Echo SRM - 211SB User manual

X7712092900
© 03/2017 ECHO Inc.
ENGLISH
Operator’s Manual
Specifications, descriptions and illustrative material in this literature are
as accurate as known at the time of publication, but are subject to
change without notice. Illustrations may include optional equipment and
accessories, and may not include all standard equipment.
99944200536
3 Ft. Extension
Attachment
FOR MODELS: SRM-2100SB, 2400SB, 210SB, 211SB, 225SB, 260SB,
261SB, PAS-2100, 2400, 2601, 210, 211, 225, 225VP, 225VPB, 230, 231,
260, 261, 265, 266, 2620
For use with Power Pruner®, Hedge Trimmer, and Articulating Hedge
Trimmer attachments only.
Users of this equipment risk injury to them-
selvesandothersiftheunitis usedimproperly
and/or safety precautions are not followed.
ECHO provides an operator’s manual and a
safety manual. Both must be read and understood for
proper and safe operation. Failure to do so could result in
serious injury.

TABLE OF CONTENTS 99944200536
2 X7712092900
© 03/2017 ECHO Inc.
TABLE OF CONTENTS
Description .................................................................................................. 3
Contents...................................................................................................... 3
Assembly..................................................................................................... 4
3 Ft. Extension Installation................................................................... 4
Specifications.............................................................................................. 5
Product Registration.................................................................................... 6

99944200536 DESCRIPTION
X7712092900 3
© 03/2017 ECHO Inc.
ENGLISH
DESCRIPTION
Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and
that you understand and follow the instructions on it. If a decal cannot be
read, a new one can be ordered from your ECHO dealer.
CONTENTS
The ECHO product you purchased has been factory pre-assembled for your
convenience. Due to packaging restrictions, some assembly may be
necessary.
After opening the carton, check for damage. Immediately notify your retailer
or ECHO Dealer of damaged or missing parts. Use the contents list to check
for missing parts.
1. LEFT HAND SHAFT GRIP - Cushioned grip for left hand.
2. DRIVE SHAFT ASSEMBLY - Lightweight aluminum drive shaft
extends reach.
3. COUPLER
____1 3 ft. (914.4 mm) Extension Attachment
____1 Storage Hook Assembly
____1 Operator’s Manual
1
2
3
15 M - 50 FT

ASSEMBLY 99944200536
4 X7712092900
© 03/2017 ECHO Inc.
ASSEMBLY
3 Ft. Extension Installation
The Pro Attachment Series is designed to accept only one ex-
tension. Use of more than one extension can result in balance
and control problems leading to possible personal injury to op-
erator and bystanders and/or unit damage. Use this extension
with ECHO Pro Attachment Series models ONLY.
1. Pull locater pin (A) on PAS
power source, and turn counter
clockwise ¼ turn to lockout
position. Loosen clamping knob
(B) and remove attachment
from power source.
2. Remove storage hook assem-
bly from the extension.
3. Carefully fit extension drive
shaft assembly into power
source coupler (C) to decal
assembly line (D), making sure
that the inner lower drive shaft
engages into the square upper
drive shaft socket.
Note: Your coupler may appear different than the coupler shown.
4. Rotate locater pin on power source coupler (A) ¼ turn clockwise to
engage drive shaft hole. Insure locater pin is fully engaged by twisting
lower drive shaft. Locater pin should snap flush in coupler. Full engage-
ment will prevent further shaft rotation.
5. Secure extension to coupler by tightening clamping knob (B).
C
A
B
B
D

99944200536 SPECIFICATIONS
X7712092900 5
© 03/2017 ECHO Inc.
ENGLISH
6. Pull locater pin (E) on extension
and turn counter clockwise ¼
turn to lockout position.
7. Carefully fit attachment drive
shaft assembly into extension
coupler (F) to decal assembly
line (G), making sure that the
inner lower drive shaft engages
into the square upper drive
shaft socket.
8. Rotate locater pin (E) on exten-
sion coupler (F) ¼ turn clock-
wise to engage drive shaft hole.
Insure locater pin is fully
engaged by twisting lower drive
shaft. Locater pin should snap
flush in coupler. Full engage-
ment will prevent further shaft
rotation.
9. Secure attachment to extension
by tightening clamping knob
(H).
SPECIFICATIONS
MODEL 999442004536
Length 995 mm (39.2 in.)
Width 81 mm (3.2 in.)
Weight 1.21 kg (2.66 lb.)
Drive Shaft 0.25 in. (6.35 mm) Flexible Shaft
Coupler Aluminum die case with plastic knob and insertion
guide lip
Handle Foamed Rubber Grip
F
E
H
H
G

PRODUCT REGISTRATION 99944200536
6 X7712092900
© 03/2017 ECHO Inc.
PRODUCT REGISTRATION
Thank you for choosing ECHO Power Equipment
Please go to http://www.echo-usa.com/Warranty/Register-Your-ECHO to
register your new product on-line. It's FAST and EASY! NOTE: your
information will never be sold or misused by ECHO, Inc. Registering your
purchase enables us to contact you in the unlikely event of a service update
or product recall, and verifies your ownership for warranty consideration.
If you do not have access to the Internet, you can complete the form below
and mail to:
ECHO Inc., Product Registration, PO Box 1139, Lake Zurich IL 60047.

99944200536 PRODUCT REGISTRATION
X7712092900 7
© 03/2017 ECHO Inc.
ENGLISH

ECHO, INCORPORATED
400 Oakwood Road
Lake Zurich, IL 60047
www.echo-usa.com
