Ecler AMIC24 User manual

AMIC24
SERVICE MANUAL

SERVICE MANUAL AMIC24
INDEX
- BLOCK DIAGRAM
- SCHEMATICS
- COMPONENTS LOCATION SCHEMA
- TESTING AND QUALITY CONTROL
- TECHNICAL CHARACTERISTICS
- WIRING DIAGRAM
- MECHANICAL DIAGRAM
- PACKING DIAGRAM

PARTS LIST: PRINTED CIRCUIT 11.1198.03.00
Code Description Reference
FCCE15100000 100u/25 C101
FCCE15100000 100u/25 C102
FCXCC2100000 100n C103
FCXCC2100000 100n C104
FCCE25220100 220u/50 ZL C105
FCCE25220100 220u/50 ZL C106
FCXCC2100000 100n C107
FCXCC2100000 100n C108
FCCE25047000 47u/50 C109
FCCE25047000 47u/50 C110
FCXCC2100000 100n C111
FCCE15100000 100u/25 C112
FCXCD4470000 470n C113
FCXCC2100000 100n C114
FCCE03000000 470u/10 C115
FCXCC2100000 100n C116
FCCE03000000 470u/10 C117
FCXCC2100000 100n C118
FCCDK1470000 C470n C119
FCCDK1470000 C470n C120
FCCE30001000 1u/63 C121
FCCE30001000 1u/63 C122
FCXCD4470000 470n C123
FCCE25010000 10u/50 C124
FCCE10000000 47u/16 C125
FCXCD4470000 470n C126
FCXCC2100000 100n C127
FCCE10000000 47u/16 C128
FCCE10000000 47u/16 C129
FCCE15100000 100u/25 C130
FCXCC2100000 100n C131
FCXCD4470000 470n C132
FCXCD4470000 470n C133
FCXCD4010000 10n C134
FCCE10000000 47u/16 C135
FCCE10000000 47u/16 C136
FCXCC2100000 100n C137
FCXCD4470000 470n C138
FCXCD4470000 470n C139
FCXCC2100000 100n C140
FCXCC2100000 100n C141
FCXCC2100000 100n C142
FCXCD1220000 22p C143
FCXCD1220000 22p C144
FCCE10000000 47u/16 C145
FCXCC2100000 100n C146
FCXCC2100000 100n C147
FCXCC2100000 100n C148
FCXCC2100000 100n C149
FCXCC2100000 100n C150
FCXCC2100000 100n C151
FCXCC2100000 100n C152
FCXCC2100000 100n C153
FCXCC2100000 100n C154
FCXCC2100000 100n C155
FCXCC2100000 100n C156
40-0251-0102 F11-08 AMIC24.xls 1 of 7

PARTS LIST: PRINTED CIRCUIT 11.1198.03.00
Code Description Reference
FCXCC2100000 100n C157
FCXCC2100000 100n C158
FCXCC2100000 100n C159
FCXCC2100000 100n C160
FCXCC2100000 100n C161
FCXCC2100000 100n C162
FCXCC2100000 100n C163
FCXCD4470000 470n C164
FCXCC2100000 100n C165
FCXCC2100000 100n C166
FCCE15220000 220u/25 C167
FCXCD4100000 100n C168
FCXCD1330000 33p C169
FCXCD4100000 100n C170
FCXCC2100000 100n C171
FCXCC2100000 100n C172
FCCE15220000 220u/25 C173
FCXCD1330000 33p C174
FCXCC2100000 100n C175
FCXCC2100000 100n C176
FCXCD4470000 470n C177
FCCE10000000 47u/16 C178
FCXCD4470000 470n C179
FCXCC2100000 100n C180
FCXCC2100000 100n C181
FCXCD4470000 470n C182
FCXCC2100000 100n C183
FCXCC2100000 100n C184
FCXCD4470000 470n C185
FCXCC2100000 100n C186
FCXCC2100000 100n C187
FCXCD4470000 470n C188
FCXCD4220000 220n C189
FCXCD4470000 470n C190
FCXCC2100000 100n C191
FCXCC2100000 100n C192
FCXCD4010000 10n C193
FCXCD4470000 470n C194
FCXCD4470000 470n C195
FCXCC2100000 100n C196
FCCE10000000 47u/16 C197
FCCE30001000 1u/63 C198
FCCE10000000 47u/16 C199
FCCDK1002200 C2n2 C200
FCCDK1002200 C2n2 C201
FCCDK1008200 C8n2 C202
FCCDK1008200 C8n2 C203
FCCDK1008200 C8n2 C204
FCCDK1008200 C8n2 C205
FCCDK1008200 C8n2 C206
FCCDK1008200 C8n2 C207
FCCDK1008200 C8n2 C208
FCCDK1008200 C8n2 C209
FCXCD2470000 470p C210
FCXCD2470000 470p C211
FCXCD2470000 470p C212
40-0251-0102 F11-08 AMIC24.xls 2 of 7

PARTS LIST: PRINTED CIRCUIT 11.1198.03.00
Code Description Reference
FCXCD2470000 470p C213
FCCDK1003300 C3n3 C214
FCCDK1003300 C3n3 C215
FCCDK1003300 C3n3 C216
FCCDK1003300 C3n3 C217
FCCDK1003300 C3n3 C218
FCCDK1003300 C3n3 C219
FCCDK1003300 C3n3 C220
FCCDK1003300 C3n3 C221
FCCDK1002200 C2n2 C222
FCCDK1002200 C2n2 C223
FCCDK1002200 C2n2 C224
FCCDK1002200 C2n2 C225
FCCDK1002200 C2n2 C226
FCCDK1002200 C2n2 C227
FCCDK1002200 C2n2 C228
FCCDK1002200 C2n2 C229
FCXCD1220100 22p 2% C230
FCXCD1220100 22p 2% C231
FCXCD1220100 22p 2% C232
FCXCD1220100 22p 2% C233
FCXCD2220000 220p C234
FCXCD2220000 220p C235
FCXCD2220000 220p C236
FCXCD2220000 220p C237
FCXCD2220000 220p C238
FCXCD2220000 220p C239
FCXCD2220000 220p C240
FCXCD2220000 220p C241
FCXCD1220000 22p C242
FCXCD1220000 22p C243
FCXCD1220000 22p C244
FCXCD1220000 22p C245
FCXCD1220000 22p C246
FCXCD1220000 22p C247
FCXCD1220000 22p C248
FCXCD1220000 22p C249
FCCE25010000 10u/50 C250
FCXCD4010000 10n C251
FCCE25010000 10u/50 C252
FCXCD4010000 10n C253
FCCE25010000 10u/50 C254
FCCE25010000 10u/50 C255
FCCDK1004700 C4n7 C256
FCCDK1004700 C4n7 C257
FCCDK1004700 C4n7 C258
FCCDK1004700 C4n7 C259
FCCDK1004700 C4n7 C260
FCCDK1004700 C4n7 C261
FCCDK1004700 C4n7 C262
FCCDK1004700 C4n7 C263
FCCE25010000 10u/50 C264
FCCE25010000 10u/50 C265
FCCE10000000 47u/16 C266
FCCE10000000 47u/16 C267
FCCE10000000 47u/16 C268
40-0251-0102 F11-08 AMIC24.xls 3 of 7

PARTS LIST: PRINTED CIRCUIT 11.1198.03.00
Code Description Reference
FCCE10000000 47u/16 C269
FCCE10000000 47u/16 C270
FCCE10000000 47u/16 C271
FCCE10000000 47u/16 C272
FCCE10000000 47u/16 C273
FCXCD2100000 100p C274
FCXCD2100000 100p C275
FCCI01198000 Printed Board 11.1198 CI102
FCXZ00012000 Z12V D101
FCXDDSB14000 SB140 D102
FCXZ00004700 Z4.7V D103
FCDDKE120000 Transil 12V 400mW D104
FCXDDSB14000 SB140 D105
FCXDDBAS2800 BAS28 D106
FCXDDBAS2800 BAS28 D107
FCXZ00005600 Z5.6V D108
FCXZ00005600 Z5.6V D109
FCXDD4007000 1N4007 D110
FCLEDSMD2000 TLMH3100 D111
FCXDDBAS2800 BAS28 D112
FCXDD4007000 1N4007 D113
FCLEDSMD2000 TLMH3100 D114
FCXDDBAS2800 BAS28 D115
FCXDDBAS2800 BAS28 D116
FCXDDBAS2800 BAS28 D117
FCXDDBAS2800 BAS28 D118
FCXFER010000 Ferrite 31 FB101
FCIC43101000 LM431AC IC101
FCIC25941000 LM2594 IC102
FCIC2041B000 TPS2041B IC103
FCREG3871000 LP3871-3.3V IC104
FCIC07201000 TL072 IC105
FCICK6R1008V K6R1008V1D IC106
FCIC18F23200 PIC18F2320 IC107
FCIC02464000 24LC64 IC108
FCIC56364100 DSP56364 IC109
FCIC74040100 74HC04 IC110
FCIC77050000 TL7705ACD IC111
FCIC53610100 CS5361 IC112
FCIC43620100 CS4362 IC113
FCTRHN1C0300 HN1C03FU IC114
FCTRHN1C0300 HN1C03FU IC115
FCTRHN1C0300 HN1C03FU IC116
FCTRHN1C0300 HN1C03FU IC117
FCIC4580E000 NJM4580E IC118
FCIC4580E000 NJM4580E IC119
FCIC4580E000 NJM4580E IC120
FCIC4580E000 NJM4580E IC121
FCIC4580E000 NJM4580E IC122
FCIC4580E000 NJM4580E IC123
FCREG1017000 Board Connector Male 3p J101
FCREG1017000 Board Connector Male 3p J102
FCCTM0003000 B3B-EH-A J103
FCCTM0005000 B5B-EH-A J104
FCBASX100000 YKF52-5003 J106
FCBASX100000 YKF52-5003 J107
40-0251-0102 F11-08 AMIC24.xls 4 of 7

PARTS LIST: PRINTED CIRCUIT 11.1198.03.00
Code Description Reference
FCBASX100000 YKF52-5003 J108
FCBASX100000 YKF52-5003 J109
FCBASX090000 YKF52-5005 J110
FCBASX090000 YKF52-5005 J111
FCCTM0012000 B12B-EH-A J112
FCCTM0012000 B12B-EH-A J113
FCCHKX068000 68uH 0.13A L101
FCCHKX068000 68uH 0.13A L102
FCIND0040000 220uH L103
FCCHKX068000 68uH 0.13A L104
FCCHKX068000 68uH 0.13A L105
FCCHKX068000 68uH 0.13A L106
FCCHKX220000 Z 2k2ê L107
FCCHKX220000 Z 2k2ê L108
FCXTT0847000 BC847B Q101
FCXTT0857000 BC857B Q102
FCRF22100000 NF10/ 1/2 R101
FCXR53100000 1k0 R102
FCXR52825000 825 R103
FCXR53100000 1k0 R104
FCXR53147000 1k47 R105
FCXR52825000 825 R106
FCXR53100000 1k0 R107
FCXR51100000 10.0 R108
FCRF22120000 NF12/ 1/2 R109
FCXR55121000 121k R110
FCXR55121000 121k R111
FCXR55121000 121k R112
FCXR55121000 121k R113
FCXR52316000 316 R114
FCXR52316000 316 R115
FCXR54100000 10k0 R116
FCXR53100000 1k0 R117
FCXR53909000 9k09 R118
FCXR53100000 1k0 R119
FCXR52464000 464 R120
FCXR53464000 4k64 R121
FCXR54100000 10k0 R122
FCXR53464000 4k64 R123
FCXR54100000 10k0 R124
FCXR54464000 46k4 R125
FCXR54100000 10k0 R126
FCXR54100000 10k0 R127
FCXR54100000 10k0 R128
FCXR54100000 10k0 R129
FCRX62680000 4 x 68 R130
FCXR54100000 10k0 R131
FCXR53147000 1k47 R132
FCXR54215000 21k5 R133
FCXR53100000 1k0 R134
FCXR56100000 1M R135
FCXR53147000 1k47 R136
FCXR54100000 10k0 R137
FCXR54100000 10k0 R138
FCXR54100000 10k0 R139
FCXR54464000 46k4 R140
40-0251-0102 F11-08 AMIC24.xls 5 of 7

PARTS LIST: PRINTED CIRCUIT 11.1198.03.00
Code Description Reference
FCXR53464000 4k64 R141
FCXR54100000 10k0 R142
FCXR54100000 10k0 R143
FCXR54464000 46k4 R144
FCXR54215000 21k5 R145
FCXR54100000 10k0 R146
FCXR54464000 46k4 R147
FCXR54100000 10k0 R148
FCXR54464000 46k4 R149
FCXR54464000 46k4 R150
FCXR53100000 1k0 R151
FCRX62680000 4 x 68 R152
FCXR51562000 56.2 R153
FCXR53100000 1k0 R154
FCXR53464000 4k64 R155
FCXR54100000 10k0 R156
FCXR53464000 4k64 R157
FCXR53464000 4k64 R158
FCXR53464000 4k64 R159
FCXR53464000 4k64 R160
FCXR53464000 4k64 R161
FCXR53464000 4k64 R162
FCXR53464000 4k64 R163
FCXR53464000 4k64 R164
FCXR55100000 100k R165
FCXR55100000 100k R166
FCXR55100000 100k R167
FCXR55100000 100k R168
FCXR55100000 100k R169
FCXR55100000 100k R170
FCXR55100000 100k R171
FCXR55100000 100k R172
FCXR52619000 619 R173
FCXR52100000 100.0 R174
FCXR52100000 100.0 R175
FCXR52619000 619 R176
FCXR52619000 619 R177
FCXR52100000 100.0 R178
FCXR52100000 100.0 R179
FCXR52619000 619 R180
FCXR52464000 464 R181
FCXR52464000 464 R182
FCXR52464000 464 R183
FCXR52464000 464 R184
FCXR52464000 464 R185
FCXR52464000 464 R186
FCXR52464000 464 R187
FCXR52464000 464 R188
FCXR53121000 1k21 R189
FCXR53121000 1k21 R190
FCXR53121000 1k21 R191
FCXR53121000 1k21 R192
FCXR53121000 1k21 R193
FCXR53121000 1k21 R194
FCXR53121000 1k21 R195
FCXR53121000 1k21 R196
40-0251-0102 F11-08 AMIC24.xls 6 of 7

PARTS LIST: PRINTED CIRCUIT 11.1198.03.00
Code Description Reference
FCXR53121000 1k21 R197
FCXR53121000 1k21 R198
FCXR53121000 1k21 R199
FCXR53121000 1k21 R200
FCXR53121000 1k21 R201
FCXR53121000 1k21 R202
FCXR53121000 1k21 R203
FCXR53121000 1k21 R204
FCXR64243000 24k3 0.5% R205
FCXR64243000 24k3 0.5% R206
FCXR64243000 24k3 0.5% R207
FCXR64243000 24k3 0.5% R208
FCXR53196000 1k96 R209
FCXR53196000 1k96 R210
FCXR53196000 1k96 R211
FCXR53196000 1k96 R212
FCXR53147000 1k47 R213
FCXR53147000 1k47 R214
FCXR53147000 1k47 R215
FCXR53147000 1k47 R216
FCXR53147000 1k47 R217
FCXR53147000 1k47 R218
FCXR53147000 1k47 R219
FCXR53147000 1k47 R220
FCXR64243000 24k3 0.5% R221
FCXR64243000 24k3 0.5% R222
FCXR64243000 24k3 0.5% R223
FCXR64243000 24k3 0.5% R224
FCXR52316000 316 R225
FCXR52316000 316 R226
FCXR52316000 316 R227
FCXR52316000 316 R228
FCXR52316000 316 R229
FCXR52316000 316 R230
FCXR52316000 316 R231
FCXR52316000 316 R232
FCXR55100000 100k R233
FCXR55100000 100k R234
FCXR55100000 100k R235
FCXR55100000 100k R236
FCXR55100000 100k R237
FCXR55100000 100k R238
FCXR55100000 100k R239
FCXR55100000 100k R240
FCXR55100000 100k R241
FCXR55100000 100k R242
FCXR55100000 100k R243
FCXR55100000 100k R244
FCXR52100000 100.0 R245
FCXR52100000 100.0 R246
FCXR52100000 100.0 R247
FCXR52100000 100.0 R248
FCXR50000000 0 RX101
FC0C01210000 1012.01.00 WI101
FCCRISX10000 10MHz X101
FCCRIS012288 12,288MHz X102
40-0251-0102 F11-08 AMIC24.xls 7 of 7

PARTS LIST: PRINTED CIRCUIT 11.1198.02.00
Code Description Reference
FCCE15100000 100u/25 C101
FCCE15100000 100u/25 C102
FCXCC2100000 100n C103
FCXCC2100000 100n C104
FCCE25220100 220u/50 ZL C105
FCCE25220100 220u/50 ZL C106
FCXCC2100000 100n C107
FCXCC2100000 100n C108
FCCE25047000 47u/50 C109
FCCE25047000 47u/50 C110
FCXCC2100000 100n C111
FCCE15100000 100u/25 C112
FCXCD4470000 470n C113
FCXCC2100000 100n C114
FCCE03000000 470u/10 C115
FCXCC2100000 100n C116
FCCE03000000 470u/10 C117
FCXCC2100000 100n C118
FCCDK1470000 C470n C119
FCCDK1470000 C470n C120
FCCE30001000 1u/63 C121
FCCE30001000 1u/63 C122
FCXCD4470000 470n C123
FCCE25010000 10u/50 C124
FCCE10000000 47u/16 C125
FCXCD4470000 470n C126
FCXCC2100000 100n C127
FCCE10000000 47u/16 C128
FCCE10000000 47u/16 C129
FCCE15100000 100u/25 C130
FCXCC2100000 100n C131
FCXCD4470000 470n C132
FCXCD4470000 470n C133
FCXCD4010000 10n C134
FCCE10000000 47u/16 C135
FCCE10000000 47u/16 C136
FCXCC2100000 100n C137
FCXCD4470000 470n C138
FCXCD4470000 470n C139
FCXCC2100000 100n C140
FCXCC2100000 100n C141
FCXCC2100000 100n C142
FCXCD1220000 22p C143
FCXCD1220000 22p C144
FCCE10000000 47u/16 C145
FCXCC2100000 100n C146
FCXCC2100000 100n C147
FCXCC2100000 100n C148
FCXCC2100000 100n C149
FCXCC2100000 100n C150
FCXCC2100000 100n C151
FCXCC2100000 100n C152
FCXCC2100000 100n C153
FCXCC2100000 100n C154
FCXCC2100000 100n C155
FCXCC2100000 100n C156
40-0251-0101 F11-08 AMIC24.xls 1 of 7

PARTS LIST: PRINTED CIRCUIT 11.1198.02.00
Code Description Reference
FCXCC2100000 100n C157
FCXCC2100000 100n C158
FCXCC2100000 100n C159
FCXCC2100000 100n C160
FCXCC2100000 100n C161
FCXCC2100000 100n C162
FCXCC2100000 100n C163
FCXCD4470000 470n C164
FCXCC2100000 100n C165
FCXCC2100000 100n C166
FCCE15220000 220u/25 C167
FCXCD4100000 100n C168
FCXCD1330000 33p C169
FCXCD4100000 100n C170
FCXCC2100000 100n C171
FCXCC2100000 100n C172
FCCE15220000 220u/25 C173
FCXCD1330000 33p C174
FCXCC2100000 100n C175
FCXCC2100000 100n C176
FCXCD4470000 470n C177
FCCE10000000 47u/16 C178
FCXCD4470000 470n C179
FCXCC2100000 100n C180
FCXCC2100000 100n C181
FCXCD4470000 470n C182
FCXCC2100000 100n C183
FCXCC2100000 100n C184
FCXCD4470000 470n C185
FCXCC2100000 100n C186
FCXCC2100000 100n C187
FCXCD4470000 470n C188
FCXCD4220000 220n C189
FCXCD4470000 470n C190
FCXCC2100000 100n C191
FCXCC2100000 100n C192
FCXCD4010000 10n C193
FCXCD4470000 470n C194
FCXCD4470000 470n C195
FCXCC2100000 100n C196
FCCE10000000 47u/16 C197
FCCE30001000 1u/63 C198
FCCE10000000 47u/16 C199
FCCDK1002200 C2n2 C200
FCCDK1002200 C2n2 C201
FCCDK1008200 C8n2 C202
FCCDK1008200 C8n2 C203
FCCDK1008200 C8n2 C204
FCCDK1008200 C8n2 C205
FCCDK1008200 C8n2 C206
FCCDK1008200 C8n2 C207
FCCDK1008200 C8n2 C208
FCCDK1008200 C8n2 C209
FCXCD2470000 470p C210
FCXCD2470000 470p C211
FCXCD2470000 470p C212
40-0251-0101 F11-08 AMIC24.xls 2 of 7
