Edco DDG-9-I-0315 Assembly instructions

DDG-9-I-0315
Operator’s Instruction Manual
NEW SINGLE-DISC FLOOR GRINDER
ELECTRIC
DDG-9 - DIRECT DRIVE Grinder
EQUIPMENT DEVELOPMENT COMPANY
EQUIPMENT DEVELOPMENT COMPANY
100 Thomas Johnson Drive, Frederick, MD 21702-4600 USA
Phone: [phone] • 301-663-1600
Fax: [phone] • 301-663-1607
edcoinc.com • [email protected]

EDDG-9-I-0315
2
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
READ AND UNDERSTAND THE OPERATORS INSTRUCTION MANUAL THOROUGHLY
BEFORE ATTEMPTING TO OPERATE THIS EQUIPMENT.
Death or serious injury could occur if this machine is used improperly.
Extreme care must be taken when operating electric
models with water present: Ensure power cord is prop-
erly grounded, is attached to a Ground-Fault-Interrupter
(GFI) outlet, and is undamaged.
Check all electrical cables - be sure connections are tight and
cable is continuous and in good condition. Be sure cable is
correctly rated for both the operating current and voltage of
this equipment.
Improper connection of the equipment-grounding conductor can
UHVXOWLQDULVNRIHOHFWULFVKRFN&KHFNZLWKTXDOL¿HGHOHFWUL
cian or service person if there is any doubt as to whether the
outlet is properly grounded. Adhere to all local codes and
ordinances.
NOTE: In the event of a malfunction or breakdown, grounding
provides a path of least resistance for the electric current to
dissipate. The motor is equipped with a grounded plug and
must be connected to an outlet that is properly installed and
properly grounded. DO NOT modify the plug provided on the
PRWRU,IWKHSOXJGRHVQRW¿WWKHRXWOHWKDYHDTXDOL¿HGHOHFWUL-
cian install the proper receptacle.
Switch motor OFF before disconnecting power.
Engine exhaust from this product contains
chemicals known to the State of California to
cause cancer, birth defects or other reproduc-
tive harm.
*DVROLQHLVH[WUHPHO\ÀDPPDEOHDQGSRLVRQRXV
It should only be dispensed in well ventilated areas,
and with a cool engine.
Small gasoline engines produce high concentra-
tions of carbon monoxide (CO) example: a 5 HP 4 cycle
engine operation in an enclosed 100,000 cu. ft. area with
only one change of air per hour is capable of providing
GHDGO\FRQFHQWUDWLRQVRI&2LQOHVVWKDQ¿IWHHQPLQXWHV
Five changes of air in the same area will produce noxious
fumes in less than 30 minutes. Gasoline or propane pow-
ered equipment should not be used in enclosed or partially
enclosed areas. Symptoms of CO poisoning include, head-
ache, nausea, weakness, dizziness, visual problems and
loss of consciousness. If symptoms occur - get into fresh
air and seek medical attention immediately.
SAFETY
MESSAGES
SAFETY MESSAGES
Indicates an imminent hazard which, if not
avoided, will result in death or serious injury.
Indicates an imminent hazard which, if not
avoided, can result in death or serious injury.
Indicates hazards which, if not avoided, could
result in serious injury and or damage to the
equipment.
Safety Instructions are proceeded by a graphic alert symbol
of DANGER, WARNING, or CAUTION.
ELECTRICAL POWERED EQUIPMENT
GASOLINE/PROPANE POWERED EQUIPMENT
Equipment should only be operated by trained personnel in
good physical condition and mental health (not fatigued). The
operator and maintenance personnel must be physically able
to handle the bulk weight and power of this equipment.
This is a one person tool. Maintain a safe operating distance
to other personnel. It is the operators’ responsibility to keep
other people (workers, pedestrians, bystanders, etc.) away
during operation. Block off the work area in all directions with
roping, safety netting, etc. for a safe distance. Failure to do so
PD\UHVXOWLQRWKHUVEHLQJLQMXUHGE\À\LQJGHEULVRUH[SRVLQJ
them to harmful dust and noise.
This equipment is intended for commercial use only.
For the operator’s safety and the safety of others, always keep
all guards in place during operation.
Never let equipment run unattended.
Personal Protection Equipment and proper safety attire must
be worn when operating this machinery. The operator must
wear approved safety equipment appropriate for the job such
as hard hat and safety shoes when conditions require. Hear-
ing protection MUST be used (operational noise levels of this
equipment may exceed 85db). Eye protection MUST be worn
at all times.
Keep body parts and loose clothing away from moving
parts. Failure to do so could result in dismemberment
or death.
Do not modify the machine.
Stopmotor/enginewhenadjustingorservicingthisequipment.
0DLQWDLQDVDIHRSHUDWLQJGLVWDQFHIURPÀDPPDEOH
materials. Sparks from the cutting-action of this machine
FDQLJQLWHÀDPPDEOHPDWHULDOVRUYDSRUV
GENERAL INSTRUCTIONS
DUST WARNING
Some dust created by power sanding, sawing,
grinding, drilling, and other construction activi-
ties contains chemicals known to cause cancer,
birth defects, or other reproductive harm. Some
examples of these chemicals are:
Lead from lead-based paints, and
Crystalline silica from bricks and concrete and other
masonry products.
Your risk of exposure to these chemicals varies depending
on how often you do this type of work. To reduce your risk:
work in a well ventilated area, use a dust control system, such
as an industrial-style vacuum, and wear approved personal
safety equipment, such as a dust/particle respirator designed
WR¿OWHURXWPLFURVFRSLFSDUWLFOHV
Do not disconnect power by pulling cord. To disconnect, grasp
the plug, not the cord.
Unplug power cord at the machine when not in use and before
servicing.

DDG-9-I-0315
3
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
SMI DUST AND SILICA WARNING
Grinding/cutting/drilling of masonry, concrete, metal and other materials can generate
dust, mists and fumes containing chemicals known to cause serious or fatal injury or ill-
ness, such as respiratory disease, cancer, birth defects or other reproductive harm. If you
are unfamiliar with the risks associated with the particular process and/or material
being cut or the composition of the tool being used, review the material safety data sheets and/or
consult your employer, the manufacturers/suppliers, governmental agencies such as OSHA and NIOSH
and other sources on hazardous materials. California and some other authorities, for instance, have
published lists of substances known to cause cancer, reproductive toxicity, or other harmful effects.
Control dust, mist and fumes at the source where possible. In this regard use good work practices and
follow the recommendations of the manufacturers/suppliers, OSHA/NIOSH, and occupational and trade
associates. Water should be used for dust suppression when wet grinding/cutting/drilling is feasible.
When the hazards from inhalation of dust, mists and fumes cannot be eliminated, the operator and any
bystanders should always wear a respirator approved by NIOSH/OSHA for the material being used.
Grinding/cutting/drilling of masonry, concrete and other materials with silica in their com-
position may give off dusts or mists containing crystalline silica. Silica is a basic component
of sand, quartz, brick clay, granite and numerous other minerals and rocks. Repeated
and/or substantial inhalation of airborne crystalline silica can cause serious or fatal respi-
ratory diseases, including silicosis. In addition, California and some other authorities have listed repairable
crystalline silica as a substance known to cause cancer. When grinding/cutting/drilling such materials, al-
ways follow the respiratory precautions mentioned above.

DDG-9-I-0315
4
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
Table of Contents
Safety and Warnings...................................................................................................................2-3
Table of Contents...........................................................................................................................4
Specifications..................................................................................................................................5
Operating Controls ........................................................................................................................6
Getting started with your New Grinder ....................................................................................7-9
Operating Instructions............................................................................................................10-11
Attaching a Vacuum ....................................................................................................................12
Servicing Head Assembly .............................................................................................................12
Quick Change Multi-Accessory Disc ............................................................................................13
Maintenance Instructions ............................................................................................................14
Maintenance Schedule.................................................................................................................15
Notes........................................................................................................................................16-18
Limited Equipment Warranty......................................................................................................19

DDG-9-I-0315
5
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
SPECIFICATIONS
NOTE: All dimensions and weights are for
reference only and subject to change at any time.
Figure 1
HOW TO ORDER REPAIR PARTS
To insure product safety and reliability, always use genuine EDCO
replacement parts when making repairs to the equipment.
When ordering parts, please specify the MODEL and SERIAL NUM-
BER of the machine as given on the NAMEPLATE. In addition, give
part number, description and quantity as listed on the parts list.
Please note: Due to improvements and changes in the equipment
the illustrations shown may be different from the actual machine.
Toll Free: Phone [phone] • Fax [phone]
DDG-9
Length 41” 60cm
Width 16 1/2” 24cm
Height 41” 60cm
-- --
Head RPM 1690
Weight 81 lbs/37kg
Noise Level Lwa - 100 dB(A)
Noise Level Leq - 90 dB(A)
HAV 9.6 M/S2
L
H
W

DDG-9-I-0315
6
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
OPERATING CONTROLS
PLEASE NOTE:
Controls shown are for the model indicated.
The location of these controls may vary on the different models.
Due to improvements and changes in the equipment,
the illustrations shown may vary from the actual machine.
ELECTRIC MODEL
Figure 2
Lifting Handle
Handle Adjustment
Switch Box
Power Cord
Electric Motor
Vacuum Port
Wheels
Leveling
Adjustment
Multi
Accessory Disc
(Underneath)
Dust
Containment Ring

DDG-9-I-0315
7
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
GETTING STARTED WITH YOUR NEW GRINDER
This unit is intended for grinding horizonal, dry floors such as concrete, asphalt or steel surfaces.
NOTE: The above illustrations are viewing the Machine from the front bottom.
NOTE the direction of rotation.
LOADING TOOLS:
1. Move handle to transport position.
2. Lean the machine back on the handle to
expose the work area and load the proper
tools for your job. Electric machines should
be unplugged.
LOADING TOOLS:
Once all tools are in the proper position re-
turn the machine to the upright position.
Return handle to the operator position and
install dust containment ring around head.
The machine should only be operated
without the dust containment ring when
edge grinding near a wall. Remember if
you are using tools with PCD’s or Strip-serts
they have a leading edge and must be
loaded as such. Also, remember the disc
turns in the direction of arrow decal.

DDG-9-I-0315
8
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
GETTING STARTED WITH YOUR NEW GRINDER
LOADING TOOLS:
Return level lock to the operator position.
LOADING TOOLS:
Lean back slightly on the handle to get the
tools off the surface and start the machine.
Lower the machine to the surface and do a
short touch pass on the concrete.
SWING AXLE:
Loosen nut at rear wheel and raise or lower
until a complete circle is achieved in a test
area on the floor.
Also machine should move freely across the
floor and not pull left or right.
DUST CONTAINMENT RING:
The Dust Containment Ring floats along with
the grinder during normal use. Only remove
this ring to grind next to walls.

DDG-9-I-0315
9
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
GETTING STARTED WITH YOUR NEW GRINDER
LEVELING:
You are looking for a complete circle.
LEVELING:
If you see a partial circle repeat the process
until complete circle is achieved.

DDG-9-I-0315
10
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
OPERATING INSTRUCTIONS
• Read and understand all operating instructions before operating this equipment.
Death or serious injury can result if this machine is used improperly.
• Concrete grinders are designed to be used to grind flat horizontal concrete slabs using
EDCO approved accessories.
• The machines are equipped with electric motors.
• They are designed to be controlled by a single operator from a position at the rear of the machine.
• When operating equipment maintain a safe distance from other personnel in the area.
BE SURE TO READ THE COMPLETE INSTRUCTIONS SUPPLIED WITH YOUR MACHINE
IMPORTANT: Perform Pre-Start Check
• Visually inspect the equipment for wear or damage.
• Be sure all guards are in place and functioning properly.
Do not operate unless all guards are in place and secure.
• Perform all daily maintenance.
• Inspect accessories - Be sure the correct accessory is installed properly on the machine,
mounting arrangement and its intended use.
• Check accessories for damage, the type of wear or damage will vary
with the type of accessory.
• Inspect work area to determine the presence and location of deck inserts, pipes, columns and objects
protruding from the slab surface so that they may be avoided during the grinding operation.
• FOR WET GRINDING: Attach the water supply. A flow rate of approximately
1/2 gallon per minute is recommended.

DDG-9-I-0315
11
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
OPERATING INSTRUCTIONS
• BEFORE STARTING THE MOTOR: Raise the front of the machine clear of the working surface.
• STARTING MACHINE: Depress and hold center button and squeeze either handle grip switch. Hold both
until motor comes up to full rpms and then release center button. Squeezing either or both handle grip
switchs will keep machine running. Once released, machine will automatically stop.
• START MOTOR AND ALLOW IT TO REACH OPERATING SPEED: Position the grinder at the starting point.
Bring the motor to full speed. Lower the machine onto the slab surface. Use a slow sweeping motion from
left to right and back continously, and do not force the machine to work, the motor should not strain when
grinding.
• FOR DRY GRINDING: Provide a respirator and dust control system.
• TO STOP THE MACHINE: Stop forward motion, tilt machine to raise off of floor. Power release handle grip
switch off and let the motor come to a complete stop.
• WHEN MANEUVERING THE GRINDER: Tilt grinder back enough so it dose not strike the slab surface. Dam-
age to accessories may occur with inadvertent contact with slab.
• DO NOT FORCE GRINDER WHILE GRINDING
• IF THE POWER SOURCE FAILS: Raise the grinder off of the floor. Disconnect the power source. Inspect the
accessories for damage. Replace damaged (or questionable) accessories immediately.
• WHEN TRANSPORTING THE GRINDER: Disconnect the power source before lifting or removing any guards.
Remove accessories when transporting.
• WHEN HOISTING OR LIFTING A GRINDER: Always inspect frame and attaching hardware for damage before
lifting. Use proper safe hoisting and lifting techniques and hardware. With handle in transport position ma-
chine can be lifted like a suitcase if you are physically capable.
Grip SwitchGrip Switch

DDG-9-I-0315
12
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
ATTACHING A VACUUM / SERVICING HEAD ASSEMBLY
PROCEDURE FOR ATTACHING A VACUUM:
When using a vacuum for dust control attach
it to the vacuum port at the rear of the ma-
chine as pictured above, securing it with a
clamp if necessary.
SERVICING HEAD ASSEMBLY:
To repair or replace morflex bushing remove
multi accessory disc to gain access.

DDG-9-I-0315
13
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
FOR USE WITH DYMA-SLIDER SYSTEM
DOUBLE DIAMOND DOTS: General Purpose Grind -
Removes general purpose epoxy, mastics, thinsets,
water-proofing coatings and more.
SINGLE DIAMOND DOTS: Aggressive Grind -
Grinds and removes thick epoxies, weather-proofing
membrane and other coatings.
PCD ACCESSORY: Extremely Aggressive
Removal - Digs through industrial strength
coverings, water-proofing membranes,
thick epoxies and much more -
Leaves a textured concrete surface.
EDCO ARROW: Hard glue
removal, fast coating removal,
create smooth surfaces and more
PEAKS: General Purpose Grind -
Smoothes surfaces with fewer scratchs - Ideal for
concrete preparation and polishing. Removes thinsets,
concrete coatings and more
Visit edcoinc.com to see all of our Quick-Change Accessories.
Accessories are subject to change.

DDG-9-I-0315
14
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
MAINTENANCE INSTRUCTIONS
1. Disconnect the machine from the power source. Disconnect the supply voltage con-
nector at the machine on electric models before performing any maintenance. All main-
tenance to be preformed by qualified personnel.
2. Never work under equipment without first properly securing the equipment to prevent it from moving
or falling. Always work on a flat and level surface.
3. Perform a visual inspection of the entire machine before each operation. Be sure all fasteners are tight
and secure, check for signs of metal cracking or fatigue, inspect for damage to electrical wiring, and in-
spect to be sure proper guards are in place and secure.
4. Before operation, check grinding discs to be sure it is tight. Grinding discs loosen with use. Tighten
bolts as required.
An occasional drop ot two of oil on the wheel bearings will help prevent binding.

DDG-9-I-0315
15
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
MAINTENANCE SCHEDULE
Before
Operation
Every 4
Hours Daily
Every 50
Hours of Op-
eration
As
Required
Visual Inspection of
Entire Machine X
Inspect Grinding Disc X
Clean Dust & Dirt Off
Machine X
Read and follow all instructions
in the Engine Manufacturer’s
Owners Manual.
Repairs are to be performed by
approved EDCO repair
technicians

DDG-9-I-0315
16
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
NOTES:
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
This page intentionally left blank.

DDG-9-I-0315
17
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
NOTES:
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
This page intentionally left blank.

DDG-9-I-0315
18
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
NOTES:
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
_____________________________________________________
This page intentionally left blank.

DDG-9-I-0315
19
301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
------- --------- -------- -- ---- - ----- - ----------
Equipment Development Company, Inc. herein referred to as EDCO (Seller) warrants that
each new unit manufactured by EDCO to be free from defects in material and workmanship
in normal use and service for a period of (1) one year (except for the cutter drum assembly
on all model concrete/asphalt planes, in which case the warranty period shall be 90 days)
from date of shipment to the original retail or equipment rental center owner.
Accessories or equipment furnished and installed on the product by EDCO but manufactured by
others, including, but not limited to engines, motors,electrical components, transmissions etc., shall
carry the accessory manufacturers own warranty.
EDCO will, at its option, repair or replace, at the EDCO factory or at a point designated by
EDCO, any part which shall appear to the satisfaction of EDCO inspection to have been
defective in material or workmanship.
EDCO reserves the right to modify, alter and improve any part or parts
without incurring any obligation to replace any part or parts previously sold without such
modified, altered or improved part or parts.
This warranty is in lieu of and excludes all other warranties, expressed, implied, statutory, or
otherwise created under applicable law including, but not limited to the warranty of merchant-
ability and the warranty of fitness for a particular purpose in no event shall seller or the manu-
facturer of the product be liable for special, incidental, or consequential damages, including
loss of profits, whether or not caused by or resulting from the negligence of seller and/or the
manufacturer of the product unless specifically provided herein. In addition, this warranty shall
not apply to any products or portions there of which have been subjected to abuse, misuse,
improper installation, maintenance, or operation, electrical failure or abnormal conditions
and to products which have been tampered with, altered, modified, repaired, reworked by
anyone not approved by seller or used in any manner inconsistent with the provisions of the
above or any instructions or specifications provided with or for the product
----- -------
Seller’s obligation hereunder are subject to, and Seller shall not be held responsible for, any
delay or failure to make delivery of all or any part of the Product due to labor difficulties,
fires, casualties, accidents, acts of the elements, acts of God, transportation difficulties,
delays by a common carrier, inability to obtain Product, materials or components or qualified
labor sufficient to timely perform part of or all of the obligations contained in these terms
and conditions, governmental regulations or actions, strikes, damage to or destruction in
whole or part of manufacturing plant, riots, terrorist attacks or incidents, civil commotions,
warlike conditions, flood , tidal waves, typhoon, hurricane, earthquake, lightning, explosion
or any other causes, contingencies or circumstances within or without the United States not
subject to the Seller’s control which prevent or hinder the manufacture or delivery of the
Products or make the fulfillment of these terms and conditions impracticable. In the event
of the occurrence of any of the foregoing, at the option of Seller, Seller shall be excused
from the performance under these Terms and Conditions, or the performance of the Seller
shall be correspondingly extended.
This document sets forth the terms and conditions pursuant to which the purchaser (“Pur-
chaser”) will purchase and Equipment Development Co.Inc. (“Seller”)will sell the products,
accessories, attachments (collectively the Products “) ordered by the Purchaser. These terms
and conditions shall govern and apply to the sale of Seller’s Products to Purchaser, regardless
of any terms and conditions appearing on any purchase order or other forms submitted by
Purchaser to Seller, or the inconsistency of any terms therein and herein.
1. - - - - -
All prices set forth on any purchase order or other document are F.O.B. Sellers facility or distribu-
tion point, as may be determined by Seller (F.O.B.Point). All prices are exclusive of any and all
taxes, including, but not limited to, excise, sales, use, property or transportation taxes related to the
sale or use of the Products, now or hereafter imposed, together with all penalties and expenses.
Purchaser shall be responsible for collecting and/or paying any and all such taxes, whether or
not they are stated in any invoice for the Products. Unless otherwise specified herein, all prices
are exclusive of inland transportation, freight, insurance and other costs and expenses relating
to the shipment of the Products from the F.O.B. point to Purchaser’s facility. Any prepayment by
Seller of freight insurance and other costs shall be for the account of Purchaser and shall be
repaid to Seller.
2. - - - - - - - - - - - -
Payment terms are as follows. 2% 10 days (to approved and qualified accounts). Net 30 days.
This is a cash discount for invoices paid within 10 days after the invoice date, regardless of
date of receipt of shipment. This is not a trade discount and will not be granted to accounts
that do not adhere to stated terms.
*All past due accounts are subject to a late payment fee of 1.5% per month or a maximum
allowed by law if different, along with the expenses incidental to collection including reason-
able attorney’s fees and costs.
*Seller reserves the right to hold shipments against past due accounts.
*Seller reserves the right to alter payment terms.
3.------- -----
All shipments will be made F.O.B. shipping point as designated in these Terms and Condi-
tions, and title shall pass at the F.O.B. point. Delivery to the initial common carrier shall
constitute delivery to the Purchaser. Any claims for loss or damage during shipment are
to be filed with carrier by the Purchaser. Seller will not assume responsibility for the per-
formance of the carrier.
Back orders will be shipped in the most practical fashion with charges consistent with our
freight policy established with the original order. UPS, FED EX, MAIL or shipments by other
couriers are subject to the same terms and conditions as outlined in paragraph #3”Freight
Terms”.
-.--------- -------- ---------
Seller shall use reasonable efforts to attempt to cause the Products to be delivered as provided
for in these Terms & Conditions. Delivery to the initial common carrier shall constitute the delivery
to the Purchaser. Sellers responsibility, in so far as transportation risks are concerned ceases
upon the delivery of the Products in good condition to such carrier at the F.O.B. point and all the
Products shall be shipped at the Purchaser’s risk. Seller shall not be responsible or liable for
any loss of income and/or profits, or incidental, special, consequential damages resulting from
Seller’s delayed performance in shipment and delivery.
-.------ -- --------- --------
Defective or failed material shall be held at the Purchaser’s premises until authorization has
been granted by Seller to return or dispose of Products. Products that are to be returned
for final inspection must be returned Freight Prepaid in the most economical way. Credit
will be issued for material found to be defective upon Seller’s inspection based on prices
at time of purchase.
6.-------- ------- -- -----
Products may be returned, provided that claim is made and Seller is notified within 7 days
of receipt of Products, and the Products are in original buyer’s possession not more than
30 days prior to return, subject to Seller’s approval. If Products are accepted for return, they
must be Freight Prepaid and buyer will be charged a minimum of 15% restocking charge,
plus a charge back for outbound freight charges if the original order was shipped prepaid.
Returns are not accepted for any Products that are specifically manufactured to meet the
buyer’s requirement of either specifications or quantity.
----------
These Terms and Conditions constitute the entire agreement between Seller and Purchaser as it
relates to terms and conditions of sale, and supersedes any and all prior oral or written agreements,
correspondence, quotations or understandings heretofore in force between the parties relating to
the subject matter hereof. There are no agreements between Seller and Purchaser with respect
to the Product herein except those specifically set forth in and made part of these terms and
conditions. Any additional terms, conditions and/or prices are rejected by Seller.
These terms and conditions may be modified, cancelled or rescinded only by a written
agreement of both parties executed by their duly authorized agents.
USE ONLY GENUINE EDCO PARTS & ACCESSORIES
- o- - o- - o- n sa- e- - - - - e sa- e- - o- o- - e- s and - - e li- e o- - o- - m
a
LIMITED EQUIPMENT WARRANTY OF SALE - TERMS & CONDITIONS 2. PAYMENT TERMS
3. FREIGHT TERMS
4. DELIVERY, DAMAGES, SHORTAGES
5. RETURN OF DEFECTIVE PRODUCTS
FORCE MAJEURE
1. PRICE
6. PRODUCTS ORDERED IN ERROR
AGREEMENTS
For your own safety, the safty of others and the life or your machine.

301-638-3326 • edcoinc.com • [email protected]
EQUIPMENT DEVELOPMENT COMPANY
SURFACE PREPARATION, RESTORATION, PROFESSIONAL
SAWING EQUIPMENT & HAND HELD TOOLS
100 Thomas Johnson Drive, Frederick, MD 21702
Phone: [phone] or 301-663-1600
Fax: [phone] or 301-663-1607
Email: [email protected]
Website: edcoinc.com
Patents Pending & Issued
Printing 3.2015
