Echo Power Pruner PP-1200 User manual

Power PrunerTM
Operator's Manual
MODEL: 99946400023 4' EXTENSION
FOR MODELS PP-1200/1250/1260
PPT-2100/2400
PPT-230/231
PPT-260/261
PPT-265/265H/265S
PPT-266/266H
PPT-280
X767000212
04/12
X7672300102
ENGLISH
FRANCAIS
ESPAñOL
WARNING
Users of this equipment risk injury to themselves and others if the unit is used improp-
erly and/or safety precautions are not followed. ECHO provides an operator’s manual
and a safety manual. Both must be read and understood for proper and safe operation.
Failure to do so could result in serious injury.

2
4foot eXtension installation
Parts Required: 1220mm (4 Foot) Extension
WARNING
The Saw Chain is sharp! Always wear gloves when handling the
cutting attachment, otherwise serious personal injury may result.
1. Loosen the two (2) screws (A), and locator screw (B) on cutting
attachment, and remove the cutting attachment.
2. Loosen clamp knob (C) turning counter clockwise.
3. Pullaluminumhousing(D)outofberglasshousing610mm(24
in.),thenslide(D)backintoberglasshousingapproximately
305mm (12 in.) exposing inner drive shaft (E).
4. Loosen the extension clamp knob (F) turning counter clockwise.
5. Align inner drive shaft adapter (G) with extension shaft (H).
NOTE
Assure locator hole in extension shaft is oriented on same side as
locator hole in aluminum housing (D).
6. Alignridgesonaluminumhousing(D)withgroovesinextension
clamp.
7. Slide extension clamp onto aluminum housing (D) until
extension stops.
8. Tighten extension clamp knob (F) securely.
G
H
D
D
B
a
F
F
C
C
D
D
D
12 in.
E
F
G

4' ExtEnsion AttAchmEnt
opErAtor'smAnuAl 3
9. Align extension drive shaft adapter (J) with cutting attachment
shaft (K).
NOTE
Locator screw in cutting attachment must align with locator hole
(L) in extension housing (M).
10. Align ridges on aluminum extension housing (M) with seams in
cutting attachment and slide cutting attachment onto extension
housing. Remove locator screw (B) to align locating hole in cutting
attachment with locating hole (L) in aluminum extension housing.
11. Install and tighten locator screw (B). Tighten two (2) cutting at-
tachment screws (A).
J
K
M
WARNING
• ThePowerPrunerTM is designed to accept only one extension. Use of more than one extension or longer shafts can
result in balance and control problems leading to possible personal injury to operator and bystanders and/or unit
damage.
• UsethisextensionwithECHOPowerPrunerTMmodelsONLY.
B
a
Ml
M
4' Extension Safety Label

eCho ConsuMer proDuCt support
If you require assistance or have questions concerning the application, operation or maintenance of this product you may
calltheECHOConsumerProductSupportDepartmentat1-800-673-1558from8:30amto4:30pm(CentralStandardTime)
Monday through Friday. Before calling, please know the model and serial number of your unit to help your Consumer Prod-
uct Support Representative.
ECHO, Incorporated 400 oakwood road
lake Zurich, il 60047
www.echo-usa.com
Copyright© 2012 By Echo, Incorporated
All Rights Reserved.
