Eagle Eye Networks DD07 User manual

Precautions
Please read this document thoroughly before
using this device, and strictly observe the rules in
this document when using this device. Failure to
correctly use electrical products may cause fire
and severe injuries. If you install this device in
public places, provide the tip "You have entered
the area of electronic surveillance" in an
eye-catching place.
Warning
Alerts you to moderate dangers which, if
not avoided, may cause minor or moderate
injuries.
Caution
Alerts you to risks. Neglect of these risks
may cause device damage, data loss,
device performance deterioration, or
unpredictable results.
Note
Provides additional information
Warning
●Strictly observe installation requirements
when installing the device. The manufacturer
shall not be held responsible for device
damage caused by users' non-conformance to
these requirements.
●Strictly conform to local electrical safety
standards and use power adapters that are
marked with the LPS standard when installing
and using this device. Otherwise, this device
may be damaged.
●Use accessories delivered with this device.
The voltage must meet input voltage
requirements for this device.
●If this device is installed in places with
unsteady voltage, ground this device to
discharge high energy such as electrical
surges in order to prevent the power supply
from burning out.
●When this device is in use, ensure that no
water or any liquid flows into the device. If
water or liquid unexpectedly flows into the
device, immediately power off the device and
disconnect all cables (such as power and
network cables) from this device.
●Do not focus strong light (such as bright bulbs
or sunlight) on this device. Otherwise, the
service life of the image sensor may be
shortened.
●If this device is installed in places where
lightning frequently occurs, ground the device
nearby to discharge high energy in order to
prevent device damage.
Caution
●Avoid heavy loads, intensive shakes, and
soaking to prevent damages during
transportation and storage. The warranty does
not cover any device damage that is caused
during secondary packaging and transportation
after the original packaging is taken apart.
●Protect this device from falls and intensive
strikes, keep the device away from magnetic
field interference, and do not install the device
in places with shaking surfaces.
●Clean the device with a soft dry cloth. For
stubborn dirt, dip the cloth into a neutral
cleanser, gently wipe the dirt with the cloth, and
then dry the device.
●Do not jam the ventilation opening. Follow the
installation instructions below when installing
the device.
●Keep the device away from heat sources such
as radiators, electric heaters, etc.
●Keep the device away from places that are
moist, dusty, extremely hot or cold, or contain
strong electric radiation.
●If the device is installed outdoors, take insect-
and moisture-proofing measures to avoid
circuit board corrosion that can affect
monitoring.
●Remove the power plug if the device is unused
for a long time.
●Before unpacking, check whether the fragile
sticker is damaged. If the fragile sticker is
damaged, contact customer services or sales
personnel. The manufacturer shall not be held
responsible for any artificial damage of the
fragile sticker.
Special Announcement
●All complete products sold by the manufacturer
are delivered along with nameplates and
accessories after strict inspection. The
manufacturer shall not be held responsible for
counterfeit products.
●This manual may contain misprints, technology
information that is not accurate enough, or
product function and operation description that is
slightly inconsistent with the actual product.

●This manual is only for reference and does not
ensure that the information is totally consistent
with the actual product. For consistency, see the
actual product.
1. Package Contents
Open the package, check the appearance of the
product for no obvious damage, and confirm the
item list for table 1-1 is consistent.
Table 1-1: Packing List
Component
Quantity
Remark
Vandal Dome Network Camera
1
Setup & Support Insert
1
Installation Location Sticker
1
T15 Screwdriver
1
Large Dome
T10 Screwdriver
1
Mini Dome
Stainless Self-Tapping Screw
PA4.0×30mm
3
Swell Plastic Button
φ5.6×29mm
3
Waterproof Rubber Seal
1
Network Access Port Protective
Cover
1
Terminal Block
1
Optional
2. Device Structure
Camera Dimensions
Note: Different devices may have different dimensions;
please refer to the actual product.
Figure 2-1: Dimensions of Mini Dome (Units: mm)
Figure 2-2: Dimensions of Large Dome (Units: mm)
3. Device Installation
Warning: To avoid moisture influence, install
the dome cover at least half an hour after the
camera is installed and powered on.
The Vandal Dome Network Camera can be
installed on the ceiling or wall. This guide
describes how to install the camera on the
ceiling.
Installation Steps
1. Use the T15 (large dome) or T10 (mini dome)
screwdriver in the accessory package to
unscrew the three screws on the dome cover.
Open the camera, as shown in figure 3-1.
Figure 3-1: Opening Camera
Large Dome Mini Dome
2. Attach the installation sticker to the ceiling.
Drill three holes as indicated by the sticker.
Remove the sticker. Drive the swell buttons
into the holes.
3. Use the three self-tapping screws to fasten
the camera on the ceiling as shown in figure
3-2.

Figure 3-2: Installing Housing
Large dome with lining Mini dome
4. Connect the network access port and power
supply of the multihead cable (if not using
PoE).
5. Adjust the lens focal length and video angle
range. This should be done while viewing the
camera’s video feed.
a. Remove the lining by pressing the arrows
marked on it, as shown in figure 3-3.
Figure 3-3: Removing Lining
Large dome with lining Mini dome
b. Slightly loosen the slotted screw as shown
in figure 3-4 to make triaxial adjustments
to the camera.
Figure 3-4: Three-Axis Adjustment
Large dome
Mini dome
c. Loosen the focus lever and gently move
the zoom lever to adjust the focal length
to the desired position (large dome only).
d. Once properly adjusted, tighten all screws.
Note
●These steps may not apply to all models; please refer
to the actual product.
●The image might appear blurry while the focus lever
is in use; move the zoom lever to fine-tune the image
and lock the lever when the image is clear.
●If the camera lens has auto-focus, set the focus value
in the camera’s web interface under Settings > Lens
Control.
6. If applicable, insert SD card as shown in
figure 3-5.
Figure 3-5: Inserting SD Card
Large dome Mini dome
7. Re-attach the lining to the main body. Align
the dome cover with the main body and
attach as shown in figure 3-6.
Figure 3-6: Assembling Lining & Cover
Large dome Mini dome
4. Device Ports
Note: Different devices may have different ports and
multi-head cables; please refer to the actual product.
Note: Lens adjustment is only applied for large domes.

Figure 4-1: Lens Adjustment
Table 4-1: Lens Adjustment Description
Port Name
Description
Focusing lever
Adjust the focus of lens, default is lock.
Zoom level
Adjust the lens focal length, default is
lock.
Figure 4-2: Multihead Cable 1
Table 4-2: Multihead Cable 1 Description
ID
Cable
Description
Comment
1
Network
Access Port
Connects to a standard
Ethernet cable
Green light: Network
connection is normal
Yellow light: Data is
being transmitted
Supports
PoE
2
Power Supply
(DC 12V)
Connects to a 12V direct
current (DC) power
supply
3
Reset Button
Long press 5 seconds to
restore original settings
Figure 4-3: Multihead Cable 2
Table 4-3: Multihead Cable 2 Description
ID
Cable
Description
Comment
1
Network
Connects to a standard
Supports
Access Port
Ethernet cable
Green light: Network
connection is normal
Yellow light: Data is being
transmitted
PoE
2
Audio Output
Connects to an external
audio device (speaker)
Applies to
cameras
with audio
function
3
Audio Input
Receives an analog audio
signal from devices such
as a microphone.
4
Reset Button
Long press 5 seconds to
restore original settings
5
Power Supply
(DC 12V)
Connects to a 12V DC
power supply
6
G
Alarm output COM
Applied for
alarm
function
OUT
Alarm output terminal
G
Alarm input COM
IN
Alarm input terminal
5. Add Camera to VMS
Change IP Address to Static
There are some situations where an IP address
needs to be static and/or the camera password
changed. These steps are optional and do not
apply to everyone.
Camera Login
1. Open an Internet browser, enter the IP
address of the camera (default value:
192.168.0.120) in the address box, and press
Enter.
2. Input the username and password and click
the login button (default username and
password are both admin). Change the
password after logging in for the first time to
ensure system security. It is recommended to
restart the device after modifying the
password.
Set Static IP
1. After logging in to the camera, navigate to
Configuration >Device >Local Network.
2. Input the desired IP address in the IP Address
box and click Apply. After changing the IP
address setting, use the new IP address to
log in to the web interface in the future.

Add Camera to VMS
Once the camera is installed and configured,
you’ll need to add it to your Eagle Eye Cloud VMS
to begin viewing and saving recordings.
1. Connect the camera to Power over Ethernet
(PoE) switch/bridge/CMVR (if no PoE
available, connect camera to power supply
and switch/bridge/CMVR).
2. Log in to Eagle Eye Cloud VMS.
3. Navigate to the Dashboard and locate the
Available Cameras section.
4. Click the plus sign next to the camera to add
it to the VMS.
