Congratulations on your new investment! The ECOsmarte Pool

System will give you many years of a safe and pure swimming

environment.Whether you are building a new pool, switching over

from chlorine, baquacil, salt chlorine generator or another sanitation

device, by choosing the ECOsmarte Pool System you have made an

environmental and health statement with your purchase.With the

ECOsmarte Pool System multiple forms of oxygen are delivered in

grams per minute.The electronic oxidation and ionization delivered by

the ECOsmarte Pool System inhibits algae and bacteria growth while

providing the oxygen necessaryto qualify as a stand alone sanitizer

for the over 20,000 residential pools wehave installed since 1994.

In Australia and Canada, your Government requires a 0.5 ppm free

chlorine residual with the ECOsmarte copper ionization.This level

must not exceed 1.0 with ECOsmarte. NO CYANIDE (Conditioner,

Stabilizer) is to be used with the ECOsmarte Pool System.

All other residential pools are to avoid the use of Chlorine.

CONTENTS DIRECTORY NEXT PAGE

ECOsmarte Pool System Owner's Manual - X, 2011 3

The Electrode Chamber maybe installed either horizon-

tally or vertically with our Quick Change Unions. Install

the Electrode Chamber between the pump and filter or

between the filter and pool on the pressure side of your

piping.The ECOsmarte Electronic Box can be installed

indoors or outdoors.The Electronic Box is water resistant

and comes with pre-wired leads to be connected to the

Electrode Chamber. If installation requires additional wire,

you may order it from your local ECOsmarte dealer.

CONTENTS OF THIS MANUAL

P. 3 Introduction

P. 5 Start-Up Procedures

P. 7 Water Vocabulary and

Testing

P.13 Closing Your Pool

P.15 Maintenance

P.16-18 Installation

P.19-22 Problem Solving/Guide

P. 22-23 Compatible/Incompatible

P. 24-25 Glass Pack ® Filter Media

P. 33 Free Electrodes for referral

P. 34 Warranty Info: Fax, Scan, Mail

SALTWATER and BROMINE POOLS

must be drained and refilled

Automated

Systems

DO NOT LET YOUR CHLORINE LEVEL

fall to ZERO prior to install.

TO POOL

WIRE HOOK-UPS

BLACK/WHITE

RED/GREEN

Connect both

to front side

of chamber.

START-UP

As we begin to protect your water against algae and

bacteria by ionization, the first seven days are critical.

You need to closely monitor two water factors in partic-

ular: pH and Copper. pH levels above 7.2 will render the copper ions inef-

fective and will prohibit accurate copper measurements. Copper ions are

the algaecide and bactericide in the water. The water in your pool needs

apH below 7.2. Ideally, begin ionizing after adjusting the pH to 6.8 and

expect the pH to rise.The total alkalinity of the pool will fall as you lower

your pH. Do not try to adjust the total alkalinity as we will be changing the

water's chemical make-up of calcium to bicarbonate.You must confirm

minimum calcium of 400 ppm.

During Start-Up the ECOsmarte Pool System will remove old sanitation

chemicals in the water.This process will require you to backwash or

clean the filter media until most of the toxic contaminant's have been

removed. A slight increase in filter pressure indicates a load of toxins has

been removed. Expect increases in filter pressure and pH rises during

Start-Up (first 2 - 3 weeks). Switch the ECOsmarte Electronic Box to the

Ionize position. After 24 hours of ionizing take a second copper and pH

measurement (see TESTINGYOUR WATER).Test the pH first and adjust

it if necessary with muriatic acid diluted with water. Once your pool has

achieved between 0.4 ppm and 0.7 ppm copper, switch the ECOsmarte

Electronic Box to Oxidize. If your pool registered copper prior to installing

the ECOsmarte Pool System, then ionizeuntil you achieve0.7 ppm, or

until the false indicators have been filtered out of the pool.

At this point, your pool should have a copper residual of approximately

0.6 ppm, with chlorine or other "old" sanitation chemical approaching

zero, and be ready to begin the WEEKLY MAINTENANCE cycle. If this is

not the case, consult the PROBLEM SOLVING section of this document.

Aminimum level of 0.4 ppm is required to protect your pool. Swimmers,

rainfall, evaporation and algae will cause your copper residual to

decrease. Once your minimum copper residual is reached, your control

box is always in the oxygen or "oxidize" mode unless your weekly water

test indicates copper is below 0.4 ppm. If you go four calendar days and

copper is below 0.4 ppm have phosphates, calcium, and pH values test-

ed at local pool store. Add Phos Free™ if necessary,if over 1,000 ppb

you may wish to use Sea Klear®.

1-800-ION-SWIM or (612) 866-1200

FREE Five Minute Phone Orientation

Available & Encouraged with All New Users.

PRELIMINARYSTEPS

(1) Stop using old sanitation chemical or device, but confirm levels.

(2) Backwash or clean filter thoroughly.

(3) Install ECOsmarte Electrode Chamber either horizontally or vertically.

Note: If chlorine is at zero put one quart Algaecide 60 in the pool until

you get copper to 0.4 ppm.

CONVERSION STEPS

(1) Lower pH to 6.8 - 7.2 range.

(2) Measure copper, see TESTING YOUR WATER

(3) Turn ECOsmarte Electronic Box to Ionize, High for all pools.Take

second Copper test after 24 hours, test pH again.

(4) It will take 48 to 72 hours of consecutive ionizing to get copper above

0.4 ppm.

ELECTRONIC CONTROL BOX

To Ionize,set the ECOsmarte Electronic Box in the ion-

izeposition. A single, circling light indicates power to the

Electronic Box. Asmall glow-lamp diode at the

Electrode Chamber indicates power to the electrodes.

You will oxidize as the default, unless a copper meas-

urement indicates a need for copper ions. On average,

oxidize 13 days, ionize 1 day, depending on your bather

load. ECOsmarte recommends turning the water over in your pool 1.5

times per-day, running the ECOsmarte Pool System only when filtering

your water.When the Electronic Control Boxis in the Oxidize position, your

pool water will be oxidized as it passes through the Electrode Chamber.

The lights on the Electronic Control Boxwill indicate the mode of operation,

confirm polarity shift, and alert you to certain problems. Under proper oper-

ating conditions a single light will circle whether in the Ionize or Oxidize

mode, and a single steady light will appear next to the selected mode.

(1) Amode light appears next to both Ionizeand Oxidizepositions regard-

less of mode selection, then power is feeding back from the selected

electrodes to the other electrodes.This is caused by highly conductive

water. As long as the lights are not blinking, leave unit in high mode;

checkagain the second season.

(2) One or more mode lights blinks, then water is extremely conductive.

Switch Box to Low. Leave box on high if both lights are on but not blinking.

(3) 98% or more of all systems run in high mode in either oxidize or ionize.

WATER VOCABULARY

The technical term for the measure of acidity or alkalinity of water. pH is

measured on a logarithmic scale from 0 to 14. At a pH of 7.0 and a water

temp of 80˚, water is neutral. A reading above 7.2 means the water is

alkaline. A reading below 6.8 means the water is acidic. During the swim-

ming season, check the pH level weekly and after heavy rainstorms.

Everything that enters your pool has a pH value. Adjustments should be

made to keep the pH within 6.8 to 7.2 range. Muriatic acid has an

extremely low pH, and, consequently, is used to lower pH. Sodium bicar-

bonate, or baking soda, has a high pH and is alkaline. With the

ECOsmarte Pool System it is important to maintain a pH within the speci-

fied range. The effectiveness of the copper ions depend on a neutral pH.

Neutral pH at 85˚F water temperature is 6.8. Water without chemicals will

want to be neutral, and starting each week at 6.8 will give you best results.

COPPER

The ECOsmarte Pool System generates copper ions. A body of water pro-

tects itself against simple organisms like algae, bacteria, and some virus-

es by maintaining a copper residual. Copper is lethal to simple organisms,

yet beneficial to complex organisms like humans and animals.

TOTAL ALKALINITY

Aclose cousin of pH, Total Alkalinity is a measurement of all the carbon-

ates in the water: Carbonate, Bicarbonate, and hydroxides. The pool

industryhas yet to develop a true Total Alkalinity Meter. Available Alkalinity

test kits measure the amount of carbonate alkalinity in the water.You have

bicarbonate (soluble) calcium that does not register on traditional alkalinity

test kits.The ECOsmarte Pool System will not cause corrosion if the alka-

linity measurement is low (below 60). If you were using chlorine the water

would become aggressiveand potentially destroypool equipment. Until an

accurate means of testing true Total Alkalinity is developed ECOsmarte

has a less scientific way of determining low Total Alkalinity. If the pool

water is clear and refracts sunlight in such a wayas to appear green your

pool likely has low alkalinity.That is, the pool looks like lime jello or green

grass; very clear and bright green. Low Total Alkalinity can cause "pH

bounce." "pH bounce" shows itself as large changes in pH after additions

of acid or alkalai. High alkalinity causes pH to drift upward. Many of the

ECOsmarte Pools balance at as low as 40 measured carbonate alkalinity.

Again, true Total Alkalinity (carbonate and bicarbonate) cannot be tested

with portable kits currently available.

pH is alkalinity dependent; that is, alkalinity is defined

as the ability of the water to resist changes in pH.

CALCIUM HARDNESS

Calcium hardness affects pool water quality. Low calcium hardness can

promote pool corrosion. High calcium hardness can cause cloudiness.

Ideal calcium hardness content is 400 ppm as measured by a suitable

kit.The ECOsmarte Pool System will eliminate scaling in your pipes.

Calcium hardness will need to be tested at start-up and if the pool is

refilled. It should also be tested after extended days of heavy rain.

ECOsmarte has many pools at 800 to 1000 ppm calcium hardness, and

draining back is recommended at 2200-2900 ppm.

POOL STORE COMPUTERS: pH, CALCIUM & PHOSPHATES

Can be a useful tool to double check your pH and calcium hardness. Do

not however adjust alkalinity or copper based on the results. Alkalinity

should be adjusted upward if the pool is crystal clear and “grass green”

or “lime green” in color. Rely only on the Lamotte Copper test kit included

with your ECOsmarte System to use the IONIZE mode and add copper

to the pool.

PHOSPHATES: Must be confirmed at ZERO once per year.

TIPS FOR pH & ALKALINITY

•For a reduction in Total Alkalinity experts recommend

"pooling" the acid in a small area of low current.

Normally, ECOsmarte Pools need no downward alka-

linity adjustment.

•Upward alkalinity adjustments should be done in 4lbs

increments per day of sodium bicarbonate. Any more

and "pH bounce" may result, causing you to waste

time and money on acid. Do NOT raise Alkalinity

unless water is clear lime green, (or “grass green but

clear.’’) - Adjust no higher than 80 ppm.

•Upward alkalinity adjustments can be made with

sodium bicarbonate, baking soda or any brand of alka-

linity enhancer. We recommend 4lbs max per day and

DO NOT OVER ADJUST.

•For a reduction in pH, walk acid around the pool and

distribute it to the entire pool, having diluted the acid

with water in a 5 gallon bucket.

TESTINGYOUR WATER

The ECOsmarte Pool System requires you to measure two aspects

of your water chemistry on a regular basis: (1) Copper Ions and (2)

Potential Hydrogen (pH). Each test needs to be performed weekly.

pH TEST

Maintain pH within the specified ECOsmarte Water Parameters. pH must be

between 6.8 and 7.2. Any pH test kit should work fine. Follow the directions

included with your kit. Remember to:

(1) Fill the sample container with pool water from at least 18" below the surface of

the pool. Avoid taking samples near the skimmers and return-jets.

(2) Test pH before testing Copper ppm.

(3) Hold tester at arms length (preferably out of direct sunlight) above the horizon.

Look at the sample water and compare to the color standard included with the

test kit. Read the pH value once match is obtained.

(4) If a pH adjustment is necessary, use muriatic acid diluted with water in a 5 gal-

lon bucket. (Dilution is to prevent "shocking" any metals out of solution).

DO NOT USE DRY ACID. See pH TALK.

pH TALK

•We can train your pH to remain Neutral. 6.8 to 7.2 is technically pH Neutral.

•The first two weeks after installation your pool may consume acid on a regular

basis.This is not unusual. If high consumption continues into the fourth week,

then possible nitrate and phosphate residuals are creating this problem and a

percentage of water may need to be drained back. Consider PHOS FREE.

•Radical changes in pH are not recommended.

•Rule of Thumb: If your pool is 15,000 gallons with a pH 7.6 or above, add at

least 1/2 gallon of acid; if your pool is 25,000 gallons or above, add at least a

full gallon.

•Acid consumption will vary according to pool water. However, pH measure-

ments are logarithmic.That is, your pool will need considerably less acid to

move from 7.2 to 6.8, then it will to move from 7.8 to 6.8.

•DILUTE ACID BEFORE PUTTING IN YOUR POOL

•Consider CO2 injection if acid demand exceeds one gallon per week after 3

weeks of operation. During the first year after purchase, all swimming pool

customers receive full credit on a trade-in to the automated CO2 system thru

your ECOsmarte dealer.

NOTE: We must also confirm minimum calcium of 400 ppm and 0 phos-

phates.While these tests are done less frequently,tests should be done

after heavy rainfall or stretches of extremely high heat.

COPPER TEST

Always test pH before Copper. If pH is above 7.2, adjust pH level and

wait for pH to come down. If pH is at 7.3 or above you will not get an accu-

rate copper measurement. If the pH is above 8.0 you may create copper

chloride (if there is still chlorine in your pool or your city "fill-water" is highly

chlorinated) which can stain your pool and bathers. Neither condition is

permanent or harmful, but both can be avoided by keeping low pH. Once

free-chlorine and total chlorine reach zero, copper chloride cannot be cre-

ated providing you do not add chlorine to the pool again.The Copper Test

procedure for the EC-70 Liquid Copper Kit, is as follows:

(1) Fill test tube with pool water to black line. Be sure to take sample from

alevel 18" or more below the surface of the water. Also, avoid samples

near the skimmer and return-jets.

(2) Add five (5) drops of Copper Reagent A to test tube. Cap and invert.

(3) Remove cap and add five (5) drops of Copper Reagent B to test tube.

Cap and invert.

(4) Remove cap and place tube in test-kit holder. Allow to stand for

approximately two minutes.

(5) While holding the tube, place color standard chart 1/2" underneath the

vertical tube. Measure the level of copper by looking directly down into

the test tube at a white portion of the color standard provided with the

kit. Match the shade of blue and record in parts per million.

NOTE: Magnets, metal removers, copper algaecides, sequestering

agents, and other chelating agents will create false copper readings.

See INCOMPATIBLE PRODUCTS.

WATER TESTING VIDEO at

www.ecosmarte.com

If you have

a pool party,

rainstorm,

or expect

either, test

your water.

WATER PARAMETERS

POOL TALK

TURNOVER CYCLES

The ECOsmarte system requires 1.5 - 2 complete turnovers during day-

light hours, or 6 to 10 hours for most in-ground or above ground pools.

Auto-cover owners will get best results opening the cover on sunny days

even though no swimming occurs (See p. 12).

NO CHEMICALS

ECOsmarte recommends letting the Pool System work for you. In other

words, be patient, the System itself will work. ECOsmarte understands

circumstances exists where a "quick-fix" is necessary, or desired. In cases

such as these the following is a list of compatible products. Note that the

list is exclusive and anything outside the list is not recommended. Again,

there is no need for regular use of any of these products.

Non-Chlorine Shock (Potassium Monopersulfate): Shock 'n Swim,

Oxybrite, and Oxyclear.

PhosFree or Sea Klear: If phosphates are above 100 ppm

Alum-based Flocculants: Any, but use sparingly, and with phosphates

Non-Metallic Algaecide:Any, but use sparingly. Any brand w / 40 or 60.

Filter Cleaner:TSP and Muriatic Acid

Borax: Use sparingly, if pH bounce or spotting have been a problem.

Requires use of acid immediately after using the Borax. 4 lbs per 10,000 Gallons.

WHAT CAUSES ALGAE PROBLEMS?

There are over 21,000 known varieties of algae! Algae spores constantly

enter the pool, brought in by wind, rain or even contaminated swimsuits or

equipment.When conditions are right, an algae bloom can occur seeming-

ly overnight.These conditions include imbalanced water, warm tempera-

tures, sunlight, and the presence of nitrates. Of course lack of proper filtra-

tion, circulation, and sanitation may be the primary causes of algae. A suc-

tion vacuum is highly recommended with the Ecosmarte system, as is

backwashing only after pressure rise of 6 lbs and before 10 lbs.

Algae is a living aquatic creature that multiplies rapidly in warm, sunny

conditions. Containing chlorophyll, algae utilizes photosynthesis to grow.

That is, they take in carbon dioxide and expend oxygen as a by-product.

The twomain problems with algae are,first, people do not want to go

swimming, and second, it takes time and money to rid the water complete-

ly of algae. Algae itself is not harmful to swimmers, but pools with algae

mayalso be residence to other pathogens.

REGULAR CHEMICALS ARE NOT REQUIREDTO RUN

SWIMMING POOLS OR SPAS.

Proper water balance and filter maintenance are necessary to prevent

algae growth. Also regular brushing prevents dirt from harboring in the

pores of your pool surface, where algae colonies like to start.The use of

specialty chemicals or algaecides may be necessary as a back up to the

ECOsmarte Pool System and existing filtration. Filtration upgrades will

solve 99% of these problems.

Again, ECOsmarte recommends allowing the system to defeat algae on

its own.You will want to adjust valving for optimum circulation and allow

your pump and filter to run 24 hours a day until the pool clears (the

ECOsmarte Pool System can be shut off after a single cycle of oxidation,

providing Copper ppm levels are above 0.4).Turn on any automatic

cleaners to stir things up. Continue to brush the walls. If the pool is real

"swampy" algaecide 40 or 60 may be a good choice. If you cannot see

the bottom of the pool and it is filled with leaves and debris, you must get

all leaves and debris out to clean the water.

1-800-ION SWIM can help with detailed advice.

CYCLE TIMES

•ECOsmarte pools should operate 24 hours per day the week

you start-up and put in the initial ionization level (Cu 0.4 ppm to

0.7 ppm)

•ECOsmarte pools should circulate 24 hours whenever your

water does not look right.

•ECOsmarte pools must circulate during daylight hours, 6 to 12

hours per day in the OXIDIZE or maintenance IONIZE mode.

•Auto-cover owners should uncover the pool 2 hours minimum

on sunny days for best results.

•“Over oxygenation” can occur on 24 hour constant circulation

after several weeks, so ECOsmarte only timing systems are

recommended for edge pools and environments where 24/7

skimming and filtration is desired.

SIZE OF POOL

Less Than 24,000 Gallons

24-39,999 Gallons

40,000 Gallons & Above

MINIMUM FILTER

300 LB

600 LB

900 LB

REQUIRED PUMP

1.0 HP

1.5 HP

2.0 HP

CLOSING

CLOSING NORTHERN POOLS - FROZEN WATER

•Test pH and Copper. Lower pH to 6.8; Raise Copper to 0.7 ppm.

DAY OF CLOSING

(1) Drain water below skimmer level.You can achieve this by running your

pump to waste through only the main drain.

(2) Turn off pump. Disconnect power to Electronic Control Box and remove

lead wires from chamber. Store Box indoors for the winter.

(3) Lay out all winterization hardware (caps, gizmos, etc.).

(4) Unscrew return jets, stand-by with jet plugs.

RETURN LINES

(1) Twist off ECOsmarte Electrode Chamber (store indoors).The 12" gap

will be your "blow spot."

(2) Using a shop-vacuum or other power blower, blow toward the return

side of the piping from the "blow spot" with all returns open.

(3) Close all return valves. Using the winter plugs, plug all jets finger tight

except the nearest jet to the pump. Open return line nearest pump and

blow air through that line, from the "blow spot." Repeat this procedure

for each return line, re-plugging each jet after water is purged.

(4) Carefully pour one gallon RV Anti-Freeze into the return side of the pip-

ing (most likely from the "blow spot"); blow Anti-Freeze through with

shop-vacuum until you can see anti-freeze come out of the intended jet.

Repeat this procedure for each line starting with the furthest jet and

working toward the pump.

PRIOR TOSUCTION SIDE WINTERIZATION

(1) Removedrain plug from hair and lint basket (sump). Allow to drain

completely.

(2) Remove drain cap from filter (if sand filter, remove smaller of two caps).

SKIMMERS

(1) Close skimmer and main drain valves.

(2) Working from the suction side of your pool piping, open and blowout

skimmers, one at a time, from the nearest skimmer to the furthest.

Close skimmer valves after blowing.

(3) Pour one gallon RV Anti-Freeze directly into each skimmer.

(4) Plug skimmers. If Gizmo is not used, leave an empty plastic Anti-

Freeze jug in skimmer cavity (plastic jug will absorb winter expansion).

All ECOsmarte pools use two winterizing principles:

Lower pH to 6.8;

Raise Copper to 0.7 ppm

CLOSING NORTHERN POOLS (Cont.)

MAIN DRAIN

(1) With skimmer valves closed, open main drain valve.

(2) Open hair and lint basket (sump) at pump. Remove basket.

Replace drain plug.

(3) Pour approximately two gallons of RV Anti-Freeze into hair and lint

basket. Close basket cover.

(4) Blow from suction side of "blow spot" with main drain valve open,

until you can see small trace of Anti-Freeze entering the pool.

(5) Close valve quickly.

MISCELLANEOUS

•Stuff rag or sock in each end of "blow spot." Rubber bind or duct-tape

rags in place.

• If you have a slide, water-powered vacuum (Polaris, Kreepy Krauly, etc.),

or water-fill hose installed on your pool they will need to be blown out and

filled with Anti-Freeze. Use above procedure in most cases. Some slides,

however, may need to be blown from the spot of disconnection.

•Set sand filter 7-way Valve to the "Winter" or "Closed" position.

•Remove ladder and railings. Lift cover plate & unfasten 7/16" or 1/2" bolts.

•If diving board is greater than 8' long and snowis expected, removeand

store inside for the winter.

•Cover pool with winter cover. If water bag cover is used, fill water bags

half-full to prevent winter cracking. Also, allow cover's slack to fall into

pool and anchor with as little on deck as possible (1 to 2 feet is ideal).

This will prevent the cover from collapsing into the pool under a load of

snow.

SOUTHERN POOL CLOSING PROCEDURE

If you are located in a region where freezing water is not a concern,

then lower pH to 6.8 and raise copper levels to 0.8 ppm.There is no

need to run the pump and filter everyday.You must however run the

pool if a frost warning is issued. Southern pool owners may adjust pH

every 2 or 3 weeks in a non-circulating pool for maximum control.

OPENING NOTES:

New ECOsmarte pools that were chemically treated the

previous year should use identical opening procedures as

before ECOsmarte was installed.The ECOsmarte unit

should be turned on when water is clear.The oxygen will

knock out the chlorine residual in 24 to 48 hours.

MAINTENANCE and

OWNER RESPONSIBILITY

(1) ECOsmarte System: Following the detailed procedure below, the

ECOsmarte Electrode Chamber must be cleaned every third month of

operation and as needed under certain water conditions.

(2) Filter Maintenance: Adequate filtration is required in order to oper-

ate a clear swimming pool. Sand filters can be cleaned by soaking sand

with one gallon of muriatic acid overnight. Apply the undiluted acid direct-

ly to the sand once per year. Cartridge filter elements must be soaked in

5:1 muriatic acid and water solution, then TSP and water for one hour

each (as needed). Replace the cartridge every 6 months for spas and

every 18 months for pools. DE Filter elements need same muriatic bath

as cartridges as well as TSP bath for one hour. (Sand filters backwash

twice after 6lbs. rise, DE filters three times after 12lbs. rise.)

(3) Pool Maintenance: GUNITE pools require pool brushing of areas

where automatic vacuum does not reach on a weekly basis. A cavitating

pump will run our Electrode Chamber dry and result in poor automatic

vacuuming. Vinyl, GUNITE, and Fiberglass pools work best with a suction

wall vacuum, not a sweep.

ELECTRODE CLEANING PROCEDURE

(1) Mix solution 5 parts water to 1 part acid in a bucket. When

adding acid to water be careful not to spill or be down wind when

pouring.

(2) Disconnect terminal clips.The Red & Green wires attach to the copper

side of the chamber,the Black & White to the titanium side. If uneven

electrode wear is noted on copper electrodes you must reverse position

of the Green & Red terminal clips after cleaning.

(3) Place entire Electrode Chamber in bucket for 10 to 15 minutes. The

build-up will slowly dissolve. DO NOT scrape the surface of the elec-

trodes. If you will be cleaning yourself, consider cleaning caps to cut

acid use and speed process. Cleaning caps from your dealer will cut

acid use and simplify this procedure.

(4) Remove Electrode Chamber from bucket and rinse with garden-hose

pressure. Make sure to rinse your hand as well.

(5) Wipe terminal clips dry and reconnect leads after reinstalling Electrode

Chamber in pressure line. Remember: Red & Green connect to the

copper side, Black & White to the titanium.

WHEN CLEANING

DO NOT DISASSEMBLE chamber OR USE METAL FILES

***************************************************************************

Electrode Chamber Installation

The ECOsmarte Electrode Chamber

may be installed either between the

pump and filter or, preferably, after

the filter. The titanium electrodes

should be aligned nearest the pool

(see diagram). If you have a spa in

line with your pool filter system,

ensure the Electrode Chamber is

located before the valves that divide

return water to the pool and spa.

Tool List:

Hack Saw

PVC Cleaner

Felt-Tip Marker

Tape Measure

PVC Cement

Copper Electrode Replacement

ECOsmarte Copper Electrodes are not pro-

tected under the five-year warranty. The life of

copper electrodes depends on multiple factors.

Worldwide the life of copper electrodes aver-

ages three years.You can extend the life of the

electrodes by following the directions in the

Owner's Manual. Remember to shut off the

Electronic Box when water is not circulating

through the Electrode Chamber. The Copper

Electrodes will continue to be ionized as long

as the electrodes are in solid contact with the

bolts. If the electrodes corrode free of the bolts

then it is time to replace them.

Do not replace your titanium bolts with

stainless or brass substitutes.

You will receivenewbolts when you purchase

electrodes from your dealer.

REFER ANY BUYING CUSTOMER TO

YOUR DEALER AND RECEIVE

A SET OF FREE COPPER BARS.

TO POOL

POOL

FROM

PUMP

ELECTRICAL INSTALLATION

Your ECOsmarte Pool System comes with paired wires for easy installa-

tion. If you remove the Electrode Chamber or re-install the System at

another location then consult this electronic guide.The Electronic Control

Box requires 110 volts A/C and will transform the current to low voltage

DC current.The output depends upon which setting you chose, low or

high. If additional wire is needed, standard 2 wire telephone cord can be

used (make sure you purchase butt-end connectors).

INSTALLATION METHOD #1

Mount the Electronic Control Box on a wall or fence near the pump and

filter system. Connect the output leads to the Electrode Chamber (white

and black to the titanium, red and green to the copper; see diagram

below). Plug the electrical cord into a 110 volt A/C outlet. Although this

method is the simplest installation, it will require someone to turn the

Electronic Box on and off when the pump is turned on and off, so that the

Electronic Control Box is never on without the water recirculating. An out-

door timer (synchronized to the pump timer) maybe installed between

the Electronic Control Box plug and the electrical outlet if desired to solve

this problem and ensure proper operation of the System. ECOsmarte has

110V outdoor timers available as do most pool stores and Home

Improvement Centers.

INSTALLATION METHOD #2

If you have an existing pump timer (220V), then the Electronic Control

Box can plug into an outdoor timer (110V) which is set in tandem with

your pump timer. Set the ECOsmarte box 15 minutes less time than the

pump.This method of installation will ensure proper operation and timing

of the Electronic Control Box with the pump cycle. If the ECOsmarte

Electronic Control Box is wired according to method #2 then someone

will still need to switch the control setting on the Boxto ionizewhen cop-

per measurements indicate a need for copper ions. Follow local codes on

all electrical wiring. (Three wire 220V systems may need upgrade to four

wire to meet code.)

SEE IMPORTANT SAFETY ISSUES ON PAGE 28

PROBLEM SOLVING

CLOUDY WATER

If your water appears cloudy, or like milk, the cause is most likely associ-

ated with the ionization descaling in your pool pipes.This process is nor-

mal, and will eventually cease. Consider this: with whatever sanitation

chemical you were previously using, the calcium carbonate has been

allowed to scale and build-up inside your pool pipes, heater, filter, and

other pool equipment.The ECOsmarte Pool System will alter the form of

calcium, and activate a descaling process which will remove the build-up

inside your pipes, heater, filter and other pool equipment.The process is

safe to you and beneficial to your pool equipment. Generally a cloudy

pool as a result of descaling will last from 1 to 3 weeks, however the con-

dition may show itself periodically until all scaling has been removed. To

speed up the removal process, you should:

(1) Clean filter media thoroughly, sand filter & DE owners should break

down filter each spring, soaking grids is critical, twice yearly.

(2) Test pH and Copper ppm and adjust as needed.

(3) Oxidize water for two cycles per day.

(4) Test water for phosphates.

ECOsmarte recommends the aboveprocedure. If a cloudy condition per-

sists beyond three weeks the filter media may be inadequate.Waiting for

pressure rise remove the minute calcium particles and aid your filter in its

removal. Glass Pack® (see inside front cover). Replacement media for

sand filters. (Sand must be changed every 3 years minimum.) Glass

Pack® should last five years.

ALGAE BLOOM

The ECOsmarte Pool System requires a pH between 6.8 and 7.2. If an

algae bloom appears it is usually because the pH drifted above 7.2, or

the copper residual is below0.4. The activealgaecide in the water is the

copper ion. Measure your copper levels and adjust as needed (between

0.4 and 0.7 ppm).The ECOsmarte Pool System does not "vaporize"

organic matter. The System will render inertsimple organisms,likealgae.

Adequate filtration is necessary to run a crystal-clear pool. If an algae

bloom occurs, there are a few things you can do to speed up the removal

of algae.

(1) Clean filter media thoroughly,

(2) Measure pH and Copper ppm and adjust as needed,

(3) Brush algae toward main drain daily,

(4) Backwash media when filter pressure rises 6-10 lbs.

Too much backwashing can cause algae to form or cloudy water.

Test water for phosphates.

ECOsmarte recommends this procedure. If an algae bloom persists beyond one

week, use a Non-Metallic Algaecide for additional help. Finally, without adequate

filtration dead algae will remain in a pool and a "bad" filter will spin algae in cir-

cles. Note: A DE Filter pool with visible algae should use 1 quart non-metal

algaecide to sanitize grids. A suction style vacuum versus a sweep or “pop-ups”

is recommended.

BAQUACIL CONVERSION (SWIM ‘N PLAY and any BIOGUANIDE)

Baquacil conversions require a slightly different start-up procedure. ECOsmarte

recommends the following:

DAY ONE

(1) Allow Baquacil to run to zero.

(2) Shock the pool water with Non-Chlorine Shock (4 lbs per 10,000 gallons)

DAY TWO

(3) 24 hours later, shock the pool water a second time with Non-Chlorine

Shock (2 lbs per 10,000 gallons)

(4) Ionize pool water until a copper ppm of 0.5 is achieved, taking longer

than other pools with 96 hours likely.

Ex-Baquacil users need to clean their electrodes (every two weeks of the

first year) to prevent a chemical seal from forming on the electrodes.

NEW VINYL LINER OR GUNITE SURFACE

Unfortunately, the most effective way to cure a new vinyl liner or GUNITE sur-

face is to lightly chlorinate it for 10 to 14 days.This process is designed to

remove plaster dust before it gets in your filter and creates a season of prob-

lems.The chlorine residual in the pool will run itself to zero within 7 days after

the curing process is complete. Use: 1 gallon of regular bleach per 10,000 gal-

lons each week for two to six consecutive weeks to oxidize the gases from the

vinyl or plaster dust from GUNITE surfaces. No metal remover in the pool.

ONLINE VIDEO RESOURCES

ONLINE SUPPORTFRAME (Password: customer2007) See P. 25

ECOsmarte Customer Service Guide

Swimming Pool Systems: Common Questions

ICAN’T GET MY COPPER TORISE

·It takes 36 to 72 consecutive running hours on ionize to get your copper to rise

·The pool will not ionize if calcium hardness is below 400, raise it to 400 at start-up

·The swimming pool will not ionize if the pool pH is above 7.3

·Make sure connectors are solid on your red/green leads and bars are clean

·CONFIRM ZERO PHOSPHATES

MY WATER IS “MURKY” or “HAZY”

·Copper is below 0.4 ppm. Switch to ionize for 8 to 16 running hours, often after

lowering pH.

·pH is above 7.2. Lower to 6.8 with acid, even if pool has CO2 injection

·Backwash is only done with 6 lbs minimum rise on sand, ZEOlite or glass filters,

12 lbs pressure rise on DE.

· Do not backwash without pressure rise except GLASS at 6 weeks running.

· Do Not Adjust a 6.6 pH pool up. Start each week at 6.8.

·Let the 6.6 pool rise on its own for a week or two.

·CONFIRM ZERO PHOSPHATES

MY POOL HAS GREEN WATER

·pH is above7.3, lower to 6.8 with acid

·Copper is above 1.0, exchange one to two feet water out, check pH.

· Do not shockpool with sodium based non-chlorine shock – use potassium

based only. GBL OXYBRITE® is a great product.

·Never use metal remover or clarifier, the pool needs two consecutive non-chlorine

shocks to remove them. MY POOL HAS ALGAE

·pH has risen above 7.4, Acid Adjust to 6.8.

·Copper is below 0.4 ppm (or likely both), switch to ionize.

·Filter maintenance,brushing, vacuuming or skimmer baskets need attention.

·Add any Algaecide with the numbers 40 or 60 on the label, follow 24 hours later

with 2 lbs per 10,000 gallons non-chlorine shock, if needed.

·CONFIRM ZERO PHOSPHATES

MY DAUGHTER HAS GREEN HAIR

·Copper is above 0.7 ppm, lower with water drained back two feet.

·pH is below6.6, raise with soda ash or baking soda.

·Calcium is below200, raise to 400.

·Customer is getting chlorine from beauty shop perm or city water.

·Wet hair before getting in the pool.

· Run copper at 0.5 ppm at this pool instead of 0.7 ppm

ALWAYS NEVER

• pH to 6.8

•Copper to 0.7

•Calcium to 400 ppm

•Use Chlorine

•Use Metal Remover

•Use Clarifier

*AVOID ADJUSTING ALKALINITY UP WITH ECOsmarte*

COMPATIBLE PRODUCTS

·Glass Pack® Filter Media, watch for ECOsmarte promos

·Algaecide 40, 60

·Non-Chlorine Shock - Potassium-Based Only (GLB OxyBrite is the best)

·Calcium Chloride or Hardness Increaser

·Phos Free, Sea Klear

·ZEOBrite with PEA Gravel Base in All Pentair, Sta-Rite, Jacuzzi Brands

ABSOLUTELY INCOMPATIBLE PRODUCTS

·AnyAlgaecide w/metal

·Any SOLID CHLORINE

·Any metal remover, Scale Control or Clarifier

·Sodium-Based Non-Chlorine Shock

·Guardex Z Media, ZEOBest

·ZEOsand and ALL CARTRIDGE FILTERS

·Enzymes START-UP POOL ISSUES

CLOSING NORTHERN POOLS

·Do Not Let Chlorine Fall to Zero Prior to Start-Up

·Bromine Pools Must Be Drained

·Baquacil Pools Are Easy If Drained

·ALL Salt Pools Should Be Drained

·Phosphates Should Be Tested At Fill Up and 2 weeks After Start-up

·Calcium Tested At Fresh Fill and After 2 Weeks Operation

·Salt Chlorine Generator Pools Must Be Drained and Wiped Down

·Surfaces cured with liquid chlorine (Not needed on fiberglass)

·Backwash at pressure rise only on sand; 6weeks on glass filtration

regardless of pressure gauge increases.

·D/E Filters broken down twice per year, grids soaked annually

·Copper at 0.7 ppm, ph 6.8. NO CHEMICALS REQUIRED other than antifreeze.

Table of contents

Popular Lighting Equipment manuals by other brands

Epstein-Design

Epstein-Design Flora 2 E27 Series manual

Kogan

Kogan KAPKVIDLBKA user guide

Hyundai

Hyundai HSL121901 user manual

SWIT

SWIT S-2051 user manual

Lightronics

Lightronics DI-104 owner's manual

PLG

PLG APE user manual

Brighter

Brighter Smart 280 user manual

CLARTE LIGHTING

CLARTE LIGHTING 601LED-PAR16 Series installation instructions

Avantes

Avantes AvaLight-XE-HP Operation and installation manual

Tracon Electric

Tracon Electric LSFLK10W user manual

American DJ

American DJ Micro 3D User instructions

Dals

Dals SM-OTP24FT installation guide

Quantum

Quantum LQM instructions

fluxia

fluxia SMD5730 Installation instruction

Lightolier

Lightolier WALL MOUNTING MONOPOINT PIN-UP Installation

Ortech

Ortech OL-1H instruction manual

American DJ

American DJ Avenger ll User instructions

LCG

LCG ST-04 user manual

EcoSmarte Pool System User manual

Popular Lighting Equipment manuals by other brands
