Echo SRM - 2400SB User manual

X7532093907
© 1/2017 ECHO Inc.
ENGLISH
Operator’s Manual
Specifications, descriptions and illustrative material in this literature are
as accurate as known at the time of publication, but are subject to
change without notice. Illustrations may include optional equipment and
accessories, and may not include all standard equipment.
99944200620
ProPaddleTM Attachment
FOR MODELS: SRM-2400SB, 260SB, 261SB, PAS-2400,
2601, 230, 231, 260, 261, 265, 266, 280, 2620
Users of this equipment risk injury to themselves and
others if the unit is used improperly and/or safety
precautions are not followed. ECHO provides an
operator’s manual. It must be read and understood
for proper and safe operation. Failure to do so could
result in serious injury.

TABLE OF CONTENTS 99944200620
2 X7532093907
© 1/2017 ECHO Inc.
TABLE OF CONTENTS
Introduction ................................................................................................. 3
The Operator’s Manual ........................................................................ 3
Servicing Information.................................................................................. 3
Parts/Serial Number ............................................................................ 3
Service................................................................................................. 3
Echo Consumer Product Support........................................................ 4
Product Registration ............................................................................ 4
Additional or Replacement Manuals.................................................... 4
Safety.......................................................................................................... 4
Manual Safety Symbols and Important Information............................. 4
International Symbols.......................................................................... 5
Personal Condition and Safety Equipment .......................................... 6
Equipment.......................................................................................... 11
Description................................................................................................ 12
Contents.................................................................................................... 13
Assembly................................................................................................... 13
ProPaddle Gear Housing to Lower Drive Shaft Assembly................. 13
ProPaddle Sweeper Drum Assembly................................................. 14
Power Head Shaft/Lower Shaft Assembly ......................................... 15
Operation .................................................................................................. 17
Break-In ............................................................................................. 17
Sweeping Operation .......................................................................... 17
Maintenance ............................................................................................ 19
Skill Levels......................................................................................... 19
Maintenance Intervals........................................................................ 20
Lubrication ......................................................................................... 20
Gear Case ......................................................................................... 22
Storage...................................................................................................... 23
Storage Hook Installation................................................................... 24
Specifications............................................................................................ 25
Product Registration.................................................................................. 26

99944200620 INTRODUCTION
X7532093907 3
© 1/2017 ECHO Inc.
ENGLISH
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and
manufactured to provide long life and on-the-job dependability. Read and
understand this manual. You will find it easy to use and full of helpful
operating tips and SAFETY messages.
The Operator’s Manual
Keep it in a safe place for future reference. Contains specifications and
information for safety, operation, maintenance, storage and assembly
specific to this product. Scan QR codes throughout the operator’s manual
for more information.
SERVICING INFORMATION
Parts/Serial Number
Genuine ECHO Parts and
Assemblies for your ECHO products
are available only from an Authorized
ECHO Dealer. When you do need to
buy parts always have the Model
Number and Serial Number of the
unit with you. For future reference
write them in the space provided
below.
Model No. _________________
Serial No. _________________
Service
Service of this product during the
warranty period must be performed by an Authorized ECHO Service Dealer.
For the name and address of the Authorized ECHO Service Dealer nearest
you, ask your retailer or call:
1-800-432-ECHO (3246). Dealer information is also available on our Web
Site. www.echo-usa.com. When presenting your unit for Warranty service/
repairs, proof of purchase is required.

SAFETY 99944200620
4 X7532093907
© 1/2017 ECHO Inc.
Echo Consumer Product Support
If you require assistance or have questions concerning the application,
operation, or maintenance of this product, call the ECHO Consumer
Product Support Department at 1-800-673-1558 from 8:00 am to 5:00 pm
(Central Standard Time) Monday through Friday. Before calling, please
know the model and serial number of your unit.
Product Registration
Register your ECHO equipment on-line at www.echo-usa.com or by filling
out the product registration sheet included in this manual. Registering your
product confirms warranty coverage and provides a direct link to ECHO if
we find it necessary to contact you.
Additional or Replacement Manuals
Replacement Operator or Safety Manuals, and Parts
Catalogs, are available from your Authorized ECHO
Service Dealer, or at www.echo-usa.com, or by contacting
ECHO Inc., 400 Oakwood Road, Lake Zurich, IL 60047
(800-673-1558). Always check www.echo-usa.com for
updated information.
Safety Videos are available from your Authorized ECHO Service Dealer. A
$5.00 shipping charge is required for each video.
SAFETY
Manual Safety Symbols and Important Information
Throughout this manual and on the product itself, you will find safety alerts
and helpful, informational messages preceded by symbols or key words.
The following is an explanation of those symbols and key words and what
they mean to you.
The safety alert symbol accompanied by the word “DANGER”
calls attention to an act or condition which WILL lead to serious
personal injury or death if not avoided.

99944200620 SAFETY
X7532093907 5
© 1/2017 ECHO Inc.
ENGLISH
The safety alert symbol accompanied by the word “WARNING”
calls attention to an act or condition which CAN lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “CAUTION”
calls attention to an act or condition which may lead to minor or
moderate personal injury if not avoided.
The enclosed message provides information necessary for the
protection of the unit.
Note: This enclosed message provides tips for use, care and
maintenance of the unit.
CIRCLE AND SLASH SYMBOL
This symbol means the specific action shown is prohibited.
Ignoring these prohibitions can result in serious or fatal injury.
International Symbols
Symbol Description Symbol Description
Warning, see
Operator’s Manual. Safety/Alert
Wear eye, ear and
head protection. Finger Severing
Wear hand
and foot protection. Rotating Cutting Attachment
Wear face shield. Wear slip resistant
foot wear.

SAFETY 99944200620
6 X7532093907
© 1/2017 ECHO Inc.
Personal Condition and Safety Equipment
Users of this product risk injury to themselves and others if the
unit is used improperly and/or safety precautions are not
followed. Proper clothing and safety gear must be worn when
operating unit.
Physical Condition
Your judgment and physical dexterity may not be good:
• If you are tired or sick.
• If you are taking medication.
Keep feet away from
blade.
Do not operate
closer than 15 m
(50 ft.) from
electrical hazards.
Keep bystanders at
least 15 m (50 ft.)
away.
DO NOT USE
BLADES - Line Head
Only Thrown Objects
Plan retreat path from
falling objects. Hot Surface
AVOID KICKOUT
Keep bystanders at least 15 m (50 ft.)
away.
Beware of thrown objects, wear eye
protection.
Keep bystanders and helpers at least
15 m (50 ft.) away.
Symbol Description Symbol Description

99944200620 SAFETY
X7532093907 7
© 1/2017 ECHO Inc.
ENGLISH
• If you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
◆Eye protection that meets ANSI Z87.1 or CE requirements
must be worn whenever you operate the unit.
◆For additional safety, a full-face shield may be worn over
safety glasses or goggles to provide protection from sharp
branches or flying debris.
Hand Protection
Wear sturdy, no-slip, rubber work gloves to improve your grip on the
handles. Gloves also provide protection against cuts and scratches, cold
environments, and reduce the transmission of machine vibration to your
hands.
Hearing/Ear Protection
ECHO recommends wearing hearing protection whenever unit is used.
Breathing Protection
Operators who are sensitive to dust or other common airborne allergens
may need to wear a dust mask to prevent inhaling these materials while
operating unit. Dust masks can provide protection against dust, plant debris,
and other plant matter such as pollen. Make sure the mask does not impair
your vision, and replace the mask as needed to prevent air restrictions.
Proper Clothing
Wear snug-fitting, durable clothing:
• Pants should have long legs, shirts should have long sleeves.
• DO NOT WEAR SHORTS.
• DO NOT WEAR TIES, SCARVES, JEWELRY, or clothing with loose or
hanging items that could become entangled in moving parts or
surrounding growth.
• Keep clothing buttoned or zipped, and keep shirt tails tucked in.
Wear sturdy work shoes with nonskid rubber soles:
• DO NOT WEAR OPEN TOED SHOES.

SAFETY 99944200620
8 X7532093907
© 1/2017 ECHO Inc.
• DO NOT OPERATE UNIT BAREFOOTED.
Keep long hair away from engine and air intake. Retain hair with cap or net.
Heavy protective clothing can increase operator fatigue, which may lead to
heat stroke. Schedule heavy work for early morning or late afternoon hours
when temperatures are cooler.
The components of this machine generate an electromagnetic
field during operation, which may interfere with some
pacemakers. To reduce the risk of serious or fatal injury,
persons with pacemakers should consult with their physician
and the pacemaker manufacturer before operating this
machine. In the absence of such information, ECHO does not
recommend the use of this machine by anyone who has a
pacemaker.
Extended Operation / Extreme Conditions
Prolonged exposure to cold and/or vibration may result in
injury. Read and follow all safety and operation instructions to
minimize risk of injury. Failure to follow instructions may result
in painful wrist/hand/arm injuries.
It is believed that a condition called Raynaud’s Phenomenon, which affects
the fingers of certain individuals, may be brought about by exposure to
vibration and cold. Exposure to vibration and cold may cause tingling and
burning sensations, followed by loss of color and numbness in the fingers.
The following precautions are strongly recommended, because the
minimum exposure, which might trigger the ailment, is unknown.

99944200620 SAFETY
X7532093907 9
© 1/2017 ECHO Inc.
ENGLISH
• Keep your body warm, especially the
head, neck, feet, ankles, hands, and
wrists.
• Maintain good blood circulation by
performing vigorous arm exercises
during frequent work breaks, and also
by not smoking.
• Limit the hours of operation. Try to fill
each day with jobs where operating the
unit or other hand-held power
equipment is not required.
• If you experience discomfort, redness,
and swelling of the fingers followed by whitening and loss of feeling,
consult your physician before further exposing yourself to cold and
vibration.
Repetitive Stress Injuries (RSI)
It is believed that overusing the muscles
and tendons of the fingers, hands, arms,
and shoulders may cause soreness,
swelling, numbness, weakness, and
extreme pain in those areas. Certain
repetitive hand activities may put you at a
high risk for developing a Repetitive
Stress Injury (RSI). An extreme RSI
condition is Carpal Tunnel Syndrome
(CTS), which could occur when your wrist
swells and squeezes a vital nerve that
runs through the area. Some believe that
prolonged exposure to vibration may
contribute to CTS. CTS can cause severe
pain for months or even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended, or twisted position. Instead try
to maintain a straight wrist position. Also, when grasping, use your whole
hand, not just the thumb and index finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitive movement.
• Do exercises to strengthen the hand and arm muscles.

SAFETY 99944200620
10 X7532093907
© 1/2017 ECHO Inc.
• Immediately stop using all power equipment and consult a doctor if you
feel tingling, numbness, or pain in the fingers, hands, wrists, or arms. The
sooner RSI/CTS is diagnosed, the more likely permanent nerve and
muscle damage can be prevented.
All over head electrical conductors and communications wires
can have electricity flow with high voltages. This unit is not
insulated against electrical current. Never touch wires directly
or indirectly, otherwise serious injury or death may result.
Do not operate this product indoors or in inadequately
ventilatedareas.Engineexhaustcontainspoisonousemissions
and can cause serious injury or death.
Read the Manuals
• Provide all users of this equipment with the Operator’s Manual and Safety
Manual for instructions on Safe Operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and animals
prevented from coming nearer than 15 m (50 ft.) while the unit is in use.
Keep a Firm Grip
• Always hold throttle handle and support handle with thumbs and fingers
tightly encircling the handles.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on ladders.
Do not over reach.
Avoid Hot Surfaces
• During operation, the drive shaft
housing and attachment bearing
housing may become very hot,
too hot to touch. Avoid contact
during and immediately after
operation.

99944200620 SAFETY
X7532093907 11
© 1/2017 ECHO Inc.
ENGLISH
Equipment
Use this attachment with ECHO approved models only. Serious
injury may result from the use of this attachment combined with
a non approved ECHO product.
• Check unit for loose/missing nuts, bolts, and screws. Tighten and/or
replace as needed.
• Inspect ProPaddle sweeper drums for damage and that they are firmly
secured in place. Replace paddles of damaged or worn excessively.
• Check that the ProPaddle attachment is firmly attached and in safe
operating condition.
Note: ECHO, INC. will not be responsible for the failure of cutting
devices, attachments or accessories which have not been
tested and approved by ECHO.
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothing and loose objects away from all openings.
◆ALWAYS stop engine, disconnect spark plug, and make
sure all moving parts have come to a complete stop before
removing obstructions, clearing debris, or servicing unit.
◆DO NOT start or operate unit unless all guards and
protective covers are properly assembled to unit.
◆NEVER reach into any opening while the engine is running.
Moving parts may not be visible through openings.

DESCRIPTION 99944200620
12 X7532093907
© 1/2017 ECHO Inc.
DESCRIPTION
Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and
that you understand and follow the instructions on it. If a decal cannot be
read, a new one can be ordered from your ECHO dealer.
1. PROPADDLE SWEEPER DRUM ASSEMBLIES - Replaceable 12-fin
rubber paddles provide efficient cleaning action on a wide variety of
surfaces. Drums may be switched from side to side to help extend
paddle life.
2. LOWER DRIVE SHAFT ASSEMBLY - Contains flexible drive cable,
outer shaft housing, safety decal, model/serial number/coupling
alignment decal, and protective cap for storage.
3. SAFETY DECAL - Provides important safety information that must be
followed.
4. MODEL LABEL - Provides model number and serial number of
ProPaddle attachment. Use this information to fill out warranty
registration card.
1
1
2
34
5
6
7

99944200620 CONTENTS
X7532093907 13
© 1/2017 ECHO Inc.
ENGLISH
5. FLEXIBLE DRIVE CABLE - Cable end fits into drive shaft coupler of
Pro Attachment Series or Split Boom models. Lubricate drive cable
every 25 hours of use with Echo Lube or high temperature automotive
grease.
6. TUBE PROTECTOR - Reversible rubber sleeve protects lower
driveshaft housing from wear.
7. PROPADDLE GEAR HOUSING ASSEMBLY - Sealed gear housing
provides maintenance-free operation.
CONTENTS
The ECHO product you purchased has been factory pre-assembled for your
convenience. Due to packaging restrictions, some assembly may be
necessary.
After opening the carton, check for damage. Immediately notify your retailer
or ECHO Dealer of damaged or missing parts. Use the contents list to check
for missing parts.
ASSEMBLY
ProPaddle Gear Housing to Lower Drive Shaft
Assembly
____1 Gear Housing Assembly
____1 Lower Driveshaft Assembly
____1 Tube Protector
____2 ProPaddle Sweeper Drum Assemblies
____2 Drum Axles
____2 Clevis Pins
____2 Hitch Pins
____2 Split Pins
____1 Operator’s Manua
____1 Storage Hook Assembly
Parts Required: ProPaddle Gear Housing Assembly, Lower Drive
Shaft Assembly, Tube Protector

ASSEMBLY 99944200620
14 X7532093907
© 1/2017 ECHO Inc.
1. Remove vinyl cap from lower end of drive shaft tube (end without
labels).
2. Remove gear housing shaft alignment screw (B) from right side of
gearcase.
3. Loosen gear housing shaft
clamp bolt (C).
4. Insert tip of flex shaft (D) into
gear housing drive socket.
5. Align hole in drive shaft tube (E)
with alignment hole in gear
housing (B).
6. Insert lower driveshaft tube
(end without model number/
coupling alignment decal) into
gear housing shaft mount.
7. Install and tighten alignment
screw (B).
8. Tighten gear housing shaft
clamp bolt (C).
9. Slide tube protector (A) flush
against gearcase housing.
ProPaddle Sweeper Drum Assembly
1. Slide tapered end of plastic
drum axles (E) onto gear
housing output shafts.
2. Align mounting holes, and
secure drum axles to shafts
with clevis pins (F).
Parts Required: 1 - ProPaddle Gear Housing/Lower Shaft Assembly
2 - ProPaddle Sweeper Drums
2 - Plastic Drum Axles
2 - Clevis Pins
2 - Hitch Pins
2 - Split Pins
D
B
C
E
B
C
A
E
E

99944200620 ASSEMBLY
X7532093907 15
© 1/2017 ECHO Inc.
ENGLISH
3. Insert hitch pins (G) through
holes in tip of clevis pins to
retain clevis pins.
4. Slide recessed ends of
sweeper drums (H) onto plastic
axles, and secure with split pins
(I). Spread tips of split pins out
to retain pins in axles.
Thrown objects hazard. Install lower drive shaft to coupler so
that gear housing clamping bolt faces downward. Otherwise
debris will be thrown toward users.
Power Head Shaft/Lower Shaft Assembly
Do not perform maintenance or assembly procedures with
engine running.
1. Set Power Head/Shaft Assembly on a level surface.
2. Pull locater pin (A) out, and turn counter-clockwise 1/4
turn to lock-out position.
3. Remove vinyl cap from attachment drive shaft.
4. Remove cardboard spacer, if necessary.
Parts Required: PAS or SRM-SB Power Head w/Shaft & Coupling
G
G
FF
HH
I

ASSEMBLY 99944200620
16 X7532093907
© 1/2017 ECHO Inc.
Note: Your coupler may appear different than coupler shown.
5. Carefully fit attachment drive
shaft assembly into coupler (B)
to decal assembly line (C),
making sure that the inner lower
drive shaft engages the square
upper drive shaft socket.
Note: Earlier model Power
Heads may have shorter
couplings.
Note: Lower bearing housing and
head assembly must be in
line with the engine.
6. Rotate locater pin (A) ¼ turn
clockwise to engage lower shaft
hole. Insure locater pin is fully
engaged by twisting lower drive
shaft. Locater pin should snap
flushin coupler.Fullengagement
will prevent further shaft rotation.
7. Secure lower shaft assembly to
coupler by tightening clamping
knob (D).
B
A
C
D
A

99944200620 OPERATION
X7532093907 17
© 1/2017 ECHO Inc.
ENGLISH
OPERATION
Note: Refer to your PAS power source Operator's Manuals for
correct engine fueling, starting and stopping instructions.
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothingand loose objects away from all openings.
Always stop engine, disconnect spark plug, and make sure all
moving parts have come to a complete stop before removing
obstructions, clearing debris, or servicing unit. Allow unit to
cool before performing service.
Break-In
1. ProPaddle sweeper drums with new paddle belts must be broken-in
before use to prevent the belts from gripping and dragging on hard
surfaces.
2. Grip the handles firmly, and
position ProPaddle well out in
front of your body.
3. Run the ProPaddle at full
throttle for 3 - 5 minutes on a
rough, abrasivesurfacesuch as
worn asphalt paving. Allow the
ProPaddle's weight to fully rest
on the paddle belts.
4. After break-in, the paddle belt
fins will slide easily over the
surface being cleaned,
providing more efficient
operation on a variety of
surfaces.
Sweeping Operation
Do not operate ProPaddle with paddles close to your body,
which could result in loss of control and possible serious injury.

OPERATION 99944200620
18 X7532093907
© 1/2017 ECHO Inc.
1. Hold unit from left side, resting
sweeper paddles on work
surface.
2. Firmly grasp throttle grip with
right hand and front handle with
left hand.
3. Position ProPaddle well out in
front of your body.
4. Accelerate to full throttle and
allow paddles to push debris
ahead. Sweep to an area
where debris can be piled and
collected.
5. Debris may be swept out and
away from corners by turning
unit over to reverse paddle
direction. Grip unit securely
using both hands. Operate
throttle trigger with thumb of
right hand. For extended use,
reposition front handle to allow
comfortable grip. Return handle
to normal position for regular
operation.
Turning ProPaddle over to reverse sweeper drum rotation will
cause debris to be swept toward operator. Reduce engine
speed, and be alert for unstable footing caused by loose debris.

99944200620 MAINTENANCE
X7532093907 19
© 1/2017 ECHO Inc.
ENGLISH
Note: Extended use of unit at
low throttle settings could
cause damage to clutch
because of clutch
slipping.
MAINTENANCE
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothingand loose objects away from all openings.
Always stop engine, disconnect spark plug, and make sure all
moving parts have come to a complete stop before removing
obstructions, clearing debris, or servicing unit. Allow unit to
cool before performing service. Wear gloves to protect hands
from sharp edges and hot surfaces.
Your ECHO unit is designed to provide many hours of trouble free service.
Regular scheduled maintenance will help your unit achieve that goal. If you
are unsure or are not equipped with the necessary tools, we recommend
that you take your unit to an ECHO Servicing Dealer for maintenance. To
help you decide whether you want to DO-IT-YOURSELF or have the ECHO
Dealer do it, each maintenance task has been graded. If the task is not
listed, see your ECHO Dealer for repairs.
Skill Levels
Level 1 = Easy to do. Common tools may be required.
Level 2 = Moderate difficulty. Some specialized tools may be required.
Click HERE or go to http://www.echo-usa.com/products/maintenance-kit for
information on Maintenance Kits.

LUBRICATION 99944200620
20 X7532093907
© 1/2017 ECHO Inc.
Maintenance Intervals
*Inspect parts at intervals indicated and service or replace as needed.
IMPORTANT - Time intervals shown are maximum. Actual use and your
experience will determine the frequency of required maintenance.
1Apply lithium based grease.
Lubrication
Level 1.
Drive Shaft
The lower attachment drive shaft must be lubricated with lithium
based grease every 25 hours of operation, otherwise drive shaft
assembly overheating and failure can result.
COMPONENT/
SYSTEM MAINTENANCE PROCEDURE SKILL LEVEL INTERVAL
Drive Shaft Grease 1 Every 25 hours of
Use1
Gear Case Lubricate 2 Before Each Use
Paddles Inspect/Switch/
Replace*1/2/2 Daily
Tube Protector Inspect/Rotate/
Reverse/Replace*1/2/2/2 Weekly
Screws/Nuts/
Bolts Inspect/Tighten/ Replace 1/1/1 Before Each Use
Parts Required: Lithium Base Grease, Mobil SHC634
synthetic gear oil
