EarthQuake DJ-ARRAY GEN2 User manual

LINE ARRAY SPEAKER SYSTEM
Earthquake Sound Corp. | [phone] | www.earthquakesound.com
DJ-ARRAY GEN2
OWNER’S MANUAL

Earthquake Sound Corp. | [phone] | www.earthquakesound.com2 DJ-Array GEN2 Manual
WARNING: This product is ca-
pable of generating high sound
pressure levels. You should ex-
ercise caution when operating
these speakers. Long term expo-
sures to high levels of sound pressure will
cause permanent damage to your hearing.
Sound pressure levels exceeding 85dB can be
dangerous with constant exposure, set your
audio system to a comfortable loudness level.
Earthquake Sound Corporation does not as-
sume liability for damages resulting from the
direct use of Earthquake Sound audio prod-
uct(s) and urges users to play volume at mod-
erate levels.
About Earthquake Sound Corporation ..........................
Introduction.......................................................................
Safety Instructions ............................................................
Assembling DJ-Array GEN2 ..............................................
Connecting DJ-Array GEN2...............................................
Specications.....................................................................
1 Year Warranty Guidelines.............................................
For Your Records ..............................................................
3
4
5
6-7
8
9
10
11
TABLE OF CONTENTS
Earthquake Sound Corporation
2727 McCone Avenue
Hayward, CA 94545
United States of America
Tel: [phone]
Fax: [phone]
© 2021 Earthquake Sound Corporation. All rights reserved.
This document should not be construed as a commitment on the part of Earthquake Sound Corporation.
The information is subject to change without notice.
Earthquake Sound Corporation assumes no responsibility for errors that may appear within this document.

Specications are subject to change without notice. DJ-Array GEN2 Manual 3
Joseph Sahyoun, US Secretary of Commerce Gary
Locke, Abraham Sahyoun and Thomas Mygind
US Commercial Ocer Sarah
Fox and Joseph Sahyoun
For over 30 years, Earthquake Sound has been producing a variety of high quality audio products that
have impressed audiophile communities around the world. It all started in 1984 when Joseph Sahyoun,
a music freak and Aerospace Engineer unhappy with the existing loud speaker technology and
performance, decided to put his advance engineering knowledge to use. He pushed technological
boundaries to the limit to create the kind of subwoofer he could live with. Earthquake quickly created a
name for itself in the car audio industry and became well known for its powerful subwoofers and
ampliers. In 1997, using his existing expertise in the audio industry, Joseph Sahyoun expanded his
company to home audio production.
Earthquake Sound has since evolved into a leader in the home audio industry, producing not only
subwoofers and ampliers but surround speakers and tactile transducers as well. Engineered by
audiophiles for audiophiles, Earthquake Sound audio products are meticulously crafted to reproduce
each and every single note perfectly, bringing your home theater experience to life. With true dedication
and full attention to details, Earthquake Sound engineers continuously develop new and better prod-
ucts to meet customers’ needs and go beyond their expectations.
From mobile audio to prosound and home audio, Earthquake Sound has been selected as the winner of
many prestigious awards based on sound quality, performance, value and features. CEA and numerous
publications have awarded Earthquake Sound with over a dozen design and engineering awards.
Additionally, Earthquake Sound has been granted many design patents by the USPO for revolutionary
audio designs that have changed the sound of the audio industry.
Headquartered in a 60,000 square foot facility in Hayward, California USA, Earthquake Sound currently
exports to over 60 countries worldwide. In 2010, Earthquake Sound expanded its export operations by
opening a European warehouse in Denmark. This accomplishment was recognized by the US Depart-
ment of Commerce who honored Earthquake Sound with an Export Achievement award at the 2011
Consumer Electronic Show. Just recently, the US Department of Commerce presented Earthquake
Sound with another Export Achievement award for expanding its export operations in China.
ABOUT EARTHQUAKE SOUND CORPORATION

The DJ-Array GEN2 line array speaker system consists of two 4x4-inch array speakers that were designed
for DJ and pro sound applications.
The complete DJ-Array GEN2 System consists of the following packaged items:
In The Box
Two (2) sets of 4 x 4” Array Speakers
Two (2) 16.5 feet (5m) 1/4” TRS Speaker Cables Six
Two (2) Metal Mounting Brackets
Mounting Hardware
INTRODUCTION
Earthquake Sound Corp. | [phone] | www.earthquakesound.com4 DJ-Array GEN2 Manual

SAFETY INSTRUCTIONS
This documentation contains general safety,
installation, and operating instruction for the DJ-
Array Gen2 speaker system. It is important to
read this owner’s manual before attempting to
use this product. Pay particular attention to the
safety instructions.
Safety First
Symbols Explained:
NOTE:
Appears on the component to indi-
cate the presence of uninsulated,
dangerous voltage inside the en-
closure - that may be sucient to
constitute a risk of shock.
Calls attention to a procedure,
practice, condition or the like that,
if not correctly performed of ad-
hered to, could result in injury or
death.
Calls attention to a procedure,
practice, condition or the like that,
if not correctly performed or ad-
hered to, could result in damage to
or destruction of part or all of the
product.
Calls attention to information that
is essential to highlight.
Important Safety Instructions:
System Installation Considerations
There are several factors to consider before in-
stalling.
What are the intended listening zones?
From where in each zone will the listener prefer to
control the system? Where will the subwoofer or
amplier be located?
Where will the source equipment be located?
9) Do not defeat the safety purpose of the polar-
ized or grounding-type plug. A polarized plug
has two blades with one wider than the other.
The grounding-type plug has two blades and a
third grounding prong. The wide blade or the
third prong is provided for your safety. If the
provided plug does not t into your outlet, con-
sult an electrician for replacement of the obso-
lete outlet.
10) Protect the power cord from being walked on
or pinched, particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11) Only use attachments and accessories speci-
ed by the manufacturer.
12) Use only a compatible rack or cart for the nal
resting position.
13) Unplug this apparatus during lightning storms
or when unused for a long period of time.
14) Refer all servicing to qualied service person-
nel. Servicing is required when the apparatus
has been damaged in a way such as: power-
supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the apparatus has been exposed
to rain or moisture, does not operate nor-
mally, or has been dropped.
15) To reduce the risk of re or electric shock, do
not expose this apparatus to rain or moisture.
1) Read these instructions in their entirety.
2) Store this manual and packaging in a safe
place.
3) Read all warnings.
4) Follow instructions (do not take shortcuts).
5) Do not use this apparatus near water.
6) Clean only with a dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instruc-
tions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatuses that produce heat.
Specications are subject to change without notice. DJ-Array GEN2 Manual 5

x4 x4
Note
The speaker stand mounting bracket is designed
to slide into a channel found at the base of the
main speaker mounting bracket shown in the
images to the right.
1.
With the included mounting hardware, fasten the
35mm speaker stand bracket to the main speaker
mounting bracket with a 3/16 hex key allen
wrench (not included). Slide the brackets together
as shown in the images to the right and use four
of the nuts and bolts to secure them together.
ASSEMBLING DJ-ARRAY GEN2 SPEAKERS
Before you begin assembling the DJ-Array GEN2 speaker system, make sure
that you have all of the required mounting hardware. Each array requires 12
bolts and four nuts for assembly.
Earthquake Sound Corp. | [phone] | www.earthquakesound.com6 DJ-Array GEN2 Manual

ASSEMBLING DJ-ARRAY GEN2 SPEAKERS CONT.
2.
3.
With the mounting brackets assembled, begin
mounting the array speakers with the remaining
mounting hardware. Each of the four array speak-
ers will require two bolts to securely fasten them
to the mounting bracket. Align the speaker con-
tacts with the mounting bracket contacts and gen-
tly push the speaker into place. Secure the array
speaker with the two bolts and be careful not to
over tighten them. Doing so could strip the
threads inside the speaker. Repeat this step for
the remaining pieces until all for speakers are se-
curely fastened to the mounting bracket.
The DJ-Array GEN2 line array speaker system is
now ready to mount onto a stand. Earthquake
Sound supplies speaker stands (sold separately)
that can match with the DJ-Array GEN2. The 2B-
ST35M steel speaker stand is recommended for
this array speaker.
Specications are subject to change without notice. DJ-Array GEN2 Manual 7

DJ-Quake Sub v2
Left Array Right Array
CONNECTING DJ-ARRAY GEN2 SPEAKERS
The DJ-Array GEN2 speakers are equipped with
1/4″ TRS input connectors at the bottom portion
of the mounting bracket. With the supplied TRS
cables, gently push one end of the TRS cable plug
into the input as shown below and push the other
end into your amplier or powered subwoofer.
The DJ-Quake Sub v2 is a great choice to pair with
these array speakers as it features multiple inputs
and outputs as well as an active 12 inch sub-
woofer to create the ultimate and portable DJ
system.
Using the supplied 1/4″ TRS cables, connect left
and right DJ-Array GEN2 speaker systems to the
left and right array inputs located on the back of
the DJ-Quake Sub v2 or any other amplier that
supports 1/4″ TRS inputs. You do not need to run
any other speaker cables for these array speakers
due to the convenient internal wiring inside the
mounting bracket.
Earthquake strongly recommends using the HUM
Kleaner active line converter and pre-amplier
when your audio system is susceptible to noise at
the source or when you need to push an audio
signal through long wire runs. Please refer to the
manual before setting up and using this product.
Earthquake Sound Corp. | [phone] | www.earthquakesound.com8 DJ-Array GEN2 Manual
HUM Kleaner

SPECIFICATIONS
DJ-ARRAY GEN2
Power Handling RMS 50 Watts Per Channel
Power Handling MAX 100 Watts Per Channel
Impedance 4-Ohm
Sensitivity 98dB (1w/1m)
High Pass Filter 12dB/oct @ 120Hz–20kHz
Array Components 4″ Midrange
1″ Compression Driver
Input Connectors 1/4″ TRS
Net Weight (1 Array) 20 lbs (18.2 kgs)
11.5ʺ
(292mm)
19.25ʺ
(489mm)
5.75ʺ
(146mm)
Specications are subject to change without notice. DJ-Array GEN2 Manual 9

Earthquake Sound Corp. | [phone] | www.earthquakesound.com10 DJ-Array GEN2 Manual
Earthquake warrants the original purchaser that all Factory Sealed New Audio Products to be free from
defects in material and workmanship under normal and proper use for a period of one (1) years from
the date of purchase (as shown on the original sales receipt with serial number axed/written on it).
The one (1) year warranty period is valid only if an authorized Earthquake dealer properly installs the
product and the warranty registration card is properly lled out and sent to Earthquake Sound
Corporation.
(A) One (1) year limited warranty plan coverage guidelines:
Earthquake pays for labor, parts, and ground freight (only in US mainland, not including Alaska and
Hawaii. Shipping to us is not covered).
(B) Warning:
Products (sent for repair) that are tested by Earthquake technicians and deemed to have no problem(s)
will not be covered by the one (1) year limited warranty. Customer will be charged a minimum of one (1)
hour of labor (at the ongoing rates) plus shipping charges back to customer.
(C) Earthquake will repair or replace at our option all defective products/parts subject to the
following provisions:
�Defective products/parts have not been altered or repaired by other than an Earthquake factory-
approved technicians.
�Products/parts are not subjected to negligence, misuse, improper use or accident, damaged by
improper line voltage, used with incompatible products or have its serial number or any part of it altered,
defaced or removed, or have been used in any way that is contrary to Earthquake's written instructions.
(D) Warranty Limitations:
Warranty does not cover products that have been modied or abused, including but not limited to
the following:
�Damages to speaker cabinet and cabinet nish due to misuse, abuse or improper use of cleaning
materials/methods.
�Bent speaker frame, broken speaker connectors, holes in speaker cone, surround & dust cap, burnt
speaker voice coil.
�Fading and/or deterioration of speaker components & nish due to improper exposure to elements.
�Bent amplier casing, damaged nish on the casing due to abuse, misuse or improper use of cleaning
material.
�Burnt tracers on PCB.
�Product/part damaged due to poor packaging or abusive shipping conditions.
�Subsequent damage to other products.
A warranty claim will not be valid if the warranty registration card is not properly lled & returned to
Earthquake with a copy of the sales receipt.
(V) Service Request:
To receive product service, contact Earthquake Service Department at [phone] and request an
RMA number (Return Material Authorization). Items shipped without a valid RMA number will be
refused. Make sure you provide us with your complete/correct shipping address, a valid phone
number, and a brief description of the problem you are experiencing with the product. In most cases,
our technicians might be able to resolve the problem over the phone; Thus, eliminating the need to
ship the product.
(V) Shipping Instructions:
Product(s) must be packaged in its original protective box(es) to minimize transport damage and
prevent repackaging cost (at the ongoing rates). Shipper claims regarding items damaged in transit
must be presented to carrier. Earthquake Sound Corporation reserves the right to refuse improperly
packed product.
ONE (1) YEAR LIMITED WARRANTY GUIDELINES

Specications are subject to change without notice. DJ-Array GEN2 Manual 11
FOR YOUR RECORDS
Notes
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
Model Name/Number: ___________________________________________________
Serial Number: ____________________________________________________________
Date of Purchase: _________________________________________________________
Authorized Dealer/Installer Info:
Name: ______________________________________________________________________
Address: ____________________________________________________________________
____________________________________________________________________
Phone: ______________________________________________________________________

Earthquake Sound Corporation
2727 McCone Avenue. Hayward CA, 94545. USA
US Toll Free: 800-576-7944 | Phone: [phone] | Fax: [phone]
www.earthquakesound.com
