Ecotec STC User manual

Operating Instructions for STC
Battery Charger

General Safety
The charger may only be used for the specified battery types.
This battery charger is supplied with pre-set charging curves
that are adapted for the battery types listed in figure 1.
Always contact the battery manufacturer to verify that the
charging curve is appropriate.
Hydrogen gas is generated when charging batteries, which
can cause an explosion.
During and immediately after charging, batteries may not be
placed in the vicinity of sparks or open flame.
Do not use the battery charger if it is damaged. Do not
touch damaged components. Turn off the input AC voltage
immediately and contact service personnel.
The battery charger has high voltage inside the charger case
that can cause personal injury or death. The metal casing
may only be opened by authorized service personnel.
Disconnect the battery and input AC power before carrying
out maintenance or cleaning the battery charger.
The Battery charger must be connected to an earth
grounded AC input source.
Batteries should only be charged in a well ventilated area.

Installation
Initial Installation
The AC input source to which the charger is to be connected must be
capable of supplying the current specified on the charger nameplate.
Avoid the use of extension cords with the charger. The use of an
improper extension cord could result in a risk of fire or electric shock.
Locate the charger cord such that it will not be stepped on, tripped over
or otherwise subjected to damage or stress.
Do not operate this charger if it has been dropped or is visibly damaged
in any manner; return to manufacturer for service.
The battery charger should be installed indoors in a low humidity and
low dust/airborne particle environment.
If several battery chargers are to be installed next to each other, they
may not be located so that warm exhaust air from one battery charger
blows into the air intake of another battery charger.
Install the battery charger so that gasses from charging battery do not
get sucked in by the battery charger fan.
The battery charger may be mounted horizontally, or suspended on a
wall with the accompanying bracket. When mounted on a wall the
charger should be placed horizontally to prevent the effects of moisture
and dirt. This charger is not intended to be mounted on mobile
equipment.
CAUTION: TO REDUCE THE RISK OF FIRE, USE THIS
CHARGER ONLY ON CIRCUITS WITH BRANCH CIRCUIT PROTECTION
(CIRCUIT BREAKER OR FUSE) OF A MAXIMUM OF 20 AMPERES IN
ACCORDANCE WITH THE NATIONAL ELECTRIC CODE, ANSI/NFPA 70
AND ALL LOCAL CODES AND ORDINANCES.

Battery Charger Application
The STC charger is intended for use in single shift and other light duty
applications. Depending on battery capacity, charging can last from 10-16 hrs.
Battery capacity ranges for each model are listed below:
Charger
Model
Output
Voltage
Max Output
Amps
Battery Size
Range
STC 24/30
24VDC
30A
225-375 AH
STC 24/45
24VDC
45A
375-525 AH
Figure 1
WARNING: TO REDUCE THE RISK OF AN ELECTRIC SHOCK,
KEEP THE CHARGER DRY. DO NOT EXPOSE IT TO RAIN OR
STANDING WATER. STORE IN A CLEAN AND DRY LOCATION.

OPERATION
Charging
Connecting a battery
1Check that the battery charger is turned off and the front panel switch
is in the OFF position. All indicator lights should be off.
2Check the charger output cables and connector to ensure there is no
visible damage.
3Connect the battery to the battery charger.
4Start the battery charger. Set the front panel switch to the ON
position.
5The battery charger will start charging automatically after a few
seconds. The upper indicator light should light solid yellow.
6When the battery reaches approximately 80% charged, the other
yellow indicator light will light. Charging time will vary depending on
battery capacity and level of charge when connected.
7The lower indicator light will turn solid green when the battery is fully
charged. When the charger is left connected to the battery,
Maintenance charging will continue periodically.
Note! –The green LED indicator light will not light immediately if a fully
charged battery is connected. This time can vary from 30 to 60 minutes.
WARNING: IN CASE OF DANGER, DISCONNECT THE
CHARGER FROM THE AC INPUT VOLTAGE

Disconnecting a battery
1Turn off the charger. Set the front panel switch to the OFF position.
2Disconnect the battery from the battery charger
Maintenance
May only be performed by qualified personnel.
Troubleshooting
May only be performed by qualified personnel.
Safety Shutoff
Charging can be terminated if:
The battery does not reach 80% charged within the preset limit, the
charger will shut off. The lower red LED will light indicating the safety
shut off.
Charging is temporarily interrupted or reduced when:
The charger internal temperature exceeds the preset values.
Error messages
Charging faults are indicated by the lower red indicator light.
CAUTION: THE BATTERY CHARGER SHOULD BE TURNED
OFF WHEN DISCONNECTING THE BATTERY. IF THE BATTERY IS
DISCONNECTED DURING AN ONGOING CHARGE CYCLE, THE
CONTACTS IN THE CHARGING CONNNECTOR WILL BE DAMAGED
AND SPARK FORMATION CAN OCCUR CAUSING A HYDROGEN
EXPLOSION.

CHARGER WARRANTY
ECOTEC warrants that each new and unused PAC800 battery charger (the
“Product”) manufactured and supplied with good workmanship is free from
any known mechanical defect, provided that;
(A) the product is installed and operated in accordance with the accepted
industrial standards and in accordance with the printed instructions furnished
by ECOTEC
(B) the product is used under normal conditions for which designed.
(C) the product is not used in a corrosive, abnormally dusty or high humidity
moisture condensing environment.
(D) the product is not subjected to misuse, accident or negligence, and the
product receives proper care, protection and maintenance under supervision of
competent personnel.
Warranty Terms and Conditions
ECOTEC Battery Chargers are warranted for one (1) year, which begins on the
date of shipment from ECOTEC. During said period, warranty covers repair or
replacement FOB 262 Fox Drive, Piqua, OH 45356.
NON-TRANSFERABLE WARRANTY. This warranty is extended by ECOTEC only
to the original user (purchaser) of new equipment from ECOTEC or one of its
authorized agents. The product purchased under this agreement shall be used
exclusively by the buyer. There shall be no third party beneficiary of this
warranty.
REPAIR LIMITATIONS ECOTEC has the right to site inspection and judgment of
the claimed defects in any product covered by this warranty. ECOTEC's liability
is limited to the repair of any defects found to exist by ECOTEC or, at ECOTEC's
option, the replacement of the defective product.
ECOTEC and its authorized agents shall not be liable for direct or indirect
damages in excess of such repair or replacement. In no event shall the
purchaser be entitled to recover for contingent expenses from, but not limited
to, telephone calls, telegrams, travel expenses, lodging, duties and taxes, labor,
rental or replacement equipment, loss of business or profit or other
commercial losses.
CONTINUED USE OF DEFECTIVE PRODUCTS. The continued use of an ECOTEC
Battery Charger that is known to be defective VOIDS ALL WARRANTIES.

Warranty Terms and Conditions, Continued
REPAIR OF MODIFIED EQUIPMENT. Except as authorized in writing the
warranty specified does not cover any equipment that has been repaired by
any party other than ECOTEC or its authorized agents. Except as authorized in
writing the warranty specified does not cover any equipment that has been
modified, mechanically or electrically, by any party other than ECOTEC.
WARRANTY EXPENSE LIMITATIONS. ECOTEC will limit the warranty expense of
all chargers to be paid at a maximum of the original purchase price of the
charger.
The provisions of this warranty shall not apply to product in use outside of the
continental USA.
Except as stated above, all other warranties and conditions, either expressed or
implied, including implied warranties of merchantability and fitness for a
particular purpose, are excluded and buyer assumes all risk and liability
resulting from the use of the goods. ECOTEC neither assumes or authorizes any
persons to assume for ECOTEC any other liability in connection with the sale or
use of the goods sold and there are no oral agreements or warranties collateral
to or affecting this written warranty.
When installing, servicing or operating these products, safe practices should be
used by skilled and qualified technical persons.
