EAPL EMS-03 V4.0 User manual

CREATED ON: April 28, 2016
1. Top Display Window
2. Botto Display Window
3. Previous button
4. Scroll/Hold button
5. Next button
6. Select button
7. Advance button
8.
Pulse Constant
Instruction Manual
EMS-03 V4.0
KWh Meter
EAPL
Introduction
Box Accessories
One (1) EMS-03 digital eter
One (1) Instruction Manual
One (1) test and Calibration certificate for energy eter
Side Anchor (2 nos.)
PA AMETE S
T PF
T W
Active Energy (KWh)
Active Energy (MWh)
Device ID
(Co unication Status)
Safety Precautions
Read and follow all the safety precautions and instructions before
installing and working with the equip ent.
! DANGE
HAZA D OF ELECT IC SHOCK, EXPLOSION O A C FLASH
• Apply appropriate personal protective equip ent(PPE) and follow
safety work practices
• Only qualified electrical workers should install this equip ent. Such work
should be perfor ed only after reading this entire set of instructions.
• If the equip ent is not used in the anner specified by the
anufacturer, the protection provided by the equip ent ay be
i paired.
• NEVER work alone.
• Turn OFF all power supplying the energy eter and the equip ent in
which it is installed before working on it.
• The successful operation of this equip ent depends upon proper
handling, installation and operation. Neglecting funda ental installation
require ents ay lead to personal injury as well as da age to
electrical equip ent or other property.
• NEVER bypass external fusing.
• NEVER short the secondary of PT
• NEVER open circuit a CT; use the shorting block to short circuit the leads
of CT before re oving the connection fro energy eter.
• Before perfor ing Dielectric or Megger testing on any equip ent in
which the energy eter is installed, disconnect all the input and output
wires to the energy eter. High voltage testing ay da age electronic
co ponents contained in the energy eter.
• The energy eter should be installed in a suitable electrical enclosure.
Failure to follow these instructions will result in death or serious injury.
• EAPL is not responsible for any consequential da ages arising out of use
of our products, though the technology is cautiously chosen and
i ple ented like any other well designed good electric eter.
Installation
Connecting cable recommendations
Insulation rating Current rating
Voltage circuit >600 VAC > 0.1A
Current circuit >600 VAC >7.5A/2.5
2
/
14AWG ini u
Tools and Fasteners
Kindly use star – type screw driver for tightening the screws.
NOTE: Installation should include a disconnecting device, like switch or
circuit breaker, with clear ON/OFF arkings, to turn-off the auxiliary
supply (control power).The disconnecting device should be within the
reach of the equip ent and the operator.
Dimension
Note: All Di ensions are in .
Front Panel
ear Panel
Page 1 of 2
OD RE YN 380011 REV 02/28-04-16

CREATED ON: April 28, 2016
Wiring
Syste Type : Star/Wye
Keys and Operation
UN Mode
• Once there is power failure, energy and Display Status will be saved.
• RS485 co unication status can be viewed in “DEV ID” para eter.”T”
for trans it,”R” for receive & “U” for device ID is atch.
P OG AM Mode
SELECT Key
P OG AM MODE : used to enter into progra ode.
: used to select digits.
ADVANCE Key
P OG AM Mode : used to increase the value by one
P EVIOUS Key
P OG AM Mode : used to progra previous para eters
UN Mode : used to view previous para eters
NEXT Key
P OG AM Mode : used to progra next para eters
UN Mode : used to view next para eters
SC OLL/HOLD Key
UN Mode: It is used to scroll/hold the para eters
Program
page
Function ange Factory
setting
1 PASSWd 0001 to 9999 1000
2 CT-PRI 1A to 5000A 5
3 CT-SEC 1A to 5A 5
4 PT-PRI 110V to 999KV 415
5 PT-SEC 110V to 500V 415
6 CLR-EN Y/N N
7 dEV-Id 1 to 247 001
8 bAUd 2400,4800,9600
and 19200(bps)
9600
9 ChPASS 0001-9999 0001
Technical Specification
Disposition
Once the product life is over, you ay send back the unit to EAPL for
disposition
Contact
Electronic Auto ation Pvt. Ltd
#20, KHB Industrial Area
Yelahanka, Bangalore -560064
Ph: [phone]/2, /42802345
E ail: info@eaplindia ail.co ,
www.eaplindia.co
Function Kilo Watt Hour Meter
ated voltage (Aux.Supply) 85 to 270 V AC / DC
ated Frequency 50 / 60Hz ± 5% for AC only
Power consumption < 5 VA / 1W
Input voltage
3 Phase 4 wire (R,Y,B,N)
Range : 415 VAC (-40% to +20%)
110 VAC (-40% to +20%)
Input current Current inputs (AR, AY, AB)
1A to 5A (to 200%)
Input Frequency 50 Hz, ± 2%
Burden < 0.2 VA per Volts/A ps input
Accuracy Class 1 / Class 0.5
ecovery Time 2 sec ini u
Communication RS-485 MODBUS RTU Protocol
Meter Constant 3200 Pulses / KWh
Ambient Temperature
Operation:
-10°C to + 55°C(14°F to 131°F)
Storage:
-25°C to + 80°C(-13°F to 176°F)
Humidity Up to 95% RH @ 40°C
1, 2, 3, 4 : R, Y, B, N
5 ,6 : No connection
7,8 : A,B (RS 485 Co unication port)
9, 10 : S1, S2 (R Phase)
11,12 : S1, S2 (Y Phase)
13,14 : S1, S2 (B Phase)
15,16 : Auxilary Supply(85-270 V AC/DC)
OD RE YN 380011 REV 02/28-04-16 Page 2 of 2
