Sunstream FL10014 Technical specifications

FORM NO.
PAGE 1 OF 36
REV.
690188
E
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
™
ASSEMBLY, USE AND INSTALLATION MANUAL
FL10014
COPYRIGHT SUNSTREAM CORPORATION 2014 - ALL RIGHTS RESERVED

Disclaimer of Liability
These assembly and installation instructions have been provided by Sunstream Corporation at
the request of the potential installer and/or assembler. If you are not an authorized Sunstream
Dealer and are not a reasonably skilled mechanic, please contact Sunstream so that we can
refer you to a local dealer who can skillfully and safely perform the assembly and installat i on
of your Sunstream boatlift.
It is the potential installer and/or assembler’s responsibility to determine whether he or she has
the necessary skills, knowledge, and tools to properly and safely assemble and/or install the
Sunstream Lift described herein. Improper assembly and/or installation may cause the Lift to
function improperly or not to function. Improper assembly and/or installation may additionally
cause a risk to personal safety or property. If the assembler and/or installer is confused or has
questions or concerns about a particular assembly or installation, he or she should contact
Sunstream by telephone at (888)-786-5438 before proceeding further. The information
contained in these instructions does not constitute a warranty or guarantee of any kind.
An assembler’s and/or installer’s failure to correctly follow these assembly and installation
instructions constitutes a waiver of the assembler and/or installer’s rights against Sunstream
regarding any subsequent damages to property or personal injury caused by the assembler’s
and/or installer’s improper assembly and/or installation .
Table of Contents
Disclaimer of Liability....................................................................................................
Parts Supplied...............................................................................................................
Assembly Instructions..............................................................................................
Prior to Launch............................................................................................................
Zincs............................................................................................................................
Installation Instructions/Mooring the FloatLift.........................................................
Operating Instructions…………………………………………………………………..
Important Safety Instructions…………………………………………..…………...….
Use and Maintenance Tips…………………………………………………...……..….....
Battery........................................................................................................................
Troubleshooting Tips..................................................................................................
Warranty…………………………………………………………………………………......
Tools Needed/Recommended:
Socket Wrench with 9/16” and ¾” Socket & Deep Socket
9/16” Wrench
¾” Wrench
Pliers
Plastic Hammer
Crescent Wrench (Adjustable Wrench)
Allen Wrenches
2 Saw Horses
8 Roller Carts
Marine grease for pins.
2
3
4-22
23
24
25-28
29-30
31-32
33
34
35
36
PAGE 2 OF 36

941117
ASSEMBLY, FRAME, PREASSEMBLED, FL10014
1X
1X
AS., FLOAT, LEFT, ROLLER, FL10
941115
1X
ASSEMBLY, FLOAT, RIGHT, FL10
94-000002-33
94-000002-32
AS., FLOAT, LEFT, 10
1X
1X
AS., FLOAT, RIGHT, ROLLER, FL10
941116
ASSEMBLY, HARDWARE KIT, PREASSEMBLED, FL10014 DOC
911121
PAGE 3 OF 36

1
ASSEMBLY
If you have any questions during the assembly process, please call your local dealer
or Sunstream as (253)-395-0500.
Before beginning assembly, find a flat area with room to work to set up your lift.
Read ahead to the Installation Procedure to determine the best location to start.
Antiseize all bolts/threaded rods. •
Grease all pins with Marine Grease. •
NOTE: Grease and Antiseize are not interchangeble.
PAGE 4 OF 36

NUT, .375-16, NYLOCK, SS
BOLT, .375-16 X 3.00, HEX, SS
2
PAGE 5 OF 36

NUT, .500-13, NYLOCK, SS
2X
BOLT, .500-13 X 2.75, HEX, SS
3
2X
PAGE 6 OF 36

2X
50 Ft-lbs
68 N-m
NUT, .500-13, NYLOCK, SS
4
PAGE 7 OF 36

4A
4C
4B
PAGE 8 OF 36

4D
PAGE 9 OF 36

285.77
285.77
a
282.00
282.00
b
4E
or
a b
PAGE 10 OF 36

4F
PAGE 11 OF 36

WASHER, .750, SS
PIN, COTTER, .125 X 1.50, SS
PIN, .750 X 4.48, SS, HIGH STRENGTH
5
PAGE 12 OF 36

NUT, .500-13, NYLOCK, SS
2X
6
50 Ft-lbs
68 N-m
PAGE 13 OF 36

REPEAT STEPS
4A - 4F
FOR
OPPOSITE
SIDE
PAGE 14 OF 36

PIN, COTTER, .125 X 1.50, SS
WASHER, .750, SS
PIN, .750 X 4.48, SS, HIGH STRENGTH
7
PAGE 15 OF 36

2X
2X
WASHER, .750, SS
PIN, COTTER, .125 X 1.50, SS
PIN, .750 X 4.48, SS, HIGH STRENGTH
8
FORM NO.
PAGE 16 OF 36
REV.
690188
E

8X
9
PAGE 17 OF 36

10
PAGE LEFT
INTENTIONALLY
BLANK
PAGE 18 OF 36

2X
WASHER, .750, SS
PIN, COTTER, .125 X 1.50, SS
BEAM
PIN, .750 X 4.48, SS, HIGH STRENGTH
11
2X
≥ 8' 10"/≥ 269cm
≤ 8' 10"/≤ 269cm
PAGE 19 OF 36

FWD
2X
BOLT, .375-16 X 3.00, HEX, SS
NUT, .375-16, NYLOCK, SS
12
PAGE 20 OF 36
