Easy@Home MD 17922 User manual

ID: #07177
m
y
h
a
n
s
e
c
o
n
t
r
o
l
.
c
o
m
C
E
R
T
I
F
I
E
D
User-friendly
Manual
LAUNDRY
User Manual
Manual
del usuario
English .....06
Español .... 33
12 STITCH
SEWING MACHINE
MÁQUINA DE COSER DE 12 PUNTADAS

Dok./Rev.-Nr. 17922 ML ALDI USA Cover 5006 1001 final_rev2
Contents
Overview .............................................................................3
Use........................................................................................5
Package contents/device parts..........................................6
General information............................................................ 7
Reading and storing the user manual ..................................7
Explanation of symbols ...........................................................7
Safety...................................................................................8
Proper use................................................................................. 8
Safety instructions................................................................... 8
Checking the sewing machine and package contents.... 15
Operating instructions...................................................... 15
Installing/changing the batteries........................................ 15
Connecting the power adapter and foot pedal................. 15
Installing/replacing a needle ............................................... 16
Winding a bobbin ................................................................... 17
Threading the sewing machine ...........................................18
Using the needle threader................................................... 20
Threading a bobbin............................................................... 20
Sewing ............................................................................... 22
Selecting/changing a stitch pattern....................................23
Adjusting tension....................................................................23
Sewing sleeves and cuffs ......................................................24
Sewing a buttonhole .............................................................24
Reverse stitch lever ................................................................26
Sewing light.............................................................................26
Replacing the presser foot ...............................................26
Removing the presser foot locking lever ........................ 27
Cleaning.............................................................................28
Storage ..............................................................................29
Troubleshooting................................................................29
Technical specifications ....................................................30
FCC Compliance Statement................................................ 31
Disposal.............................................................................. 32
Disposing of the packaging ..................................................32
Disposing of the sewing machine........................................32

A
LHOFF
3
11
10
9
8
7 6 5
4
321

4
B
C
12 13 14 15
17
18
19
2021
22 23 24 25 26 27
29 28
16

5
H
D E
F G
30
31
5

6
Package contents⁄device parts
1Take up lever 17 Presser foot lifter
2Pattern selection dial 18 Presser foot locking lever
3Handwheel 19 Presser foot
4Reverse stitch lever 20 Power adapter input
5Drawer 21 Foot pedal input
6Power OFF/speed switch 22 Bobbin, 2×
7Bobbin compartment cover 23 Needle threader
8Needle clamp screw 24 Needle
9Light button 25 Thread spool, 2×
10 Thread cutter 26 Thread spool cap
11 Thread tension dial 27 Thread spool pin foot
12 Bobbin winder stop 28 Power adapter
13 Bobbin winder pin 29 Foot pedal
14 Spool pin 30 Battery compartment cover
15 Thread guide disk 31 Battery, 4×
16 Thread guide
The package contents include four AA (LR6) 1.5 V batteries.

General information
7
General information
Reading and storing the user manual
This user manual accompanies this 12 stitch sewing machine
(hereafter referred to as the “sewing machine”), and contains
important information on setup and use.
Before using the sewing machine, read the user manual carefully.
This particularly applies to the safety instructions. Failure to do so may result in
personal injury or damage to the sewing machine.
Store the user manual in a safe place for future reference. Make sure to include
this user manual when passing the sewing machine on to third parties.
Explanation of symbols
The following symbols and signal words are used in this user manual, on the
sewing machine or on the packaging.
DANGER! This signal symbol/word designates a hazard
with a high degree of risk, which will result in
death or severe injury if not avoided.
WARNING! This signal symbol/word designates a hazard
with moderate risk, which may result in
death or severe injury if not avoided.
CAUTION! This signal symbol/word designates a hazard
with low risk, which may result in minor or
moderate injury if not avoided.
NOTICE! This signal word warns of possible damage
to property.
This symbol provides you with useful additional information on
handling and use.
The power adapter has a positive polarity.
Energy efficiency level VI
The energy efficiency level is a standard scale for rating the
efficiency of external and internal power supplies. The energy
efficiency symbol indicates the efficiency level and the ratings
are classified up to level VI (most efficient level).

Safety
8
ETL Listed products are tested by Intertek and meets the
minimum requirements of U.S. and/or Canadian electrical safety
standards. It reflects a manufacturers dedication to the safety
and quality of their products.
The Federal Communications Commission (FCC) requires all
commercial electronic devices to comply to this norm (see
section ‘Declaration of conformity’).
UL develops standards and test procedures for products,
materials, components, assemblies, tools and equipment,
chiefly dealing with product safety.
Safety
Proper use
The sewing machine is exclusively designed for stitching and sewing together
fabrics. It is only intended for personal use and not suitable for commercial
purposes.
Only use the sewing machine as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
Safety instructions
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic safety precautions should always be
followed, including the following:
Read all instructions before using the sewing machine.
DANGER– To reduce the risk of electric shock:
1. An appliance should never be left unattended when plugged in. Always
unplug this appliance from the electric outlet immediately after using and
before cleaning.
WARNING– To reduce the risk of burns, fire, electric shock, or injury to
persons:
1. Do not allow the sewing machine to be used as a toy. Close attention is
necessary when this appliance is used by or near children.
2. Use this appliance only for its intended use as described in this manual. Use
only attachments recommended by the manufacturer as contained in this
manual.

Safety
9
3. Never operate this appliance if it has a damaged cord or plug, if it is not
working properly, if it has been dropped or damaged, or dropped into
water. Return the appliance to the nearest authorized dealer or service
center for examination, repair, electrical or mechanical adjustment.
4. Never operate the appliance with the air openings blocked. Keep the air
openings free of lint, hair, loose clothes and the like.
5. Never drop or insert any object into any opening.
6. Do not use outdoors.
7. Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
8. To disconnect, turn all controls to the off (“OFF”) position, then remove plug
from outlet.
9. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
SAVE THESE INSTRUCTIONS
WARNING!
Risk of electric shock!
A faulty electrical installation, excessive line voltage, or incorrect
operation may result in an electric shock.
− Only connect the sewing machine if the outlet
corresponds to the data on the rating plate.
− Only connect the sewing machine to an easily accessible
outlet so that you can quickly disconnect it from the power
supply in the event of a problem.
− Do not use the sewing machine if it is damaged or if the
power cord or plug is defective.
− Do not open the housing; instead, have a qualified
professional perform repairs. Contact a qualified repair
center for this. Liability and warranty claims are waived
in the event of repairs performed by the user, improper
connection, or incorrect operation.
− Only parts that comply with the original device's technical
specifications may be used for repairs. This device contains

Safety
10
electrical and mechanical parts which are essential for
providing protection against sources of danger.
− Do not use the sewing machine with an external timer or
separate remote control system.
− Do not immerse the sewing machine, power adapter,
power cord, or the foot pedal in water or other liquids.
− Never touch the power plug with wet or damp hands.
− Never move, pull, or carry the sewing machine by its
power cord.
− Keep the sewing machine, the power supply unit, and the
power cord away from open flames and hot surfaces.
− Lay the power cord and foot pedal cord so that they do not
pose a tripping hazard.
− Do not kink the power cord or foot pedal cord and do not
lay them over sharp edges.
− Only use the sewing machine indoors. Do not use it in
damp rooms or in the rain.
− Do not place the sewing machine such that there is a risk
of it falling into a tub or sink.
− Never reach to retrieve an electrical device if it has fallen
into water. In such a case, immediately disconnect the
power plug.
− Do not use the sewing machine on soft surfaces, such as a
bed or couch.
− Always switch the sewing machine off and unplug it when
you are not using it, when you intend to clean it, or in the
event of a malfunction.

Safety
11
WARNING!
Risk of injury!
Improper use of the sewing machine can cause serious injury.
− Never operate the sewing machine with any air openings
blocked. Keep ventilation openings of the sewing
machine and foot pedal free from the accumulation of lint,
dust, and loose cloth. Keep fingers away from all moving
parts. Special care is required around the sewing machine
needle.
− Always use the proper needle plate. The wrong plate can
cause the needle to break.
− Do not use bent needles.
− Do not pull or push fabric while stitching. It may bend the
needle, causing it to break.
− Switch the sewing machine off (“0FF”) and take your foot
off the foot pedal when making any adjustments in the
needle area, such as threading a needle, changing a
needle, threading a bobbin, or changing the presser foot.
− Always unplug the sewing machine from the electrical
outlet when making any user servicing adjustments as
mentioned in this user manual.
WARNING!
Danger for children and persons with impaired physical,
sensory or mental capacities (e.g., partially disabled
persons, older persons with reduced physical and mental
capacities) or lack of experience and knowledge (e.g.,
older children).
− If they are supervised or have been instructed on how to
safely use the sewing machine and have understood the
risks associated with operating it, this sewing machine
may be used by children ages eight and over as well

Safety
12
as persons with impaired physical, sensory or mental
capacities, or those lacking experience and knowledge.
Children may not play with the sewing machine. Cleaning
and user maintenance must not be performed by
unsupervised children.
− Keep children under the age of eight away from the
sewing machine and power cord.
− Do not leave the sewing machine unattended while in use.
− Do not leave children unattended near the sewing machine.
− Make sure that children do not play with any plastic
wrapping or small parts. They may get caught in the
wrapping when playing and suffocate and/or swallow
small parts and choke.
WARNING!
Danger of explosion or leakage!
Batteries that have been inserted improperly may leak and
cause a fire or explosion.
− Only replace the batteries with the same or equivalent
battery type.
− Always change the entire set of batteries. Never mix old
and new batteries or batteries with different charges.
− When inserting batteries, ensure that the polarity is correct
(positive [+] and negative [–]).
− Never expose batteries to excessive heat, for example direct
sunlight or fire. Do not throw batteries in an open fire.
− Never disassemble batteries, do not short circuit them and
do not recharge batteries that are not rechargeable.
− Remove dead batteries from the sewing machine
promptly.

Safety
13
WARNING!
Risk of injury!
If children swallow batteries, the batteries can leak and result in
poisoning and death. Touching damaged batteries may result
in injury.
− Store both new and used batteries so that they are out of
the reach of children.
− If you suspect that a battery has been swallowed or
otherwise consumed, consult a physician immediately.
− Always wear gloves when handling and disposing of
leaky batteries
CAUTION!
Risk of injury!
Improper handling of the sewing machine may result in injury.
− Do not sew clothing directly on you or another person's
clothing while it is being worn.
− Remove clothing before sewing.
NOTICE!
Risk of damage!
Improper handling of the sewing machine may result in damage
to the sewing machine.
− Place the sewing machine on an easily accessible, level, dry,
heat-resistant and sufficiently stable work surface. Do not
place the sewing machine on the edge of a work surface.
− Never place the sewing machine on or near hot surfaces
(stovetops, etc.).

Safety
14
− Ensure that the power cord does not come into contact
with hot surfaces.
− Never expose the sewing machine to high temperatures
(heaters etc.) or to the effects of the weather (rain etc.).
− Never attempt to clean the sewing machine by immersing
it in water and do not use a steam cleaner to clean it.
Otherwise, you could damage the sewing machine.
− Stop using the sewing machine if any plastic parts are
cracked, broken, or deformed. Only replace damaged
parts with corresponding original spare parts.
− Always remove the batteries before operating the sewing
machine with the power adapter.

Checking the sewing machine and package contents
15
Checking the sewing machine and package
contents
NOTICE!
Risk of damage!
If you are not cautious when opening the packaging with a
sharp knife or other pointed object, you may quickly damage
the sewing machine.
− For this reason, be very careful when opening it.
1. Take the sewing machine out of the packaging.
2. Check to make sure that all parts are included (see Figs. A, B, C, and D).
3. Check whether the sewing machine or any individual parts are damaged. If
this is the case, do not use the sewing machine. Contact the manufacturer
via the service address indicated on the warranty card.
Operating instructions
There are two ways to operate the sewing machine:
• the foot pedal (when the power OFF/speed switch is in the
“OFF” position), or
• the power OFF/speed switch (L stands for low speed while
H stands for high speed)
Installing/changing the batteries
1. Make sure the Power OFF/speed switch 6is in the “OFF” position.
2. Turn the sewing machine over onto a flat surface and remove the battery
compartment cover 30 (see Fig. D).
3. Remove any old or dead batteries.
4. Insert four AA batteries (type LR6 (AA) 1.5 V) into the compartment, making
sure the polarity (+/–) is correct, and replace the battery compartment
cover.
Connecting the power adapter and foot pedal
1. Make sure the Power OFF/speed switch 6is in the “OFF” position and the
batteries are removed.
2. Insert the jack of the power adapter 28 into the power adapter input 20
on the back of the sewing machine (see Fig. E).

Operating instructions
16
3. Plug the power adapter into an easily accessible outlet.
4. Connect the foot pedal 29 to the sewing machine by inserting the jack
of the foot pedal into the foot pedal input 21 on the back of the sewing
machine.
Installing/replacing a needle
CAUTION!
Risk of injury!
Improper handling of the sewing machine may result in injury.
− Remove the batteries and unplug the power adapter
before replacing a needle.
1. Turn the handwheel 3
counterclockwise to raise the
needle to its highest position.
2. Hold the old needle and
loosen the needle clamp
screw 8by turning it
counterclockwise.
Remove the old needle and
carefully discard it.
3. Insert a new needle into the
clamp with the flat side of the
needle towards the back of
the sewing machine.
Be sure to push the needle all
the way into the clamp before
tightening the needle clamp
screw.

Operating instructions
17
Winding a bobbin
• Always use a metal bobbin, otherwise the magnetized bob-
bin case will not be able to function properly, resulting in a
lack of tension on the bobbin thread.
• Bobbins
22 and thread spools 25 may be stored in the
small drawer 5on the side of the machine (see Fig. F).
1. Turn the sewing machine so
that you are facing it from
behind.
2. Place an empty bobbin onto
the bobbin winder pin 13
and push it to the left.
3. Place a spool of thread on
the spool pin 14 , so that the
thread rolls off the spool in a
counterclockwise direction.
If desired, place the thread
spool cap 26 on the spool
pin.
4. Guide the thread to the thread
guide disk 15 and slip it
securely under the disk, going
counterclockwise.
5. Wrap the end of the thread
clockwise around the bobbin
several times.

Operating instructions
18
6. Press the foot pedal 29 (or set the power OFF/speed switch to “L” if you're
using batteries) to start winding.
7. Stop winding after the desired amount of thread is wound onto the
bobbin.
8. Push the bobbin winder pin and bobbin back to the right.
9. Remove the bobbin from the bobbin winder pin and then cut the thread.
Threading the sewing machine
1. Set the power OFF/speed
switch 6to the “OFF”
position. L OFF H
2. Raise the presser foot lifter 17
and turn the handwheel 3
counterclockwise until
the needle is in its highest
position.
3. Place a thread spool 25 onto
the spool pin 14 , making sure
that the thread rolls off the
spool in a counterclockwise
direction.
When needed, use the thread
spool pin foot 27 and/or
thread spool cap 26 .
4. Hook the thread through
the thread guide 16
and then securely slip it
counterclockwise under the
thread guide disk 15 .

Operating instructions
19
5. Bring the thread down
through the tension disk slot,
go around the U-turn, and
bring it back up.
6. Pass the thread through the
eye of the take up lever 1,
from right to left.
7. Bring the thread back down
and thread the guide, from
top to bottom, on the needle
clamp.
8. Thread the needle from front
to back, making sure that
the thread is to the back of
the needle and on top of the
presser foot.

Operating instructions
20
Using the needle threader
1. Gently push the wire loop
of the needle threader 23
through the eye of the needle,
from back to front.
2. Pass about 4 inches of thread
through the wire loop of the
needle threader.
3. Pull the needle threader back
through the eye of the needle,
bringing the thread with it.
Threading a bobbin
Always use a metal bobbin, otherwise the magnetized bobbin
case will not be able to function properly, resulting in a lack of
tension on the bobbin thread.
1. Turn the handwheel 3
counterclockwise until the
needle is in its highest position.
2. Raise the presser foot lifter 17 .
3. Slide the bobbin compartment
cover 7towards you and
remove it.
