WaterLogic WL7 FW Reference guide

WL7FWManual Page71‐Revision:6‐11‐2019
WL7FWINSTALLATIONPROCEDURES

SafetyandInstallationGuidelines
EnsureallLocal,State,andFederalLawsandCodesincludinghealthandsafetyguidelinesaremet
wheninstallingWaterlogicEquipment.Onlyqualifiedservicetechniciansshouldattempt
installationandserviceofWaterlogicEquipment.

WARNING!ELECTRICALSHOCKHAZARD.Alwaysunplug(isolatefrompowersupply)toprevent
electricalshockexceptwhereelectricaltestsarespecified.

WARNING!IMPROPERSUPPLYORCONNECTIONCANRESULTISRISKOFSHOCK.
Connecttoa15amp120V60Hzproperlygroundedoutlet(GFIisrecommended).Ensurepolarity
iscorrectandalwaysusea3‐prongoutlet.Consultaqualifiedelectricianifyouhaveany
questions.

WARNING!USEONLYWaterlogicSUPPLIEDPOWERCORD.Locatesystemwithin5feetof
powersupply.Neveruseanextensioncordoradapter.Donotuseadamagedpowercordor
plug.Keeppowercordoutofheavytrafficareasandawayfromheatsources.Donot,underany
circumstances,removegroundprongoralterthepowercord.Neverpullthepowerplugfromthe
outletwithawethandorallowtheplugtogetwet.Failuretousethesuppliedpowercordwill
voidULCertificationandWarranty.

CAUTION!INDOORUSEONLY.Neverexposetodirectsunlight,heatsources,orambientair
temperatureabove37°C(100°F)orbelow2°C(35°F).Installindoorsandkeepunitawayfrom
excessivehumidity.Neverexposetofreezingtemperatures.Ensurethereisadequateclearance
aroundtheunittoallowrefrigerationsystemcondensertodissipateheat.Warmerenvironments
requiremoreclearancearoundtheunit.Minimumclearancearoundallsurfacesofthemachineis
2‐inches.Installswheretheambienttemperatureexceeds27°C(80°F),requireaminimumof4‐
inchesclearanceforproperheatdissipationandefficientoperation.

CAUTION!USEAWATERPRESSUREREGULATOR.Waterlogicwillnotberesponsibleforinjuryor
damagecausedbyexcessivewaterpressure.Operatingpressuremustbe40psito60psi.Be
awareanyofpotentialpressuresurgescausedbybuilding/municipalpumpingstations.

CAUTION!USEUVSTABILIZEDSUPPLYLINES.Feedwaterover37°C(100°F)candamagethe
treatmentcomponents.Waterblockdevicesandexternalleakdetectorsarestrongly
recommended.Locatetheunitasclosetothewatersupplyandtheelectricalconnectionsas
possible.Locatetheunitasclosetothewatersupplyandtheelectricalconnectionsaspossible.
Immediatelyisolateorclosewatersupplyvalveandcontactservicerepresentativeifleakis
noticed.

WARNING!STOREANDTRANSPORTUNITEMPTY.ALWAYSSANITIZEBEFOREUSE.
Theunitmustbecompletelydrainedandsealedbeforestoringtoavoidstagnationandreduce
microbiologicalcontamination(potentialbacterialgrowth).Sanitizebeforeusetoeliminateany
potentialmicrobiologicalcontaminates 

Pre‐installationandsanitizationproceduresasprescribedinthismanualmustbeperformedbefore
installingtheWL7FWWaterPurificationSystems.

AlwaysinstallindoorsandplacetheWaterlogicWL7FWWaterPurificationSystemonafirm,flat
andstablesurfacewithadequateairgaptoallowproperandefficientoperation.

WL7FWManual Page72‐Revision:6‐11‐2019
WL7FWINSTALLATIONPROCEDURES

1. Attachthewatersupplylinetothe1/4”feedwaterinletbulkheadfittingonthebackoftheunit.
Waterlogicrequirestheuseofawaterpressureregulator.Waterfeedpressuremustbe
between40‐60psiand2lpm(0.5gpm).Turnonthewatersupplyandcheckforleaks. 

2. ChecktoensurethatbothPower(Red)andHeater/Compressor(Green)Switches
areintheO=OFFposition.
NOTE:SwitchhasinternalLEDthatilluminateswhenplacedinI=ONposition. 

3. ConnectthepowercordtothebackoftheWaterlogicWL7FWWaterPurificationSystemandto
a120Volt15ampdedicatedsupply.GFCIprotectionisrecommended. 

4. TurnONtheMainPower(Red)Switch.LeaveGreenSwitchOFF.
CAUTION!NEVERTURNONHEATERBEFOREFILLINGHOTTANK.
GreenCompressor/HeaterSwitchmustbeintheO=OFFpositionwhilethehottankisempty.
Damagecouldoccurwithinoneminuteandtheoverload(highlimit)willrequiremanualresetif
heateristurnedonwithanemptyhottank.

5. WL7FWwillbeinStart‐UpModewheneveryouturnONtheMainPower(Red)Switchand
Heater/Compressor(Green)SwitchisintheOFFposition.
Thestart‐upsequenceshouldtakeapproximately5minutestocompletewhensystemisempty
andstatusbarwillflushindicatingprogress
Start‐UpModeprocessisasfollows:
 PerformsSelf‐DiagnosticChecks




 Fillsicebathwithcoolingwaterandflushesfiltersintothebath.





 Fillssparklingtank(ifequipped).CO
2
supplydoesnotneedtobeconnected.




 Displaywillpromptinstallertofillthehottanktocompletestartup





WL7FWManual Page73‐Revision:6‐11‐2019
WL7FWINSTALLATIONPROCEDURES

6. Followinstructionsonthescreen.TheWL7FWwillinstructinstallertoholdthedispensebutton
untilasteadystreamofwaterisflowingtothefaucet.ThisfillstheHotTank.

7. TheinstallershouldthenturnONtheHeater/Compressor(Green)Switch.

8. TheWL7FWwillnowbeinOperationalModewithbothswitchesintheON
positionandthehomescreenwillappearonthedisplay.

9. Dispensecoldintocontaineruntilsteadystreamofwateris
presenttoremoveanytrappedairfromthecircuitandrepeatforthe
ambient(roomtemperature)circuit.

10. Connect3Bar(42.5psi)supplyoffoodgradeCO
2
totheCO
2
inletbulkheadfittingonthebackof
theunit.Dispensesparklingwateruntilonlygasisflowingtothefaucettopurgethesystemof
trappedair.WL7FWshouldautomaticallyrefillthecarbonatorinapproximately30secondsonce
thedispensebuttonisreleased.Theinjectionpumpwillturnon2secondsafterreleasing
sparklingdispensebutton.PremiumSparklingWaterwillnotbeproduceduntilthesystemhas
reachcoldsetpoint.

11. Itwilltaketheheaterapproximately10minutestoheatthewatertothefactorysetpointof87°C
(187°F).Thehotstatusbarwillflushwhenheaterisonandbesolidwithheateroff.Thehot
statusbararrowsindicatetanktemperature
frombelow40°C(104°F)onfarlefttoset
pointonthefarright.

Dispenseacupofhotwatertoensurethe
temperature/odor/tasteisacceptable.



WARNING!HOTWATERCANBURNORSCALD.TheWL7FWWaterPurificationSystem
producesHotWaterupto95°C(203°F).Waterabove52°C(125°F)cancausesevereburnsor
scalding.Hotwatershouldbedispensedcarefullyintoinsulatedcontainertoavoidinjury.

12. OncetheWL7FWWaterPurificationSystemicebathbuildsacompleteiceringinapproximately
90minutesdependinguponenvironment.Thecompressorwillshutoffoncetheiceringhas
reachedthicknessicesensor.

Thecoldstatusbarwillflushwhen
compressorisonandbesolidwith
compressoroff.

Youcanvisuallyinspecttheicering build
throughtheaccessholeinthetopoftheicebathifneeded.Thecondenserattherearoftheunit
willbuildheatasindicationtherefrigerationsystemisoperatingproperly.Routeallhoseaway
fromdirectcontractwithheatfromthecondensingcoilsatthebackoftheunit.

WL7FWManual Page74‐Revision:6‐11‐2019
WL7FWINSTALLATIONPROCEDURES

13. Dispenseacupofcoldwatertoensurethetemperature/odor/tasteisacceptable.

14. Thesparklingchamber(carbonator)mustbecompletelyregenerated(emptied)afewtimesonce
theicebathhasreachedsettemperatureandthedrinkingwaterlineandsparklingchamberare
cold.Regenerationwillclearthechamberoftheinitialairandwatertrappedduringstartupand
ensurethatpremiumsparklingwaterisproduced.Alwaysuse3Bar(42.5psi)supplyoffood
gradeCO
2
andensurebathhasreachedcoldsetpointbeforeregeneratingsparklingwatertank.

TheWL7FWiceringtakeshourstocompletelymeltoffinambientconditionsandcanbeusedto
helpreducedsetuptimeinfieldifunitispreparedinshopandleftoperationalpriortofield
installation.Theremainingiceringwillreducecoolingtimeatinstallation.

15. Dispenseacupofsparklingwatertoensurethetemperature/odor/tasteisacceptable.Sparkling
output(carbonationlevel)canbetestedifneeded.AdditionalinformationonWaterlogic
PremiumSparklingWatercanbefoundinthismanualinsections:

 WL7FWPrinciplesofOperation‐DispensingSparklingWater
 WaterlogicPremiumSparklingWaterOverview

16. MovetheWaterlogicWL7FWWaterPurificationSystemintoitsfinaloperatingposition.Be
surethataminimumof2”clearanceismaintainedaroundboththesidesandthebackofthe
unit.Thisisimportanttoallowproperairflowandheatexchangeofrefrigerationsystem.

17. Levelunitusingtheadjustablefeettolevelifnecessary.Neverinstallonincline.

18. WhentheunithasreacheditsHotTempSetPoint,ensuretheheatercyclesoff.

19. WhentheunithasreacheditsIceBathSetPoint,ensurethecompressorcyclesoff.

20. Oncetheunitisatthetargettemperature(s),samplethewatertoensurewatermeets
expectationsandadditionalrinsingoradjustmentisnotrequired.


21. ChecktheWL7FWWaterPurificationSystemforanyleaks.ExternalLeakProtectionisalways
recommended.

22. ConfirmallprogramsettingsarecorrectandresettheBottleCounterto
Zeroifneeded.Entermaintenancemodeandpressandholddispense
buttonuntilbottlecounterflasheson
displayandtwobeepsareheard.Bottlecounterwillresettozero
onceyoureleasedispensebutton.Exitmaintenancemodeby
tappingdispense5timesin10seconds.

AlwaysadjustHotandExtraHotSettingdownwheninstallingat
elevationtoavoidboilinghottank.

