Berner BCLL TOP User manual

BCLL BASIC: 183845
BCLL-G BASIC: 351719
Instruction Manual/Safety instructions
Brugsanvisning/Sikkerhedsinstruktioner
Bedienungsanleitung/Sicherheitshinweise
Notice d’Utilisation/lndications de sécurité
Bruksanvisning/Sikkerhetsforskrifter
Käyttöohje/Turvallisuusohjeet
Bruksanvisning/Säkerhetsinstruktioner
Instrucciones de manejo/Instrucciones de segurid
Manuale d’lstruzioni/lndicazioni per la sicurezza
Gebruiksaanwijzing/Veiligheidsinstructies
Manual de instruçôes/lnstruçôes de segurança
Kullanım Kılavuzu/Güvenlik talimatları
Εγχειρίδιο Οδηγιών/Οδηγίες ασφαλείας
Lietošanas rokasgrāmata / drošības norādījumi
Kezelési útmutató/Biztonságtechnikai útmutatások
Korisnički priručnik/sigurnosne upute
Návod na použitie/bezpečnostné pokyny
Manual de operare/Instrucţiuni de securitate
Instrukcja obsługi/instrukcje dotyczące bezpieczeństwa
Naudotojo vadovas / saugos instrukcijos
Návod k použití/Bezpečnostní pokyny
EN CROSSLINE LASER TR ÇAPRAZ ÇİZGİLAZERİ
DA SIGTE-LASERAPPARAT EL ΑΛΦΑΔΙ ΛΕΪΖΕΡ ΣΤΑΥΡΟΥ
DE KREUZLINIENLASER LV KRUSTLĪNIJU LĀZERS
FR LASER À RÉTICULE HU KERESZTVONALAS LÉZERKÉSZÜLÉK
NO KRYSSLASER HR LASER S KRIŽNIM LINIJAMA
FI RISTIKKOLASER SK PRIEČNY LASER
SV LINJELASER RO LASER LINIAR
ES LÁSER RETICULAR PL KRZYŻOWY LASER LINIOWY
IT LASER A FASCI INCROCIATI LT KRYŽMINIS LAZERINIS NIVELYRAS
NL DRADENKRUISLASER CZ KŘÍŽOVÝ LASER
PT LASER DE LINHA CRUZADA

2
English 9
Dansk 26
Deutsch 44
Français 63
Norsk 82
Suomi 99
Svenska 116
Español 134
Italiano 153
Nederlands 172
Português 191
Türkçe 210
Ελληνικά 227
Latviešu 247
Magyar 265
Hrvatski 283
Slovenčina 300
ROMÂNĂ 318
Polski 337
Lietuvių 356
Čeština 374

1
A
11
4
5
10
3
2
1
79
8
6

2
J1
J2
36 37
39 38
35
35

3
B
C1
12 10
13
8
14

4
C2
C3
9
8
14
15

5
C4
D
16

6
E
F
30
28
24
21 23
22
19
17
20
25
18

7
26
29
27 31
G
H

8
I1
I2
32 33
34 33

9
ENGLISH
CROSSLINE LASER BCLL/BCLL-G BASIC
Congratulations!
You have chosen a Berner tool. Years of experience, thorough product
development and innovation make Berner one of the most reliable partners
for professional power tool users.
Technical data
BCLL BASIC BCLL-G BASIC
Voltage 4.5 V 4.5 V
Type 1 1
Laser Diode Red Green
Battery size 3 × LR6 (AA) 3 × LR6 (AA)
Laser power < 1.3 mW < 1.3 mW
Laser class 2 2
Wavelength 630-680 nm 515-535 nm
Protection class IP54 IP54
Self-leveling range +/- 4 ° +/- 4 °
Operating temperature -10 – +45 °C -10 – +45 °C
Receptacle thread 1/4" × 20 TPI 1/4" × 20 TPI
Weight 0.75 kg 0.75 kg
Definitions: Safety Guidelines
The defi nitions below describe the level of severity for each signal word.
Please read the manual and pay attention to these symbols.
DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which,
if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.

10
ENGLISH
Denotes risk of electric shock.
Denotes risk of fire.
Safety Instructions for Lasers
WARNING! Read and understand all instructions. Failure to
follow all instructions listed below may result in electric shock,
fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
• Do not operate the laser in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
• Use the laser only with the specifically designated batteries. Use of
any other batteries may create a risk of fire.
• Store idle laser out of reach of children and other untrained
persons. Lasers are dangerous in the hands of untrained users.
• Use only accessories that are recommended by the manufacturer
for your model. Accessories that may be suitable for one laser, may
create a risk of injury when used on another laser.
• Tool service MUST be performed only by qualified repair personnel.
Repairs, service or maintenance performed by unqualified
personnel may result in injury. For the location of your nearest
authorized Berner repair agent, refer to the list of authorized Berner
repair agents on back of this manual or visit www.berner.eu on the
Internet.
• Do not use optical tools such as a telescope or transit to view the
laser beam. Serious eye injury could result.
• Do not place the laser in a position which may cause anyone to
intentionally or unintentionally stare into the laser beam. Serious
eye injury could result.
• Do not position the laser near a reflective surface which may reflect
the laser beam toward anyone’s eyes. Serious eye injury could result.
• Turn the laser offwhen it is not in use. Leaving the laser on increases
the risk of staring into the laser beam.

11
ENGLISH
• Do not operate the laser around children or allow children to
operate the laser. Serious eye injury may result.
• Do not remove or deface warning labels. If labels are removed user
or others may inadvertently expose themselves to radiation.
• Position the laser securely on a level surface. Damage to the laser or
serious injury could result if the laser falls.
• Dress properly. Do not wear loose clothing or jewelry. Contain long
hair.
Keep your hair, clothing, and gloves away from moving parts.
Loose clothing, jewelry or long hair can be caught in moving parts. Air
vents often cover moving parts and should also be avoided.
WARNING: Use of controls or adjustments or
performance of proceures other than those specified
herein may result in hazardous radiation exposure.
WARNING! DO NOT DISASSEMBLE THE LASER. There
are no user serviceable parts inside. Disassembling the
laser will void all warranties on the product. Do not modify
the product in any way. Modifying the tool may result in
hazardous laser radiation exposure.
WARNING: Fire hazard! Avoid short-circuiting the contacts of
a removed battery.
Additional Safety Instructions for Lasers
• This laser complies with class 2 according to EN 60825-1:2007. Do not
replace a laser diode with a diff erent type. If damaged, have the laser
repaired by an authorised repair agent.
• Do not use the laser for any purpose other than projecting laser lines.
An exposure of the eye to the beam of a class 2 laser is considered safe for
a maximum of 0.25 seconds. Eyelid refl exes will normally provide adequate
protection.
At distances over 1 m, the laser complies with class 1 and thus is considered
completely safe.
• Never look into the laser beam directly and intentionally.
• Do not use optical tools to view the laser beam.
• Do not set up the tool at a position where the laser beam can cross any
person at head height.

12
ENGLISH
• Do not let children come in contact with the laser.
Residual Risks
The following risks are inherent to the use of this device:
– injuries caused by staring into laser beam.
Labels on Tool
The following pictographs are shown on the tool:
Read the instruction manual before use
Laser warning
Do not stare into the laser beam.
DATE CODE POSITION
The Date Code, which also includes the year of manufacture, is printed on
the inside of the battery compartment.

13
ENGLISH
Example:
2013 XX XX
Year of Manufacture
Important Safety Instructions for Batteries
WARNING: Batteries can explode, or leak, and can cause
injury or fire. To reduce this risk:
• Carefully follow all instructions and warnings on the
battery label and package.
• Always insert batteries correctly with regard to polarity
(+ and –), marked on the battery and the equipment.
• Do not short battery terminals.
• Do not charge batteries.
• Do not mix old and new batteries. Replace all of them at
the same time with new batteries of the same brand and
type.
• Remove dead batteries immediately and dispose of per
local codes.
• Do not dispose of batteries in fire.
• Keep batteries out of reach of children.
• Remove batteries if the device will not be used for
several months.
Batteries (fig. B)
BATTERY TYPE
This laser operates on three LR6 (AA-size) batteries.
INTENDED USE
The crossline laser BCLL BASIC/BCLL-G BASIC has been designed to
project laser lines to aid in professional applications. The tool can be used
indoor for horizontal (level), vertical (plumb). The applications range from
layout of walls and windows to installation of framing track.
DO NOT use under wet conditions or in presence of fl ammable liquids
or gases. The crossline laser is a professional tool. DO NOT let children
come into contact with the tool. Supervision is required when inexperienced
operators use this tool.

14
ENGLISH
Package Contents
The package contains:
1 Crossline laser
1 Wall mount
3 LR6 (AA-size) batteries
1 Kitbox
1 Instruction manual
1 Strip of security labels
• Take the time to thoroughly read and understand this manual prior to
operation.
Description (fig. A)
1 On/off switch (vertical laser beam)
2 On/off switch (horizontal laser beam)
3 Low battery indicator
4 Vertical laser beam
5 Horizontal laser beam
6 Vertical laser beam indicator
7 Horizontal laser beam indicator
8 Pivot bracket
9 Wall mount
10 Battery compartment cover
11 1/4” × 20 female thread
Unpacking
FITTING THE WARNING LABEL
The safety warnings on the label shown on the laser must be formulated in
the language of the user.
For that purpose, a separate sheet of self-adhesive labels has been supplied
with the tool.
WARNING: Check that the safety warnings on the label have
been formulated in your language.

15
ENGLISH
The warnings should read as follows:
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
• If the warnings are in a foreign language, proceed as follows:
– Remove the required label from the sheet.
– Carefully place the label over the existing label.
– Press the label in place.
ASSEMBLY AND ADJUSTMENT
WARNING! Do not place the laser in a position which
may cause anyone to intentionally or unintentionally
stare into the laser beam. Serious eye injury may result
from staring at the beam.
Replacing Batteries (fig. B)
The attachment uses batteries of type LR6 (AA).
• Open the battery compartment cover (10).
• Replace the batteries (12). Make sure the new batteries are placed as
indicated.
• Close the battery compartment cover.
WARNING: When replacing batteries, always replace
the complete set. Do not mix old batteries with new ones.
Preferably use alkaline batteries.
LOW BATTERY INDICATOR (FIG. A)
The tool has been equipped with a low battery indicator (3) located on the
control panel. The low battery indicator is lit while the tool is switched on. It
will blink to indicate that the batteries need to be replaced and the tool will
automatically shut down.
• Switch off the tool and remove the batteries as soon as the indicator
blinks.

16
ENGLISH
Setting up the Tool (fig. C1 - C4)
The tool facilitates various set-ups, making it useful for several applications.
FLOOR SET-UP
• Place the tool on a relatively smooth and level surface.
WALL SET-UP (FIG. C1)
The keyhole (13) in the pivot bracket (8) is used for mounting to wall
constructions.
Alternatively, the tool can be attached to metal studs directly using the
magnets (14).
• Drive a screw or nail into the wall.
• Hang the tool onto the fastener by the keyhole.
FITTING THE TOOL TO THE WALL MOUNT (FIG. C2 - C4)
The tool has been equipped with a wall mount (9) for mounting to wall track
to aid in drop ceiling installation and other specialty leveling projects. The
pivot bracket (8) has magnets to attach the tool to the wall mount.
• Align the magnets (14) with the metal plate on the wall mount (9).
• To remove the wall mount, pull the wall mount from the tool applying
suffi cient force.
To fi t the wall mount to wall track, proceed as follows:
• Open the clamp jaws (15).
• Place the clamp jaw around the wall track and release the clamp to
close the clamp jaws shut on the track.
To mount the wall mount to a wall, proceed as follows:
• Hold the tool at the desired position against the wall and mark the
location of the mounting hole on the wall.
• Drill a hole at the marked location.
• Insert a corresponding plug into the hole.
• Hold the tool in front of the plug.
• Turn a screw into the mounting hole (16).
Adjusting the Tool
• To initiate the leveling procedure, switch on the tool. The level and/
or plumb orientation is correctly adjusted as long as the laser beams
remain on.

17
ENGLISH
• The laser beams start fl ashing to indicate that the tool has been set up
at a slope that is beyond the self-leveling range of 4°. Switch the tool off ,
re-adjust the tool set-up within the self-leveling range and switch the tool
on again.
Aligning the Laser Line (fig. D)
• Align the laser line of either one of the laser beams with the position
mark. Move the tool as required.
OPERATION
WARNING! Do not place the laser in a position which
may cause anyone to intentionally or unintentionally
stare into the laser beam. Serious eye injury may result
from staring at the beam.
Instructions for Use
WARNING: Always observe the safety instructions and
applicable regulations.
• Always mark the centre of the laser dots.
• Make sure the tool has been set up securely.
• Extreme temperature changes cause movement of internal parts that
may aff ect the accuracy of the tool. Regularly check the accuracy while
using the tool under these circumstances.
• Although the tool corrects small out-of-level errors automatically, when it
is bumped, re-adjustment to balance or set-up may be required.
• If the tool has been dropped or has tipped over, check whether there is
damage by performing the fi eld calibration checks.
See Maintenance.
Switching On and Off (fig. A)
The tool has separate switches to operate the vertical laser line and the
horizontal laser line.
• To switch the vertical laser beam (4) on, press the on/off switch (1).
• To switch the horizontal laser beam (5) on, press the on/off switch (2).
• To switch either laser beam off , press the on/off switch again.

18
ENGLISH
Transferring a Position Mark (fig. D)
The tool produces two laser lines in horizontal and in vertical direction, to
transfer a mark.
• Align the relevant laser beam with the mark.
Rotating the Tool (fig. E)
When in wall set-up, the tool can be rotated manually to transfer the
horizontal laser line. Rotate the tool to the left or right as required.
Laser Accessories (Optional)
DIGITAL LASER DETECTOR: BCLLD/BCLLD-G (DETECTOR) (FIG. F, G)
The Berner Digital Laser Detector (BCLLD/BCLLD-G) helps in locating
a laser beam emitted by the laser in bright light conditions or over long
distances. The detector can be used in both indoor and outdoor situations
where it is diffi cult to see the laser beam.
BCLLD is designed exclusively for use with the BCLL BASIC and BCLL TOP
line lasers. It is not for use with rotating lasers.
BCLLD-G is designed exclusively for use with the BCLL-G BASIC and
BCLL-G TOP line lasers. It is not for use with rotating lasers.
The detector gives both visual signals through the LCD display window (17)
and audio signals through the speaker (18) to indicate the location of the
laser beam.
The Berner Digital Laser Detector can be used with or without the detector
clamp. When used with the clamp, the detector can be positioned on a grade
rod, leveling pole, stud or post.
Batteries (fig. F)
The digital laser detector is powered by a 9-volt battery. To install the battery
provided, lift up on the battery compartment cover (19). Place the 9-volt
battery in the compartment, aligning the battery as shown on the embossed
icon.
Detector Controls (fig. F)
The detector is controlled by the power button (21) and the volume button
(22).
When the power button is pushed once, the detector is turned on. The top of
the sensor window shows the ON icon and the volume icon.
The Berner Digital Laser Detector also has an auto shut-off feature. If
