Dear Customer,
ThankyouforpurchasingtheLawnLeafSweeper.
Rakingleavesoffthelawnisoneofthoseback-achingjobsthatseemstolastallautumn.
WhichiswhyyouneedthissuperLeafSweeper.Notmotorised,sothere’snonoise,petrol
fumesortrailingelectriccables,youjustgentlypushitalongandstrollbehind.Revolving
brushesmadefromtoughnylonwhiskleaves,twigs,grassandothergardendebrisintothe
roomycollectingbag,readyforcompostingormulching.Suitableforanysizelawn,theheight
ofthebrushesadjuststothreedifferentheightssoitworksjustaswellonpaths,drives,
eventenniscourts.OnesatisedownerusedtheLawnLeafSweeperonhishotelcarpark!
Ruggedlymadefromsteelandplastic,it’slightandmanoeuvrable.
PARTS
Beforeyoubeginassembly,ensureyouhaveallpartslistedbelow.
Part Description Quantity
a Handlebar 1
b Handle support 2
c Handle connector 2
d Hopper crossbar 1
 e M5washer 4
 g Hopperbag 1
 h Hopperframesiderod 2
i Hopper frame base rod 1
 j Topframeconnector 1
 k Hopperframeconnectorright 1
l Hopper frame connector left 1
 m Sweeperbody 1
 n Brushes 8
 p Supportlegright 1
 q Supportlegleft 1
 r M5lockingnut 6
s M5 x30mm bolt 6
 u 4mmx3quarterinchscrew 8
ASSEMBLY
1. Attachthehandlesupports(b)tothehandlebar
(a)usinghandleconnectors(c),2xM5bolt(s)
and2xM5lockingnut(r).
2. Attachassembledhandlesectiontothe
sweeperbody(m)byinserting4xM5
bolts(s)fromtheinsideofthesweeper
body,throughtheholesonthebottom
ontheassembledhandlesectionand
securingusingM5washers(e)andM5
lockingnuts(r).
3. Attachedleftandrightsupportslegs(p&q)tothesweeperbody(m)andsecureusing4mmx3/4in
screws(u).
4. Inserthopperframesiderod(h)intothesleevetop
cornerofthehopperbag(g)withthethreadedend
rst.Repeatfortheotherside.
Paperweight60gsm
everyday solutions
™
Est. 1992

Support Line: 0844 441 8448
For more innovative products from Easylife please visit:
www.easylifegroup.com
everyday solutions
™
Est. 1992
8. Presstogethertheholesandpinsatthetopofthebrushes(n)toform4sets.
9. Holdtheassembledbrushsetstogetherandslideeachsetintothegroovesontherotoruntileach
setclicksintoplace.Slotcanbewidenedbylooseningcentralscrew,ensurethisisre-tightened
after insertion.
10.Cliptheassembledhopperintopositiononthehandleandslottheconnectorsintotherecesseson
thesweeperbody(m).
5. Insertthehopperframebaserod(i)intothe
sleeveonthebottomofthehopperbag(g).
6. Connectthehopperframesiderods(h)togetherusingtop
frameconnector(j).Connectthehopperframebaserod(i)to
theassembledframebyconnectinghopperframeconnector
right(k)andthreadedendofhopperframeconnectorleft(l)
tothethreadedendsofthehopperframesiderods(h).
Connectbothconnectorstothehopperframebaserod(i)
ensuringtheshorterhorizontalttingontheconnectorsare
facingoutwards.
7. Attachthehoppercrossbar(d)tothehandleandassembledhopperensuringthehopperrods
andthehandleclicksecurelyintoplacewiththeclipsonthehoppercrossbar(d).Ensurethisis
ttedcorrectlywiththehopperrodsclippingintothehoppercrossbar(b)fromabove.Ifassembled
incorrectly,thehoppercandetachduringuse.

Support Line: 0844 441 8448
For more innovative products from Easylife please visit:
www.easylifegroup.com
everyday solutions
™
Est. 1992
WARNING (continued)
• DoNOTuseonsteepslopes.
• WhenusingonaslopealwayspushtheLeafSweeperacrossthesloperatherthanupordown
theslope.
• DoNOTuseifdamaged.
• DoNOTusetosweepupliquids.
• DoNOTattempttorepairtheLeafSweeperyourself.
• Adjustthebrushheightifthebrushesjamfrequentlyorifthesweepingperformanceisreduced.
• Notrecommendedforuseonlonggrassoverapprox.6cm(21/2in)inlength.
• Afteranextendedperiodwithoutuse,checkallxingsaresecureandcheckallmovingpartsand
lubricate if necessary.
BEFORE USE
• Adjusttheheightoftheleafsweepingbrushestothedesiredlevel.
 -Thelowersettingsaresuitableforallsurfaces
 -Themiddlesettingsforwet,slipperyorroughandloosesurfaces
 -ThehighersettingsformaintenanceandmovingtheLeafSweeper.
• Tosettothedesiredheight,loosentheknobonthefrontofthesweeperbodyandafteradjustingto
thedesiredheight,re-tightentheknobsecurely.
• Alwayscheckthatthenuts,bolts&screwsaresecureandtightenifnecessary.
• Ensuretheareatobesweptisclearofobstructionsbeforeuse.
• Afteranextendedperiodwithoutuse,checkallxingsaresecureandcheckallmovingpartsand
lubricate if necessary.
DURING USE
• Takecaretoavoidinjurytongerswhenadjustingthemachine.
• Takeextracarewhenchangingdirectionorworkingonaslope.
• Keepthemachineuprightatalltimes.
• DoNOTapplyheavydownwardforcewhenoperating.Thiswillcausegreaterfrictiontotheground
andmaycausedamagetothebrushes.
• Wherepossible,operatedownwind.
AFTER USE
• Emptyleafcollectionbag.
• Cleanafteruse.
• Allowleafcollectionbagtodrybeforere-attaching.
• Storeinacool,dryplace.
CLEANING
• Brushescanberemovedforcleaningandre-ttedaspertheassemblyinstructions.
• Wipethehoppercleanwithasoftdampcloth.
• Periodicallybrushanyleafdebrisormudfromaroundthewheelstopreventthemlocking.
WARNING
• Wearsuitableeyeprotectionduringuse.
• Wearsuitableoutdoorfootwear.
• Foroutdooruseonly.
• Keepawayfromchildren.
• Ensureworkareaisclearofobstructionsbeforeuse.
• DoNOTrunwiththeleafsweeperwheninuse.
• Alwayspushinastraightlineinaforwarddirection.
