Ecoplus 1/10 HP User manual

Contents
INSTRUCTION MANUAL
Safety Information................................................................ 1
Features ................................................................................. 2
Specifications.....................................................................2-3
Installation..........................................................................4-5
Operation ............................................................................... 6
Cleaning & Storage.............................................................. 7
Troubleshooting .................................................................... 8
Parts List & Wiring Diagram.............................................. 9
Limited Warranty................................................................ 10
Thank you for purchasing an EcoPlus®Water Chiller!
To get the most out of your chiller and enjoy safe, reliable operation, please thoroughly read
and understand this Instruction Manual before operating. Please keep it for future reference.
WATER CHILLERS
1/10
HP
1/4
HP
1/2
HP
IMPORTANT: After unpacking (or accidental tipover)
allow chiller to stand upright for 20 minutes before starting.
®

Safety Information
1
To prevent injury to user, others and/or property damage, the following safety instructions must be
followed. Ignoring these instructions may cause harm or damage due to faulty operation.
Seriousness is indicated by the following symbols:
• Do not exceed the rating of the power circuit or share the outlet with other appliances.
• Do not start or stop the chiller by switching the power source on/off or by plugging or
unplugging the power cord.
• Always use the factory-installed 3-prong, grounded, polarized power plug and cord.
• Never attempt to operate chiller with a damaged or modified power cord.
• Do not insert or remove plug from outlet with wet hands or standing in water.
• Do not place chiller near a heat source, flammable materials or hazardous chemicals.
• Disconnect the power if strange sounds, smells or smoke come from the unit.
• Never attempt to take apart or repair the chiller yourself. Repairs must be done by factory
authorized service personnel.
• Before cleaning the chiller, always turn off the power and unplug the power cord.
• Do not drink or use any water drained from the unit.
WARNING!
Possible death or serious injury.
CAUTION
Possible injury or property damage.
WARNING!
• Do not install chiller in closets, cabinets or other small spaces.
• Do not place chiller where water may splash or leak onto the unit.
• Never cover the intake or exhaust openings with clothes, towels or other objects.
• Use extreme caution when operating near children, the elderly and infirm.
• Never insert fingers or foreign objects into ventilation grilles or other openings.
• Do not place heavy objects on the power cord or run it under carpets and rugs.
• Do not climb, sit or stand on the chiller, or place objects on top of it.
• Clean filter every two weeks, making sure it is installed securely.
• If water enters the chiller due to a leak or spill, turn it off and disconnect the power. Contact
a qualified service technician.
CAUTION

Your EcoPlus® Water Chiller incorporates the latest in refrigeration technology and manufacturing
techniques to ensure reliability and long service life. Some of these features include:
• Digital Control System for stable and accurate temperature control
• High efficiency energy use for economical operation
• Freon-free R134a refrigeration system that is safe and environmentally friendly
• Anti-corrosive, pure titanium evaporator
• Auto overcurrent protection system
• Retains settings if the unit is unplugged or in case of power outage (auto restart)
Features
Specifications
2
1/10 HP
42 Gal. (160L)
82˚F (28˚C)
61˚F (16˚C) 64˚F (18˚C)
61˚F (16˚C)
82˚F (28˚C) 82˚F (28˚C)
80 Gal. (300L) 132 Gal. (500L)
Max. Refrigerated Water Volume
Water Temp. Before Refrigeration
(Ambient Temp. 86˚F (30˚C)
Water Temp. After Refrigeration
Refrigeration Time (Hours)
NOTES:
1. Rate of flow is determined by several factors, including size of pump, height of chiller above water pump, size of tubing
and any kinks, clogs or other obstructions to water flow.
2. Performance tests were done with an ambient room temperature of 86˚F (30˚C), water temperature (before refrigeration)
of 82˚F (28˚C), and a total water volume of 42 gallons (160L) with 1/10 HP model; 80 gallons (300L) with 1/4 HP model;
and 132 gallons (500L) with 1/2 HP model (see Performance Curves on Page 4).
3. When the volume of water to be refrigerated is reduced and/or the water and ambient room temperatures are lower,
cooling rate and efficiency will be increased.
4. Refrigeration efficiency is determined according to the installation location, lighting, heat source(s), pump, filter and
other connecting parts. For greatest efficiency, EcoPlus®pumps and parts should be used.
5. If there is not enough air exchange in the room where chiller is installed, refrigeration efficiency may be reduced.
1/4 HP 1/2 HPModel
6.35 oz. (180g)
28.7 lbs. (13 Kg) 42.5 lbs. (19.3 Kg) 43.7 lbs. (19.8 Kg)
7.76 oz. (220g)
66 - 317 GPH
(250 - 1200 L/H)
15.75 x 8.58 x 16.34 in.
(400 x 218 x 415 mm)
17.13 x 11.61 x 18.5 in.
(435 x 295 x 470 mm)
18.1 x 12.6 x 23.43 in.
(460 x 320 x 595 mm)
264 - 660 GPH
(1000 - 2500 L/H)
317 - 793 GPH
(1200 - 3000 L/H)
9.17 oz. (260g)

PERFORMANCE CURVES
Models: 1/10 HP & 1/4 HP
Model: 1/2 HP
Ambient Temperature: 86˚F (30˚C) Water Temperature (before refrigeration): 82˚F (28˚C)
Total Water Volume: 1/10 HP – 42 Gal. (160L), 1/4 HP – 80 Gal. (300L)
Ambient Temperature: 86˚F (30˚C) Water Temperature (before refrigeration): 82˚F (28˚C)
Total Water Volume: 132 Gal. (500L)
WATER TEMPERATUREWATER TEMPERATURE
REFRIGERATION TIME (Hours)
REFRIGERATION TIME (Hours)
Specifications
3
NOTE: Lower water volumes will result in faster temperature drops.
86.0 / 30
84.2 / 29
82.4 / 28
80.6 / 27
78.8 / 26
77.0 / 25
75.2 / 24
73.4 / 23
71.6 / 22
69.8 / 21
68.0 / 20
66.2 / 19
64.4 / 18
62.6 / 17
60.8 / 16
59.0 / 15
86.0 / 30
84.2 / 29
82.4 / 28
80.6 / 27
78.8 / 26
77.0 / 25
75.2 / 24
73.4 / 23
71.6 / 22
69.8 / 21
68.0 / 20
66.2 / 19
64.4 / 18
˚F / ˚C
˚F / ˚C

DO NOT install outdoors.
Operate only on
a flat, stable,
horizontal surface.
Avoid banging or shaking.
Clearance: allow at least 8” (20cm)
in front; 16” (40cm) in rear.
Do not knock the chiller over or turn it upside down – this may cause
damage to the refrigeration system. If unit is
tipped or knocked over, turn the power OFF.
Set the unit upright and level again and
wait 20 minutes before switching it back on.
Never cover during operation.
Installation
4
Please DO NOT dispose of any packaging until you have checked that all parts are included and
the chiller is operational. In the unlikely event of missing parts or damage, contact the retailer
where you purchased the unit immediately. Do not leave children unattended with the chiller or
packaging. Disposal of all materials must be carried out responsibly, safely and recycled
wherever possible.
• Provide a grounded power outlet and circuit to be used only for the chiller (any electrical work
must be done by a qualified electrician).
• Power source must conform to the power requirements specified on the product nameplate.
• ALWAYS disconnect the power supply when installing or cleaning the chiller.
Package Contents:
• 1 Chiller Unit
• 1 Instruction Manual
• 4 Inlet/Outlet Adapters with Nuts and Rubber Seals
• 1 Spare Fuse
Keep out of direct sunlight
and away from flammable
materials, moisture,
dust and any heat
source.
UNPACKING THE CHILLER
INSTALLING THE CHILLER
IMPORTANT!
For best results and safest operation, install the chiller indoors in a well ventilated location.
8 in
(20cm)
16 in
(40cm)

Installation
5
Required pump size depends on chiller model, water volume and rate of circulation. Recommended
pump sizes for effective water chilling are within the following ranges:
CHOOSING THE CORRECT EXTERNAL PUMP
Water level inside the reservoir is correct and there are no leaks in any hoses or connections.
Power supply is correct and the plug is inserted completely into the outlet.
 Double-check the whole system to make sure there are no breaks or clogs.
For the most effective water cooling and energy efficiency, locate chiller below water level. If chiller
must be placed above reservoir level, make sure height above pump does not exceed 26 ft. (8m).
For best performance, keep hoses as short as possible. The sum of all hose lengths should not
exceed 25 ft. (7.6m).
TYPICAL INSTALLATION
This chiller does NOT have an internal pump for system circulation.
An appropriately sized external pump is required.
1/10 HP
1/4 HP
1/2 HP
66 - 317 GPH (250 - 1200 LPH)
264 - 660 GPH (1000 - 2500 LPH)
317 - 793 GPH (1200 - 3000 LPH)
42 (160)
80 (300)
132 (500)
Max. Reservoir Volume
Gallons (Liters)
Rate of Circulation – Pump Size
Gallons Per Hour (Liters Per Hour)
Reservoir
Chiller Pump
(separate from nutrient pump)
Chiller
Hose
Adapter
Nut
Seal
Chiller
WATER
LEVEL
Chilled water return
IMPORTANT! Always check the following before starting chiller:
Chiller
Model
FITTING
CONNECTION

SPECIAL FUNCTIONS AND PROTECTION DEVICES
• Temp. Display Adjustment: If necessary, the display of actual water temperature can
be adjusted 2.4˚F (1.5˚C) up or down. Press the UP and DOWN keys at the same time for
6 seconds until the numerical display flashes. Then, press the UP or DOWN keys to adjust.
• Compressor Protection: If the compressor somehow becomes overloaded, a protection
device will automatically shut it off, then attempt a restart after about 3 minutes.
• Sensor Circuit Protection: If the water temperature sensor has an open or broken circuit,
the chiller will shut down and a “P1” or “P2” error message will be displayed.
Operation
6
USING THE DIGITAL CONTROL PANEL
Setting Water Temperature: To enter a temperature setting, press the SET button and hold
for more than 3 seconds. The previously set temperature will appear on the display. Press the UP
or DOWN key to enter a new temperature setting from 37-90˚F (3-32˚C). To accept, press the SET
button again (or just wait about 8 seconds and it will automatically store your new setting and
revert to normal operation). The actual water temperature displays continuously while the chiller
is working. To Compare Actual and Set Water Temperatures: Press the SET button once. The set
temperature will appear, alternating with a display of the actual water temperature (when actual
water temperature is displayed the “Cooling” indicator light goes OFF – when the set
temperature is displayed the same indicator FLASHES).
Automatic Temperature Control: When the compressor stops for over 3 minutes and water
temperature rises 1˚F above the set temperature, the chiller will automatically restart. Once the
set water temperature is reached, the “Cooling” indicator light will go off and the compressor
will stop. NOTE: The “Cooling” indicator light will also flash if any protection device (see below)
is activated for at least 3 minutes.
SET UP
DOWN
3-Digit Temperature Display
“Cooling” Indicator Light
Temperature Adjustment Buttons

Cleaning & Storage
7
CLEANING THE CHILLER
STORING THE CHILLER
For safe, efficient operation and long service life, it is essential to regularly clean the chiller and all
hoses, connections and other components in the system in which it is installed. Thorough cleaning
is recommended every 1-2 months, including:
• Rinse collected debris from filters, external reservoir pump, all inlet and outlet connections,
hoses, etc., with clear, lukewarm water. Soap, detergent or bleach is NOT recommended because
any remaining residues can contaminate the nutrient solution. The chiller housing, digital
control panel, power switch and other external surfaces must be cleaned with a soft, dry cloth.
NEVER immerse the chiller in water or spray it down with a hose!
• Clean air filters every 2 weeks:
1. Loosen screw on front cover, turning counterclockwise (Fig. 1).
2. Gently pull cover toward you to remove (Fig. 2).
3. Loosen screws on attached filter and remove (Fig. 3 & 4).
4. Lift bottom clips and pull out to remove side filters (Fig. 5 – 1/4 & 1/2 HP Models only).
5. Loosen screws on attached filters and remove (Fig. 6 & 7)
6. Remove dust with a brush or vacuum cleaner, or rinse well in lukewarm water (Fig. 8).
Make sure filters are thoroughly DRY before reinstalling them.
Disconnect chiller from the system. Gently tilt the unit to drain water out through the inlet and
outlet connections. DO NOT INVERT CHILLER TO DRAIN! Clean and dry filters, wipe down external
surfaces with a soft cloth, cover with plastic bag, insert into carton and store in a safe, dry place.
Always make sure unit is unplugged before performing any cleaning!

Troubleshooting
8
Before calling service, check the troubleshooting chart
below for solutions to the most common problems.
Chiller doesn’t run
Display is blank
Water not cooling
enough (or not
at all)
Compressor runs normally,
but fan stops running and
unit can’t dissipate heat
Water temperature setting
is too high
Lower water temperature
setting
Air filters are clogged
with dust
Clean air filters as directed
on Page 7
Fan may need to be replaced
by qualified service personnel
Unit is noisy
and/or rattles
Not enough refrigerant
Total water volume too high Reduce water volume
Have qualified personnel
replenish refrigerant
Fuse has blown
Not plugged all the way in
Connected to wrong
voltage and frequency
Protection device
has been activated
Chiller keeps
turning itself
on and off B. Check ventilation around unit.
If heat is not accumulating,
wait 3 minutes and unit will
automatically restart
Change fuse
SOLUTION

Parts List & Wiring Diagram
9
1. Digital Control Panel Enclosure
2. Circuit Board
3. Enclosure Back Cover
4. Water Inlet & Outlet Adapters
5. Nut
6. Housing
7. Handle
8. Condenser
9. Fan
10. Compressor
11. Base
12. Power Switch
13. Power Input
14. Fuse
15. Water Temp. Sensor
16. Water Tank
17. Intake Air Filter
18. Front Cover
PARTS LIST
WIRING DIAGRAM
1/10 HP Model Shown

Limited Warranty
10
Sunlight Supply,®Inc. One-Year Limited Warranty: The EcoPlus® Chiller covered in this manual is
warranted under normal use for one year after purchase date. Any part determined defective in material or
workmanship can be returned to an authorized service location designated by Sunlight Supply, shipping
prepaid, and will be repaired or replaced at the option of Sunlight Supply.
Limitation of Liability: To the extent allowable under applicable law, Sunlight Supply’s liability for
consequential and incidental damages is expressly disclaimed. Sunlight Supply’s liability in all events is limited
to and shall not exceed the purchase price paid.
Warranty Disclaimer: Sunlight Supply provides product information in this literature for the sole purpose of
identification, and does state or imply that the products are merchantable or fit for a particular purpose, or that
the products will conform to the descriptions.
Product Suitability: Many jurisdictions have codes and regulations governing sales, construction, installation
and/or use of products for certain purposes, which may vary from those in neighboring areas. While Sunlight
Supply attempts to assure that its products comply with such codes, it cannot guarantee compliance, and cannot
be responsible for how the product is installed or used. Before purchase and use of a product, review the
product applications, and all applicable national and local codes and regulations, and be sure that the product,
installation, and use will comply with them.
Your EcoPlus® Chiller from Sunlight Supply,® Inc. is covered for one (1) full year against manufacturer defects.
The warranty information below must be filled out and mailed back with a copy of the purchase receipt for
warranty to be in effect. Abuse, neglect, misuse or mis-application of the product will void the warranty.
Select Power Model: 1/10 HP 1/4 HP 1/2 HP
EcoPlus® Chiller / /
_____________________________________________________________________________________________________________________________
PRODUCT NAME SERIAL NUMBER DATE OF PURCHASE
_____________________________________________________________________________________________________________________________
NAME
_____________________________________________________________________________________________________________________________
ADDRESS
_____________________________________________________________________________________________________________________________
CITY / STATE/ ZIP
( )
_____________________________________________________________________________________________________________________________
PHONE EMAIL ADDRESS
Where purchased:
_____________________________________________________________________________________________________________________________
STORE NAME
WARRANTY REGISTRATION FORM
Mail this Product Registration Form within 15 days of purchase to:
Sunlight Supply,®Inc., EcoPlus® Warranty Dept.
5408 NE 88th Street - Bldg A, Vancouver WA 98665 USA
Detach and return

DO NOT dispose of this product in the trash, on the landscape
or into any unsorted waste stream! It may contain hazardous
substances that can leach into groundwater and find their way
into the food chain. This unit contains VALUABLE RESOURCES
that are easy to recycle and re-use. Services available
may include:
PLEASE BE RESPONSIBLE
A. Municipal Collection Systems: Most cities and towns have recycling
programs where electronic waste can be turned in for recycling
free of charge.
B. Retailer Return: When buying a new product, many retailers will take back
an old product free of charge.
C. Manufacturer Return: Many manufacturers accept old products for
recycling free of charge.
D. Scrap Dealers: Many scrap dealers will buy old electronics or take them
free of charge.
www.ecoplususa.com
®
