Easy-Laser E710 User manual

MANUAL
English
05-0461 Revision 13
System version 11.0
E710

CONTENT
INTRODUCTION 1
Service and calibration 3
Travelling with your measurement system 4
DISPLAY UNIT 5
Reset the Display unit 5
Navigation buttons 6
OK buttons 6
Function buttons 6
Status bar 7
Screen dump 8
LED lights 8
Battery 9
Note! 9
Charge the Display unit 9
APC via USB cable 9
Dry cell batteries 9
Charge the Detector/Measuring units 9
Calculator 10
Measurement le handling 11
Save le 11
File manager 11
Favourites 12
Open le as template 13
Copy le to USB memory 13
Barcode 13
Print le (Optional) 14
Report 14
Download le to PC 14
Control panel 15
Filter 15
Unit and resolution 16
Detector rotation 16
Date and time 16
Language 17
User 17
Backlight 17
Automatic power off 18
VGA 18
System update 18
License 20
Bluetooth® set up 21
CHOOSE PROGRAM 23
Preparations 23
PROGRAM VALUES 25
Tolerance 26
Zoom 26
Halve or Zero set value 27
Live values – colours 27
Automatic recording 28
Precision level E290 (Optional equipment) 28
Streaming values 29
Calibration check 30
HORIZONTAL 31
Adjust measuring units 32
Select machines 33
Enter distances 34
Measure using Easy Turn™ 35
Measure using Multipoint 36
Quality assessment 37
Measure using 9-12-3 38
Result and adjust 39
Live values 40
Thermal compensation 42
RefLock™ 43
Tolerance 44
SOFTFOOT 47
MACHINE TRAIN 49
Build machine train 50
Enter distances 52
Measure using EasyTurn™ 53
Measure using Multipoint 54
Measure using 9-12-3 55
Result 56
Result Machine view 56
Result Table view 57
Result Graph view 58
Lock feet pair 59
Best t and Manual t 59
Uncertain coupling 59
Adjust 60
Tolerance 62
VERTICAL 63
Preparations 63
Measure 64
Result 65
Adjust machine 66

CARDAN 67
Mount the units 67
Cone laser beam 68
Rough alignment 69
Measure 69
Result 70
Adjustment 70
STRAIGHTNESS 71
Show target 72
Show reference target 72
Measure 73
Quickmode 74
Add and delete points 75
Result 76
Tolerance 79
Calculation settings 80
Reference points 80
Best t operations 82
Waviness 83
Straightness settings 84
FLATNESS 87
Preparation 87
Enter distances 87
Measure 89
Result table 90
Result grid 91
Result 3D 91
Calculation settings 92
Reference points 92
Best t 92
TWIST 93
Measure 93
Result 94
FLANGE FLATNESS 95
Preparations 95
Measure 97
Result 98
Reference points 100
Custom reference points 100
Three reference points 100
Best t 101
Taper result 103
Tolerance 104
PARTIAL FLANGE FLATNESS 105
Measure 107
Result 108
FLANGE FLATNESS SECTION 109
Preparations 110
Measure 111
Rotate ange 111
PARALLELISM A 113
Prism set up 114
Precision level 115
Calibrate the precision level 115
Measure 116
Measure vertical value 117
Measure horizontal value 118
Adjust roll live 119
Detector angle 119
Result 120
PARALLELISM B 123
Preparations 124
Calibrate the precision level 124
Calibrate E2 detector 125
Laser setup 126
Measure 127
Measure vertical value 127
Measure horizontal value 128
Switch measurement direction 128
Result 129
Move laser 132
BTA 133
Measure using Display unit 135
Measure without Display unit 138
VIBROMETER 139
Measure 140
Vibration level 141
Bearing condition value 142
OFFSET AND ANGLE 143
BATTERY PACKS 145
TECHNICAL DATA 147
Display unit E51 148
Measuring units 149
BTA E180 (Optional) 150
Vibrometer (Optional) 151
Precision level E290 152
INDEX 153

1
INTRODUCTION
Damalini AB
Damalini AB develops, manufactures and markets Easy-Laser®measurement and
alignment equipment based on laser technology.
We have more than 25 years of experience from measurement tasks in the eld and
product development. We also provide measurement service, which means that we
ourselves use the equipment we develop, and continuously improve it. Because of this
we dare to call ourselves measurement specialists.
Do not hesitate to contact us about your measurement problems. Our expertise will
help you solve it in an easy way.
Declaration of conformity
Equipment: Easy-Laser®product range
Damalini AB declares that the Easy-Laser®product range is
manufactured in conformity with national and international regulations.
The system complies with, and has been tested according to the
following requirements:
EMC Directive 2004/108/EG
Low Voltage Directive 2006/95/EC
Laser Classication Europe: SS_EN 60825-1
USA: CFR 1040.10/11
RoHs Directive 2011/65/EU
WEEE Directive 2012/19/EU
The calibration of the equipment fully complies with ISO9001:2008 #7.6
For Bluetooth®devices: This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Disposal of old electrical and electronic equipment (Applicable through-
out the European Union and other European countries with separate col-
lection programs)
This symbol, found on product or on its packing, indicates that this prod-
uct should not be treated as household waste when disposed of.
It should be handed over to an applicable collection point for the recycling of electrical
and electronic equipment. By ensuring this product is disposed correctly, you will help
to prevent potential negative consequences to the environment and human health. For
more detailed information about the recycling of this product, please contact your local
city ofce, household waste disposal service or the retail store where you purchased
this product.
Quality certicate
Damalini AB is ISO 9001:2008 certied. Certicate number 900958.
Damalini AB conrm, that our products are produced according to applicable national
and international regulations and standards. All components are checked before assem-
bly and nal products are tested in functionality and visually checked before delivery
The calibration of the equipment fully complies with ISO9001: 2008 #7.6

2
Introduction
Limited warranty
This product is manufactured under Damalini’s strict quality control system. Should
the product fail within two (2) years from the date of purchase under normal usage
conditions, Damalini will repair or replace the product free of charge.
1. Using new or refurbished replacement parts.
2. Exchange the product with a product that is new or which has been manufactured
from new or serviceable used parts and is at least functionally equivalent to the
original product.
Proof of purchase date should be conrmed, and sent together with a copy of the origi-
nal purchase document.
Warranty is valid under normal usage described in the user’s manual appended with
the product. The warranty comprises failure on Easy-Laser®product that could be
related to material and/or fabrication errors. The warranty is valid only in the country
of purchase.
The warranty is not valid in the following cases:
• If the product is broken due to mishandling or incorrect operation
• If the product has been exposed to extreme temperature, calamity, chock or high
voltage.
• If the product has been modied, repaired or disassembled by unauthorized per-
sonnel.
Compensation for possible damage due to failure on Easy-Laser®product is not in-
cluded in the warranty. Freight cost to Damalini is not included in the warranty.
Note!
Before delivery of the product for warranty repair, it is the responsibility of the buyer
to backup all data. Data recovery is not included in the warranty service and Dama-
lini is not responsible for data that may be lost or damaged during transit or repair.
Lithium Ion battery limited warranty
Lithium ion batteries inevitably lose power during their lifetimes, depending on usage
temperatures and the number of charging cycles. Therefore, the internal rechargeable
batteries used in the E-series are not included in our general 2-year warranty. There
is a 1 year warranty for the battery capacity not to fall below 70 % (a normal change
means that the battery must have more than 70 % capacity after more than 300 charg-
ing cycles). A2 year warranty applies if the battery becomes unusable because of a
manufacturing fault or factors that Damalini AB could be expected to have control of,
or if the battery displays abnormal loss of capacity in relation to use.
Extended warranty
Easy-Laser® Measurement and Alignment Systems meet the highest quality standards!
For this reason, we have extended the warranty to you to a total of 3 years — free of
charge!
The prerequisite for a warranty extension is that you register your system parts on
the Internet within 6 months of purchase. The warranty period begins on the date of
purchase. The warranty extension applies to all products in accordance with the Easy-
Laser® Warranty requirements.

3
Introduction
Safety precautions
Easy-Laser®is a laser instrument in laser class II
with an output power less than 1 mW, which
requires the following safety precautions:
• Never stare directly into the laser beam
• Never aim the laser beam at anyone else’s eyes.
Note!
Opening the laser units can result in hazardous radiation, and will invalidate the
manufacturer warranty.
If starting the machine to be measured would result in injuries, the possibility to un-
intentionally start it must be disabled before mounting the equipment, for example by
locking the switch in the off position or removing the fuses. These safety precautions
should remain in place until the measurement equipment has been removed from the
machine.
Note!
The system should not be used in explosive risk areas.
Service and calibration
Our Service centres will quickly assist you if your measurement system need to be
repaired or when it is time for calibration.
Our main Service centre is located in Sweden. There are several local Service centres
that are certied to carry out limited service and repair. Contact your local Service
centre rst before sending your equipment for service or repair. All Service centres are
listed on our web site under Service and Calibration.
Before sending your measuring system to our main Service centre, please ll in the
online Service and Repair report. www.easy-laser-service.com
Manuals as PDF
You can download our manuals in pdf format from our website. The pdf’s are also
available on the USB memory stick that is delivered with most systems.
EasyLink
The new version of our database program EasyLink is available on the USB memory
stick that is delivered with most systems. You can always download the latest version
from damalini.com>download>software.

4
Introduction
Travelling with your measurement system
When travelling by airplane with your measurement system we strongly recommend
that you check which rules apply for each airline company. Some companies/countries
have limitations for checked baggage when it comes to items including batteries. For
information about Easy-Laser® batteries, please see system unit details in the end of
this manual. It is also good practice to remove the batteries from the equipment, when
possible, e.g. D22, D23 and D75.
Compatibility
The E-series is not compatible with previous analogue units from the D-series. You can
however continue to use previous brackets.
Disclaimer
Damalini AB and our authorized dealers will take no responsibility for damage to
machines and plant as a result of the use of Easy-Laser®measurement and alignment
systems.
Copyright
© Damalini 2015
We might change and correct the manual in later issues without further information.
Changes to the Easy-Laser®equipment may also affect the accuracy of the informa-
tion.
October 2015
Fredrik Eriksson
Quality Manager, Damalini AB
Damalini AB, PO Box 149, SE-431 22 Mölndal, Sweden
Phone: [phone], E-mail: [email protected]
Web: www.damalini.com

5
DISPLAY UNIT
Navigation buttons
Function buttons
Numeric buttons
LED signals
OK buttons
AConnection for external power.
BNetwork connection. (Not available on all systems.)
CExternal connection. Use for projector for example. (Not available on all systems.)
DUSB A (master). Use for USB memory.
EUSB B (slave). Use for connecting to a PC.
FConnection for Easy-Laser® equipment.
GProtective cover.
Reset the Display unit
Press and hold the On/Off button to reset the Display unit.
A B C D E F
Battery compartment
(Not available on all systems.) G

6
Display unit
Navigation buttons
To navigate on the screen, use the navigation buttons. The selected icon is marked with
a yellow frame. The navigation buttons are also used to move between the icons in a
submenu and to change the values in the elds.
Navigation buttons
Numerical buttons
OK button
Function buttons
OK buttons
There are two green OK buttons and they both work in the same way. Press to
select the currently selected icon for example.
Function buttons
The icons above the function buttons change depending on which view is currently
displayed on screen.
Below is a list of the most common icons.
Back to previous view. Press and hold to leave current program.
Back. There is no “previous view”. Leave the current program.
More. Contains a submenu with general functions,
such as (Control panel) and (Save le).
Submenus
The icons formed as an arrow contain a submenu. Use the navigation buttons to navi-
gate in a submenu. Press to select.
Function button with arrow contains submenu

7
Display unit
Status bar
The Status bar contains additional information such as warning icon, current time and
Bluetooth®connection.
Measurement unit.
Change units via Settings.
The yellow arrow indicates
that there are sub-menus
There are also text messages regarding:
• The selected icon.
• Hints on what information you are expected to ll in.
Status bar icons
Warning. Select the function button to get additional information
regarding the warning.
Warning. Displayed when the coordinates has been rotated in the detector.
Go to Control panel to rotate coordinates.
Hourglass. The Display unit is in the middle of a task.
Display unit charging. Indicating that a power adaptor is plugged in.
Display unit is low in battery.
Measurement progress. Time depending on which lter you have selected.
Selected lter.
Peripheral.
Indicates that a peripheral device is plugged in, such as a projector.
Bluetooth®. Indicates that the Bluetooth®functionality is activated.
The number beside indicates the number of Bluetooth®units connected.
Printing report on thermal printer. The thermal printer is optional equipment.
Printing performed OK.
Printing problem.

8
Display unit
Screen dump
It is possible to take screen dumps of what is currently displayed on screen. You can
e-mail the screen dump or use it for reports.
Take a screen dump
1. Press and hold the numeric button period (.) for 5 seconds.
2. An hour glass is displayed on the status bar.
3. The screen dump is saved in the le system as a .jpg le. It is named with current
date and time. Select to open saved les. See “Measurement le handling”
on page 11.
LED lights
Right indicator
Yellow Flashing: The internal battery in the Display unit is charging.
Left indicator
Left indicator has several functions and colours:
Red/Blue Quick ashing: Reprogramming the system.
Red Flashing: Warning, for example low battery.
Blue Flashing: Searching for detectors equipped with Bluetooth®.
Fixed light: Connected to detectors equipped with Bluetooth®.
Green Flashing: Display unit is starting.
Fixed light: The internal battery in the Display unit is fully charged.
Light blue Flashing: Backlight is off, but the Display unit is still on. Press any
button to activate the Display unit.

9
Display unit
Battery
Select to display the Battery view. This view gives you a good overview of the
battery status of all connected equipment.
Display unit
Dry cell batteries
(not available for all systems)
Detector or
Measuring unit
Serial number
Battery pack
Charging
The E-series is not compatible with units from the D-series.
Note!
When nished working for the day, charge the whole system. Plug in the power adap-
tor to the Display unit and connect the measuring units by using cable.
Charge the Display unit
The Display unit can be used from -10ºC to +50ºC. Charge the Display unit within the
temperature range of ±0ºC to +40ºC.
Note!
If you shut the Display unit off while charging, it will charge faster.
Power adaptor
With the power adaptor plugged in, you can keep on working.
A PC via USB cable
While you have this connection, you can open the les in the Display unit via the
explorer in your PC. However, the Display unit is locked.
Dry cell batteries
When you get a battery warning, insert four R14 dry cell batter-
ies in the battery compartment. This will prolong the power of
the Display unit so that you can nish your measurement. How-
ever, if the internal battery is completely empty, the dry cell
batteries do not have enough power to start up the Display unit.
Charge the Detector/Measuring units
The Detectors and Measuring units are charged by the Display unit when connected by
cable. If you are using Bluetooth®units, switch to cable when the battery in the Detec-
tor/Measuring unit is low.
Charge the Bluetooth®units
The Bluetooth®units are powered by the Detector/Measuring units. To save energy, the
Bluetooth®units will only connect when you are using a measurement program. There
is no power switch on the unit. To switch off, simply unplug the unit.
See “Charge the Display unit” on page 9.
USB

10
Display unit
Calculator
The calculator is found on the Start view and Control panel ( ).
1. Select and to open the calculator.
2. Use the numerical buttons and function buttons to enter values.
3. Use the button to compute.
Select to display sub-menu
Use OK button as equal sign (=)
Unit converter
The unit converter is found on the Start view and Control panel ( ).
1. Select and to open Unit converter.
2. Select a category. Move using the navigation buttons up and down.
3. Press navigation button right. The result column is activated.
4. Select a unit to convert from.
5. Enter an amount. The other units are recalculated.
In the example below, one inch is selected.
Select category
Select unit and amount

11
Display unit
Measurement le handling
Save le
1. Select and to save your measurement.
2. Enter a le name. The date and time will automatically be added to the le name.
The measurements that you save will be available to other users as well.
3. Press to save the le.
File manager
Select (found on the start view and Control panel) to open saved measurements.
The File manager is displayed. Here you can easily when and from which program the
le was saved.
Press to open a measurement le.
Function buttons
Back to previous view.
“Report” on page 14.
“Open le as template” on page 13.
“Print le (Optional)” on page 14.
Sort les alphabetically.
Sort les by measurement program.
Sort by time.
Show all les.
Show only xml les.
Show only pdf les.
Show only jpg les.
Show only Favourites. See “Favourites” on page 12.
“Copy le to USB memory” on page 13.
Delete les. Delete all displayed les or only selected le.
xml
A measurement le.
jpg
“Screen dump” on page 8
PDF
Areport. The PDF report can not be
opened in the Display unit.
PDF is not available for E420.

12
Display unit
Favourites
It is possible to save a measurement as a Favourite. A Favourite can be used for exam-
ple when you have many anges or machines with the same dimensions. This way you
do not have to enter the same distances or tolerances every time. When you have saved
as Favourite, a new icon is displayed on the start screen.
Create a favourite
1. Select to open the File manager and select a le.
2. Select and to save the selected le as a Favourite.
3. Go to the start screen and select to see all favourites.
4. Press to open a Favourite. All distances are lled in.
Import favourites
The favourite les are saved in the folder Favourites in the Display unit.
1. Plug in the Display unit to a PC and open the Favourites folder.
2. Copy the .FAV (favourite) le to the root of an USB memory stick.
3. Connect the USB stick to a Display unit and select and to import.
Delete favourite
1. Select to open the File manager and select a le.
2. Select and to show all Favourite les.
3. Select a le and .
Show Favourite
Import Favourites
from USB
Create Favourite

13
Display unit
Open le as template
You can open a saved measurement and use it to make a new measurement. This is
very useful when you have many anges or machines with the same dimensions for
example. This way you do not have to enter the same distances every time.
1. Select (found on the Start view and Control panel). The File manager is
displayed.
2. Select a le in the list and select . The Edit distance view is displayed.
3. Change distances if needed and proceed to measuring view.
Copy le to USB memory
You can easily copy a saved measurement or other les to a USB memory.
1. Insert a USB memory.
2. Select the le you want and select .
3. A folder is automatically created on the USB memory. The le is saved in the
folder \Damalini\archive\.
Barcode
Save le with barcode
The barcode scanner is not included in all systems. The rst time you measure a
machine, you stick a barcode on the machine and save the measurement together with
the scanned barcode. Next time you align the same machine, all you need to do is scan
the barcode and all machine data is read.
1. Scan the barcode on the machine.
2. Enter a le name.
3. Press to save the le. All measurement
data is saved together with the barcode.
The barcode number is added to the le name.
When you connect the Display unit to a PC the whole le name is shown:
Open le with barcode
• Start the Display unit and scan the barcode. The latest measurement that was
made and saved with this barcode is automatically opened.
OR
• Select to open File view. Scan the barcode on the machine. All measure-
ments saved with this barcode are shown.
File name
Barcode number
File name Barcode numberDate and time User Barcode reader

14
Display unit
Print le (Optional)
Part no. 03-1004
The thermal printer is optional equipment.
1. Save the measurement. To print from a Shaft program, you need to
open a saved measurement before you can print a report.
2. Connect the thermal printer and select and .
3. The progress is displayed on the status bar.
Printing report on thermal printer.
Printing performed OK.
Printing problem.
You can also save a measurement, download the pdf-report to your PC and print the
pdf-report.
Report
A report is generated and saved in the ling system. You can not open an old mea-
surement and save it again (program Machine train is an exception to this). You can
however generate a new report from an opened le. This means you can for example
change the language and make a new report from the opened measurement. You can
download the report to a PC and print it.
Company logo
You can replace the logo on the report with your own .jpg le.
1. Name your logo logo.jpg. The default logo has the proportions of 230x51
pixels.
2. Connect the Display unit to your PC using the USB-cable.
3. Place your image in the Display unit’s folder Damalini/custom/reports/
logo.
File extensions (for example .jpg) are often hidden in the Explorer window. To dis-
play le extensions do the following: Open an Explorer window and press Alt to show
menu. Select Tools > Folder options. Click the View tab > Advanced settings > Clear
the Hide extensions for known le types check box.
Date format
By default, the date and time format is set to Central European Time (CET).
You can change the date and time format used in your PDF reports.
See “Date and time” on page 16.
Download le to PC
1. Start the Display unit.
2. Connect the USB cable between the Display unit and PC.
3. While you have this connection, the Display unit is blocked.
4. View and/or copy the les to the PC.
EasyLink
You can also use our database program EasyLink to view the les on your PC.
EasyLink is available on the USB memory stick that is delivered with
most systems. You can always download the latest version from damalini.
com>download>software.

15
Display unit
Control panel
Select and to open the Control panel. Some of the settings are personal
and will be default next time you start the system.
Filter
Select to open the Filter view.
The lter you select on the Filter view will be saved as a personal setting.
If the laser beam passes through air with varying temperature, this may inuence the
direction of the laser beam. If measurement values uctuate, this could mean unstable
readings. Try to reduce air movements between laser and detector by, for instance,
moving heat sources, closing doors. If the readings remain unstable, increase the lter
value (more samples will become available to the statistical lter).
Selected lterMeasurement progress. Time is depending on
which lter you have selected.
Select lter
Use as short a time as possible that still produces acceptable stability
during the measurement. Default is set to 1. Normally you will use a
lter value of 1-3. If you set the lter type to 0, no lter will be used.
Use the numerical buttons 3, 6 and 9 to set the lter. In the Filter view
but also when you are using a measuring program.
Note!
All settings are not available
for all systems.
Use numerical buttons to select lter
Current noise level in
the system before and
after ltering
Currently selected lter
Use numerical but-
tons to set lter.
Button 6 will restart
the lter
Graph shows ltered
noise level over time
Press function button 6
to test how long the mea-
surement progress is

16
Display unit
Unit and resolution
Personal setting
Select to open the Units and resolution view. Use the navigation buttons to
move between the elds. Set Metric or Imperial and which resolution you want to use.
Default is set to 0.01 mm (0.4 mil). The selected unit is shown on the Status bar.
Note!
It is possible to select 0.0001mm only in
the E940 system.
For E420, only 0.01mm is possible.
Detector rotation
Personal setting
The coordinate system can be rotated 90º. Select to open the Detector rotation
view. When you have rotated the coordinates, a warning is displayed on the Status bar.
Detector rotation will only affect detectors with two axis.
Detector rotation view
Date and time
Select to open the Date and Time view. Set the date and time. Default is set to
Central European Time. (CET)
Date and time view
Select to set the date format used in your PDF reports.
Date and time used in PDF reports
Warning displayed on
Status bar
