EcoWater ETF2100PF10 User manual

1
PRINTEDINU.S.A.PartNo.7217933 (02/2000)
EcoWaterSystems
P.O.Box64420 St.PaulMN55164 -9888
OWNERS
MANUAL
How to maintain and operate your
EcoWater multi--purpose filter
SERIES
ETF2100 PF

Unpacking,TableofContents
ECOWATER
SYSTEMS
3
2
UNPACKING
EcoWaterMulti--PurposeFiltersareshipped from
the factoryin1mastercarton consisting of ...
...Mineraltankand valve assembly
...Controllercoverand timerassembly
...Skin--pack ofsmall parts(includesthismanual)
NOTE:Filtering mineral isnotincluded.See
page 21 forordering information.
Thoroughly check the filterforpossibleshipping
damage and partsloss.Alsoinspectand note any
damage tothe shipping carton.Notifythe trans-
portation companyifdamage ispresent. EcoWater
isnotresponsibleforin--transitdamages.
Removeanddiscard(RECYCLE)allpackingmateri-
als.Wesuggest thatyou do notremovethe small
partson the skin--pack until you arereadyto use
them.Filterassemblyinstructionsare on page 5.
TABLEOFCONTENTSPage
Warranty/SafetyGuides3
Specifications/Dimensions4
Assembly5
Planning Installation 6 -- 7
Installation Steps8-- 10
Programming FacePlate--Timer11 -- 13
FilterOperation
General14
Service/Backwash/FastRinse 14 -- 16
ServiceInformation
Neutralizing Filter17
Taste&OdorFilter17
Troubleshooting 18 -- 19
Wiring Schematic19
RepairParts20 -- 23

Warranty,SafetyGuides
ECOWATER
SYSTEMS
3
3
EcoWater Systems, Inc.
AdvantageWarranty
Series ETF 2100 WaterSystem
Congratulations!You havejustpurchased the highestqualitywaterconditioning
productonthe market. Toregisteryourwarranty,completetheenclosedWarranty
Registration Card and mail itwithin 30 days ofpurchase.
To whom is this warranty extended?
EcoWaterSystems, Inc.warrantsitsproductstothe originalownerand
guaranteesthat the productswill be free fromdefectsinmaterialsand
workmanshipfromthe originaldate ofinstallation.
Howdoes mywarrantywork?
If, during the respectivewarrantyperiod,a partproves,afterinspection by
EcoWater, to be defective,EcoWaterwill,atits sole option repairor replacethat
partatno charge,otherthan normalshipping and installation charges.
Whatis covered bythewarranty?
EcoWatersystems, Inc.guaranteesthat,
forthe LIFETIMEof the originalowner, the SALT TANKand the MINERALTANK
willnotrust, corrode,leak,burst,orin anyothermannerfailto performtheirproper
functionsand that,
fora period ofFIVE (5)YEARSafterinstallation, the VALVE BODYwill be free of
defectsinmaterialsandworkmanshipandwill performitsproperfunctionandthat,
fora period ofTHREE (3)YEARSafterinstallation, the ELECTRONIC
FACEPLATEwill befree ofdefectsinmaterialsandworkmanship andwillperform
itsnormalfunctionsand that,
fora period ofONE(1)YEARafterinstallation,ALL OTHERPARTSwillbe free of
defectsinmaterialsand workmanship and will performtheirnormalfunctions.
Howdo Iobtainlocal service?
Shouldyou need service,yourlocal,independentEcoWaterDealerisonlya
phone call away.
PHONE:
IfIneedapartreplacedafterthefactorywarranty expires, is that part
warranted?
Yes,EcoWaterSystems, Inc.warrantsFACTORYREPAIRSaswell asall
replacementpartsfora period of90 DAYS.
Are any additional warranties available?
We are pleased tosay,YES!EcoWaterSystems, Inc.offersan EXTENDED,
PARTSONLYWARRANTYforthe ELECTRONICSportion ofyourproduct. This
warrantyis called the “PerfectTen”and extendsthe three yearwarrantyon the
electronicFACEPLATE,WIRINGHARNESS,DRIVE MOTOR,TRANSFORMER,
POWER CORD,SENSOR HOUSING,and MICROSWITCHES to a totalofTEN
YEARSfromthedateoforiginalinstallation.Shouldyourlocaldealernotofferthis
warranty,you may contact the factoryforadditional information.*
General Provisions
The abovewarrantiesare effective provided the waterconditionerisoperated at
waterpressuresnotexceeding 125 psi,andatwatertemperaturesnotexceeding
120°F;providedfurtherthat the waterconditionerisnotsubjectto abuse,misuse,
alteration,neglect, freezing,accidentornegligence;and provided furtherthatthe
waterconditionerisnotdamagedasthe resultofanyunusualforceofnaturesuch
as,butnotlimitedto, flood,hurricane,tornado orearthquake.EcoWaterSystems,
Inc., isexcused iffailureto performitswarrantyobligationsistheresultofstrikes,
governmentregulation,materials shortages,orothercircumstancesbeyond its
control.
To obtainwarranty service,noticemustbe given,withinthirty(30)days of thedis-
coveryof the defect, toyourlocalEcoWaterSystemsdealer.
*THERE ARENOWARRANTIES ONTHEWATER CONDITIONERBEYOND
THOSE SPECIFICALLYDESCRIBEDABOVE.ALL IMPLIEDWARRANTIES,
INCLUDINGANYIMPLIEDWARRANTYOFMERCHANTABILITYOROF
FITNESSFORAPARTICULARPURPOSE,AREDISCLAIMEDTOTHEEXTENT
THEY MIGHTEXTEND BEYOND THE ABOVE PERIODS.THE SOLE
OBLIGATIONOFECOWATERSYSTEMS, INC.UNDERTHESE WARRANTIES
ISTOREPLACEOR REPAIRTHECOMPONENTORPARTWHICH PROVES
TOBE DEFECTIVE WITHINTHE SPECIFIEDTIMEPERIOD,AND ECOWATER
ISNOTLIABLEFOR CONSEQUENTIALORINCIDENTALDAMAGES.NO
ECOWATER DEALER,AGENT,REPRESENTATIVE,OROTHERPERSONIS
AUTHORIZEDTOEXTEND OREXPAND THEWARRANTIES EXPRESSLY
DESCRIBEDABOVE.
Somestatesdo notallowlimitationson howlong an implied warrantylastsor
exclusionsorlimitationsofincidentalorconsequentialdamage,sothelimitations
and exclusionsinthiswarrantymaynotapplytoyou.Thiswarrantygives you
specificlegalrights,andyou mayhave other rightswhichvaryfromstatetostate.
Thiswarrantyappliestoconsumer--owned installationsonly.
SAFETYGUIDES
Followthe installation instructions carefully.Failure
toinstall the filterproperlyvoidsthewarranty.
Beforeyou begininstallation,read thisentiremanu-
al.Then,obtain all the materialsand tools you will
need tomakethe installation.
Check localplumbing and electricalcodes.The
installation mustconformtothem.
NOTE:Codesinthe state ofMassachusettsrequire
installation byalicensed plumber.Forinstallation,
useplumbingcode248--CMRoftheCommonwealth
ofMassachusetts.
Use onlylead--free solderand fluxforall
sweat-solderconnections,asrequired by state and
federalcodes.
Usecarewhenhandling thefilter.Donotturnupside
down,drop,orseton sharp protrusions.
Do notlocatethe filterwherefreezing temperatures
occur.Do notattempt tofilterwaterover120°F.
Freezing,orhotwaterdamagevoidsthewarran-
ty.
Avoidinstalling in directsunlight. Excessivesun
heatmay cause distortion orotherdamage to non--
metallicparts.
Thefilterrequiresaminimumwaterflow(seespecifi-
cations)at the inlet. Maximumallowableinletwa-
terpressureis 125 psi. If daytime pressureisover
80 psi,nighttime pressuremayexceed the maxi-
mum.Use a pressurereducing valveifnecessary.
Adding a pressurereducing valvemayreducethe
flow.
Thisfilterworks on 24 volt--60 hzelectricalpow-
eronly.Besureto usethe included transformer.
This systemisnotintended to be used fortreating
waterthatismicrobiologicallyunsafe orofunknown
qualitywithoutadequate disinfection before orafter
the system.

14”
14”
A
B
Specifiecations/Dimensions
ECOWATER
SYSTEMS
3
4
ETF2100PF10
10”DIAx47”
RESINTANK
ETF2100PF12
12”DIAx54”
RESINTANK
FILTERTYPE,Mineral¡
SEDIMENTREMOVAL
FilterAggregatelimitsfactoryrecommendation
based on wateranalysis
ACID NEUTRALIZER
Neutralitewatersupply pHlimits6.0to 6.8 6.0to 6.8
TASTE&ODOR REMOVAL
Activated Carbon limitsfactoryrecommendation based on wateranalysis
AMOUNTMINERALRECOMMENDED(cu. ft.)1to 1--1/4 2
AMOUNTGRAVEL(lbs.)17 29
AMOUNT FILTERSAND RECOMMENDED(lbs.)¡10 14 -- 15
SUPPLYWATERPRESSURELIMITS(PSI)20 -- 125 20 -- 125
SUPPLYWATERTEMERATURELIMITS(_F)35 -- 120 35 -- 120
MINIMUMINLETWATERFLOW,
BACKWASHAND FASTRINSE
FLOWTODRAIN(gal.perMin.)5 7
BACKWASHTIME(MINUTES)©25 25
FASTRINSE TIME(MINUTES)©5 5
¡notincluded withfilter©Default times-- cyclelengthisadjustable
ETF2100PF10 ETF2100PF12
A57”62--1/2”
B50”55--3/4”

AssemblyInstructions
ECOWATER
SYSTEMS
3
5
FILL THEMINERAL TANK
1.Removethe tank clamps, figure 1,valve assem-
bly,o--ring seals(3),and the top distributor.
2.Usingafunnel,add the specified amountof filter
sand, then the mineral.
Note:The filterisfactoryfilled withthe correct
amountofgravel.Filtersand,and the desired filter
mineralare notincluded.
CAUTION:To preventsand and mineralfromenter-
ing the bottomdistributorand riser, temporarilyplug
withaclean rag.
standpipe
top distributor
resin
tank
valve
assembly
clampretainer (2)
clampsection (2)
o--ring,
13/16”x1--1/16”
o--ring,
2--7/8”x3--1/4”
(thick)
o--ring,
2--3/4’ x3”
(thin)
standpipe
FIGURE1
SANITIZING THEFILTER
Careistaken at the factorytokeep you waterfilter
clean and sanitary.Materialsused tomakethe filter
will notinfectorcontaminateyourwatersupply,and
willnotcausebacterialtoformorgrow.However,dur-
ing shipping,storage,installing and operating,
bacteriacould getintothe filter.Forthisreason,sani-
tizing,asfollows,is suggested when installing.
Pourabout1 oz.(ETF2100PF10),or2 oz.
(ETF2100PF12),of the following disinfectantintothe
filter.
1.Calciumhypochlorite,availableingranularortablet
form,undertrade names such asPerchloron orHTH.
2.Common 5.25%household bleachsuch asClorox,
Linco,BoPeep,WhiteSail,Eagle,etc.
NOTE-- ACTIVATED CARBONFILTERS:ACTI-
VATED CARBONWILL ABSORBTHE SANITIZING
AGENT,EXPENDINGSOMECAPACITY.
SANITIZINGCONTINUEDINSTEP 9,PAGE10,
AND STEP 2ONPAGE12.
3.Thoroughly clean all sand and mineralfromthe
tanktop opening.Then,install the top distributor
and o--ring seals(4),exactlyas showninfigure 1.
4.Lowerthe valve assembly,ontothe mineraltank,
centering overthe standpipe,Push downward, to
squeezethe o--rings,and install the clampsections
and bothretainers.BE SURETHECLAMPS AND
RETAINERSAREFIRMLYINPLACE.

Planning Installation
ECOWATER
SYSTEMS
3
6
FIGURE2-- TYPICALINSTALLATION DRAWINGS
INLET-- OUTLETOPTIONS
1”coppertube
(2supplied)
1”x1”sweat
1”x3/4”sweat
1”sweatx1”
or3/4”pipe
thread
floordrain
floordrain
NOTE:Faceplate and support
notshownforclarityofdrawing.
Tieorwire valve drain hose in place,
tokeep overfloordrain.
valve drain hose
valve drain hose
1--1/2”
airgap
120V, 60Hz
outlet
transformer
(supplied)
totimer
totimer
1--1/2”
airgap
INLET
INLET
OUTLET
OUTLET
3-- valve
bypass system
inletvalve
outletvalve
bypass valve
UNFILTERED
WATER
UNFILTERED
WATER
FILTERED
WATER
OUTSIDE
FAUCETSOUTSIDE
FAUCETS
INLET--OUTLETPLUMBING OPTIONS
1.ALWAYS INSTALL eitheran EcoWaterbypass
valve,#7214383,ora3valve bypass system.
2.Use 1”... or,3/4”(minimum)pipe and fittings.
3.Usesweatcopper... or, threaded pipe*... or,PVC
plasticpipe.*
*Sweatsoldering isrequired to adapt tothe fittings
(1” male)supplied withthe filter,orobtain approved
compressionadaptors.The following specialfittings
are availablefromEcoWater.Be suretocomply
withall localplumbing codes.
OPTIONALINLET/OUTLETFITTINGS
#7104546 PVCNipple--- Useinplaceof
includedcopperinletandoutlet tubes.
#7129211 AdaptorFitting,1–1/2” (2)--- Usein
placeofincludedcopperinletandoutlet tubes.
#7120259 Elbow--- Extendsinletand/oroutletin
any90°direction.
OTHER REQUIREMENTS
4.Adrainisneeded for regeneration dischargewa-
ter.Afloordrain,closetothe filterispreferred.A
laundrytub,standpipe,etc., are otheroptions.
CAUTION:DRAINWATEREXITSTHEHOSE AT
AFAST FLOWRATE,AND ATWATERSYSTEM
PRESSURE.BE SURETHEHOSE ISFASTENED
INSOMEMANNERTOPREVENT“WHIPPING”,
ANDSPLASHINGTOPREVENTWATERDAMAGE
TOSURROUNDINGAREA.
5.A120v--60Hz,grounded electricaloutlet(contin-
uously“live”isneed within 10’ of the filter.

Planning Installation
ECOWATER
SYSTEMS
3
7
TOOLS YOU MAYNEED
Dcommon screwdriverDpliers
Dcross--pointscrewdriverDtape measure
SOLDERED COPPERTHREADED CPVCPLASTIC
Dtubing cutterDhacksawor
pipe cutterDhacksaw
Dpropane torchDthreading toolDadjustable
wrench
DLEAD--FREE
solderand fluxDpipe jointcom- pound*Dsolventcement*
Demery cloth,
sandpaperorsteel
wool
Dprimer
MATERIALS YOU MAYNEED
Hbypass valve,or3valves
Hpipe and fittingsasrequired
H 5/8”I. D.minimumdrainhose,eitherstandardgar-
den hose,orhose onto a barbfitting*
*VALVE DRAINOPTIONS:Flexible drain hoseis
notallowed in all localities(check yourcodes).For
arigidvalve drainrun,plumb according tolocal
codes.Toconnect tothe valve drainfitting,pur-
chase an adaptor,garden hosethread x5/8”(mini-
mum)tube.Use a hacksawtocutoffbarbsfromthe
fitting.
SELECTINSTALLATION LOCATION
Considerall of the following when selecting an
installation location forthe filterselected.
STofilterallwaterinthehome,installthefilterclose
tothewatersupplyinlet. Toconservefilteredwa-
ter,outside faucets shouldremainonraw water.
SIfotherwaterconditioning equipmentisinstalled,
locate as showninFigure 3.
SAnearbydrainisneededtocarryawayregenera-
tion discharge water.Afloordrainispreferred,
withalaundrytub,standpipe,etc., asotherop-
tions(check yourlocalcodes).
SThe filterworks on 24 voltsonly.Atransformeris
included (FORINDOOR USE)toreduce
120V--60 Hzhouse electricalpower.Provide an
approved,grounded outletwithin 10’ of the filter.
The filterincludesa 10’ powercableforconnec-
tion between the transformerand the timer.
SPosition the filteratleast6”fromsurrounding
walls,orotherappliances, to allowaccess for
servicing.
SIfinstallingthefilterinanoutsidelocation,besure
toprovideprotection fromtheelements,contami-
nation,vandalism,and sunlightheat. The sun’s
heatcan meltplasticparts.
FIGURE3

Installation
ECOWATER
SYSTEMS
3
8
1. INSTALL INLETAND OUTLET FITTINGS
Note:All fittingsareonthe small parts skin pack.
a.Insert the turbine support, intothe valve outlet
port, up tothe shoulder.
NOTE:If installing the EcoWaterbypass valve,
see separateinstructionsincluded withit.
b.Slide a lubricated o--ring onto one of the copper
tubes.Carefullyinsertthecoppertubeintotheoutlet
port(figure 4)and securein placewith a plastic“C”
clip.
Note:Forlubrication,usesilicone grease approved
foruse on potablewatersupplies.
c.Repeatstepbonthe inletside.
2. TURN OFF WATERSUPPLY
a.Closethe mainwatersupply valve,nearwell
pump orwatermeter.
b.Shutoff the electricityorfuelsupplytothe water
heater.
c.Open high and lowfaucetsto drain all waterfrom
hose pipes.
3. INSTALLING 3--VALVE BYPASS
If installing a 3--valve bypass system,plumb as
needed,using FIGURE2 asa guide. If installing
sweatcopper,be suretoUSE LEAD--FREE SOL-
DERasrequired byfederaland Statecodes.Use
pipe jointcompound on outside pipe threads.
4. MOVE FILTER INTOPLACE
Movethe filterintothe installation position,setting
onasolid.smooth and levelsurface. If needed,
placethe filteron a section of3/4”plywood.Then
shimunderthe plywood tolevelthe filterFIGURE5.
CAUTION:DONOTPLACE SHIMSDIRECTLY
UNDERTHESHROUD.The weightofthe tankmay
causethe shroud tofracture at the shim.
5.ASSEMBLEINLETAND OUTLETPLUMBING
Measure,cutandlooselyassemble pipe and fittings
fromthe mainwaterpipe (orfrombypass valves
installedinstep3),tothefilterinletandoutletcopper
tubes.
BE SUREUNFILTEREDWATERSUPPLY PIPE
GOES TOTHEFILTERINLETSIDE.Tracethewa-
terflowdirection tobesure.
VALVE
INLET
o--ring seal(2)
1”coppertube (2)
clip(2)
turbine support
FIGURE4FIGURE5
shroud
3/4”plywood
shim

Installation
ECOWATER
SYSTEMS
9
3
6.COLDWATERPIPE GROUNDING
Thehousecoldwaterpipe (metalonly)isoftenused
asa ground forthe house electricalsystem.The
3--valve bypass type ifinstallation,showninFIG-
URE2,willmaintaingroundcontinuity. Ifyouusethe
plasticbypassvalve atthe filter,continuityisbroken.
Torestorethe ground,install one of the following
grounds.
a.Usethe included hoseclampsand wiretojumper
acrosstheinletandoutletcoppertubesFIGURE6a.
NOTE:Hoseclampsmustbe placed on pipesbe-
foresoldering.
b.Install a#4copperwire across the removed sec-
tion ofmainwaterpipe,securely clamping on both
ends(figure 6b).
7.CONNECTINLETAND OUTLETPLUMBING
Completethe inletand outletplumbing asapplica-
ble.
a.SOLDERED COPPER
(1)Thoroughly clean and fluxall joints.
(2)Removetheinletand outlet tubesfromthevalve
(pull plastic“C”clips),and o--ringsfromthe tubes.
DONOTSOLDERWITHTUBES INT THE VALVE.
SOLDERINGHEATWILL DAMAGETHE VALVE.
(3)Makeall solderconnections.Besuretokeepfit-
tingsfullytogether,and pipes square and straight.
NOTE:Ifusing ground (step 6a),hoseclampsmust
be placed on pipesbeforesoldering.
(4)AFTERPLUMBINGHAS COOLED,repeat
steps1b and 1c.
b.THREADEDPIPE
(1)Applypipe jointcompound to all outside pipe
threads.
(2)Tighten all threaded joints.
(3)If SOLDERINGTOINLETAND OUTLET
TUBES,observesteps(1)through (4)above.
c.CPVCPLASTICPIPE
(1)Clean,primeandcementalljoints(followinstruc-
tionsof the plasticpipe and fittingsmanufacturer).
(2)IFSOLDERINGTOINLETAND OUTLET
TUBES,observe preceding steps(1)through (4).
8. INSTALL VALVE DRAIN HOSE
a.Connectalength of5/8”I.D.(minimum)hoseto
the valve drain elbowon the controllerFIGURE2.
The elbowacceptseithera hose ontothe barbfit-
ting,orstandard garden hose ontothe threads.To
usethe threads,cutoff the barbswith a hacksaw.
NOTE:Flexibledrain hoseisnotallowedinalllocali-
ties.See option on page 7.
b.Run the hoseto a floordrain,and astypically
showninFIGURE2, tie orwirethe end to a brick or
otherheavyobject. Thiswill prevent“whipping”dur-
ing regenerations.Besureto provide a 1--1/2”mini-
mumairgap, to preventpossiblesewerwaterback-
up.
ground wire
clamp(2)
FIGURE6FIGURE7
B
A3-- Valve Bypass
OUTLET
VALVE INLET
VALVE
BYPASS
VALVE
toconditioner
fromconditioner
EcoWater
Bypass Valve
DforSERVICE:
-- Openthe inletand outlet
valves.
-- Close the bypass valve.
DforBYPASS:
-- Close the inletand outlet
valves.
-- Openthe bypass valve.
PUSHIN
forbypass
PULL OUT
forservice
Install hoseclampsbefore
soldering coppertubes
copper
tubes
hoseclamp,
ground (2)ground wire

Installation
ECOWATER
SYSTEMS
3
10
NOTE:In addition to a floordrain,you can use a
laundrytub orstand pipe asa good drain point for
thishose.Avoidlong drain hoseruns,orelevating
the hose.
9.PRESSURETESTINGFORLEAKS
TOPREVENTEXCESSIVE AIRPRESSUREIN
THEFILTERAND PLUMBINGSYSTEM,DOTHE
FOLLOWINGSTEPS INORDER
a.Open two ormorefiltered waterfaucets,both hot
and cold.
b.Referringtofigure7,turnthebypassvalvestoser-
vice position.
c.Slowlyopen the mainwatersupply valve.
d.Closethe filtered waterfaucetsafterboth of the
following occur.
-- water runs smoothly,with no airbubbles
-- you can smell the sanitizing (page 5)bleach odor
at the faucets
e.Check yourcompleteinstallation forleaks. If re-
workisrequired,be sureto observe precautionsin
step 6.
10.CONNECTALL LEADWIRES
a.Connectthe wireharness tothevalveswitchFIG-
URE9.The switchison the outletside valvevalve
cover,behind the motor.
NOTE:Checktobesuretheconnectoris secure,on
the back of the timer.
b.Attachthe maleconnector,on the valvemotor
leadwire, the the matching femaleconnectoron the
faceplatetimer.
c.Connect the powercableleadstothe twotermi-
nalson the transformer.
11.CONNECT TOELECTRICALPOWER
Connect the timerpowercableleadstothe twoter-
minalsonthetransformerFIGURE9.Plugthetrans-
formerinto a continuously“live”,grounded,
120V--60Hzhouse electricaloutlet, approved bylo-
calcodes.
12.TOCOMPLETEINSTALLATION,DOTHEPRO-
GRAMMINGSTEPS ONPAGES 11 AND 12.
NOTEWATER HEATERSTART--UPONPAGE12.

Programming Face PlateTimer
ECOWATER
SYSTEMS
3
11
F
I
G
U
R
E
1
0
displaydisplaydisplayCURRENT TIME
AND DAY keypad RECHARGETIME
keypad
RECHARGEDAYS
keypad
SETkeypad
VACATION/RECHARGENOW
keypad
1.Whenthetransformerispluggedintotheelectrical
outlet, 12:00 AM,SUndaybeginstoflashinthetime
display.Set the timeofday and presentday of
week asfollows:
A. Set Timeof Day
1.Press the CURRENT TIME AND DAY keypad
once.The hourdisplay continuestoflash.
2.PresstheSETkeypaduntilthepresenthourofthe
day showsinthe display.BesureAMformorning
hours,orPMforafternoon and evening hours
shows.
Note:Press SETand quicklyreleasetomovethe
hourdisplayahead one at timetothe correcthour.
Or,holdthe SETkeypad tomovethe displayahead
two hourseachsecond, tothe correcthour.
3.PressCURRENT TIMEAND DAY keypadonceto
steadythe hourdisplay,and minutesbegintoflash.
Press SETuntil the correctminutes showinthe dis-
play.
4.Press CURRENT TIME AND DAY keypad again
tosteadytheminutedisplay(daywillbeginflashing).
B. SetPresent Day of Week
1.Press the SETkeypad toset the presentdayof
the weekinthe display.
Note:Press SETand quicklyreleasetomovethe
daydisplayone atatime.Or,holdthe SETkeypad
tomovethe displayahead two days eachsecond.
2.Press the CURRENT TIME AND DAY keypad
againtosteadythe entire display.
C. SetDays and Timeof Backwash
Note:The timerisfactory set(default time)for
Monday,Wednesday,and Saturdaybackwashes,
beginning at12:00 AM. If you have an EcoWater
conditioneroranotherfilterinstalled, the backwash
timerand/ordays should be offset to assure ade-
quatewaterflowandpressure.Forexample,setthe
filtertostartbackwash at12:00 AM,or4:00 AM,if
the conditioneris set to beginrecharge at2:00 AM.
1.Press RECHARGETIMEkeypadonce, to display
the factory setbackwash days and starting time
(flashing).Tochange the backwashstart time,do
step2following,otherwisetotostep 3.
2.Pressthe SETkeypaduntil thedesiredbackwash
starting timeshowsinthe display.
Note:Press SETand quicklyreleasetomovethe
displayahead one houratatime.Or,holdthe SET
keypad tomovethe displayahead two hourseach
second.
3.Press the RECHARGEDAYS keypad and
SUndaybeginstoflash.
...If you wantbackwasheson Sunday,press the
SETkeypad to displayON.
NOTE:One backwash eachweekisusually suffi-
cient tokeep the mineralbed clean and expanded.
If the watersupply containsiron,orhigh sediments,
additionalbackwashesmaybe needed.
...If you do notwantSundaybackwashes,press
SETkeypad to displayOFF.

Programming Face PlateTimer
ECOWATER
SYSTEMS
3
12
4.Press the RECHARGEDAYS keypad againto
displayaflashing MOndayand ON(factory setre-
charge).As you didinstep 3,usethe SETkeypad
tochange the displayfromONtoOFF,orfromOFF
toON,asdesired.
5.Press RECHARGEDAYS keypad to displaya
flashing TUesday,WEdnesday,etc., eachtime us-
ing the SETkeypad to displayeitherONorOFF as
needed.
2.Press and holdthe VAC/RCHGkeypad forthree
secondsuntil RCHGbeginstoflashinthe display,
starting a backwash.Thisbackwashflushes“fines”
fromthenewmineral,and purgesairandbleach,re-
maining fromthe sanitizing procedure.The filter re-
turnstoservicein about45 minutes.
3.RESTART THEWATER HEATER:Turn on the
electricorfuelsupplytothe waterheater,and light
the pilot, ifapplies.Note:The waterheaterisfilled
with unfiltered waterand,ashotwaterisused,itre-
fillswithfiltered water. Inafewdays,hotwaterwill
be fullyfiltered.To havefullyfiltered waterimmedi-
ately,waituntil the recharge (step 2 above)isover.
Then,drainthe waterheateruntil water runs cold.
THE SOLIDSTATETIMERISNOWPRO-
GRAMMED AND INSTALLATIONISCOMPLETE.
FEATURES / OPTIONS
RECHARGENOW-- Foran immediate extra back-
wash atanytime,usethisfeature.Press and hold
inthe VAC/RCHGkeypad forthree secondsuntil
RCHGflashesinthe display.The filterbackwashes
for25 minutes, followed bya 5 minutefastrinse
cycle.Then the filter returnstoservice.
VACATION-- Thedayyou leaveonvacation,oroth-
erlongabsence,press(DONOTHOLDIN)theVAC/
RCHGkeypad.VAC beginstoflashinthe display.
The timerwill keep time,but the filterwill notback-
wash and wastewater.
Note:Whileinthe VACATIONsetting, the filterwill
go through a backwashif the RECHARGENOW
featureisused (see above).
WHENYOU RETURN,press the VAC/RCHGkey-
pad againtoreturnthe filtertoservice,and the cor-
recttime ofdayinthedisplay.Remembertotothis
orthefilterwill notbackwashand you will soon
have unfilteredwater.
DOUBLEBACKWASH-- Although available on this
timer,adoublebackwashcycleisnotnormallyneed-
edwithasediment,tasteandodor,orneutralizingfil-
ters.Toset, ifdesired...
1.Pressand holdSETuntill
18:88 showsinthe display..
2.Press CURRENT TIME
AND DAY to display3
dashes.
3.PressSETtodisplaydbl.
4.Press CURRENT TIME
AND DAY to display18:88.
5.Press SETtoreturn present time.
Tocanceldouble backwash,repeat the above
steps.Displays fordbland ------ occurinreverse or-
der.
TIMER“POWER--OUTAGEMEMORY”-- If electri-
calpowertothe timergoesoff, the “memory”built
intotimercircuitry keepsall settingsforatleast two
days ormore.The displayisblankand the filterwill
notbackwash.When electricalpowercomeson,
one of twothingswill happen.
1.The present time ofdaywill show,meaning the
timermemoryhas keptall settings.
Note:If the filterwasina backwashwhen power
waslost, itwill nowfinishthe cycle.
2.Thedisplaywill showatime,butitwillbeflashing.
Thetimermemorydidnotkeepthetimesettingsand
theymustbe reset.
Theflashingdisplay istoremindyou toresetthe
timer.
Notes:
When powercomeson, the flashing displayreturns
toatime of12:00 AMSUnday, then beginstokeep
time again. If you do notresetall timesettings, the
filterwill backwashthree days eachweek(default
time).However,backwashmaybe on the wrong
days and at the wrong time.
If the filterwasin a backwashwhen powerwentoff,
thevalvewill returntoservicepositionwithoutfinish-
ing the cycle. If yourwaterisunfiltered,usethe RE-
CHARGENOWfeaturetostartanothercycle.

Programming Face PlateTimer
ECOWATER
SYSTEMS
13
INFORMATION FOR QUALIFIEDTECHNICIANSONLY
RECHARGECYCLETIMEADJUSTMENTS:Factory setdefaultcycletimesare:
BACKWASH...25 minutes,and FASTRINSE...5minutes.Dothe following tocheck forcorrectcycletimes.
Note:Removing fromelectricalpower (about two
days) resetstimestofactory setdefaults.
DISPLAY MUSTSHOWTIME AND DAY
1.Press and holdSET...
entire display comeson.
2.Press RECHARGETIME
... 2:00 shouldshowinthe
display. If not, press SET
until 2:00 does show.
3.Press RECHARGETIME
... 3:25 shows,meaning #3
cycle(backwash)and 25
minutes.
a.If3:25 does show,go to
step 4.
*b.Ifotherthan3:25(3:00to
3:30),press SETuntil 3:25
shows.
4.Press RECHARGETIME
... 4:05 shows,meaning #4
cycle(fastrinse)and 5 min-
utes.
a.If4:05 does show,go to
step 5.
b. If otherthan 4:05 (4:00 to
4:30),press SETuntil 4:05
shows.
5.PressRECHARGETIME
... 18:88 shows.
6.Press SETtoreturn present time and day.
*Or,setothercyclelength,ifdesired.

FilterOperation
ECOWATER
SYSTEMS
3
14
GENERALINFORMATION
...SEDIMENTFILTERS-- Asediment filterremoves,
sand,clay,silt, orfine organicmatterfromwater.
You can see sedimentinwaterbyholding a sample,
inaclearglass,uptoalight. The particlesareeither
suspended orsettled tothe bottomof the glass.
“FilterAggregate”mineralmechanicallyfiltersthe
sedimentparticlesaswaterpassesthroughthebed.
Thismineral lastsindefinitelywhen properlymain-
tained.
...ACID NEUTRALIZERS-- Acidwater (6.0to 6.8
pH)is corrected with an acid neutralizerfilter.Acid
water,although sometimes clearin appearance,
shortensthelife ofironpipe,and corrodescopperor
brass pipe and fittings. It causesgreen orblue
stainson plumbing fixturesand mayetch porcelain
enamelovera period of time.
Acidwater,asitpassesthrough the filterNeutralite
mineralbed,dissolves some of the mineral.This
raisesthe pHabove 6.8, to neutralizethe acid.Be-
causethemineraldoesdissolve,the filtereventually
needsrefilling.The time between refills varieswith
the degree ofacidityand howmuchwaterisused.
The average life of the be isaboutone year.
...TASTE AND ODORFILTERS-- Ataste and odor
filterremovesmosttastes,odorsandcertainorganic
colorsfromwater.Bad tastesand odorsare due to
avarietyofcauses(chlorine,petroleum, tannins,
etc.).The activated carbon mineral,ofataste and
odorfilter,hasa high capacityforabsorbing these
impurities.
Theactivatedcarbonbedusuallylastsforaboutone
year.However,high amountsof tastesand odors
and/orexcessivewaterusagemayshortenthistime.
Activated carbon isnonregenerative and needsre-
placing when exhausted.
SERVICE, BACKWASH AND FASTRINSE
SERVICE(See figure 11): Unfiltered waterenters
the valveinletport. Internalvalve porting routesthe
waterdown and out the top distributor,intothe min-
eraltank.The waterisfiltered asitpassesthrough
the mineralbed, then entersthe bottomdistributor.
Filtered waterflowsback intothe valve and out the
valve outlet, tothe housefiltered waterpipes.
Intime, the filterneeds cleaning toremovesedi-
ments,dirt, iron,etc., fromthe mineralbed.This
cleaning isdone intwostages,orcycles,called
backwash and fastrinse. It is started automatically
bythe timer.
BACKWASH(See figure 12): The timerstartsthe
valvemotorand movesthe valveinto backwash
position.Waterisrouted down and out the bottom
distributor,up through the mineralbed,and out the
top distributortothe drain.The fast flow(controlled
byaflowplug inthe drainfitting)flushesdirt, sedi-
ments,iron deposits,etc. tothe drain.The mineral
bed islifted and expanded formaximumcleaning.
FASTRINSE (See figure 13): Valverotation posi-
tionstheinnerdiscs sowaterflowentersthemineral
tankthrough the top,and exitsat the bottom, tothe
drain.The fast flowofwaterdownward,packs the
mineralbed and preparesit for returntoservice.
The timerenergizesthe valvemotoragaintoreturn
the valvetoservice.

FilterOperation
ECOWATER
SYSTEMS
3
15
WATERFLOW PATHS
FIGURE11
SERVICECYCLE
FIGURE12
BACKWASH CYCLE

FilterOperation
ECOWATER
SYSTEMS
16
FIGURE13
FASTRINSE CYCLE

Service Information
ECOWATER
SYSTEMS
17
NEUTRALIZINGFILTER-- CHECKINGTHEMIN-
ERAL LEVELINTHETANK:Asexplained on page
14, the mineraldissolvesinthe waterto neutralize
the acid.Howfastisdissolvesdependson how
muchwateryou household usesand the pHof the
water.
Everyfewmonths you shouldmeasurethe mineral
bedlevelinthetank.Alwaysaddnewmineralbefore
the tankisempty.Tomeasure,do the following.
1.Referto page 12 and initiatethe RECHARGE
NOWfeature.
2.When waterstartstorun fromthe drain hose,put
the plumbing bypass valve(s)in bypass posi-
tion...see figure 7,page 9,TODEPRESSURIZE
THEFILTER.
3.Unplug the transformerat the wall outlet.
4.Removethe controllercover.
5.Disconnectthe inletandoutletcoppertubes...see
page 8.
6.Removethe valve assemblyfromthe mineral
tank...page 5.
7.Removethe top distributorand fouro--ring
seals...page 5.
FIGURE14
SUGGESTED
FREEBOARD
ETF2100PF10 15”
ETF2100PF12 16”
8.Useayardstick orsteeltape measuretofind the
distance downtothe top of the mineralbed...FI-
GURE14. If 15”belowthe suggested freeboard,
add more neutralitematerial.
9.Useafunnelto add moremineral,ifneeded.
10.Flush all mineralfromthe tanktop opening.
Then replacethe distributorand fouro--ring
seals...figure 1,page 5.
11.Dothe following stepstoreturnthe filtertoser-
vice.
-- step 4,page 5
-- step 1b and 1c,page 8
-- step 8,page 9,ifhosewasdisconnected
-- steps9through 12,page 10.
Note:Afterelectricalpowerisapplied,see page 11
if the time displayisflashing.
-- initiateRECHARGENOWfeature,see page 12.
TASTEAND ODORFILTER-- REPLACINGTHE
ACTIVATEDCARBONMINERALBED(SEEPAGE
14): Whenthefilternolongerremovestastesand/or
odorsfromthewater,the activated carbon bed must
be replaced.Toreplacethe bed:
1.Dosteps1through 7,aboveleft.
2.Carefullylaythefiltertankover.Pullthestandpipe
and bottomdistributorfromthe mineralbed.
3.Dumpthe contentsof thetankinto a suitablecon-
tainer.
4.Standthetankuprightandreplacethe bottomdis-
tributorand standpipe.
5.Add the required amountsofgravel, filtersand,
and activated carbon mineral...see specifications,
page 4.
6.Dosteps10 and 11,above.

PM
MOWETHFRSA
RCHG..
AM
TU
SU
Service Information
ECOWATER
SYSTEMS
18
TROUBLESHOOTING
ALWAYS MAKE THESE INITIALCHECKSFIRST
1.Doesthe time display showthe correct time of
day?
...If displayisblank,check powersourcetothefilter.
...If timeisflashing,powerwasoff forovertwodays.
The filter resumesnormaloperation butback-
washesoccurat the wrong time.
2.Plumbing bypass valve(s)mustbe inSERVICE
position (see figure 7,page 9).
3.Theinletandoutletpipesmustconnecttothefilter
inletand outletrespectively.
4. Isthe transformerplugged into a “live”grounded
wall outlet, and the powercablefastened securely?
5.The valve drain hosemustbe free ofkinks and
sharp bends.
If you do not find the problemaftermaking the initial
checks,do the MANUALADVANCEDIAGNOS-
TICS.
MANUALADVANCEDIAGNOSTIC
Usethe following proceduresto advancethe filter
valvethrough the regeneration cyclestocheck op-
eration.
Removethe top coverto observecamand switch
operation during valverotation.
DISPLAY MUSTSHOWTIME AND DAY
1.Press and holdset for3
secondsuntil 18:88 displays.
2.Press RECHARGEDAY to
displaythe position switch
open orclosed indicator.
The letter (P)and dash or
dashesindicate position
switch operation.The letter
showsif the switchis closed.
Adashshowswhen the
switchisopen.
NOTE:Thepositionswitchisclosedwhentheplung-
erisdepressed,open when extended.
CORRECTSWITCH
DISPLAYS VALVE CYCLE STATUS
-- -- valveinservice,backwash or
fastrinse position
-- Pvalverotating fromone posi-
tion to another
NOTES:
Whileinmanualadvance, the time displaywill auto-
maticallyreturntothe present time,ifaface plate
keypad isnotpressed withinfourminutes.
Pressing VAC/RCHGwhilethe motorisrunning has
no effect.
3.To enterbackwash,press and holdVAC/
RCHGforthree secondstostart the motor.
a. If the motordoesnotrun,check the motorand all
wiring connections.
Lookforafastflowofwaterfromthe drain hose(see
specs).
a.Anobstructedflowindicatesaplugged topdistrib-
utor,backwashflowplug,ordrain hose.*
*Note:Besure householdwaterpressure(well sys-
tem)ismaintainedataminimumof20psi.Adjustthe
pumpswitch upward,ifneeded.
4.PressVAC/RCHGtomovethefilterintofastrinse.
Again,lookfora drainflowrate about the same and
in backwash.
5.Toreturnthe filtertoservice,press VAC/RCHG
once.
6.Upon returning toservice,press RECHARGE
DAY to display18:88.
7.Press SETtoreturntothe present time.

Service Information
ECOWATER
SYSTEMS
3
19
OTHERSERVICE
UNFILTEREDWATERBYPASS (unfiltered water
“bleeds”intofiltered watersupply.
1.Defectiveinletdisc,sealorwavewasher (see
pages30 and 31).
2.Missing ordefective o--ring(s)atresintankto
valveconnection (see Keyno.11,page 29).
WATERLEAKS FROMDRAIN HOSE (during ser-
vice)
1.Defectiveinletdisc,seal,orwavewasher.
2.Defective o--ring on inletdisc shaft.
3.Defective outletdisc,seal,orwavewasher.
AUTOMATICELECTRONIC DIAGNOSTICS
The face plate hasaselfdiagnosticfunction forthe
electricalsystems(exceptinputpower).The face
platemonitorsthe electronic componentsand cir-
cuitsforcorrectoperation. If amalfunction occurs,
an errorcode appearsinthe face plate display.
POSSIBLEDEFECT
CODEMOST LIKELYä----------------------------------------------------------------------------äLEAST LIKELY
Err 01 Err 02
Err 03 Err 04 wiring harness orconnection to position switch/switch/valve defectcausing high torque /motorinoperative
Err 05 faceplate
PROCEDUREFOR REMOVINGERROR CODEFROMFACEPLATE:1.Unplug transformer-------- 2.Correctdefect-------- 3.
Plug intransformer-------- 4.Wait for6minutes.The errorcode will returnif thedefectwasnotcorrected.Press and holdtheVAC/RCHG
keypad for3secondsasan alternatewaytoclearan errorcode.
M
24V
24VAC
TRANSFORMER
NC
NO
BACKOF TIMER
white
WIRING SCHEMATIC
POSITION
SWITCH
HEADER1HEADER2
shuntrequired
on both headers
Headers arelocatedoncir-
cuitboard,underthe cover.

RepairParts
ECOWATER
SYSTEMS
3
20
18
20
19
4
1
23
9
8
10
11
12
13
14
15
16
17
6
7
5
