Eclipse E-iSERV CD3200 User manual

E-iSERV Operation Guide
We appreciate your purchase of this CD receiver.
Please read through this manual for correct operation.
We suggest that after reading it you keep this manual
in a safe place for future reference.
CD/USB Multi-Source Receiver with Bluetooth
wireless technology

Motion Picture customization
Importing display data
Motion Picture Customize
Load the Display data in the USB memory or CD-R, which is downloaded from the E-iSERV
(website), to the main unit. For details of the operation, see ‘Importing display data (DISP Data)’
in the Owner’s Manual.
The application for creating Motion Picture screens (Cutting Board) can be downloaded, allowing
you to create your own original Motion Picture screens.
You can create your own file by downloading the cutting board application. You can download the
ready-made files from the server.
How to download the Motion Picture files
Download the Motion Picture from the E-iSERV website, and then write it to USB
memory or CD-R.
ATTENTION
<When using a USB memory drive>
• Data downloaded from the ECLIPSE website (E-iSERV) should be saved in folders on the USB
memory as follows:
(NOTE: in order for the system to properly recognize and load DISP data,
the user must create and name their folders as shown in the diagram below).
ECLIPSE
DISP
File extension
ZZZZZZZ.XXX
Must be created by user
Motion Picture .eld
• The main unit cannot be in USB music playing mode during this procedure.
<When using a CD-R>
• The main unit can only import files located in the root directory of the CD-R.
File extension
ZZZZZZZ.XXX
Motion Picture .eld
• Disc formats that may be used are as follows:
• CD-ROM (MODE 1)
• CD-ROM (MODE2_FORM 1)
* NOTE: CD-ROMs written in MODE2_FORM2 cannot be read.
• When data is imported from a CD-R, the importing process will take a long time if a lot of
data other than the import data has also been saved to the CD-R.
11

Load the downloaded data from the USB memory or CD-R to the unit. For details of
the operation, see 'Importing display data (DISP Data)' in the Owner's Manual.
22

Steering Remote Control
Importing steering remote data (U.S.A. only)
Steering Remote Control
The vehicle’s factory loaded steering remote becomes inoperable when the CD3200 is installed.
The ECLIPSE website (E-iSERV) provides software that enables steering remote operation even
with the installation of the main unit. Import this software into your CD3200.
How to operate the Steering Remote Control
Download the file for Steering Remote setting from the E-iSERV website, then write
it to USB memory or CD-R.
ATTENTION
<When using a USB memory drive>
• Data downloaded from the E-iSERV website should be saved to folders created in the USB
drive as shown below (NOTE: in order for the system to properly recognize and load steering
remote data, the user must create and name their folders as shown in the diagram below).
ECLIPSE
DATA
File extension
XXXXXXX.ssw Automatically generated filename
Must be created by user
• Files retrieved from the E-iSERV website are given automatically generated filenames upon download.
• The main unit cannot be in USB music playing mode during this procedure.
<When using a CD-R>
• The main unit can only import files located in the root directory of the CD-R.
File extension
XXXXXXX.ssw Automatically generated filename
• Disc formats that may be used are as follows:
• CD-ROM (MODE 1)
• CD-ROM (MODE2_FORM 1)
* CD-ROMs written in MODE2_FORM2 cannot be read.
• When data is imported from a CD-R, the importing process well take a long time if a lot
of data other than the import data has also been saved to the CD-R.
11

Load the downloaded data from the USB memory or CD-R to the unit. For details
of the operation, see ' Reading steering remote data (U.S.A. only) ' in the Owner's
Manual.
ATTENTION
• This function is available only for the vehicles that have steering remote with the voltage
detection type interface.
• For detail of the setting, please contact to ECLIPSE dealer.
22
