Ecosoft MO6500BWTSS User manual

Instrucon manual
Ecoso RO System MO6500BWTSS

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
3
INSTRUCTION MANUAL ECOSOFT RO SYSTEM MO6500BWTSS
CONTENTS:
1. Acronyms and abbreviaons.................................................................................. 4
2. Product descripon................................................................................................. 4
2.1. Overview.......................................................................................................... 4
2.2. Technical specicaons.................................................................................... 5
2.3. Product water capacity charts......................................................................... 6
3. Installaon and startup........................................................................................... 7
4. Installaon requirements........................................................................................ 9
5. Operang requirements......................................................................................... 9
6. Shipping and storage requirements........................................................................ 11
7. Troubleshoong...................................................................................................... 12
8. Controller................................................................................................................ 14
8.1. Overview.......................................................................................................... 14
8.2. Input & output specicaons.......................................................................... 14
8.3. Operang modes............................................................................................. 15
8.4. Program sengs.............................................................................................. 18
A. Wiring diagram....................................................................................................... 22
B. Pipe and instrument diagrams................................................................................ 24

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
4INSTRUCTION MANUAL ECOSOFT RO SYSTEM
MO6500BWTSS
1. ACRONYMS AND ABBREVIATIONS
2. PRODUCT DESCRIPTION
CIP — Clean-in-place PCB — Printed circuit board
FF — Forward ush P&ID — Piping and instrumentaon diagram
NC — Normally closed RO — Reverse osmosis
NO — Normally open BW — Brackish water
TDS — Total dissolved solids
2.1. OVERVIEW
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilies, or lack of experience and knowledge, unless
they have been given supervision or instrucon concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they do
not play with the appliance.
Ecoso RO systems operate as follows.
Raw water is fed through sediment prelter in order to remove parcles. If raw water is treated
with anscalant or other RO chemicals, the prelter housing ensures beer mixing.
Then, high pressure pump feeds the water into the membrane module or membrane array, in
which feed water undergoes separaon process and splits into permeate and concentrate streams.
Permeate (puried water) goes to the permeate outlet and is collected in water tank. Permeate
line is also ed with a pressure switch to halt the unit if signicant pressure builds in permeate
line indicang a full pressurized tank or pipeline shuto.
Float switch has to be put inside an ambient pressure tank (if used) to start and stop the unit
depending on the level of permeate in the tank.
Part of the concentrate stream is discharged to drain via drain rotameter. The rest goes back to
the sucon end of the high pressure pump via recycle rotameter.
Flow rates of drained and recycled concentrate have to be regulated to specied ranges in the
Technical specicaons with the regulang valves built in the rotameters.
When service is interrupted by oat switch or pressure switch signal, the system runs a forward
ush (membrane rinse) cycle, then switches to standby. The controller receives temperature and
conducvity of permeate, permeate level, pressure switch statuses, and external inhibion signals.
Ecoso brackish water reverse osmosis systems are used for demineralizing water in industrial,
municipal, commercial applicaons. Ecoso BW RO system can be used to demineralize low to
medium salinity feed water. System components comprise stainless steel skid, prelter housing,
high pressure pump, pressure vessels with membranes, electrical panel, process controller, and the
necessary valves and instruments.

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
5
INSTRUCTION MANUAL ECOSOFT RO SYSTEM MO6500BWTSS
2.2. TECHNICAL SPECIFICATIONS
Table 1. Physical parameters
Model (SKU) MO6500BWTSS MO12000BWTSS
Rated capacity, LPH* 280 500
Membranes 1 × 4040 2 × 4040
Power consumpon 2.2 kW
Dimensions ( Width × Depth × Heigth ) 0.75 × 0.54 × 1.52 m
Approximate dry weight 130 kg 150 kg
Port sizes (feed water inlet, permeate
outlet, concentrate drain outlet) ½”
Working ow rates in typical operang condions**
Recycle ow rate 500…1000 l/h 500…1000 l/h
Drain ow rate 150…300 l/h 250…500 l/h
Permeate ow rate 250…400 l/h 450…700 l/h
Water consumpon per forward ush 40…60 l
* at feed water temperature = 25⁰С, TDS=10 g/l, 40% permeate recovery
** feed water must comply with requirements in Table 2. See Installaon and Startup secon
for a more specic instrucon on Permeate, Drain, and Recycle ow rates.
Table 2. Limitaons
Inuent water quality ***
Max. Total
Hardness
150 mg/l CaCO3
(without an-
scalant)
Max. Iron,
Manganese, Hy-
drogen Sulde
0.05 mg/l
Max. Silica
20 mg/l
(without an-
scalant)
Max. Chemical
Oxygen Demand
(KMnO4)
5.0 mg/l O2
Max. Total Sis-
solved Solids 10 000 mg/l Max. Chlorine (connuous) 0.1 mg/l
Operang parameters
Required supply
water pressure 0.2…0.4 MPa Max. operang pressure 2.5 MPa
Temperature of
water 5…30 °C Electrical power 230 V, 50 Hz (1 phase)
***Some limitaons may not apply if using anscalant, oxygen scavenger, or
other type of chemical pretreatment.
Tap feed water must be
pre-ltered from ne
parcles and chlorine
before entering the
RO system. Well water may contain
impuries such as hardness, iron,
manganese, silica, hydrogen sulde
that can quickly lead to membrane
failure. Some of these challenges
can be addressed by using injecon
of anscalant. Perform a detailed
laboratory analysis of your well
water and consult a water treatment
specialist to see if you need addional
equipment for treang your well water.

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
6INSTRUCTION MANUAL ECOSOFT RO SYSTEM
MO6500BWTSS
Figure 2.1 Ecoso MO6500BWTSS
ow rate chart
Permeate ow rates are calculated under the following condions:
• 1.5…2.0 bar inuent water pressure
• 0 bar backpressure in the permeate line
• variable permeate recovery (shown on the top)
• 80% of the rated membrane ux
See the following secon for instrucons on process setup.
1 1
0
100
200
300
400
500
600
700
800
0 1 2 3 4 5 6 7 8 9 10 11 12
Permeate flow rate, l/h
Feed water total dissolved solids, g/l
25 °C
15 °C
5 °C
0
100
200
300
400
500
600
700
800
0 1 2 3 4 5 6 7 8 9 10 11 12
Permeate flow rate, l/h
Feed water total dissolved solids, g/l
25 °C
15 °C
5 °C
75% 70% 65% 60% 55% 50% 45% 40%
75% 70% 65% 60% 55% 50% 45% 40%
Permeate
recovery, %
Permeate
recovery, %
Figure 2.2 Ecoso MO12000BWTSS
ow rate chart
2.3. PRODUCT WATER CAPACITY CHARTS

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
7
INSTRUCTION MANUAL ECOSOFT RO SYSTEM MO6500BWTSS
3. INSTALLATION AND STARTUP
3.1 Rest the unit on a at level surface capable of supporng its weight (see Table 1). Install
permeate tank next to the unit. Inspect the RO system carefully for damage, including piping, valves
and instruments, pump, pressure vessels, prelter housings, electrical panel before proceeding
with connecon and startup.
3.2 Install membrane in each pressure vessel as follows. Remove the pipes connected to the
pressure vessel ends. Take apart clamp unions or dismantle ange/Victaulic couplings if necessary.
Aer all adjacent pipes are disconnected and will not get in the way, remove one of the lids of each
pressure vessel. Typically, the lids are held with clamps that must be loosened.
Make a cut in membrane packaging bag and insert membrane in the pressure vessel. The brine
seal ring has to be at the feed end of the vessel. Central tube of the membrane has to mate with
membrane adapter installed at the concentrate end of pressure vessel. If necessary, remove the
opposite lid also for easier inseron of the membrane. Install the lids back in place. Install the
holding clamps back on the lids.
3.3 Connect raw water pipeline from the water main or booster pump. Connect drain and
permeate pipes to the respecve connecon ports of the RO system. Recommended pipe size is at
least equal to that of the connecon port. Use appropriate ngs as necessary. Ensure air gap at
the end of drain line to prevent backsiphonage. Run permeate pipe from the permeate outlet to
the permeate tank and connect using appropriate ngs or glands.
3.4 Put the oat switch inside permeate tank aer moving ballast the necessary length up
the cord to provide enough level dierence between acvated and deacvated posion. Aer the
rst lling of the tank, verify that the oat switch acvates and deacvates in the right posions.
3.5 If the RO system has permeate rinse enabled, install the necessary piping. If using
service interrupon by external signal (microswitch), remove jumper from the stop terminals in
the electrical panel. Then, run a cable from the microswitch to the panel and connect to the Stop
terminals. If using anscalant or other RO chemicals, refer to the dosing pump’s instrucon manual
for informaon concerning the dosing pump.
3.6 Run power to the RO system. Connect the phase(s), neutral, and earth conductors as
shown on the electrical diagram. Use a suitable ampacity circuit breaker in your distribuon panel.
Cauon! Electrical installaon should only be done by a qualied electrician.
Observe direcon of arrow on pressure vessel when installing membrane. Use glycerol
or a similar RO-compable lubricant as needed. Avoid touching membrane with hands.
Use sterile rubber gloves when handling membrane.
It is strongly recommended to use short runs of pipe or hose the size of which matches
or exceeds that of the connecon port.

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
8INSTRUCTION MANUAL ECOSOFT RO SYSTEM
MO6500BWTSS
3.9 Let the unit run for 1 hour discarding both permeate and concentrate to drain to ush out
the membrane preservave. Watch ow rate and pressure gauges to make sure they do not deviate
from the setpoint.
Take care not to exceed the maximum specied pressure in membrane module. If the
membrane pressure rises above the upper limit in specicaon, open recycle ow
regulang valve to bring it down.
Turn regulang valve knobs smoothly when regulang recycle and drain ow. Do not
make rapid turns or apply disproporonate force as this can damage the unit.
START UP THE SYSTEM AS FOLLOWS:
3.7 Fully open recycle and drain ow regulang valves before powering up the system. Make
sure to discard all permeate obtained during the rst run of the RO system.
3.8 Power up the system. The controller will boot up and begin service. Wait unl the air
is vented from the system and the pressure reading stabilizes. In case low feed pressure fault or
another fault occurs, see Troubleshoong secon for help.
Tighten drain ow control valve unl drain rotameter reading meets the specicaons (see
Table 1). Then, start turning down recycle regulang valve. This will rapidly raise pressure in the
membrane array (shown on pressure gauge up front). Stop regulang recycle ow control when the
permeate ow rate reaches full capacity or when the pressure in the membrane module reaches
the upper limit (see Table 1).
Aer seng up the recycle ow rate, check the drain ow rate again and readjust it to the
approximate value obtained with the following formula:
EXAMPLE:
Assume feed water TDS = 6 g/l, t = 15 °C.
On Figure 2.1 MO6500BWTSS ow capacity chart the following approx. values will be found:
Permeate ow rate = 300 l/h ≈ 5 l/min
Recovery ≈ 55% = 0.55
Using the above formula, Target Drain Flow Rate = 300/0.55 - 300 = 245 l/h ≈ 4 l/min
Therefore, the RO system has to be set up as follows:
1. Tighten Drain Flow Control unl Drain rotameter shows 4 LPM.
2. Tighten Recycle Flow Control unl Permeate rotameter shows 5 LPM.
3. Recycle rotameter ow rate depends on other factors and may vary signicantly, but should in most
cases be within the range specied in Table 1.
4. Verify that the Operang pressure does not exceed the maximum value of 25 bar.
5. Verify that the obtained Permeate Flow Rate and Drain Flow Rate are consistent with the Permeate
Recovery used in the calculaon.
Target Drain Flow Rate = Permeate Flow Rate - Permeate Flow Rate
Permeate Recovery
where the Permeate Flow Rate and Permeate Recovery values are to be found on the system
capacity graphs (from your raw water TDS and temperature) in Product descripon secon.

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
9
INSTRUCTION MANUAL ECOSOFT RO SYSTEM MO6500BWTSS
4. INSTALLATION REQUIREMENTS
• Installaon and setup of the unit should be undertaken by a qualied professional. Room
or area where the unit is to be installed must meet workplace standards of local building code.
• The unit must not be operated in outdoor environments. Do not expose to weather
condions (rain, temperature uctuaons, proximity of heang equipment, direct sunlight etc).
• Air at workplace should be free of corrosive vapors, airborne dust, and brous maer.
• To provide access to the unit for maintenance and repair purposes, respect the following
clearances between the unit and building structures: 500 mm to the le or right, 200 mm above.
• Electrical connecons must comply with local electrical code. Make sure to follow
applicable grounding and insulaon rules.
• Supply, drain, and delivery pipework must comply with local plumbing code and have
sucient ow capacity. Drain line of the unit must be separated from oor drain with an air gap.
• Construcon material or inside lining of permeate tank must be resistant to water
corrosion (e. g. stainless steel, polypropylene). Tank should be installed next to the unit.
• Anscalant pump sucon line length should not exceed 1.5 m. Refer to dosing pump’s
manual to adjust pump’s sengs if it has not been factory congured.
5. OPERATING REQUIREMENTS
5.1 Operator of the unit must strictly follow these guidelines and general electrical safety
precauons.
5.2 When operang the unit, ensure that pressure and ow rates are within specicaon
limits and that power supply is clean and uninterrupted.
5.3 Perform the following at least once a month:
• verify that pressure and ow rate parameters have not deviated (substanally);
• verify ghtness (absence of leaks) from connecons and visual integrity of parts.
5.4 In order to monitor performance of the RO machine, regularly keep record of
operaon and write down parameter readings. Use membrane manufacturer’s soware tools for
normalizaon to control for uctuaons of pressure, temperature, and other operang condions.
5.5 Change polypropylene cartridge when it has clogged. Pressure drop of 0.1 MPa or greater
on the sediment lter indicates that lter cartridge needs to be replaced as soon as possible.
If power supply cable or any other electrical wiring is damaged, it must be replaced by a
vendor’s service sta or similarly qualied person.

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
10 INSTRUCTION MANUAL ECOSOFT RO SYSTEM
MO6500BWTSS
5.6 Perform CIP or another suitable chemical cleaning protocol when any of the following
condions are encountered:
• normalized permeate ow rate drops 10-15% of its inial value;
• normalized conducvity of permeate increases 10-15% of inial value, raw water
conducvity remaining at the same level;
• normalized pressure drop along the membrane array rises 10-15% of its inial value.
5.7 Aer installing freshly cleaned membrane, perform 1 hour rinse discarding all permeate
and concentrate. If chemical cleaning fails to restore normalized ow or rejecon to design
specicaons, membrane element is irreparably fouled and has to be replaced.
5.8 To prevent microbial contaminaon, the unit should be operated for at least 1 hour a day.
In case 48 hours or longer shutdown is to occur, membrane should be treated with preservave
soluon. Preservave treatment is accomplished by circulang 1% sodium metabisulte soluon
through the membrane module for 30 minutes or by preparing metabisulte soluon of the above
strength in the module. Before resuming operaon of a machine that had been treated with
preservave, rinse the membrane.
Do not use supply water with over 0.1 mg/L of free chlorine without pre treatment with
acvated carbon or other means of dechlorinaon. Chlorine will destroy the membrane.
5.9 To replace sediment lter cartridge proceed as follows:
• remove the power from the unit;
• shut o water supply and relieve pressure;
• screw o lter bowl and remove it, taking care not to spill water on parts of the unit;
• remove spent cartridge from the bowl, place a clean one inside and screw the bowl back on.
5.10 To replace membrane element proceed as follows:
• remove the power from the unit;
• shut o water supply and relieve pressure;
• disconnect feed, permeate, and concentrate tube connecons at membrane module
outlets;
• unfasten clamps holding the pressure vessel and take down the vessel;
• remove caps from the pressure vessel;
• push the membrane element from the feed end towards the discharge end (in the
direcon of the arrow). Extract the membrane element by pulling it at the discharge end
of the vessel;
• install new membrane element, observing ow direcon as indicated by the arrow;
• fasten the caps and install the vessel back in place;
• re-connect tubes back to the vessel.

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
11
INSTRUCTION MANUAL ECOSOFT RO SYSTEM MO6500BWTSS
Do not perform any maintenance, repair, cleaning, moving the unit or ancillary units
(permeate tank, media lters etc), when the unit is connected to power and water
supply.
Do not subject pressure vessel to mechanical impact (shocks, stac load etc).
The manufacturer shall not be held liable for any damages incurred by the owner of the
unit or any third party due to failure to adhere to the safety precauons or installaon
guidelines herein.
6. SHIPPING AND STORAGE REQUIREMENTS
• The unit must be stored indoors. Ambient air quality must meet workplace standards.
• Carry out preservave treatment of membrane elements when preparing for an extended
downme.
• The RO machine in its original packaging can be shipped by all types of air, sea or ground
transport.
• During transportaon, the unit must be protected from exposure to low temperatures
and jolts/vibraon.

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
12 INSTRUCTION MANUAL ECOSOFT RO SYSTEM
MO6500BWTSS
7. TROUBLESHOOTING
Problem Possible cause Correcve acon
The controller
is not starng
aer powering
up the unit
No power /
incompable power
supply
Ensure that the power meets Technical specicaons.
If the power supply is adequate, then switch o the
power rst, open the controller housing and check:
— the fuses are not blown
— wires in screw terminals #30, #31, #32 are not loose
Circuit breaker
trips in the
main panel
Power supply does
not meet system
requirements
The system requires clean power supply compliant with
the Technical specicaons.
Check for brownout, overvoltage, power surges.
The pump will
not start aer
the controller
boots up
Controller is in
Standby mode
Check if the permeate tank is full, or if the oat switch has
stuck in the upward posion. Check that the permeate
pipeline is not blocked or shut o with a valve.
Controller is in Stop
mode
Push START buon to see if it is manually stopped. If
nothing happens, then (remove the power rst!) open
the electrical panel and check that Stop terminals are
connected with a jumper wire.
Controller is in Service
mode but the pump
isn’t running
Thermal protecon switch (built-in the motor juncon
box) may trip due to pump stalling, jamming, or
inadequate voltage. It will release aer cooling down.
Another possibility is a loose wire in the controller
terminal block or in the electrical panel (remove power
before accessing the electrical parts!)
Low feed
pressure
fault occurs
immediately
aer startup
The air has not been
completely purged
from the system
Fill the system completely with water. One way to do this
is to enter controller sengs and temporarily set 1.1 High
pressure pump delay to 255 seconds, then revert back
aer the air bubbles disappear.
Obstrucon in the
water supply pipeline
Avoid using long runs of small diameter pipes. Check that
there are no sharp bends if using a exible hose.
Clogged prelter Check the lter cartridge and replace if necessary.
Do not access any electrical parts before ensuring that the electrical power has been
removed.
Do not access any electrical parts or aempt any diagnoscs / repair unless you are a
trained electrician.

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
13
INSTRUCTION MANUAL ECOSOFT RO SYSTEM MO6500BWTSS
Problem Possible cause Correcve acon
Low feed
pressure
fault occurs
aer running
smoothly for a
while
Insucient water
supply capacity
leading to a sharp
pressure drop during
Forward Flush cycle
The system requires a higher supply water ow rate for
the duraon of the Forward ush cycle.
If the problem can’t be resolved, it can be bypassed by
entering the Controller Sengs and changing 1.7 Read
low feed pressure during Forward Flush to o (Warning:
this will lead to less ecient membrane rinse so quicker
membrane deterioraon)
Clogged pre-lter
cartridge or water
supply pressure dip
Check the lter cartridge and replace if necessary.
Check that the inuent pressure is stable.
High
permeate
conducvity
High water
temperature
Check that the feed water temperature meets the
provisions of Technical specicaons
Operang pressure
and/or concentrate
ow rate is too low
Check that the ow rates and the operang pressure
meet the provisions of Technical specicaons
Poor quality inuent
water
Verify that the water analysis meets the requirements of
the Technical specicaons
Damaged seal on
the membrane or
membrane coupling
connector
Replace the damaged seals
Membrane fouling,
scaling, or mechanical
damage
Replace the membrane or carry out chemical cleaning
Low permeate
ow rate
Low water
temperature
Check that the feed water temperature meets the
provisions of Technical specicaons
Operang pressure
and/or concentrate
ow rate is too low
Check that the ow rates and the operang pressure
meet the provisions of Technical specicaons
Membrane fouling or
scaling Replace the membrane or carry out chemical cleaning
Other Other issue / unclear
possible cause Contact your vendor’s customer support

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
14 INSTRUCTION MANUAL ECOSOFT RO SYSTEM
MO6500BWTSS
8. CONTROLLER
8.2. INPUT & OUTPUT SPECIFICATIONS
Table 2. List of terminals
PURPOSE VOLTAGE MARKING PIN #
Power supply
Live 110-220 VAC,
50/60 Hz
L32
Neutral N 31
Ground Ground 30
Input terminals
Conducvity meter Cond 1 — white
2 — black
Temperature sensor + Term −
3 — red
4 — green
5 — blue
Low feed pressure switch
5 V
(only use dry contact
NC/NO switches)
P_in 8–9
High operang pressure switch P_max 10–11
High permeate pressure switch P_perm 12–13
Permeate oat switch Level 14–15
Stop switch Stop 6–7
Output terminals
Pump contactor
110-220 VAC (matching
the power supply
voltage)
PUMP 28–29
27 (ground)
Alarm signal out ALARM 25–26
Entry electric valve Valve_IN
24 (neutral)
23 (open)
22 (ground)
Flush electric valve Valve_Rinse
21 (neutral)
20 (open)
19 (ground)
Bypass electric valve Valve_Bypass
18 (neutral)
17 (open)
16 (ground)
Ecoso OC5000 process controller is used for automang reverse osmosis system operaon. The
input and output device connecons are described in the table below.
Depending on current status and input device readings the controller will operate in any of the
following modes: Service, Standby, Forward Flush, Stop, Fault (described in the following secon).
The user interface comprises two buons and an LCD display. STOP buon is used for stopping
the unit (short press) or entering the Sengs menu (long hold). START buon is used for scrolling
in the Sengs menu or iniang a Forward Flush (if pressed during service screen display).
8.1. OVERVIEW
For more detail, please see the wiring diagram.

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
15
INSTRUCTION MANUAL ECOSOFT RO SYSTEM MO6500BWTSS
When operang, the controller will be in any one of the following modes: Service, Stop, Forward
Flush 1, Forward Flush 2, Standby, Fault. Immediately aer starng, the controller will display
rmware version and then proceed to Service if tank permeate level is low and backpressure switch
is not acvated.
Here and below informaon is relevant to the rmware version “OC5000EC ver_03”. For
informaon on dierent rmware versions please contact your technical support.
Conguring and manipulang the controller is done using START and STOP buons. Current
mode of operaon and pertaining informaon is shown on the LED display. Opening the circuit in
the Stop domain of terminal block (see gure 1) will bring the controller to Stop mode regardless of
its current mode of operaon. Closing the circuit will take the controller back to the mode that had
been interrupted. Stop terminals can be used to connect a microswitch on pre-treatment media
lter, a relay or other means of external control to the controller.
Following is the descripon of controller modes.
SERVICE.
In Service mode, the RO machine produces permeate. If no fault condions are taking place, oat
switch is low and backpressure switch is not acvated, the controller will operate in Service mode.
Display will ash cumulave runme of the RO machine, remaining me before scheduled
maintenance alert (if set in conguraon step 3.1), temperature and conducvity of permeate
(or TDS of permeate if conguraon step 1.15 is set to “on”). Pushing START once will iniate
Forward Flush 1, pushing START twice in 0.5 seconds or less will iniate Forward Flush 2 (if
conguraon step 1.3 is set to non-zero value), pushing STOP will bring on Stop mode. If high
feed pressure, low feed pressure, or high permeate conducvity condion occurs, the controller
will go into Fault mode.
FORWARD FLUSH 1
During Forward Flush 1, membranes are rinsed with high ow of raw water allowing concentrate run
freely to drain. Forward Flush 1 occurs during normal operaon with frequency set in conguraon
steps 1.5, 1.6. It is also acvated in Service mode if the controller is going to transion to Standby
aer reading high tank level or high permeate pressure. It can be manually acvated while in Service
by pushing START buon.
8.3. OPERATING MODES
Status of outputs in SERVICE
Booster and anscalant pumps on
Entry valve open
Forward ush valve closed
Bypass valve open (if conguraon step 1.3 is set to 0)
closed (if conguraon step 1.3 is non-zero value)
Alarm o

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
16 INSTRUCTION MANUAL ECOSOFT RO SYSTEM
MO6500BWTSS
Pushing STOP will abort Forward Flush 1 and bring the controller to Stop mode. Pushing
START will cycle the controller to Forward Flush 2 mode (if conguraon step 1.3 is set to non-zero
value). If high feed pressure or low feed pressure occurs, the controller will go into Fault mode. Low
feed pressure fault during Forward Flush 1 can be disabled in conguraon step 1.7.
FORWARD FLUSH 2
Forward Flush 2 consists in rinsing membranes with permeate supplied from permeate tank by
permeate pump.
Pushing STOP will abort Forward Flush 2 and bring the controller to Stop mode. Pushing
START will abort Forward Flush 2 and bring the controller to Service or Standby (depending on tank
level and backpressure status).
STANDBY
In Standby, the unit is stalled and ready to resume service. Standby mode is brought on by reading
high tank level or tripping permeate backpressure switch.
Forward Flush 2 occurs aer each Forward Flush 1 if conguraon step 1.3 is set to non-zero
value. It can be manually brought on by pushing START during Forward Flush 1 or double pushing
START during Service.
Status of outputs in FORWARD FLUSH 2
Booster and anscalant pumps on (if conguraon step 1.4 is set to ‘on’)
o (if conguraon step 1.4 is set to ‘o’)
Entry valve closed
Forward ush valve open
Bypass valve open
Alarm o
Forward ush 2 with permeate is only possible if the RO system is equipped with rinsing
electric valve.
Status of outputs in FORWARD FLUSH 1
Booster and anscalant pumps on
Entry valve open
Forward ush valve open
Bypass valve closed
Alarm o
Status of outputs in STANDBY
Booster and anscalant pumps o
Entry valve closed
Forward ush valve closed
Bypass valve closed
Alarm o

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
17
INSTRUCTION MANUAL ECOSOFT RO SYSTEM MO6500BWTSS
Pushing STOP will bring the controller to Stop mode. Pushing START will take the controller
into Service if permeate is low and backpressure switch is inacve. Otherwise, pushing START
will iniate Forward Flush 1 and Forward Flush 2 (if set) and then bring the controller back to
Standby. When oat switch or permeate backpressure switch deacvate, the controller will go back
to Service.
FAULT
In Fault mode, the unit is stalled to protect the equipment from dangerous operang condions.
Fault mode is brought on by acvang low feed pressure switch (to prevent ‘dry running’), high
feed pressure switch (to protect against overpressure), or reading an excessively high permeate
conducvity value (which could mean membrane rupture or other malfuncon if conguraon
step 1.16 is set to non-zero value.).
Fault mode can only be quit manually by pushing START. Ensure the cause of fault is eliminated
before quing Fault mode. Pushing STOP will bring the controller to Stop mode.
STOP
In Stop mode, the unit is stalled and awaing further input. Stop mode can be manually brought
on by pushing STOP in any mode, or by stop switch opening circuit between STOP terminals on
the printed circuit board.
Upon pushing START or deacvang stop switch, the controller will resume from where it was
interrupted.
Status of outputs in FAULT
Booster and anscalant pumps o
Entry valve closed
Forward ush valve closed
Bypass valve closed
Alarm on
Status of outputs in STOP
Booster and anscalant pumps o
Entry valve closed
Forward ush valve closed
Bypass valve closed
Alarm o

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
18 INSTRUCTION MANUAL ECOSOFT RO SYSTEM
MO6500BWTSS
Conguraon sengs are stored in non-volale memory. Access to each submenu is protected
with passcode. To enter conguraon menu, hold STOP for 8 seconds. In the menu, eding and
storing values is helped by ashing cursor. START buon moves cursor one posion to the right,
STOP buon increments selected digit by one, cycles between opons, or scrolls to the next
screen when the cursor is at the ‘>’ symbol.
*During the rst run of the R.O. unit, the parameter can be increased to the maximum value in order to vent
the air and ll the system with water. Make sure to revert it back to the factory seng of 10 sec.
8.4. PROGRAM SETTINGS
MENU FACTORY SETTINGS
SETTINGS
1. SETTINGS AND CALIBRATION PASSCODE PROMPT 0000
1.0 Language English
1.1 High pressure pump delay, s 10 s*
1.2 Forward Flush 1 duraon, s 60 s
1.3 Forward Flush 2 duraon, s 0 s
1.4 High pressure pump power during Forward Flush 2, on/o o
1.5 Frequency of periodic Forward Flush in Service, h 4 hour
1.6 Frequency of periodic Forward Flush in Standby, h 24 hour
1.7 Read low feed pressure during Forward Flush, on/o on
1.8 Low feed pressure switch, NO/NC NC
1.9 Low feed pressure Fault delay, s 3 s
1.10 High feed pressure switch, NO/NC NO
1.11 Permeate backpressure switch, NO/NC NC
1.12 Backpressure Standby delay, s 1 s
1.13 Tank level switch, NO/NC NC
1.14 Tank level Standby delay, s 1 s
1.15 Display TDS in ppm o
1.16 Permeate conducvity Fault threshold, μS/cm 0 μS/cm
1.17 Permeate conducvity Fault delay, s 0
1.18 Display temperature C
1.19 New sengs and calibraon passcode -
2. SETTINGS AND CALIBRATION PASSCODE PROMPT 0000
2.1 First point value, μS/cm -
2.2 Second point value, μS/cm -
3. MAINTENANCE PASSCODE PROMPT 0000
3.1 Schedule maintenance stop, on/o o
3.2 Scheduled stop period, h (if 3.1 is set to ‘on’) 500 h
3.3 New maintenance passcode

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
19
INSTRUCTION MANUAL ECOSOFT RO SYSTEM MO6500BWTSS
1. Sengs
Hold STOP for 8 seconds to launch menu prompt. Push START to enter Sengs submenu.
Enter passcode in the prompt. Factory passcode is ‘0000’.
1.0 Language
Choose language to display operaon informaon & menu. Avialable languages include English
& Russian.
1.1 High pressure pump delay
Enter length of interval between opening the entry valve and starng the pump when the unit is
going into Service (0…255 seconds).
1.2 Forward Flush 1 duraon
Enter length of Forward Flush 1 (0…255 seconds). Forward Flush 1 will not be performed if the
parameter is set to zero.
1.3 Forward Flush 2 duraon
Enter length of Forward Flush 2 (0…255 seconds). Forward Flush 2 will not be performed if the
parameter is set to zero. Default seng is zero (Forward Flush 2 disabled).
1.4 High pressure pump power during Forward Flush 2
This seng species whether the high pressure pump will be powered during Forward Flush 2
(on/o).
1.5 Frequency of periodic Forward Flush in Service
This seng determines how oen Service mode is interrupted to run forward ush sequence
(once in 0…255 hours).
1.6 Frequency of periodic Forward Flush in Standby
This seng determines how oen Standby mode is interrupted to run forward ush sequence
(once in 0…255 hours).
1.7 Read low feed pressure during Forward Flush
This seng species if low feed pressure switch status will be read by the controller during
forward ush. If set to ‘o’, low feed pressure situaon will not bring about Fault mode.
1.8 Low feed pressure switch
This seng species whether low feed pressure switch is normally closed (NC) or normally open
(NO) type.
1.9 Low feed pressure Fault delay
Specify the length of me before the controller goes into Fault mode if low feed pressure condion
occurs (0…255 seconds). The pump will connue to run for this many seconds before Fault mode is
switched to. If set to 0, pump will stop running immediately aer low feed pressure occurs.

This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
20 INSTRUCTION MANUAL ECOSOFT RO SYSTEM
MO6500BWTSS
1.10 High feed pressure switch
This seng species if high feed pressure switch is normally closed (NC) or normally open (NO)
type.
1.11 Permeate backpressure switch
This seng species whether backpressure switch is normally closed (NC) or normally open (NO)
type.
1.12 Backpressure Standby delay
Specify the length of me before the controller goes into Standby if high permeate pressure
condion occurs (0…255 seconds). Controller will connue to operate in Service mode for the set
length of me before running pre-Standby forward ush or will iniate Forward ush immediately
if value set to 0.
1.13 Tank level switch
This seng species whether oat switch is normally closed (NC) or normally open (NO) type.
1.14 Tank level Standby delay
Specify the length of me before the controller goes into Standby if tank level switch goes high
(0…255 seconds). Controller will connue to operate in Service mode for the set length of me
before running pre-Standby forward ush or will iniate Forward ush immediately if value set to 0.
1.15 Display permeate TDS in ppm
If set to “on”, electrical conducvity (EC) of permeate will be displayed as TDS in ppm as TDS =
0.5147 * EC.
1.16 Permeate conducvity Fault threshold
Specify maximum acceptable permeate conducvity. Conducvity reading above this value will
iniate Fault mode (‘High permeate TDS’). If set to zero, fault threshold will not be used.
1.17 Permeate conducvity Fault delay
Specify the length of me before the controller goes into Fault mode when high permeate
conducvity is being read. Step 1.17 is displayed only if step 1.16 is set to non-zero value.
1.18 Display temperature
Select units of temperature (C for Celsius, F for Fahrenheit).
1.19 New sengs and calibraon passcode
Verify passcode.
