Eclipse E-iSERV CD3100 Operation User manual

CD3100.doc
Instructions for the Steering Remote Controls on the ECLIPSE CD3100
1. Connection of Hardware (except Steering Remote connection)
1) Remove the factory radio.
2) Install the CD3100 (consult ECLIPSE technical support for assistance).
NOTE: At this point, only the main connector should be plugged into the CD3100 and
the CD3100 should not be completely installed.
2. Create a file on a CDR
1) Insert a blank CDR into a Windows OS computer.
2) Run your CD burner software and burn “XXXXXXX.ssw” into the root of the CDR.
(See “Steering Remote Table.pdf” to identify the correct SSW file name.)
3. Setting up the CD3100
1) Power up the CD3100.
2) Push and hold the “EQ/MENU” button.
3) Push “Up” or “Down” to scroll to “FUNC” and push “SEL” to select it.
Up EQ/MENU
SEL
Down
4) Push the “Up or the “Down” to scroll to “STEERING SW” and push “SEL” to select it.
5) The front panel automatically opens.
6) Insert the CDR created in section 2 into the CD slot.
7) The front panel automatically closes.
1

CD3100.doc
8) Wait until the “XXXXXXX.SSW” is displayed on the CD3100.
9) If more than 1 SSW files are on the CDR, choose the one to be used by pushing the
“Up or the “Down” to scroll.
10) Push the “SEL” buttonÆ“OK” is displayed.
11) Push the “SEL” to continue. Æ“READING” Æ“COMPLETED” will be displayed.
12) The CDR will be ejected automatically.
13) Push the “OPEN” to close the front panel.
14) Push “RTN” twice to return to the main screen.
4. Connection of Hardware (Steering Remote connection)
1) Power off (ACC-OFF) the CD3100.
2) Brown/Black wire (STEERING1) and Brown wire (STEERING2) of the CD3100 are to
be connected to remote control wires from the vehicle. See “Steering Remote
Table.pdf” for the details.
3) Power up the CD3100 and check the functions.
4) Complete the installation of the CD3100.
2
