Introduction
Introduction
Introduction
Introduction
Congratulations with your xLogic SuperRelay provided by Easy Electronic Co., Ltd.
The xLogic SuperRelay is a compact and expandable CPU replacing mini PLCs, multiple timers,
relays and counters.
The xLogic SuperRelay perfectly fits in the space between timing relays and low-end PLCs. Each
CPU incorporates not only a real-time clock and calendar, but also provides support for optional
expansion I/O modules to enhance control and monitoring applications. Data adjustments can
easily be performed via the keypad, the LCD display, or through the easy-to-use xLogic soft.
DIN-rail and panel - mounted options are both are available, offering full flexibility to the various
installation needs of your application.
The xLogic SuperRelay is available in 120V/240V AC or 12V and 24V DC versions, making it the
ideal solution for relay replacement, or simple control applications as building and parking lot
lighting, managing automatic lighting, access control, watering systems, pump control,
ventilation systems, home automation and a wide field of other applications demanding low
cost to be a primary design issue.
We strongly recommended taking the time to read this manual, before putting the xLogic
SuperRelay to work. Installation, programming and use of the unit are detailed in this manual.
The feature-rich xLogic SuperRelay provides a for off-line operation mode, allowing full
configuration and testing prior to in-field service commissioning. In reviewing this manual you
will discover many additional advantageous product properties, it will greatly simplify and
optimize the use of your xLogic SuperRelay.
