Aqua Cooler H2O NOW User manual

1
H2ONOW –CHILLER
Usage and Care Manual

2
Product Diagram: (Metal version and Plastic version)

3
Technical Specifications
Important Safety Instructions
When using electrical appliances, basic safety precautions should be followed to reduce the
risk of fire, electric shock, and injury to persons or property. Read all instructions before using
any appliance.
Keep combustible material such as furniture, bedding, pillows, clothes, and/or papers
away from the back of the unit.
Do not operate this, or any other appliance, with a damaged power cord.
No other appliance should be plugged into the same outlet. Be sure that the plug is
fully inserted into the outlet.
Do not run the power cord over carpeting or other heat insulators.
Do not cover the power cord.
Keep the power cord away from high traffic Areas
Do not submerge the power cord in water.
We do not recommend the use of extension cords as they may overheat and cause a
risk of fire.
Exercise caution and use reasonable supervision when the appliance is used by or
near children.
Do not use this product to dispense anything other than water.
If the supply cord is damaged, the manufacturer, one of its service agents or a
similarly qualified person must replace it in order to avoid a hazard.

4
Remove power plug or disconnect from the main power source before servicing the
appliance.
Warranty will also be voided if installation is not carried out as detailed in this
instruction manual.
Important Information About Grounding
To provide additional protection from the risk of shock, this unit MUST be connected
to a residual current device (RCD) outlet at all times. Use of an extension cord will
void any warranties.
This appliance must be grounded. Improper use of the grounding plug can result in a
risk of electric shock, causing serious injury and possibly death.
This appliance is equipped with a power cord having a grounding wire with a
grounding plug and must be connected into a properly-grounded, polarised outlet.
Consult a qualified electrician if the grounding instructions are not completely
understood, or if doubt exists as to whether the appliance is properly grounded
Do not under any circumstances cut or remove the third (ground) prong from the
power cord plug. Do not use an adapter plug with this appliance.
Installation Instructions
Important information about the unit and operation:
1. The underbench chiller is not intended for outdoor use.
2. All service work to be carried out by authorised Aqua Cooler service agents only.
Failure to do so will void the warranty on the water cooler.
3. Warranty will also be voided if installation is not carried out as detailed in the Aqua
Cooler installation instructions.
4. Please ensure the chiller is not tilted during transportation. If the chiller is tilted,
please leave the chiller in upright position for at least 30 minutes before turning on
the chiller.
5. If the power cord is unplugged, please wait for at least 3 minutes to re-plug the power
cord to prevent initiating the overload protector of compressor.
6. The compressor motor is equipped with an automatic reset protector which will
disconnect the motor from the line in case of an overload.
Unpacking the water fountain:
1. Place the machine on a hard, flat surface. Make certain the unit is level. The unit
should not be close to sources of heat otherwise performance may be affected.
2. Please inspect the carton and water cooler for evidence of rough handling and
concealed damage. Damage claims should be filed with the carrier.

5
Connecting the fountain to mains water supply:
The installation must be in accordance with AS/NZS 3500.1 and AS/NZS 3500.2.
Aqua Cooler recommends this process is performed by qualified personnel only.
1. Ensure power is switched off, the unit should not be turned on until the internal tank
is full.
2. Refer to photo on the next page for parts assembly example.
3. Ensure proper ventilation by allowing 50mm clearance on each side of the cooler.
4. The unit is supplied with a mains pressure relief valve and a shut off valve which must
be installed in between the mains water supply source and the underbench chiller
“water inlet” fitting.
5. Minimum water pressure is 100 kpa and maximum is 700 kpa. The recommended
maximum water inlet temperature is 38°C.
6. Please note this unit is fitted with a waste drain and connection to the mains water
drainage system is required.
7. Check the available power supply against the underbench chiller data plate to assure
correct electrical service. Be sure that the plug is fully inserted into the grounded
outlet and that no other appliance is plugged into the same outlet.
8. Connect the mains water to the underbench chiller via 1/4” pipe, ensuring that the
supplied mains pressure relief valve is placed inline between the mains water source
and the water chillers water inlet fitting. We recommend a shut off valve or similar is
installed between the mains water pipework and the pressure limiting valve.
9. Connect the chilled water to the faucet (sold separately) from the water outlet
connection on the underbench chiller to the inlet point connection of the faucet,
please refer to your chosen faucet details for further information.
10. Turn on water supply, ensuring you turn your faucet on to purge the system of air
until a steady stream of water appears from your faucet. Continue to flush fresh
water through the system for 5 minutes.
11. Turn on the thermostat to desired coldness and wait for the water to chill down for
the first time.
12. For models equipped with faucet or glass filler, please assemble the faucet or glass
filler by placing the neck onto the desired position of the sink.
13. Check all connections for water leaks.
Removing from service:
1. Disconnect the power supply cord.
2. Disconnect the water supply.
3. Disconnect the faucet from unit. Refer to your faucet instructions for further
information.
4. Drain the reminding water inside the reservoir.

6
Maintenance:
1. The only maintenance operation required is the removal of dirt and lint from the
condenser. Inspection should be made at 3 month intervals.
2. Disconnect the power supply.
3. Clean the condenser with a small stiff non-wire brush.
4. The unit is equipped with a hermetically sealed compressor and requires no
additional lubrication.
5. The fan motor on this unit seldom needs oiling. If required, a few drops of SAE 10 oil
should be used
6. Aqua Cooler recommends the water fountain is cleaned every month, ensuring there
is no blockage in the condenser or in the back of the unit. Please remove all
potentially harmful factors to prevent any scratch or damage to the unit.
7. If customers require the unit’s spare parts information, please contact the Aqua
Cooler Service Department for further assistance.
H2O Now - Chiller Parts Assembled:

7
Marks
The appliance is complying with applicable ACMA regulatory arrangements (Regulatory Compliance
Mark) and WaterMark WMTS 105:2016.
Trouble Shooting
If you need any assistance with troubleshooting please call Aqua Cooler service department
on 1800 AQUA COOLER or [phone] or email [email protected]
1. No water flowing out of the glass filler or faucet
Possible Reasons Solutions
Mains water is not available Check the mains water to the building is still
available. Check there is no isolation valves
on the plumbing pipework that has been
closed off preventing water being provided
to the chiller.
The faucet is faulty and is not letting
water through
Check with your faucet instructions on how
to troubleshoot a faulty faucet
2. Water is not cold
Possible Reasons Solutions
The cooling thermostat is turned
off
Turn on the mechanical thermostat controller to
desired coldness by turning the knob to “cold”
Power failure Check if the power cord is properly plugged in or
if there is power outage
Cooling system failure Please turn off the cooler and water supply. Call
technical service for detailed inspection.

8
Spare Part List
No Specifications Qua
ntity Code No Specifications Qua ntity Code
1 Nut 2 H2OPC-SP1 11 Floor plate 1 H2OPC-SP11
2 Frame 1 H2OPC-SP2 12 Mat 4 H2OPC-SP12
3 Dust-proof
net 1 H2OPC-SP3 13 Front panel 1 H2OPC-SP13
4 Compressor 1 H2OPC-SP4 14 knob 1 H2OPC-SP14
5 Cold
thermostat 1 H2OPC-SP5 15 The ship type switch 1 H2OPC-SP15
6 Hang plate 1 H2OPC-SP6 16 Rear panel 1 H2OPC-SP16
7 Indicator light 1 H2OPC-SP7 17 Power Plug 1 H2OPC-SP17
8 Cold tank 1 H2OPC-SP8 18 The motor fan 1 H2OPC-SP18
9 Evaporator 1 H2OPC-SP9 19 Dryer 1 H2OPC-SP19
10 Plug 1 H2OPC-SP10 20 Condenser 1 H2OPC-SP20
Exploded Diagram
