Easy-Laser XT11 User manual

User Manual
English
05-0835 (EN) Revision 2.0 |User Manual last built: 9/12/2017

CONTENTS
DISPLAY UNIT
XT11 Startscreen 7
Info display on XT11 8
New, continue and save 9
New or Continue session 9
Save 9
Finalize 10
Finalize a measurement 10
View a finalized measurement 10
Create a template 11
File manager 12
Copy/Edit 12
Filter 13
Select filter 13
Charge XT11 14
Camera 15
IR camera 16
Settings 16
Screenshot 18
Settings 19
Units 19
Language 19
User information 19
Time and date 20
Display 20
Wi-Fi 21
System information 22
Update software 22
MEASURING UNITS
Overview 23
Select measuring units 23
Charge 23
Information in the Display unit 23
XT40 24
Info display 24
XT60 25
Info display 25
VALUES
Overview 27
Select measuring units 27
Enlarge the value box 27
Measure 29
Halve value 29
Zero set value 29

Autorecord 30
Calibration check 31
Quick check 31
Precision check 31
HORIZONTAL
Workflow 33
Prepare 34
Set up measuring units 34
Rough align 35
Enter distances 36
Coupling diameter 36
Gap 36
RPM 37
Tolerance 37
Softfoot 37
Thermal compensation 38
Name the machine 40
Measure using EasyTurn™ 41
Measure using 9-12-3 43
Measure using Multipoint 45
Measure using Continuous sweep 47
Result 49
Result table 50
As found or As left 51
Quality assessment 52
Adjust 53
Live values for EasyTurn™ 53
Live values for 9-12-3 54
Report 55
Save a report 55
Select a report template 55
Add a note 55
Add a photo 56
Add user information 56
Share a report to USB 56
BELT
Overview 57
Prepare 59
Mount the units 59
Sheave width 60
Tolerance 60
Measure with Display unit 62
Adjust 63
Measure without Display unit 64
Measure 64

Settings 64
Align with targets 64
Report 66
TECHNICAL DATA
Display unit XT11 67
Display unit 67
Cables 68
Brackets etc. 68
Measuring units XT40 69
Laser classification 69
Measuring units XT60 71
Laser classification 71
XT440 Shaft 73
A complete system contains 73
Customize your XT11 73
XT660 Shaft 75
A complete system contains 75
Customize your XT11 75
XT190 BTA 77
Laser transmitter 77
Detector 78
LEGAL NOTICE
Declaration of conformity 79
Quality Certificate 79
Copyright 80
Disclaimer 80
Warranty 80
Safety precautions 80
Laser safety 81
Traveling with your measurement system 81
Service and calibration 81

This page intentionally left blank to ensure
new chapters start on right (odd number)
pages.

DISPLAY UNIT
XT11 STARTSCREEN
A. The info display show battery information. See "Info display on XT11" on the next page.
B. On/Off button.
C. Lock screen/Battery
When the Display unit is off: Press to see the battery status.
When the Display unit is on: Press to lock the touch function on the screen. Prevents unintentional clicks, for
instance when moving between work positions.
D. OK button.
E. Tap the screen to open a program.
On the startscreen you will find the icons for the programs you have downloaded, plus some default icons:
See "File manager" on page 12
See "Settings" on page 19
Open Help.
See "Camera" on page 15
For technical information regarding XT11, See "Display unit XT11" on page67
7

INFO DISPLAY ON XT11
The info display gives information about the battery status for both the Display unit and the connected measuring units.
When the Display unit is off, you can press to show battery information.
A. Battery information for the connected measuring units.
B. Serial number for the measuring unit. This number is also found on the back of the measuring unit.
C. The screen is locked. Press to enable the touch function on the screen again.
D. Battery information for Display unit XT11.
The remaining battery power is shown in percentage.
Battery is low, please charge.
The battery is being charged. When fully charged it shows 100.
No batteries, the Display unit is run via the adapter. Contact your Service center.
The battery is empty, the Display unit will turn off in approx. 5 seconds.
The cover is open, usually after a battery change. Close the cover.
Unbalanced battery, usually shown after a battery change. Start the Display unit and wait. When the
warning is gone, charge the Display unit.
The battery in the Display unit has a high temperature. Stop charging the Display unit and let it cool.
Start the Display unit and wait.
At least one of the batteries in the Display unit is damaged or missing.
Cannot start the Display unit. Contact your Service center.
Lock screen
When the Display unit is on: Press lock the touch function on the screen. Prevents unintentional clicks, for
instance when moving between work positions. To unlock, press again.
8
DISPLAY UNIT

NEW, CONTINUE AND SAVE

A. Start a program.
B. The measurement is saved automatically through the entire workflow.
C. You can go to the home screen, have a coffee break, charge the batteries or even use another program. Even if
you are interrupted, you are able to continue the same measurement session later on.
D. When you select Finalize, the measurement file is added to the File manager. See "Finalize" on the next page
E. It is possible to create a editable copy of the finalized measurement. See "File manager" on page12.
New or Continue session
Tap the program icon to start a new measurement.
If you leave an ongoing measurement session, the next time you will start the same program you are asked if you want
to start a new measurement or continue on the previous session.
A. Tap to continue the previous session.
B. Tap to start a new measurement. The ongoing session
will be deleted.
Save
The measurement is saved automatically through the entire workflow. When you select Finalize, the measurement file
is added to the File manager. See "Finalize" on the next page
9
DISPLAY UNIT

FINALIZE
The measurement is saved automatically through the entire workflow. When you have finished the measurement, you
finalize it. When a measurement has been finalized, it is no longer editable. It is however possible to open a copy and
continue working were the last session was ended. For information regarding Copy/Edit, See "File manager" on
page12.
Finalize a measurement
Usually, you finalize when you have finished your measurement. See " Report" on page55.
1. Tap and .
2. Enter a new name, or leave the default name.
3. Tap . The file is finalized and no longer editable. The measurement file is added to the File manager.
A. Tap here to change the default file name.
B. Tap to finalize the measurement.
View a finalized measurement
1. Tap to open the File Manager.
2. Tap the measurement you want to view.
If you want to create a editable copy of the open measurement, tap and to open a copy of it.
A. Measure view and Adjust view are not active.
B. Distances are visible but not editable.


10
DISPLAY UNIT

Create a template
You can choose to finalize before you have finished the measurement. This is a quick way to create a simple template.
1. Enter distances, RPM and thermal compensation for example.
2. Tap to finalize.
3. Name the file. The file is saved in the File manager.
4. Tap to open the File manager.
5. Tap to open a editable copy. This measurement will be saved with a new name when you finalize it.
11
DISPLAY UNIT

FILE MANAGER
On the Start view, tap to open the File Manager.
A. File types.
B. Delete files.
C. Share files.
D. Edit/Copy file.
File types
Measurements. All finalized measurements are stored in File Manager and represented by the corresponding
program icon. Tap a file to view. See "Finalize" on page 10.
Pdf-report. Tap a file to open it. Reports are stored as PDF-files.See " Report" on page 55.
Excel file. It is not possible to view Excel files in the XT11 Display unit. To view it, share it to a USB memory
stick.
Photos, IR-photos and screenshots. Images are stored as .png-files. The files are named with the date and
time they were created. Tap a file to open. See "Camera" on page 15, See "Screenshot" on page 18
Delete file
Tap next to the file to delete from the File Manager. You will be asked to confirm the deletion.
Copy/Edit
When a measurement has been finalized, it is no longer editable. It is however possible to open a copy and continue
working were the last session was ended.
lTap to open a editable copy of the selected measurement. This measurement will be saved with a new name
when you finalize it.
lIf you have a finalized measurement open, tap and to open a copy of it.
12
DISPLAY UNIT

FILTER
If the laser beam passes through air with varying temperature, this may influence the direction of the laser beam. If
measurement values fluctuate, this could mean unstable readings. Try to reduce air movements between laser and
detector by, for instance, moving heat sources or closing doors. If the readings remain unstable, increase the filter
value (more samples will become available to the statistical filter).
Select filter
Tap to expand the filter tab. Use as short a time as possible that still produces acceptable stability during the meas-
urement. Default is set to 1. The filter value you choose, will be default next time you start the program.
Select filter on the tab.
13
DISPLAY UNIT

CHARGE XT11
Charge the display unit by plugging in the power adapter. For information about the battery status See "Info display on
XT11" on page8. To fully charge the battery takes approximately 3 hours. It is possible to keep on using the equip-
ment while it is charging.

NOTE! When finished working for the day, charge the whole system. Plug in the power adapter to the display
unit.
Switch battery
If the battery must be switched, it is recommended that you contact your service center.
14
DISPLAY UNIT

CAMERA
1. Tap and . The camera is also available from the start view.
2. Tap [TAKE PHOTO]. The camera is opened.
3. Tap to take a photo.
The photo is saved in File manager as a .png file. It is named with current date and time. If you have an ongoing meas-
urement, the photo is added to the report. Currently, only one photo can be added to the report. If a new photo is taken,
the previous one will be overwritten.
15
DISPLAY UNIT

IR CAMERA
The IR (thermal) camera is optional equipment (Part No. 12-0968) and cannot be retrofitted.
1. Tap and . The camera is also available from the start view.
2. Tap to start the IR camera. Allow the camera to acclimatise for about five minutes in the environment in
which it is to be used. This will ensure an optimal IR measurement.
3. Press to take a photo.
An IR photo is saved in the File manager as a .png file. It is named with current date and time. If you have an ongoing
measurement, the photo is added to the report. If a new photo/IR photo is taken, the previous one will be overwritten in
the report.
A. Heat scale.
B. Crosshair. This is where the temperature is registered (Temp, e and Tbkg).
C. Tap to open Settings.
D. Temp: The average temperature.
e: The emissivity value.
Tbkg: The reflected background temperature.
Settings
Palette
Change the color presentation of the infrared images. Select between iron, glowbow, grey, rain or yellow.
16
DISPLAY UNIT

Show/hide
If you hide the crosshair and/or metadata, it will not be shown on the saved image either.
Emissivity (e)
The emissivity value of the surface/object is captured by the crosshair. The correct emissivity value is important for an
accurate calculation. Possible values: 0.01 - 1.00, but we do not recommend value below 0.6. The value is normally
set from a list of emissivity values for some common materials.
l1.00 for a perfect blackbody.
l0.01 for a perfect shiny (in the infrared spectrum) object.
Background temperature (Tbkg).
The reflected background temperature of the surface/object. Can normally be set to the ambient temperature. Value
<382ºC (720ºF). Has no effect when e = 1.00
Unit
Select Celsius or Fahrenheit.
17
DISPLAY UNIT

SCREENSHOT
It is possible to take screenshots of what is currently displayed on the XT11 screen.
1. Press the button.
2. Tap .
3. The screen dump is saved in File manager as a .png file. It is named with current date and time.
18
DISPLAY UNIT

SETTINGS
Tap on the startscreen to open the Settings menu.

Units
You can choose between metric or imperial units for your measurements. The selected unit is shown in the upper right
corner of your screen during your measurements.
1. Tap on the startscreen to open the Settings menu.
2. Tap and select unit and resolution. Default is set to 0.01 mm.
3. Tap to close the Settings view. Your new settings are saved.
Language
1. Tap on the startscreen to open the Settings menu.
2. Tap and select a language.
3. Tap to close the Settings view. Your new setting is saved.
User information
The information you enter will be visible in the coming reports that is using the template "Detailed".
1. Tap on the startscreen to open the Settings menu.
2. Tap and enter user information.
Select logo
1. Insert a USB memory stick to the XT11.
2. Tap and select an image. (If you are not using the XT11, the file manager of your device will be opened.)
3. Tap "Use selected logotype".
Reset logo
Tap to reset the logotype to standard Easy-Laser.
If you reset the logotype, you have to insert the USB memory stick if you want to select your logotype again.
19
DISPLAY UNIT


Time and date
1. Tap on the startscreen to open the Settings menu.
2. Tap to set the time and date.
3. Tap to close the Settings view. Your new settings are saved.
Display
Adjust the brightness to make it easier to read in bright sunlight for example. Remember however that a high contrast
consume more battery power. Default is set to 40%
1. Tap on the startscreen to open the Settings menu.
2. Tap and adjust the brightness.
3. Tap to close the Settings view. Your new setting is saved.
20
DISPLAY UNIT
