector trips,
the data line IO link C/Q to X81 carries a low signal.
Trip is acknowledged via the momentary switch on the circuit protector in question.
7.2 Model of the EM12D-TIO intelligent supply module
The EM12D-TIO has an internal ELBus® interface enabling the communication with the electronic REX12D circuit protector. There
are two different models of the supply module. The choice of the model in question is determined by the IODD used.
7.2.1 Models for the operation of 32 channels
Up to 16 devices with max. 32 channels can be connected to the supply module. Only the status is transmitted cyclically with this
model. It accommodates both REX12D-Tx1 (1-channel) circuit protectors or REX12D-Tx2 (2-channel) or even a combination of both.
7.2.2 Models for the operation of 16 channels
Up to 16 channels can be connected to the supply module. This extended version not only provides cyclical transmission of the
status, but also the present current of the load circuits. Due to the limited transmission width with IO link of 32 bytes, the number
of channels is limited to 16 due to the higher number of data to be transmitted. The model accommodates both REX12D-T1
(1-channel) circuit protectors or REX12D-Tx2 (2-channel) or a combination of both.
7.2.3 Population errors
If a double channel device is connected as channel 16/17 or 32/33, the control unit will receive the information that a device is
available at channel 16 or 32.
When reading out the Cominfo of the circuit protector, a message will be received saying that the circuit protector has wrong
parameters.
The channels cannot be operated (cannot be switched on).
7.2.4 Error device addressing
Due to mechanical problems, there may be addressing errors. This will become evident as follows: some channels are OFF after
applying voltage. They cannot even be switched on by means of the button (LED orange or green). Possible causes are deformed
or missing contacts in the connector arm.

17
7.3 IODD file
The IODD file is in the download area of the E-T-A website and can be downloaded there. It is set up according to the regulations
of the IO link user organisation (PROFIBUS User Organisation e.V.).
Various IODDs are available.
A revision has been inserted informing about the previous functional extensions.
ETA-EM12D-TIO-00 I-16-... Extended version, communication with up to 16 channels
ETA-EM12D-TIO-00 I-116-... Standard version, communication with up to 32 channels
This revision index can also be found on the supply module.
If the revision index on the device and the revision index of the loaded IODD are identical, all options of the device can be exploited.
Should the revision index of the supply module be higher than the IODD used, only the options of the IODD will be supported
(downward compatible).
However, no device with a lower revision index than that of the IODD can be used.
Please observe that the IODD used also determines the model of the supply module. The extended version allows communication
with 32 channels. However, this version only cyclically transmits the status of the circuit protectors. The standard version allows
communication with max. 16 channels. Besides transmission of the status, this version also allows cyclical transmission of the
present load current.
7.4 Software versions of EM12D
In the context of functional or portfolio extensions, the firmware used in the supply module is extended or adjusted. Downward
compatibility is ensured with all devices. Old devices do not support new functionalities nor corresponding portfolio extensions
because these are not implemented in the old firmware.
The following table lists the functional scope and the IODD to be used for the corresponding version
Version Device ID Firmware Device types Functionality IODD
A 11 v1.0.2 REX12D-TA1-100-
DC24V-xA;
REX12D-TA2-100-
DC24V-xA/xA
16 channels (max. 16 devices),
cyclical: current value, status;
non-cyclical: load voltage, diagnosis;
standard rated current 1A;
data storage
ETA-EM12D-TIO-20160714-
IODD1.1
E 12 v1.1.7 — PLC-Look functionality;
statistical information (Min.Max.Avg)
ETA-EM12D-TIO-000-E-
201-0311-IODD1.1
F 13 v1.1.9 REX12D-TE2-100-
DC24V-1A-10A
SIO mode supported;
standard current rating 10A
ETA-EM12D-TIO-000-F-
20181031-IODD1.1
H 15 v1.2.1 REX12D-TE2-100-
DC24V-1A-4A-CL2
(Class2)
— ETA-EM12D-TIO-000-H-
20190308-IODD1.1
I 16 v1.3.0 REX12D-TA1-100-
DC24V-xA;
REX12D-TA2-100-
DC24V-xA/xA;
REX12D-TE2-100-
DC24V-1A-10A;
REX12D-TE2-100-
DC24V-1A-4A-CL2:
from software
version 2.0.0 (All-In-
One)
faster ELBus®cycle time ETA-EM12D-TIO-000-I-16-
20190312-IODD1.1
116 faster ELBus®cycle time;
32 channels (max. 16 devices);
non-cyclical: current value
ETA-EM12D-TIO-000-I-116-
20190312-IODD1.1
fig. 12: Software versions EM12D

18
parameters byte type range description
load current F1
load current F2
load current F3
load current F4
load current F5
load current F6
load current F7
load current F8
load current F9
load current F10
load current F11
load current F12
load current F13
load current F14
load current F15
load current F16
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
byte
byte
byte
byte
byte
byte
byte
byte
byte
byte
byte
byte
byte
byte
byte
byte
0 – 255 A standardised value with a resolution of 100 mA is made
available.
Example for calculation of the measuring value:
Value (15): 10 = 1.5 Ampere
status ON/OFF
(Channel Status)
16 HighByte
17 LowByte
Word 0xFFFF bit 0 = channel 1
bit 1 = channel 2
bit 2 = channel 3
bit 3 = channel 4
bit 4 = channel 5
bit 5 = channel 6
bit 6 = channel 7
bit 7 = channel 8
bit 8 = channel 9
bit 9 = channel 10
bit10 = channel 11
bit 11 = channel 12
bit 12 = channel 13
bit 13 = channel 14
bit 14 = channel 15
bit 15 = channel 16
8 Cyclical I/O data
The IODD file defines the data communication between the IO link master and EM12D-TIO intelligent supply module. In detail
these are the status and the load current of the electronic circuit protectors. In addition it is possible to switch the devices on or
off or reset them in the event of a failure.
8.1 Data model for max. 16 channels
8.1.1 Data from IO link master to EM12D-TIO (16 channels)
Each channel of each electronic circuit protector can be switched on or off or reset via the cyclical data. In addition, status information
and measuring values are transmitted.
Inputs

19
parameters byte type range description
overload
(Channel Overload)
18 HighByte
19 LowByte
Word 0xFFFF bit 0 = channel 1
bit 1 = channel 2
bit 2 = channel 3
bit 3 = channel 4
bit 4 = channel 5
bit 5 = channel 6
bit 6 = channel 7
bit 7 = channel 8
bit 8 = channel 9
bit 9 = channel 10
bit10 = channel 11
bit 11 = channel 12
bit 12 = channel 13
bit 13 = channel 14
bit 14 = channel 15
bit 15 = channel 16
short circuit
(Channel Shortcircuit)
20 HighByte
21 LowByte
Word 0xFFFF bit 0 = channel 1
bit 1 = channel 2
bit 2 = channel 3
bit 3 = channel 4
bit 4 = channel 5
bit 5 = channel 6
bit 6 = channel 7
bit 7 = channel 8
bit 8 = channel 9
bit 9 = channel 10
bit10 = channel 11
bit 11 = channel 12
bit 12 = channel 13
bit 13 = channel 14
bit 14 = channel 15
bit 15 = channel 16
limit value
(Channel Threshold)
22 HighByte
23 LowByte
Word 0xFFFF bit 0 = channel 1
bit 1 = channel 2
bit 2 = channel 3
bit 3 = channel 4
bit 4 = channel 5
bit 5 = channel 6
bit 6 = channel 7
bit 7 = channel 8
bit 8 = channel 9
bit 9 = channel 10
bit10 = channel 11
bit 11 = channel 12
bit 12 = channel 13
bit 13 = channel 14
bit 14 = channel 15
bit 15 = channel 16

20
parameters byte type range description
Hardware Lock
(Device Locked Off)
24 HighByte
25 LowByte
Word 0xFFFF bit 0 = channel 1
bit 1 = channel 2
bit 2 = channel 3
bit 3 = channel 4
bit 4 = channel 5
bit 5 = channel 6
bit 6 = channel 7
bit 7 = channel 8
bit 8 = channel 9
bit 9 = channel 10
bit10 = channel 11
bit 11 = channel 12
bit 12 = channel 13
bit 13 = channel 14
bit 14 = channel 15
bit 15 = channel 16
system width
information
(Overall Status)
26 byte 0xFF bit 0 = low voltage
bit 1 = permanently ON (for diagnostic purposes)
bit 2 = EL-Bus error (from index I)
bit 3 = reserve
bit 4 = reserve
bit 5 = reserve
bit 6 = reserve
bit 7 = reserve
reserve
(Reserve)
27 byte 0xFF The reserve byte was put in for reasons of compatibility, it is
intended for a later use.
Input voltage
(Supply Voltage)
28 HighByte
29 LowByte
Word 0 – 65535 A standardised 16-bit-value with a resolution of 10 mV is made
available.
Example for calculation of the
measuring value:
Value (2512) : 100 = 25.12 Volt
fig. 13: Reading data with 16 channels
