EdenPURE GEN40 A5956 User manual

GEN40 Super Heater-Cooler
User Manual
PLEASE READ AND SAVE THESE INSTRUCTIONS
Model No.: A5956
EdenPURE®
MALFUNCTION
Heater won’t turn
on
The heater won’t
turn off
Abnormal noise
from the fan
Indicator light is off
REASONS
The cord isn’t
plugged in to the
outlet
The power button is
not on
Damage to the main
body
Bad connection of
power button
Damage to the main
body
Damage to the
circuit board
Foreign object in the
fan
The indicator light is
damaged
SOLUTION
Check the plug
Check the power
button
Contact the
manufacturer for
maintenance
Check the power
button
Contact the
manufacturer for
maintenance
Clear the foreign
object
Contact the
manufacturer for
maintenance
©2019 EdenPURE® I-5628 BR11908R-1
Troubleshooting
Warranty
This GEN40 comes with a ONE-YEAR LIMITED COMPONENT
WARRANTY. If your unit does not appear to be working properly,
please contact our service center by calling 1-800-225-6595. Prior
to your call, we encourage you to visit our service related website
www.edenpuresupport.com for troubleshooting tips and service
instructions if needed.
EdenPURE®
7800 Whipple Ave. NW
N. Canton, OH 44720
800-225-6595
www.edenpureservice.com
5

Welcome
Thanks for choosing the EdenPURE®GEN40 Super Heater-Cooler.
Before using, please read the following instructions carefully.
Contents
Introduction.......................................................................................1
Specifications.....................................................................................1
Control Panel .....................................................................................2
Instructions........................................................................................2
Warnings ............................................................................................3
Notes...................................................................................................3
Maintenance......................................................................................4
Troubleshooting ................................................................................5
Warranty.............................................................................................5
4. If you want the unit to oscillate, touch and hold the “ ” button
on the unit for 2 seconds or touch the “ ” button on the
remote. The unit will then oscillate left and right. To turn the
oscillation off, touch and hold the “ ” button on the unit for 2
seconds or touch the “ ” button on the remote.
5. To have the unit swing back and forth, touch and hold the
“” button on the top of the machine for 2 seconds or touch
the “ ” button on the remote. The unit will then swing back
and forth. To turn the swing function off, touch and hold the
“” button on the top of the unit for 2 seconds or touch the
“” button on the remote.
6. The timer can be set for either 2, 4 or 6 hours. To set the timer,
touch the “ ” button on the top of the unit once for 2 hours,
twice for 4 hours and three times for 6 hours. A red light will
indicate the amount of time you’ve selected. Or, touch the “ ”
button on the remote to toggle between 2, 4 and 6 hours.
7. If the unit is on without a timer being set, it will automatically
shut off after being on for 24 hours.
8. If the unit is set to turn off from the timer function, it will
automatically remember the timer length from the last time it
was turned on and will revert to that time period.
9. The panel on the unit and the remote control can be used
interchangeably, as they are synchronized.
Warnings
Don’t cover the heater to prevent it from overheating.
Don’t touch the protection grill in front of the thermal unit. It may
get warm.
Don’t block air inlets. Keep at least 6 inches of air space between
furniture and the unit.
Notes
1. Before using the unit, please make sure that you have a 110v
outlet to plug the unit into.
2. If the power cord becomes damaged, contact the manufacturer
immediately to have the cord replaced.
3. Don’t put the unit near curtains or anything that can be sucked
into the unit.
3

Control Panel
Instructions
Please check to make sure all parts are intact before use.
1. Press the on/off switch on the base of the unit. The unit will be
in stand-by mode.
2. Touch the POWER button on the top of the unit or on the
remote control and you will hear a click. The unit will turn on
in high heat mode. The indicator light will be red. Touch the
POWER button again to turn the unit off. It will continue to
run for several seconds to purge the warm air out of it.
3. After turning the unit on, you can change modes by touching
the “MODE” button on the remote. The modes are High Heat,
Low Heat and Fan.
Introduction
The EdenPURE®GEN40 comes equipped with easy, touch button
operation on the unit, as well as a remote control. It puts out a lot
of air, while running quietly. It has a tip-over switch, which shuts
the unit off if it were to tip over. The GEN40 can be set to oscil-
late to provide heating/cooling over a wide area. It has a carrying
handle at the top, so it is portable and can be moved from room to
room.
The GEN40 uses a PTC thermal unit, which heats up quickly but
does not have an open flame, so it is suitable for home and office
use.
Specifications
Name: GEN40 Rated voltage: 120V
Model: A5956 Rated Power: 1500W
Electric shock class: II Rated frequency: 60Hz
Handle
Remote
Control
Dust
Screen
Remote
Control
Place
Indicator
light
Light red light - High heat
Dark red light - Low heat
Blue light - Fan
No light - Off
Turnplate
Base
PTC
Plug
On/Off
12

Control Panel
Instructions
Please check to make sure all parts are intact before use.
1. Press the on/off switch on the base of the unit. The unit will be
in stand-by mode.
2. Touch the POWER button on the top of the unit or on the
remote control and you will hear a click. The unit will turn on
in high heat mode. The indicator light will be red. Touch the
POWER button again to turn the unit off. It will continue to
run for several seconds to purge the warm air out of it.
3. After turning the unit on, you can change modes by touching
the “MODE” button on the remote. The modes are High Heat,
Low Heat and Fan.
Introduction
The EdenPURE®GEN40 comes equipped with easy, touch button
operation on the unit, as well as a remote control. It puts out a lot
of air, while running quietly. It has a tip-over switch, which shuts
the unit off if it were to tip over. The GEN40 can be set to oscil-
late to provide heating/cooling over a wide area. It has a carrying
handle at the top, so it is portable and can be moved from room to
room.
The GEN40 uses a PTC thermal unit, which heats up quickly but
does not have an open flame, so it is suitable for home and office
use.
Specifications
Name: GEN40 Rated voltage: 120V
Model: A5956 Rated Power: 1500W
Electric shock class: II Rated frequency: 60Hz
Handle
Remote
Control
Dust
Screen
Remote
Control
Place
Indicator
light
Light red light - High heat
Dark red light - Low heat
Blue light - Fan
No light - Off
Turnplate
Base
PTC
Plug
On/Off
12

Welcome
Thanks for choosing the EdenPURE®GEN40 Super Heater-Cooler.
Before using, please read the following instructions carefully.
Contents
Introduction.......................................................................................1
Specifications.....................................................................................1
Control Panel .....................................................................................2
Instructions........................................................................................2
Warnings ............................................................................................3
Notes...................................................................................................3
Maintenance......................................................................................4
Troubleshooting ................................................................................5
Warranty.............................................................................................5
4. If you want the unit to oscillate, touch and hold the “ ” button
on the unit for 2 seconds or touch the “ ” button on the
remote. The unit will then oscillate left and right. To turn the
oscillation off, touch and hold the “ ” button on the unit for 2
seconds or touch the “ ” button on the remote.
5. To have the unit swing back and forth, touch and hold the
“” button on the top of the machine for 2 seconds or touch
the “ ” button on the remote. The unit will then swing back
and forth. To turn the swing function off, touch and hold the
“” button on the top of the unit for 2 seconds or touch the
“” button on the remote.
6. The timer can be set for either 2, 4 or 8hours. To set the timer,
touch the “ ” button on the top of the unit once for 2 hours,
twice for 4 hours and three times for 8hours. A red light will
indicate the amount of time you’ve selected. Or, touch the “ ”
button on the remote to toggle between 2, 4 and 8hours.
7. If the unit is on without a timer being set, it will automatically
shut off after being on for 24 hours.
8. If the unit is set to turn off from the timer function, it will
automatically remember the timer length from the last time it
was turned on and will revert to that time period.
9. The panel on the unit and the remote control can be used
interchangeably, as they are synchronized.
Warnings
Don’t cover the heater to prevent it from overheating.
Don’t touch the protection grill in front of the thermal unit. It may
get warm.
Don’t block air inlets. Keep at least 6 inches of air space between
furniture and the unit.
Notes
1. Before using the unit, please make sure that you have a 110v
outlet to plug the unit into.
2. If the power cord becomes damaged, contact the manufacturer
immediately to have the cord replaced.
3. Don’t put the unit near curtains or anything that can be sucked
into the unit.
3

4. Make sure the unit is placed on a flat stable surface.
5. Don’t use the unit in a flammable environment. Keep it away
from flammable objects.
6. The protection grill is used to separate the thermal unit from the
user. If the protection grill is damaged, contact the manufacturer
to have it replaced. Do not continue to use the unit.
7. When not using the unit for longer periods of time, make sure
it is turned off and unplugged from the outlet.
8. Make sure you unplug the unit before moving it to another area.
9. Do not twist or pull the cord from the outlet. Remove it holding
the end of the plug.
10. Do not place the unit in a place where it may lean more than
10 degrees and do not lay it on it’s side while using.
11. To avoid getting burned, do not touch the protection panel
when the unit is in use.
12. Turn the power off before unplugging the unit.
13. Don’t unplug the unit with wet hands.
14. Don’t use the unit around water such as in bathtubs, around
sinks or around swimming pools.
15. Don’t put your fingers into the protection grill while the unit is
turned on.
16. Keep out of reach of children.
17. If the unit becomes dirty, turn it off, unplug it and clean it
with a soft cloth and gentle soap. Don’t clean with abrasive
substances.
Maintenance
Turn the unit off before performing any type of maintenance.
1. Clean any dirt that may be on the unit immediately. Otherwise
it may fade or damage the unit.
2. Clean only with a soft cloth and gentle soap or detergent.
3. After cleaning the unit, store it in the box in a dry place.
4. Only clean the outside of the unit. Never clean the thermal
unit.
5. Don’t spray water directly into the unit.
4

GEN40 Super Heater-Cooler
User Manual
PLEASE READ AND SAVE THESE INSTRUCTIONS
Model No.: A5956
EdenPURE®
MALFUNCTION
Heater won’t turn
on
The heater won’t
turn off
Abnormal noise
from the fan
Indicator light is off
REASONS
The cord isn’t
plugged in to the
outlet
The power button is
not on
Damage to the main
body
Bad connection of
power button
Damage to the main
body
Damage to the
circuit board
Foreign object in the
fan
The indicator light is
damaged
SOLUTION
Check the plug
Check the power
button
Contact the
manufacturer for
maintenance
Check the power
button
Contact the
manufacturer for
maintenance
Clear the foreign
object
Contact the
manufacturer for
maintenance
©2019 EdenPURE® I-5628 BR11908R-1
Troubleshooting
Warranty
This GEN40 comes with a ONE-YEAR LIMITED COMPONENT
WARRANTY. If your unit does not appear to be working properly,
please contact our service center by calling 1-800-225-6595. Prior
to your call, we encourage you to visit our service related website
www.edenpuresupport.com for troubleshooting tips and service
instructions if needed.
EdenPURE®
7800 Whipple Ave. NW
N. Canton, OH 44720
800-225-6595
www.edenpureservice.com
5
