Ecorack E-cart User manual

IMPORTANT WARNING: All vehicular transports are potentially hazardous. Any person(s) using EcoRack products are personally responsible

for following the given directions for use and/or installation and accepts full responsibility for any and all damages or injury of any kind including

death, which may result from their use and/or installation.

It is critical that all EcoRack racks and accessories be properly and securely attached to your vehicle. Improper attachment could result in a serious

accident, and could cause serious bodily injury or death to you or to others. You are responsible for securing the racks and accessories to your car,

checking the attachment’s prior to use, and periodically inspecting the products for adjustment, wear, and damage.

You must read and understand all of the instructions and cautions supplied with your EcoRack products(s) prior to installation or use. If you do not

understand all of the instructions and cautions, or, if you have no mechanical experience and are not thoroughly familiar with the installation

procedures, you should have the product installed by a professional installer.

MISE EN GARDE IMPORTANTE: Tout transport d’un chargement sur le toit d’un véhicule est potentiellement dangereux. Une personne qui

utilise les produits EcoRack doit suivre sans faute les instructions d’installation et d’utilisation fournies et assume l’entière responsabilité pour

tout dommage ou toute blessure, y compris un décès, pouvant résulter d’une telle installation ou utilisation.

Il est essentiel de xer correctement et solidement les supports et les accessoires à votre véhicule. Une mauvaise installation ou attache pourrait

provoquer un accident, entraîner des blessures corporelles graves à vous et aux autres et même causer la mort. Vous avez la responsabilité de

xer solidement les supports et les accessoires à votre véhicule, de vérier l’installation avant l’utilisation et d’inspecter périodiquement le produit

pour déceler tout signe d’usure ou de dommage ou tout problème d’ajustement.

Vous devez lire et comprendre les instructions et les mises en garde fournies avec les produits EcoRack avant l’installation et l’utilisation. Si vous

ne comprenez pas les instructions et les mises en garde ou si vous ne possédez pas d’expérience en mécanique et ne connaissez pas à fond les

procédures à suivre d’installation, vous devriez faire monter et poser le produit par un installateur professionnel.

EcoRack

Transport Systems

Kayak Carrier

E-CART

2018

ER509

EcoRack

Transport Systems

Kayak Carrier

-CART

MALONE

DownLoaderDownLoaderTM

J-STYLE FOLDING KAYAK CARRIER

12’ Safety LinesJawz Universal Adapters Mounting BoltsKayak Carriers Load Straps T-Knobs

60mm

70mm

Installation & Loading Instructions - Please Read Before Beginning

Veuillez lire les instructions avant d’entreprendre l’installation et le chargement

. Insert Mounting Bolt through one hole of a Jawz adapter.

Insert washer and loosely apply a T-knob. See image 2.

. Faites passer le boulon de fixation dans l’un des trous

d’un adaptateur Jawz puis vissez légèrement un bouton

en ‘‘T’’ à la base du boulon. (Figure 2)

. Prior to installation, insert a bolt into the mounting holes in

the bottom of the carriers. Push upward to open the two

mounting hole covers located in the Base pads.

. Insert a Mounting Bolt into one mounting hole from the top

side. Rotate and close the mounting hole cover.

See image 1.

. Insérez un boulon de fixation dans l’un des trous hexagonaux

situés sur le côté supérieur du support.

(Figure 1)

. Place the carrier onto the front cross bar with the boarding

ramp facing out. Swing the Jawz under the cross bar as

shown. See image 3.

. Placez le support sur la barre transversale avant, la rampe

de chargement vers l’extérieur. Faites passer l’adaptateur

Jawz sous la barre transversale, tel qu’indiqué. (Figure 3)

Mounting Bolt Washers

Base Pad

Covers

KAYAK & CANOE CART

CLIPPERCLIPPER

MALONE

Assembly & Loading Instructions - Please Read Before Beginning

Veuillez lire les instructions avant de débuter l’assemblage et le chargement

Strap #2

Courroie #2

Strap#1

Courroie #1

Frame

Cadre

Retainer Pin (2)

Goupilles de retenue (2)

Tires (2)

Pneus (2)

. Insert retainer pin through axle. Fold the ring over

the end of the axle to lock. Repeat Step 1 and 2 for

second wheel. See image 2.

. Insérez la goupille de retenue dans l’axe. Repliez

l’anneau sur l’extrémité de l’axe afin de le verrouiller.

Répétez les étapes 1 et 2 pour la deuxième roue.

(Figure 2)

. Install wheel to axle.

See image 1.

. Installez la roue à l’axe de façon à ce que la tige de soupape

pointe vers l’extérieur.

(Figure 1)

. Prepare the cart for the boat by opening the frame (A)

and deploying the kick stand (B). See image 3.

. Préparez le chariot en ouvrant le cadre (flèche A) et en

déployant la béquille (flèche B). (Figure 3)

MPG502

EcoRack

Transport Systems

Kayak Carrier

E-CART

EcoRack

Transport Systems

Kayak Carrier

-CART

Frame

Cadre

Strap (1) Courroie (1)

Tires(2)

Pneus(2)

EcoRack

Transport Systems

Kayak Carrier

E-CART

Instructions d’assemblage et de chargement – Chariot Deluxe MPG502

Assembly & Loading Instructions - MPG502 Deluxe Cart

MALONE

. Pull the free end until the knot is tight.

See image 5.

. Tirez sur le bout plat de la courroie

jusqu’à ce que le nœud soit bien serré.

(Figure 5)

. Using Strap #1, dress the free end of the strap

around the frame tube and through the loop.

See image 4.

. Passez le bout plat de la courroie #1 autour du

cadre du chariot, puis glissez-le dans la boucle.

(Figure 4)

. Using Strap #2, dress the buckle end of the strap

around the opposite frame tube and through the

loop. Pull the buckle end until the knot is tight.

See image 6.

. Passez la courroie #2 autour du cadre du côté

opposé du chariot, puis glissez-la dans la boucle.

Tirez sur l’extrémité de la courroie afin de serrer le nœud.

(Figure 6)

. Locate Straps #1 and #2 outside of the frame

so that when the boat is loaded, the straps

will be out of the way. See image 7.

. Assurez-vous que les courroies #1 et #2 soient

à l’extérieur du cadre afin que celles-ci soient

libres une fois l’embarcation chargée.

(Figure 7)

Dress the free end of the load strap around the

forward facing frame tube as shown. See image

Faire passer l’extrémité libre de la sangle

autour du tube de cadre orienté vers l’avant.

Voir image 4.

Pull until even and lay strap to side.

See image 5

Tirer jusqu’à égalité et étendre la sangle sur le

côté. Voir image 5.

Place the boat on the cart approximately two-

thirds of the way back. See image 6

Mettre l’embarcation sur le chariot environ aux deux tiers

vers l’arrière. Voir image 6.

Bring load strap over boat and dress free end

around frame tube as shown. See image 7

Ramener la sangle sur l’embarcation et faire

passer l’extrémité libre autour du tube de

cadre. Voir image 7.

EcoRack

Transport Systems

Kayak Carrier

E-CART

Instructions d’assemblage et de chargement – Chariot Deluxe MPG502

Assembly & Loading Instructions - MPG502 Deluxe Cart

MALONE

. Pull the free end until the knot is tight.

See image 5.

. Tirez sur le bout plat de la courroie

jusqu’à ce que le nœud soit bien serré.

(Figure 5)

. Using Strap #1, dress the free end of the strap

around the frame tube and through the loop.

See image 4.

. Passez le bout plat de la courroie #1 autour du

cadre du chariot, puis glissez-le dans la boucle.

(Figure 4)

. Using Strap #2, dress the buckle end of the strap

around the opposite frame tube and through the

loop. Pull the buckle end until the knot is tight.

See image 6.

. Passez la courroie #2 autour du cadre du côté

opposé du chariot, puis glissez-la dans la boucle.

Tirez sur l’extrémité de la courroie afin de serrer le nœud.

(Figure 6)

. Locate Straps #1 and #2 outside of the frame

so that when the boat is loaded, the straps

will be out of the way. See image 7.

. Assurez-vous que les courroies #1 et #2 soient

à l’extérieur du cadre afin que celles-ci soient

libres une fois l’embarcation chargée.

(Figure 7)

Instructions d’assemblage et de chargement – Chariot Deluxe MPG502

Assembly & Loading Instructions - MPG502 Deluxe Cart

MALONE

. Pull the free end until the knot is tight.

See image 5.

. Tirez sur le bout plat de la courroie

jusqu’à ce que le nœud soit bien serré.

(Figure 5)

. Using Strap #1, dress the free end of the strap

around the frame tube and through the loop.

See image 4.

. Passez le bout plat de la courroie #1 autour du

cadre du chariot, puis glissez-le dans la boucle.

(Figure 4)

. Using Strap #2, dress the buckle end of the strap

around the opposite frame tube and through the

loop. Pull the buckle end until the knot is tight.

See image 6.

. Passez la courroie #2 autour du cadre du côté

opposé du chariot, puis glissez-la dans la boucle.

Tirez sur l’extrémité de la courroie afin de serrer le nœud.

(Figure 6)

. Locate Straps #1 and #2 outside of the frame

so that when the boat is loaded, the straps

will be out of the way. See image 7.

. Assurez-vous que les courroies #1 et #2 soient

à l’extérieur du cadre afin que celles-ci soient

libres une fois l’embarcation chargée.

(Figure 7)

Instructions d’assemblage et de chargement – Chariot Deluxe MPG502

MALONE

. Place the boat on the cart so that the weight is

slightly forward of center. See image 8.

. Positionnez l’embarcation sur le chariot de façon

à ce que son poids soit légèrement vers l’avant par

rapport à son centre. (Figure 8)

Assembly & Loading Instructions - MPG502 Deluxe Cart

. Retract the kickstand for transport. See image 10.

. Repliez la béquille lors du transport. (Figure 10)

Forward of

center

. As the weight of the boat is lowered, the cart

will shift position and the kickstand will be

elevated for easy access. See image 9.

. Sous le poids de l’embarcation, le chariot

s’inclinera légèrement vers l’avant. La béquille

se soulèvera afin que vous puissiez y accéder

facilement. (Figure 9

. Dress the free end of Strap #1 up and through

the buckle of Strap #2. Pull the free end to

tighten the cart to the boat. See image 11.

. Glissez le bout plat de la courroie #1 dans la

boucle de la courroie #2. Tirez sur le bout plat

de la courroie afin de fixer l’embarcation au

chariot. (Figure 11)

Retract

Kickstand

Positionnez

l’embarcation

légèrement

vers l’avant.

Repliez la

béquille lors

EcoRack

Transport Systems

Kayak Carrier

E-CART

EcoRack

Transport Systems

Kayak Carrier

E-CART

Bring load strap back up and through the cam

buckle. See image 8

Ramener la sangle vers le haut et l’insérer dans la

boucle à came. Voir image 8.

Pulling downward to tighten fully, tuck any

excess strap out of the way, so not to roll over

it. See image 9

Tirer vers le bas pour bien serrer. Rentrer la

partie de sangle en trop pour ne pas rouler sur

elle. Voir image 9.

Retract the kickstand for transport. See image 10

Désengager la béquille pour le transport. Voir

image 10.

You are now ready to portage your kayak. See

image 11

Vous êtes maintenant prêt pour le portage du

kayak. Voir image 11.

1111

Instructions d’assemblage et de chargement – Chariot Deluxe MPG502

Assembly & Loading Instructions - MPG502 Deluxe Cart

MALONE

. Pull the free end until the knot is tight.

See image 5.

. Tirez sur le bout plat de la courroie

jusqu’à ce que le nœud soit bien serré.

(Figure 5)

. Using Strap #1, dress the free end of the strap

around the frame tube and through the loop.

See image 4.

. Passez le bout plat de la courroie #1 autour du

cadre du chariot, puis glissez-le dans la boucle.

(Figure 4)

. Using Strap #2, dress the buckle end of the strap

around the opposite frame tube and through the

loop. Pull the buckle end until the knot is tight.

See image 6.

. Passez la courroie #2 autour du cadre du côté

opposé du chariot, puis glissez-la dans la boucle.

Tirez sur l’extrémité de la courroie afin de serrer le nœud.

(Figure 6)

. Locate Straps #1 and #2 outside of the frame

so that when the boat is loaded, the straps

will be out of the way. See image 7.

. Assurez-vous que les courroies #1 et #2 soient

à l’extérieur du cadre afin que celles-ci soient

libres une fois l’embarcation chargée.

(Figure 7)

Instructions d’assemblage et de chargement – Chariot Deluxe MPG502

Assembly & Loading Instructions - MPG502 Deluxe Cart

MALONE

. Pull the free end until the knot is tight.

See image 5.

. Tirez sur le bout plat de la courroie

jusqu’à ce que le nœud soit bien serré.

(Figure 5)

. Using Strap #1, dress the free end of the strap

around the frame tube and through the loop.

See image 4.

. Passez le bout plat de la courroie #1 autour du

cadre du chariot, puis glissez-le dans la boucle.

(Figure 4)

. Using Strap #2, dress the buckle end of the strap

around the opposite frame tube and through the

loop. Pull the buckle end until the knot is tight.

See image 6.

. Passez la courroie #2 autour du cadre du côté

opposé du chariot, puis glissez-la dans la boucle.

Tirez sur l’extrémité de la courroie afin de serrer le nœud.

(Figure 6)

. Locate Straps #1 and #2 outside of the frame

so that when the boat is loaded, the straps

will be out of the way. See image 7.

. Assurez-vous que les courroies #1 et #2 soient

à l’extérieur du cadre afin que celles-ci soient

libres une fois l’embarcation chargée.

(Figure 7)

MALONE

. For severe terrain transport, a second load

strap (not provided) attached to the forward

frame tubes may be required.

See image 13.

. Si vous transportez l’embarcation sur un

terrain présentant de nombreux obstacles,

vous pourriez devoir attacher une deuxième

courroie (non comprise) aux tubes avant

du cadre. (Figure 13)

. Lift the front of the boat and pull forward to

transport. See image 12.

. Lors du transport, soulevez la partie avant

de l’embarcation, puis tirez. (Figure 12)

. Disassemble the cart for convenient storage in the

canoe or kayak. See image 14.

. Une fois démonté, le chariot peut être entreposé à

l’intérieur du canot ou du kayak. (Figure 14)

CAUTION:

1. Do not tow with any motorized vehicle.

2. Do not carry passengers in boat during transport.

AVERTISSEMENT :

1. Ce chariot n’est pas conçu pour être remorqué à l’aide d’un véhicule

motorisé.

2. Aucun passager ne doit se trouver à l’intérieur de l’embarcation lors

de son transport.

Assembly & Loading Instructions - MPG502 Deluxe Cart

Always check wheels, hardware and load straps for proper and secure attachment before transport. Use of this

product for any other application other than canoe or kayak transport voids warranty.

Assurez-vous que les roues, la quincaillerie et les courroies soient bien attachées avant d’entreprendre le transport

de votre embarcation. L’usage de ce produit à des fins autres que le transport d’un kayak ou d’un canot en annule la garantie.

MALONE AUTO RACKS, 81 County Road, Westbrook, Maine 04092

Phone: 207-774-9100 Fax: 207-615-0551

Website: www.maloneautoracks.com Email: technical@maloneautoracks.com

Instructions d’assemblage et de chargement – Chariot Deluxe MPG502

EcoRack

Transport Systems

Kayak Carrier

E-CART

EcoRack

Transport Systems

Kayak Carrier

E-CART

rear

Instructions d’assemblage et de chargement – Chariot Deluxe MPG502

Assembly & Loading Instructions - MPG502 Deluxe Cart

MALONE

. Pull the free end until the knot is tight.

See image 5.

. Tirez sur le bout plat de la courroie

jusqu’à ce que le nœud soit bien serré.

(Figure 5)

. Using Strap #1, dress the free end of the strap

around the frame tube and through the loop.

See image 4.

. Passez le bout plat de la courroie #1 autour du

cadre du chariot, puis glissez-le dans la boucle.

(Figure 4)

. Using Strap #2, dress the buckle end of the strap

around the opposite frame tube and through the

loop. Pull the buckle end until the knot is tight.

See image 6.

. Passez la courroie #2 autour du cadre du côté

opposé du chariot, puis glissez-la dans la boucle.

Tirez sur l’extrémité de la courroie afin de serrer le nœud.

(Figure 6)

. Locate Straps #1 and #2 outside of the frame

so that when the boat is loaded, the straps

will be out of the way. See image 7.

. Assurez-vous que les courroies #1 et #2 soient

à l’extérieur du cadre afin que celles-ci soient

libres une fois l’embarcation chargée.

(Figure 7)

Instructions d’assemblage et de chargement – Chariot Deluxe MPG502

Assembly & Loading Instructions - MPG502 Deluxe Cart

MALONE

. Pull the free end until the knot is tight.

See image 5.

. Tirez sur le bout plat de la courroie

jusqu’à ce que le nœud soit bien serré.

(Figure 5)

. Using Strap #1, dress the free end of the strap

around the frame tube and through the loop.

See image 4.

. Passez le bout plat de la courroie #1 autour du

cadre du chariot, puis glissez-le dans la boucle.

(Figure 4)

. Using Strap #2, dress the buckle end of the strap

around the opposite frame tube and through the

loop. Pull the buckle end until the knot is tight.

See image 6.

. Passez la courroie #2 autour du cadre du côté

opposé du chariot, puis glissez-la dans la boucle.

Tirez sur l’extrémité de la courroie afin de serrer le nœud.

(Figure 6)

. Locate Straps #1 and #2 outside of the frame

so that when the boat is loaded, the straps

will be out of the way. See image 7.

. Assurez-vous que les courroies #1 et #2 soient

à l’extérieur du cadre afin que celles-ci soient

libres une fois l’embarcation chargée.

(Figure 7)

EcoRack 81 County Rd. Westbrook, Maine 04092

Website: www.ecorack.net Email: [email protected]

MALONE

Limited One Year Warranty

MALONE AUTO RACKS, 81 County Road, Westbrook, Maine 04092

Phone: 207-774-9100 Fax: 207-615-0551

Website: www.maloneautoracks.com Email: sales@maloneautoracks.com

Repair or replacement of a defective product, or the issue of a refund or credit (as determined by Malone) is the original

retail purchaser’s exclusive remedy under this warranty. Damage to original purchaser’s vehicle, cargo, or property, and/

or to any other person or property is not covered by this warranty.

This warranty is expressly made in lieu of any and all other warranties, express or implied, including the warranties of

merchantability and tness for a particular purpose.

Malone’s sole liability is limited to the remedy set forth above. In no event will Malone be liable for any direct, indirect,

consequential, incidental, special, exemplary, or punitive damages , or, for any other damages of any kind or nature

(including but not limited to, lost prots, lost income or lost sales).

Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations

may not be applicable. This warranty gives you specic legal rights and you may also have other rights which vary from

state to state.

In addition, all vehicular transports are potentially hazardous. Any person using MALONE products are personally

responsible for following the given directions for use, installation and accepts full responsibility for any and all damages

or injury of any kind including death, which may result from their use.

The Malone Auto Racks (Malone) Limited One Year Warranty covers certain Malone-brand products that have been specically

identied for inclusion in the program and is eective for one year from the date of purchase for the original retail purchaser.

This warranty is terminated after one year from the date of purchase, or, when the original retail purchaser sells or otherwise

transfers the product to any other person or entity during the one year warranty period.

Subject to the limitations and exclusions described in this warranty, Malone will remedy defects in materials and/or

workmanship by repairing or replacing, at its option, a defective product without charge for parts or labor. Malone may

elect, at its option, not to repair or replace a defective product but rather issue to the original retail purchaser a refund

equal to the purchase price paid for the product, or credit to be used toward the purchase of a replacement Malone

product.

This warranty does not cover, and no warranty is given for defects or problems caused by normal wear and tear which

includes but is not limited to surface (aesthetic) metal corrosion, scratches, dents, deformities, accidents, unlawful

vehicle operation, or any modication of a product not performed or authorized in writing by Malone.

In addition, this warranty does not cover problems resulting from conditions beyond Malone’s control including, but not

limited to, theft, misuse, overloading, or failure to assemble, mount or use the product in accordance with Malone’s

written instructions or guidelines included with the product available to the original retail purchaser.

No warranty is given for Malone products purchased outside of the United States, Canada and Mexico.

If the product is believed to be defective, the original retail purchaser should contact the Malone dealer from whom it

was purchased, who will give the original retail purchaser instructions on how to proceed. If the original retail purchaser

is unable to contact the Malone dealer, or the dealer is not able to remedy the defect, the original retail purchaser should

contact Malone by email at technical@maloneautoracks.com.

In the event that the product must be returned to Malone, a technician at the email address above will provide the

original purchaser with return shipping instructions. The original purchaser will be responsible for the cost of mailing

the product to Malone. In order to receive any remedy under this warranty, a copy of the original purchase receipt,

a description of the defect and a return address must be provided.

Disclaimer of Liability

EcoRack

Transport Systems

Kayak Carriers

J-RACK

EcoRack Transport Systems (EcoRack) Limited One Year Warranty covers certain EcoRack-brand products that have

been specically identied for inclusion in the program and is effective for one year from the date of purchase for the

original retail purchaser.

This warranty is terminated after one year from the date of purchase, or, when the original retail purchaser sells or

otherwise transfers the product to any other person or entity during the one year warranty period.

Subject to the limitations and exclusions described in this warranty, EcoRack will remedy defects in materials and/or

workmanship by repairing or replacing, at its option, a defective product without charge for parts or labor. EcoRack may

elect, at its option, not to repair or replace a defective product but rather issue to the original retail purchaser a refund

equal to the purchase price paid for the product, or credit to be used toward the purchase of a replacement Malone

product.

This warranty does not cover, and no warranty is given for defects or problems caused by normal wear and tear which

includes but is not limited to surface (aesthetic) metal corrosion, scratches, dents, deformities, accidents, unlawful

vehicle operation, or any modication of a product not performed or authorized in writing by EcoRack.

In addition, this warranty does not cover problems resulting from conditions beyond EcoRack’s control including, but

not limited to, theft, misuse, overloading, or failure to assemble, mount or use the product in accordance with EcoRack’s

written instructions or

guidelines included with the product available to the original retail purchaser.

No warranty is given for EcoRack products purchased outside of the United States, Canada and Mexico.

If the product is believed to be defective, the original retail purchaser should contact the EcoRack dealer from whom it

was purchased, who will give the original retail purchaser instructions on how to proceed. If the original retail

purchaser is unable to contact the EcoRack dealer, or the dealer is not able to remedy the defect, the original retail

purchaser should contact EcoRack by email at [email protected]

In the event that the product must be returned to EcoRack, a technician at the email address above will provide the

original purchaser with return shipping instructions. The original purchaser will be responsible for the cost of mailing

the product to EcoRack. In order to receive any remedy under this warranty, a copy of the original purchase receipt, a

description of the defect and a return address must be provided.

2018

Repair or replacement of a defective product, or the issue of a refund or credit (as determined by EcoRack) is the

original retail purchaser’s exclusive remedy under this warranty. Damage to original purchaser’s vehicle, cargo, or

property, and/or to any other person or property is not covered by this warranty.

This warranty is expressly made in lieu of any and all other warranties, express or implied, including the warranties

of merchantability and tness for a particular purpose.

EcoRack’s sole liability is limited to the remedy set forth above. In no event will EcoRack be liable for any direct,

indirect,consequential, incidental, special, exemplary, or punitive damages , or, for any other damages of any kind

or nature(including but not limited to, lost prots, lost income or lost sales).

Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations

may not be applicable. This warranty gives you specic legal rights and you may also have other rights which vary from

state to state.

In addition, all vehicular transports are potentially hazardous. Any person using EcoRack products are personally

responsible for following the given directions for use, installation and accepts full responsibility for any and all

damages or injury of any kind including death, which may result from their use.
