eControls WRC User manual

Wireless Remote Control
For Direct Damper Control User Manual
Model WRC
Made in USA
MENU
SET
Introduction
The WRC can control airflow from 1024 different wireless
dampers installed on ceiling diffusers or registers. Each
damper is programmed from the WRC with a Zone number
from 1 to 32 and an Address from 1 to 32. Typically, a single
WRC would control up to 32 different diffusers or dampers with
the same Address. If more than 32 diffusers need to be
controlled in a single building, work spaces or floors in that
building could be assigned to differentAddresses and another
WRC used for that floor or work space.
The actuator/damper can be digitally set to any airflow from
0% (fully closed) to 100% (fully open) using the WRC. The
remote remembers the setting for each zone when the zone is
selected.
ZONE
AIRFLOW
%
SEL
ENT
Up and Down keys for setting the
Airflow level, Zone number or Address.
Displays the selected zone
or damper number.
Displays the percent
of maximum airflow.
SEL key is used to select the
Zone or Address number
or program the damper Zone
and Address.
ENT key is used to enter or
save the selected Airflow, Zone or
Address number and send
data to the damper.
26945 Cabot Road, Bldg #101 / Laguna Hills, CA 92653 / 949-916-0945 Fax [phone]
www.eControlsUSA.com eControls

Selecting the Zone
Number
Press and release the SEL key and the LCD will show the
Zone number. Use the Up and Down keys to change the Zone
number, and press the ENT key. The new Zone number and
Airflow will be displayed. Zones or diffusers are numbered 1 to
32.
ZONE
Selecting the Address
Number
Select a unique address number corresponding to the
department, floor or building. Press and release the SEL key
twice and the LCD will show the Address number. Use the Up
and Down keys to select the Address, and press the ENT key.
ADR
ZONE
PRG DPR
Setting the Damper Zone
and Home Address
The WCD Damper Actuator must be programmed to receive
the remote commands corresponding to the selected Zone
and Address numbers. After selecting the Zone and Address
numbers as previously described, press the small pushbutton
switch on the WCD Damper Actuator. The LED will alternately
blink red and green. During the next 30 seconds, the Zone and
Address can be programmed into the WCD Damper Actuator.
Press and release the SEL key three times until PRG DPR
appears in the lower left corner of the LCD. Press the ENT key
and the WCD Damper will be programmed with the Zone and
Address number.
2
Adjusting Airflow
Low Battery Warning
After selecting the Zone number, press the Up and Down keys
to set the Airflow. Pressing the ENT key sends the new Airflow
setting to the WCD Damper.
When batteries are low, the display will show “Lob” and the
batteries should be changed. Lithium AAA batteries should be
used for longer life.
ZONE
AIRFLOW
%
Remove battery cover
and install two AAA batteries
as shown.
ZONE
AIRFLOW
%
3-Year Limited Warranty
This is a “Limited Warranty” which gives you specif rights. You may
have other rights which vary from state to state.
For a period of three years from the date of purchase, any malfunction
caused by factory defective parts or workmanship will be corrected at
no cost to you. See the complete Warranty at eControlsUSA.com.
