1.Introduction
E78-TBL-01 is a test kit specially designed for E78 series SMD SOC modules, combined with
USB to TTL serial port backplane. E78-TBL-01 leads all the pins of E78-400M22S for customer
testing and development, which greatly reduces the difficulty of customer testing and development.

Chengdu Ebyte Electronic Technology Co., Ltd. E78-TBL-01 User Manual
Copyright ©2012–2021, Chengdu Ebyte Electronic Technology Co., Ltd.
4
2 Pin Definition
Pin number
definition
Function Description
1
5V
5V network on the backplane
2
VCC
Module power input
3
3.3V
3.3V network on the bottom board, which can be
shorted with VCC with jumper cap for module
power input
4
GND
Floor reference ground
5
VCC
Module power input
6
SETB
Module MCU GPIO
7
DIO1
Module multi-purpose digital IO, cannot be used as
external GPIO
8
BUSY
Module SPI busy indicator, cannot be used as
external GPIO
9
I2C_SDA
Module I2C SCL pin
10
I2C_SCL
Module I2C SDA pin
11
UART_CTS
Module UART CTS pin
12
UART_RTS
Module UART RTS pin
13
XRES
Module external reset pin
14
ADC_IN
Module ADC input pin
15
AUX
Module MCU GPIO
16
SETA
Module MCU GPIO
17
UART_RX
Module UART RX pin
18
UART_TX
Module UART TX pin
19
SWD_DATA
Module SWD Data pin
20
SWD_CLK
Module SWD Clock pin
21
GND
Ground
22
GND
Ground
23
GND
Ground
24
GND
Ground

Chengdu Ebyte Electronic Technology Co., Ltd. E78-TBL-01 User Manual
Copyright ©2012–2021, Chengdu Ebyte Electronic Technology Co., Ltd.
5
3 Quick Test
3.1 Driver Installation
Download CH341SER.EXE and install it on your computer.
This driver supports 32/64Windows10/8.1/8/7/VISTA/XP, SERVER2016/2012/2008/2003,
2000/ME/98. This program has passed Microsoft digital signature authentication, and supports USB
to 3-wire and 9-wire serial ports.
3.2 Hardware Connection
Please prepare the Micro USB cable and antenna, connect them to E78-TBL-01, and open the
corresponding serial port.
As shown in the picture, plug in the jumper cap and select 3.3V power supply to power the module.
Both E78-TBL-01 are configured in this way. Open the corresponding serial port to send and
receive data.
