Echo SRM - 340 User manual

Grass Trimmer/Brush Cutter
Operator'sManual
MODEL, SRM - 340
Serial Number 03001001 - 03999999
WARNING DANGER
Readrulesforsafeoperationandinstructionscarefully. ECHOprovidesanOperator's
ManualandaSafetyManual. Bothmustbereadandunderstoodforproperandsafe
operation.
WARNING
The engine exhaust from this
product contains chemicals known
to the State of California to cause
cancer, birth defects or other
reproductive harm.
X7502126800 X750003660
01/03

2
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job
dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will
find both easy to use and full of helpful operating tips and SAFETY messages.
THE OPERATOR'SMANUAL
Read and understand this manual before operation. Keep it in a safe
place for future reference. Contains specifications and information for
operation, starting, stopping, maintenance, storage and assembly
specific to this product.
THE SAFETY MANUAL
Read and understand this manual before operation. Keep it in a safe
place for future reference. Explains possible hazards involved with the
use of Edgers and the measures you should take to make their use
safer.
Copyright©2003ByEcho,Incorporated
All Rights Reserved.
TABLE OF CONTENTS
Introduction ........................................................................ 2
- The Operator's Manual .............................................. 2
- The Safety manual ...................................................... 2
Manual Safety Symbols and Important Information ......... 3
Safety.................................................................................. 3
- Decals ......................................................................... 3
- International Symbols................................................. 4
Safety Instructions ............................................................. 5
- Personal Condition and Safety Equipment................. 5
- ExtendedOperation/ExtremeConditions ................... 5
- Equipment .................................................................. 6
- Safe Operation ............................................................ 7
Emission Control ................................................................ 7
Description ......................................................................... 8
- Package Contents ........................................................ 8
- SRM-340 Parts ........................................................... 9
- SRM-340 Part Descriptions..................................... 10
Specifications.................................................................... 11
Assembly.......................................................................... 12
- Drive Shaft /Power Head .......................................... 12
- PlasticShield Installation.......................................... 12
- Nylon Head Installation ........................................... 13
- BladeInstallation ...................................................... 13
- Front Handle/Barrier Bar Installation
and Adjustment ........................................................ 14
- Throttle Linkage and Ignition Leads ......................... 15
- Balance and Adjust Unit........................................... 15
Pre-Operation ................................................................... 16
- Operation with Blades.............................................. 16
- Fuel ........................................................................... 18
Operation.......................................................................... 19
- StartingColdEngine ................................................. 19
- StartingWarmEngine ............................................... 20
- StoppingEngine........................................................ 20
Maintenance ..................................................................... 21
- SkillLevels................................................................ 21
- Maintenance Intervals .............................................. 21
- Air Filter ................................................................... 22
- Fuel Filter ................................................................. 22
- SparkPlug................................................................. 23
- CoolingSystemCleaning .......................................... 23
- Exhaust System ........................................................ 24
- Carburetor Adjustment Emission ............................. 25
- Lubrication................................................................ 26
- Nylon Line Replacement .......................................... 26
- Sharpening Metal Blades .......................................... 28
Troubleshooting................................................................ 29
Storage .............................................................................. 30
ServicingInformation........................................................ 32
- Parts.......................................................................... 32
- Service ....................................................................... 32
- ECHO Consumer Product Support.......................... 32
- Warranty Card .......................................................... 32
- Additional or Replacement Manuals ........................ 32
Specifications, descriptions and illustrative material in this
literature are as accurate as known at the time of publica-
tion, but are subject to change without notice. Illustrations
may include optional equipment and accessories, and may
not include all standard equipment.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 3
This symbol accompanied by the words WARNING and
DANGER calls attention to an act or condition that can
lead to serious personal injury to operator and bystand-
ers.
The circle with the slash symbol means whatever is
shown within the circle is prohibited.
MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION
IMPORTANT The enclosed message
provides information necessary for the
protection of the unit.
NOTE This enclosed message provides
tips for use, care and maintenance of the
unit.
Throughout this manual and on the product itself, you will find safety
alerts and helpful information messages preceded by symbols or key
words. The following is an explanation of those symbols and key
words.
SAFETY
DECALS
Locate these safety decals on your unit. The complete unit illustration,
found in the "DESCRIPTION" section, will help you locate them. Make
sure the decals are legible and that you understand and follow the
instructions on them. If a decal cannot be read, a new one can be
orderedfromyourECHOdealer. SeePARTSORDERINGinstructions
for specific information.
DEBRISSHIELDDECAL
Metal Debris
Shield
89017740630
WARNING DANGER
This unit can be dangerous and cause
serious injury if improperly used. To
reduce injury risk to operator, helpers
and bystanders, read and understand
the Operator's and Safety Manuals,
which are provided in Spanish.
ADVERTENCIA PELIGRO
Esta unidad puede ser peligrosa y producir lesiones
personales graves si no se usa en forma adecuada. Para
reducir el riesgo de lesionarse, los operadores, los
ayudantes y los espectadores deben leer y comprender el
Manual Del Operador y los Manuales De Seguridad que se
entregan escritos en español.
Shaft Decal
Spanish Decal English Translation

4
Shaft Decal
WARNING DANGER
• This unit can be dangerous and cause serious injury if improperly
used. To reduce injury risk to operator, helpers and bystanders,
read and understand the Operator's and Safety manuals.
• Blindness can occur from objects that are thrown or ricocheted even
with shield in place. Operators, helpers and bystanders must wear
ANSI Z87.1 approved eye protection.
• Always wear hearing protection when operating unit.
• Prevent accidental contact with unit and any cutting attachment.
Maintaina15m(50ft.)radius,DANGERZONEsurroundingthe
operator. ONLY the operator, dressed in proper protective clothing
shouldbeintheDANGERZONE.
• BewareofKICKOUT(bladethrust)whenusingblades. Special
precautions are necessary for blade operation, see your Operator's
and Safety Manuals. ONLY install ECHO approved blades on
Brush Cutters (SRM) models equipped with proper blade shield,
U-handles, harness, blade collar, nut and cotter pin.
• Blade/Cutting attachment does not stop immediately after releasing
throttle. Keep hands and feet clear of blade/cutting attachment
unless engine is shut off and cutting attachment is not moving.
• INSPECTBLADESBEFOREUSE.
• DONOTUSEDAMAGED,CRACKED,BENT,DULLOR
IMPROPERLYSHARPENEDBLADES.
• Do not remove shields, modify the unit or install attachments or
parts not approved by ECHO. Approved attachment information
and replacement Operator's and Safety Manuals are available from
yourECHOdealerorbywriting:ECHO,INCORPORATED,400
OAKWOOD RD., LAKE ZURICH, IL 60047.
Hot
Surface
Symbol
description/application Symbol form/shape Symbol
description/application
Symbol form/shape
"WARNING, SEE
OPERATOR'S
MANUAL
Wear eyes, ears and
head protection Finger Severing
Wear hand and
foot protection
Safety/Alert
Keep bystanders and helpers
away 15 m (50 ft.).
DONOTsmoke
nearfuel.
DONOTallow
flamesorsparks
nearfuel.
INTERNATIONALSYMBOLS
P/N89016054130
Carburetor adjustment
- Idle speed
Carburetor adjustment
- High speed mixture
Emergency stop Fuel and oil mixture
Carburetor adjustment
- Low speed mixture
Primer Bulb
Ignition
ON/OFF
SYMBOL DESCRIPTION SYMBOL DESCRIPTION
Choke Control
"Cold Start"
Position
(ChokeClosed)
Choke Control
"Run"
Position
(ChokeOpen)

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 5
SAFETYINSTRUCTIONS
PERSONAL CONDITION AND SAFETY EQUIPMENT
WARNING DANGER
Trimmer/Brush Cutter users risk injury to themselves and others if the trimmer/brush cutter is used improperly
or safety precautions are not followed. Proper clothing and safety gear must be worn when operating a
trimmer.
EXTENDED OPERATION/EXTREME CONDITIONS
Vibration and Cold
It is believed that a condition called Raynaud’s Phenomenon, which
affects the fingers of certain individuals may be brought about by
exposure to vibration and cold. Exposure to vibration and cold may
cause tingling and burning sensations followed by loss of color and
numbness in the fingers. The following precautions are strongly
recommendedbecausethe minimum exposurewhichmighttrigger the
ailmentisunknown.
• Keep your body warm, especially the head, neck, feet, ankles,
hands and wrists.
• Maintain good blood circulation by performing vigorous arm
exercises during frequent work breaks and also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where
operating the trimmer or other hand-held power equipment is not
required.
• If you experience discomfort, redness and swelling of the fingers
followed by whitening and loss of feeling, consult your physician
before further exposing yourself to cold and vibration.
Physical Condition
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
• ifyouaretakingmedication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
Wear eye protection that meets ANSI Z87.1 or CE
requirements whenever you operate the trimmer.
Hand Protection
Wear no-slip, heavy duty work gloves to improve your
grip on the Trimmer/Brush Cutter handles. Gloves also
reduce the transmission of machine vibration to your
hands.
Hearing Protection
ECHOrecommendswearinghearingprotectionwhenever
unit is used.
Proper Clothing
Wear snug fitting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DONOTWEARSHORTS,
• DONOTWEARTIES,SCARVES,JEWELRY.
Wear sturdy work shoes with non-skid soles;
• DONOTWEAROPENTOEDSHOES,
• DONOTOPERATEUNITBAREFOOTED.

6
Repetitive Stress Injuries
It is believed that overusing the muscles and tendons of the fingers,
hands, arms, and shoulders may cause soreness, swelling, numbness,
weakness, and extreme pain in those areas. Certain repetitive hand
activities may put you at a high risk for developing a Repetitive Stress
Injury(RSI).AnextremeRSIconditionisCarpalTunnelSyndrome
(CTS), which could occur when your wrist swells and squeezes a vital
nerve that runs through the area. Some believe that prolonged exposure
to vibration may contribute to CTS. CTS can cause severe pain for
months or even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended or twisted position.
Instead try to maintain a straight wrist position. Also, when grasping,
use your whole hand, not just the thumb and index finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitive
movement.
• Do exercises to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a doctor if
you feel tingling, numbness, or pain, in the fingers, hands, wrists, or
arms. The sooner RSI/CTS is diagnosed, the more likely permanent
nerve and muscle damage can be prevented.
EQUIPMENT
WARNING DANGER
Use only ECHO-approved attachments. Serious injury may result from the use of a non-approved attachment
combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments, or accessories
which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this
manual and safety manual.
• Check unit for loose/missing nuts, bolts and screws. Tighten and/or
replace as needed.
• Inspect fuel lines, tank, and area around carburetor for fuel leaks. DO
NOT operate unit if leaks are found.
• Inspect shield for damage, and ensure that the cut-off knife is
securely in place. Replace if either is damaged or missing.
• Check that the cutting attachment is firmly attached and in safe
operating condition.
• Check that front loop handle and shoulder strap/ or shoulder/
waist harness are adjusted for safe, comfortable operation. See
Assembly Section for proper adjustment.
• Keep exhaust area clear of flammable debris. Avoid contact during
andimmediatelyafteroperation.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 7
SAFE OPERATION
WARNING DANGER
Do not operate this product indoors or in inadequately ventilated
areas. Engine exhaust contains poisonous emissions and can cause
serious injury or death.
Provide Safety Instructions To All Operators
• Provide all operators of this equipment with the Operator's Manual
and Safety Manual for instructions on safe operation.
Keep A Firm Grip
• Hold the front and rear handles using both hands, with thumbs and
fingers encircling the handles
Keep A Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on
ladders. Do not over reach.
PRODUCTEMISSIONDURABILITY
The 300 hour emission durability period is the time span selected by the manufacturer certifying the engine emissions
output meets applicable emissions regulations, provided that approved maintenance procedures are followed as listed
in the Maintenance Section of this manual.
EMISSION CONTROL
EPA Phase 1
The emission control system for these engines is EM (Engine Modification).
AnEmissionControlLabelislocatedon theengine. (Thisisan EXAMPLEONLY,information onlabel variesbyengine
FAMILY).
IMPORTANTENGINEINFORMATION
ENGINE FAMILY: 3EHXS.0344RA
DISPLACEMENT: 34.0 CC
THIS ENGINE MEETS U.S. EPA PH1 EMISSION
REGULATIONS FOR SMALL NON ROAD ENGINES.
REFER TO OWNER'S MANUAL FOR MAINTENANCE
SPECIFICATIONS AND ADJUSTMENTS.

8
DESCRIPTION
Your new Echo product has been factory pre-assembled for your convenience. Due to packaging restrictions, shield
installation and other final assembly may be necessary.
Check the contents carefully, and notify your retailer or ECHO Dealer immediately if any parts are missing or damaged.
Use the contents list below to check for missing parts.
PACKAGE CONTENTS
__ 1 PowerHead
__ 1 Drive Shaft Assembly w/Gear Housing
__ 1 Front Handle
__ 1 FrontHandleBracket
__ 4 5mmx35mmscrews
__ 4 5mmnuts
__ 1 NylonTrimmerHead
__ 1 PlasticDebrisShield
__ 1 ShieldPlate
__ 3 5mmx16mmscrews(ShieldPlate-GearCase)
__ 1 MetalShield
__ 1 MetalShieldBracket
__ 3 5mmx15mmscrews(Shield-GearCase)
__ 2 5mmx8mmscrews(Bracket-Shield)
__ 4 5mmnuts(Bracket-Shield&GearCase)
__ 4 5mmlockwashers(Bracket-Shield&GearCase)
__ 1 Standard Shoulder Harness
__ 1 Safety Glasses
__ 1 Echo2-StrokeOil
__ 10 2mmx25mmCotterPins
__ 1 8mmx10mmOpen-endwrench
__ 1 CombinationSocket/ScrewdriverTool(Scrench)
__ 1 LockingTool
__ 1 “4mm“”L””hexwrench”
__ 1 Operator’s Manual
__ 1 Safety Manual
__ 1 Warranty Registration Card
__ 1 LimitedWarrantyStatement
SafetyVideo(Recommended)

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 9
6
7
8
9
4
5
21
10
3
MODEL SRM-340 PARTS
13
11
12
21
16
14
15
22
17
20
18 19
23

10
1. POWERHEAD-IncludestheEngine,Clutch,FuelSystem,IgnitionSystem,andRecoilStarter.
2. GRIP-Rear(righthand)handle.
3. THROTTLETRIGGERLOCKOUT-Thislevermustbeheldduringacceleration.Operationofthethrottletriggeris
prevented unless throttle trigger lockout lever is engaged.
4. STOPSWITCH - "SLIDE SWITCH" mounted on top of the Throttle Trigger Housing. Move switch FORWARD to
RUN,BACKtoSTOP.
5. FRONT HANDLE - Provides a secure forward grip for holding unit. Must be positioned for proper cutting attitude
and operator comfort.
6. DRIVESHAFTASSEMBLY-IncludestheRear(righthand)Handleassembly,GearHousingassembly,Blade
attachment parts, Drive Shaft, and Safety Decal.
7. NYLONCUTTINGATTACHMENT-Containsreplaceablenylontrimminglinethatadvanceswhenthetrimmerhead
is tapped against the ground while the head is turning at normal operating speed.
8. CUT-OFFKNIFE- Automatically trimslineto the correctlength(5in.) afterheadistapped on thegroundwhile nylon
cutting attachment is turning. If trimmer is operated without a cut-off knife, the line will become too long, the engine
will overheat and engine damage may occur.
9. PLASTICDEBRISSHIELDASSEMBLY- Deflectsdebris. MUSTbeinstalledonunitbeforeNylonLineHeaduse
(See Assembly Instructions). Shield assembly includes the Cut-Off Knife and Safety Decal. Mounts on the Gear
Housing Assembly just above the cutting attachment. Helps protect the operator by deflecting debris produced
during the trimming operation. This shield must be replaced with the steel shield for blade use.
10. THROTTLETRIGGER- Controlsenginespeed. Springloadedtoreturntoidlewhenreleased. Duringacceleration,
press trigger gradually for best operating technique.
11. BLADES - Circular steel blades for grass, weeds, or brush cutting applications. (Harness, metal shield, and U-handle
required for blade operation.)
12. METALBLADESHIELD-Requiredwhenunitisequipped withblades. Donotoperateunitwithoutshield.
13. SHOULDER HARNESS - An adjustable shoulder strap that suspends the unit from the operator's shoulder. Using
the strap reduces operator fatigue and enhances safety.
14. CHOKE - Adjusts Fuel/Air ratio for starting or running engine. The choke control is located at the top of the air filter
case. Move choke lever to "Cold Start" ( ) to close choke for cold starting. Move choke lever to "Run" ( )
position to open choke.
15. SPARKPLUG-Providessparktoignitefuelmixture.
16. TOPGUARD-Protectsoperator's arm from the hotengineduringnormal operation.
17. SPARKARRESTOR-CATALYTICMUFFLER/MUFFLER-Themufflerorcatalyticmufflercontrolsexhaustnoise
and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the muffler. Keep
exhaustareaclearofflammabledebris.
18. FUELTANK-Holdsfuelandcontainsthefuelfilter.
19. RECOILSTARTERHANDLE-Startsengine. Pullhandleslowlyuntilstarterengages,thenquicklyandfirmly.
When engine starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.
20. FUELTANKCAP-Coversandsealsfueltankopening.
21. PRIMERBULB- Primes carburetorforquickstarting. Pumping primerbulbbefore startingenginedrawsfresh fuel
from the fuel tank, priming the carburetor for starting. Pump primer bulb until fuel is visible and flows freely in the
clear fuel tank return line. Pump bulb an additional 4 or 5 times.
22. AIRCLEANER-Filtersoutdirtanddebrisinair. Containsreplaceablefilterelement.
23. SAFETYVIDEO-(Notincludedwithunit)P/N99922202540EnglishversionandP/N99922203508Spanishversion
are availableatacostof $5.00 from ECHO, INC. oranyauthorizedECHOdealer. The video overviews safety precau-
tions and proper operating techniques and is supplemental to the Safety Manual. Read and understand the Safety
Manual for complete information on safe operation.
MODEL SRM-340 PART DESCRIPTIONS

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 11
SPECIFICATIONS
* Install and use U-Handle when operating any model with blade.
MODEL ---------------------------------------------------------- SRM-340
Length------------------------------------------------------------ 1835mm(72.2in.)
Width------------------------------------------------------------- 330mm(13.0in.)
Height ------------------------------------------------------------ 260mm(10.2in.)
Weight (dry) w/Cutter Head ----------------------------------- 7.3kg(16.1lb.)
Engine Type ----------------------------------------------------- Air cooled, two-stroke, single cylinder gasoline engine
Bore--------------------------------------------------------------- 38.0mm(1.50in.)
Stroke------------------------------------------------------------- 30.0mm(1.18in.)
Displacement ---------------------------------------------------- 34.0cc(2.08cu.in.)
Exhaust ----------------------------------------------------------- SparkArrestorMuffler
Carburetor ------------------------------------------------------- Walbro diaphragm model WT w/purge
Ignition System ------------------------------------------------- Flywheel magneto, capacitor discharge
SparkPlug ------------------------------------------------------- NGKBPM-7A, (Gap0.65mm(0.026in.)
Fuel --------------------------------------------------------------- Mixed(GasolineandTwo-strokeOil)
Fuel/OilRatio ---------------------------------------------------- 50:1ECHOHighPerformance,two-strokeaircooledengineoil
Gasoline ---------------------------------------------------------- 89 Octane unleaded. DO NOT use fuel containing methyl
alcohol,morethan 10% ethylalcoholor 15% MTBE.
Oil ----------------------------------------------------------------- 50:1ECHOHighPerformance,two-strokeaircooledengineoil
FuelTank Capacity --------------------------------------------- 0.8lit.(27.1USfl.oz.)
StarterSystem --------------------------------------------------- AutomaticRecoilStarter
Clutch ------------------------------------------------------------ CentrifugalType
DriveShaft ------------------------------------------------------- 8mmSpline SteelShaft
RotatingDirection ---------------------------------------------- CounterClockwiseviewedfromtop
Cutter Head ------------------------------------------------------ Nylonlinehead(2-line)
Handles* --------------------------------------------------------- Front-Loop,RightGripStandard
U-Handle --------------------------------------------------------- Optional
Shoulder Harness ----------------------------------------------- Standard
Idle Speed-------------------------------------------------------- 2500-3300RPM
Wide Open Throttle Speed (W.O.T.)
withNylonLineHead ------------------------------------------ 9000-11,000RPM
Wide Open Throttle Speed (W.O.T.) with Blade ------------ 9500-11,000RPM

12
ASSEMBLY
DRIVE SHAFT/POWER HEAD
Tools Required: 4 mm Hex Wrench
Parts Required: Power Head, Drive Shaft Assembly
1. Stand power head upright on a level surface.
2. Loosen the two (2) drive shaft clamp bolts at engine drive shaft
clamp, and remove center drive shaft location bolt (A).
3. Carefully fit driveshaft assembly to engine making sure that
inner drive shaft engages into clutch mount.
4. Turn drive shaft housing until locating hole lines up with location
hole in clamp and install center drive shaft location bolt (A).
NOTE
Gear housing must be aligned properly with engine. Aligning
center locating hole in driveshaft housing with center drive shaft
bolt (A) provides correct alignment.
5. Tighten two (2) drive shaft clamp bolts (B) securely.
PLASTICSHIELD INSTALLATION
(Nylon line operation)
Tools Required: Screwdriver,LockingTool
Parts Required: Plastic Debris Shield, Shield Plate,
three(3) 5x16mmscrews.
WARNING DANGER
The plastic shield is for use with the Nylon Line Head only. Install
Metal Shield when using plastic or metal blades, or serious injury
mayresult.
1. Align hole in upper plate (D) with notch in gear housing (G), and
insert locking tool to prevent splined shaft from turning. Arrow on
gear housing flange points to notch location.
2. Remove cotterpin(A), L.H.bladenut (B),lowerplate (C),and
upper plate (D) from PTO shaft. Turn blade nut clockwise to
remove.
3. Remove locking tool. Retain lower plate, blade nut, and cotter pin
for future use with blade conversions.
4. Align plastic debris shield (F) with the drive shaft, and install on
the bottom of the gear housing flange.
5. Place shield plate (E) on shield, align holes and install three (3)
screws.
6. Replace upper plate (D) on PTO shaft.
ED
F
A
A
B
B
CBA
D
G

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 13
NYLON HEAD INSTALLATION
Tools Required: LockingTool,17x19mmScrench
Parts Required: NylonLineHead.
1. Make sure plastic debris shield (F) is properly aligned, and upper
plate (D) is installed on splined PTO shaft.
2. Align hole in upper plate (D) with notch in gear housing (G), and
insert locking tool (H) to prevent splined shaft from turning.
3. Thread line head (I) onto PTO shaft by turning it counter-clockwise
until head is tight against upper plate (D).
4. Removelockingtool.
NOTE
Model SRM-340 includes necessary blade conversion parts.
Blades are not provided with trimmer/brushcutters and must be
selected for type of cutting being performed. See page 16,
"Choosing The Correct Blade."
Install Metal Shield
Tools Required: 8x10mmOpen-endWrench,Screwdriver,Scrench,
Locking Tool
Parts Required: Metal Shield, Shield Bracket,
3-5 x 15 mmscrewsw/captivatedflat and lock-
washer, (metal shield to gear housing).
2-5x8mmscrews,2-5mmnuts,2-5mmlock-
washers, (bracket to shield).
2- 5mm nuts,2-5mmlockwashers
(bracket to gear housing)
1. If installed, remove nylon line head, upper plate and plastic shield,
and set upper plate aside for use with blade installation. Retain
plastic shield, shield plate, and plastic shield hardware for conver-
sion back to nylon line operation.
2. Align hole in upper plate (D) with notch in gear housing (G), and
insert locking tool to prevent splined shaft from turning. Arrow on
gear housing flange points to notch location.
3. Remove splitpin(A),L.H. blade nut(B),lowerplate (C), and upper
plate (D) from PTO shaft. Turn blade nut clockwise to remove.
4. Removelockingtool.
5. Loosely attach bracket (J) to shield (K) and attach shield to bottom
of gear housing (G) with hardware provided.
6. Tighten all shield hardware.
BLADE OPERATION
K
J
G
CBA
D
G
H
D
G
F
I
WARNING DANGER
You must install a Barrier Bar or U-Handle Kit and all Blade Conversion parts shown in the following instructions
before operating this unit with metal blades, otherwise serious injury may result.

14
Install Blade
Tools Required: Locking Tool, Scrench.
Parts Required: Upper Plate w/ 20 mm pilot, Lower Plate, 10 mm Nut
w/L.H. threads, 2 x 25 mm Cotter Pin, Blade.
1. Install upper plate (D) on splined PTO shaft, pilot side down.
BladeinstallationrequiresUpperPlate(D)with20mmpilot.
2. Install Blade (L) on upper plate pilot. Blades must be installed so
that rotation arrow on blade matches rotation of unit: teeth toward
direction of rotation (See debris shield decal). Secure blade with
LowerPlate(C),and10mmL.H.nut(B).Turnnutcounter-clockwise
on PTO shaft to tighten.
3. Align hole in upper plate with notch in gear housing, and insert
Locking Tool (H) to prevent splined shaft from turning. Arrow on
gear housing points to notch. Tighten 10 mm nut securely.
4. Insert Split Pin (A) in hole in PTO shaft, and bend pin legs around
shaft counterclockwise to retain 10 mm nut.
IMPORTANT
Never reuse a cotter pin - install a new cotter pin each time a blade is
installed or replaced.
5. Tri-CutBlade(M)isinstalledwithGlideCup(N).
6. Removelockingtool.
D
20
H
L
BA
C
D
L
C
B
A
HM
N
FRONT HANDLE/BARRIER BAR INSTALLATION AND ADJUSTMENT
A
A
B
C
Tools Required: Screwdriver.
Parts Required: Loop Handle Assembly: Loop Handle, Loop Handle
Bracket,5mmx35mmScrews(4),5mmNuts(4)
Optional: BarrierBar,P/N99944200455
WARNING DANGER
The Barrier Bar must be installed when using grass or weed blades,
otherwise serious personal injury may result.
Handle Only
1. Install loop handle (A) and handle bracket (B) on drive shaft, and
position for comfortable operation. Tighten screws.
Handle and Barrier Bar
1. Install loop handle (A) and barrier bar (C) on drive shaft, and
position for comfortable operation. Tighten screws.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 15
THROTTLE LINKAGE AND IGNITION LEADS
AB
C
Tools Required: 8x10mmOpen-endWrench
Parts Required: CableClips
1. Unscrew air filter cover knob and remove cover.
2. Place inner throttle cable in slot of carburetor swivel (B).
3. Loosen nut (A) and place threaded end of throttle linkage on
carburetor. Finger tighten nut (A).
4. Check throttle for freedom of movement and that wide open
throttle / low idle extremes are adjusted properly. If adjustment
cannot be achieved with adjusting nuts, consult with your Echo
Dealer for correct adjustment procedure.
5. Tighten nut (A). Connect 2 ignition leads from throttle cable tubing
to 2 ignition leads (C) on engine. Gather ignition wires and
position behind air filter case.
6. Install airfilterand cover.
A
B
BALANCE AND ADJUST UNIT
1. Loosen harness clamp screw.
2. Put on harness and attach unit to harness.
3. Slide harness clamp up (A) or down until unit balances with head
approximately50-75mm(2-3in.)fromtheground.
4. Tighten harness clamp screw.
5. Loosen upper U-Handle clamp screws (B), and position U-Handle
forcomfortableoperation.
6. Tighten U-Handle clampscrewsand8mm clamp bolt securely.

16
PRE - OPERATION
OPERATION WITH BLADES
Preparing the Trimmer/Brush Cutter for Blade Use
WARNING DANGER
Bladeuse DEMANDSspecific Trimmer/BrushCutterconfiguration.Operationwithoutspecifiedshield,handle,and
harness can result in serious personal injury.
Grass/Weed Blades require:
Installationof metalshield(A),accessoryBarrierBar(B) P/N
99944200455,and usestandardharness(C).
NOTE
The Barrier Bar is NOT A HANDLE and should not be
gripped when using or carrying the unit.
Brush/Clearing Blades require:
Installationofmetalshield(A),U-HandleKit(D),P/N
35130455830,anduseharnesswithhippad(E).
NOTE
ModelSRM-340 includesMetal Shield,Standard
Harness, and blade mounting hardware.
A
B
C
E
A
D
Choosing the Correct Blade
WARNING DANGER
The type of Blade used MUST be matched to the type and size of material cut. An improper or dull blade can cause
serious personal injury. Blades MUST be sharp. Dull blades increase the chance of kickout and injury to yourself
and bystanders.
NOTE
The Barrier Bar is used to restrict rearward movement of the unit. For heavy-duty or extended use, U-handles should
be used. See your Echo dealer or Trimmer/Brush Cutter Safety Manual for details regarding U-Handles. If you have
additionalquestions,contactyourEchoServiceDealer,orcallEchodirectlyat1-800-673-1558.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 17
Plastic/Nylon Grass/Weed Blades may be used where ever the nylon
line head is used. DO NOT use these blades for heavy weeds or brush!
8 Tooth Grass Weed Blade - use for grass, garden vegetation, and thick
weeds. DO NOT use this blade for brush or heavy woody growth, 19
mm(3/4in.)diameterorlarger.
SRM-340SeriesP/N69600121431
80 Tooth Brush Blade - use for cutting brush and woody growth up to
64mm(2-1/2in.)diameter.
SRM-340SeriesP/N69500121431
22 Tooth Clearing Blade - use for dense thickets and saplings up to 64
mm(2-1/2in.)diameter.
SRM-340SeriesP/N99944200130
Shoulder/WaistHarness(P/N30100052131)UseoftheShoulder/Waist
Harness is required for blade operation, and is recommended for ALL
Trimmer/BrushCutteruse.
The Shoulder/Waist Harness suspends the trimmer from the operator's
shoulder, and reduces operator fatigue during nylon line trimming or
cutting with a blade.
Operator safety is also enhanced by restricting trimmer movement and
preventing blade or line contact with the operator's hands and feet
during operation.
NOTE
In case of Emergency, the trimmer/brushcutter can be released from
the the harness by pulling up on the quick-release collar.

18
IMPORTANT
Spilled fuel is a leading cause of
hydrocarbon emissions. Some states
may require the use of automatic fuel
shut-off containers to reduce fuel
spillage.ContactyourECHOdealerfor
orderinginformation.
After Refueling
• Wipe any spilled fuel from the unit.
• Moveatleast3m (10ft.)from refueling
location before starting.
After Use
• DO NOT store a unit with fuel in its tank.
Leaks can occur. Return unused fuel to an
approved fuel storage container.
Storage
Fuel storage laws vary by locality. Contact
your local government for the laws affecting
your area. As a precaution, store fuel in an
approved, air tight container. Store in a well
ventilated, unoccupied building, away from
sparks and flames. Do not store fuel longer
than 30 days.
IMPORTANT
Storedfuelages. Do notmixmorefuel
than you expect to use in thirty (30)
days, ninety (90) days when a fuel
stabilizerisadded.
IMPORTANT
Stored two-stroke fuel may separate.
ALWAYS shake fuel container thor-
oughly before each use.
FUEL
Fuel Requirements
Gasoline - Use 89 Octane [(R + M)/2] (mid grade or higher) gasoline
known to be good quality. Gasoline may contain up to 15% MTBE
(methyltertiary-butylether).Gasoholcontainingmethyl (wood) alcohol
is NOT approved.
TwoStrokeOil-Atwo-strokeengineoilmeetingISO-L-EGD(ISO/CD
13738)andJ.A.S.O. FCStandards, mustbeused. EchobrandPremium
50:1 oil meets these standards. Engine problems due to inadequate
lubricationcaused byfailureto useanISO-L-EGDandJ.A.S.O.FC
certifiedoil,suchasEchoPremium50:1Two-strokeOil,willvoidthe
two-stroke engine warranty. (Emission related parts only are covered
for two years, regardless of two-stroke oil used, per the statement listed
intheEmissionDefectWarrantyExplanation.)
IMPORTANT
EchoPremium2-StrokeOilmaybemixedat50:1ratioforapplication
in all Echo engines sold in the past regardless of ratio specified in
those manuals.
Mixing Instructions
1. Fill an approved fuel container with half of the required amount of
gasoline.
2. Add the proper amount of 2-stroke oil to gasoline.
3. Close container and shake to mix oil with gasoline.
4. Addremaininggasolineandremix.
5. Install fuel container cap and wipe any spilled fuel from container
and surrounding area.
Handling Fuel
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling, otherwise serious personal injury may result.
• Use an approved fuel container.
• DONOTsmokenearfuel.
• DONOTallow flamesorsparks nearfuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel caps
slowly allowing pressure to equalize.
• NEVERrefuelaunitwhentheengineis HOT!
• NEVERrefuela unitwiththe enginerunning.
• DONOTfillfuel tanks indoors. ALWAYSfillfueltanks outdoors
over bare ground.
• Securely tighten fuel cap after refueling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or
operate unit until leakage is repaired.

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'SMANUAL 19
OPERATION
STARTING COLD ENGINE
WARNING DANGER
The cutting attachment should not rotate at idle. If attachment
rotates, readjust carburetor according to "Carburetor Adjustment"
instructions in this manual or see your ECHO Dealer, otherwise
serious personal injury may result.
1. Stop Switch
Move stop switch button (A) forward, away from the STOP
position.
2. Choke Lever
Move choke lever (B) to Cold Start ( ) Position.
3. Primer Bulb
Pumpprimerbulb(C) until fuel is visibleandflowsfreelyin the
clear fuel tank return line. Pump bulb an additional 4 or 5 times.
4. Recoil Starter
Lay the trimmer on a flat, clear area and pull the recoil starter handle
(D)untilenginefires(5pullsmaximum).
5. Choke Lever
After engine fires, move choke lever to Run ( ) position and pull
recoil starter handle/rope (D) until engine starts and runs. Allow
unit to warm up at idle for several minutes.
NOTE
If engine does not start with choke in “Run” position after 5 pulls,
repeat instructions 4 and 5.
6. Throttle Trigger
After engine warm-up, gradually depress throttle trigger to increase
engine RPM to operating speed.
D
B
C
D
A

20
STARTING WARM ENGINE
WARNING DANGER
The cutting attachment should not rotate at idle. If attachment
rotates, readjust carburetor according to "Carburetor Adjustment"
instructions in this manual or see your ECHO Dealer, otherwise
serious personal injury may result.
1. Stop Switch
Move stop switch button (A) away from the STOP position.
2. Recoil Starter
Lay the unit on a flat clear area and pull the recoil starter handle (D)
until the engine fires.
NOTE
If engine does not start after 5 pulls, use Cold Start Procedure.
STOPPING ENGINE
1. Release Throttle.
Allow engine to return to idle before shutting off engine.
2. Stop Switch.
Move stop switch button backward to STOP position.
WARNING DANGER
If engine does not stop when stop switch is moved to "STOP"
position, move choke lever to closed "Cold Start" position to stall
engine. Have your ECHO dealer repair stop switch before using
trimmeragain.
A
D
A
