Installation Guide
EC3002
Media Converter

Installation Guide
FTTH Media Converter - EC3002
with One Fixed 100BASE-FX Single-Fiber Line Connection,
and One 10BASE-T / 100BASE-TX (RJ-45) Port

EC3002
E062005-R01
150000047700A

i
Contents
Introduction 1
Key Features 2
Description of Hardware 3
Fiber Cable Connection 3
UTP Port 3
External DIP Switch Settings 4
Internal DIP Switch Settings 5
LED Indicators 6
Installing the FTTH CPE 7
Package Contents 7
System Requirements 7
Mounting the CPE 8
Desktop Mounting 9
Wall Mounting 9
Connecting to the CPE 10
Making a Connection to the UTP Port 10
Powering On the CPE 11
Configuring the TCP/IP Protocol 12
Windows 95/98/NT 12
Windows 2000 12
Windows XP 12
Mac OS Systems 13
Product Specifications 14
Troubleshooting 15
Diagnosing CPE Indicators 15
If You Cannot Connect to the Internet 15
Port and Cable Assignments 16
RJ-45 Ethernet Port 16
Straight-Through Wiring 16
Crossover Wiring 17
EMI Certification 18
Safety Compliance 18
FCC - Class B 18
Warning: Fiber Optic Port Safety 18
Avertissment: Ports pour fibres optiques - sécurité sur le plan optique 18
Warnhinweis: Faseroptikanschlüsse - Optische Sicherheit 18
Wichtige Sicherheitshinweise (Germany) 19

Contents
ii

1
Introduction
Fiber-To-The-Home (FTTH) has always been an attractive option for Internet
access. It has all the benefits of optical fiber. It provides a future-proof network, in
that you do not have to go through the hassles of upgrading from ADSL to xDSL, or
digital co-ax to digital wireless. It does not have to struggle with electromagnetic
interference problems, and with no active “outside-plant” components, it offers the
highest reliability. Moreover, it does not require electric power and is immune to
lightning and other transients. These properties of fiber lead to the lowest possible
power and operational costs, such as maintenance, provisioning and facilities
planning.
The EC3002 Media Converter is an ideal Customer Premises Equipment (CPE) for
an FTTH system. The CPE is a single-channel fiber-to-copper media converter
housed in a compact unit. It allows a service provider to extend an Ethernet
connection over optical fiber directly to a subscriber. The CPE has an embedded (no
external plug/socket) 100BASE-FX full-duplex single-fiber single-mode cable
connection that runs from the service provider’s central office (CO). The
single-mode fiber connection can be run up to distances of 15 km from the CO. The
CPE also provides one standard 10/100BASE-TX RJ-45 Ethernet port for
connecting to a customer’s PC, switch, or other network device using twisted-pair
cable.
EC3002 CPE
100BASE-FX full-duplex
single-fiber (WDM) link to CO
(up to 15 km)
Subscriber’s Home
Central Office
(CO)
10/100BASE-TX UTP
connection to computer
(up to 100 m)

Introduction
2
Key Features
• High-speed Internet access
• Optical fiber port supports transmission distances up to 15 km
• Built-in transparent bridging between different media segments
• Supports 1K MAC addresses — forwards packets only if necessary
• Always-on fast optical fiber connection eliminates dial-up delays, providing
transparent Internet access
• Auto-negotiating 10/100BASE-TX Ethernet port
• Provides DIP switch setting to force 10/100BASE-TX port speed, duplex mode,
and MDI/MDI-X wiring
• Internal DIP switch setting for Auto MDI-X, flow control, MAC learning and Link
Pass Through
• Compliant to IEEE 10BASE-T, 100BASE-TX, and 100BASE-FX standards
• Provides back pressure for half-duplex and IEEE 802.3x flow control for full-duplex
• Internal mechanism prevents the fiber connection from being disconnected
accidently
• Natural air cooling system without using a fan
• LEDs indicate Ethernet activity and fiber link status
• Provides device status information for management from the CO
• Simple plug-and-play installation
• Space-saving compact size

3
Description of Hardware
The EC3002 is an FTTH CPE product for high-speed Internet access applications.
The CPE includes an embedded fiber cable connection, an RJ-45 Ethernet port, a
DIP-switch for the RJ-45 port settings, an internal DIP switch for Auto MDI-X, flow
control, MAC learning and Link Pass Through, LED status indicators, and an AC
power adapter connection.
The following figure shows the components of the CPE.
Fiber Cable Connection
The single-mode fiber cable connection from the service provider’s CO is embedded
(connected internally) within the CPE. There is no external plug and socket
connection, which prevents theCPE from being disconnected accidently. Also, there
are no configuration settings or maintenance necessary for the fiber cable link.
The single-fiber connection supports a 100BASE-FX full-duplex link to the CO. The
CPE’s fiber transceiver uses Wavelength Division Multiplexing (WDM) technology to
achieve bi-directional operation (1550 nm transmit, 1310 nm receive) over a single
optical fiber. The WDM single-mode fiber link can run up to 15 km from the CO.
UTP Port
The RJ-45 Ethernet port labeled “UTP” operates at 10 or 100 Mbps, and supports
auto-negotiation of speed, duplex mode (i.e., half or full duplex), and flow control.
The UTP port can also be forced to a specific speed and duplex mode via a
DIP-switch setting. Using the DIP switch you can also set the port for MDI or MDI-X
operation, so you can use straight-through cable for all connections.
Vent (Natural Air
Cooling System)
Top Panel
LED Indicators
Rear Panel
DIP-Switch
(4 bit)
DC12V Line
(embedded)
RJ-45 socket
Fiber Line
(embedded)
Optical IN/OUT
Auto
MDI-X
100
Full
UTP
DC IN 12V
ON
EC3002

Description of Hardware
4
External DIP Switch Settings
The CPE has a four-bit DIP switch located on its rear panel next to the UTP port
(see figure below). The DIP switch allows you to enable/disable auto-negotiation for
the UTP port and manually force the speed and duplex mode setting. Also, there is
one switch for setting the UTP port to MDI or MDI-X wiring. The ON position for the
DIP switch is down.
The following table lists the DIP-switch settings:
Note: Auto-negotiation must be disabled, i.e., switch Auto (bit 4) set to OFF, for switches
Full (bit 3),100 (bit 2) and MDI-X (bit 1) to be functional.
DIP SW Bit Name Description
1MDI-X ON: Port wired as MDI-X. (Only functional when Auto is OFF).
OFF: Port wired as MDI.
2100 ON: Port operating as 100BASE-TX. (Only applies if Auto is OFF.)
OFF: Port operating as 10BASE-T.
3Full ON: Full-duplex mode. (Only applies if Auto is OFF.)
OFF: Half-duplex mode.
4Auto ON: Auto-negotiation enabled.
OFF: Auto-negotiation disabled. (Force setting using bits 1-3.)
Optical IN/OUT
Auto
MDI-X
100
Full
UTP
DC IN 12V
ON
DIP Switch
DIP Switch On Position

Internal DIP Switch Settings
5
Internal DIP Switch Settings
The CPE has a second four-bit DIP switch located internally next to the LEDs (see
figure below). This DIP switch sets the capabilities available to the external DIP
switch and allows flow control to be enabled/disabled. The ON position for the DIP
switch is down.
The following table lists the Internal DIP switch settings:
DIP SW Bit Function Description
1Auto MDI-X ON: The external "MDI-X" DIP switch is disabled and Auto MDI-X is
available on the UTP port.
OFF: The external "MDI-X" DIP switch is enabled.
2MAC learning
disable ON: MAC learning function is disabled.
OFF: MAC learning function is enabled.
3Flow Control
disable ON: Disable flow control.
OFF: Enable flow control.
4Link Pass
Through ON: Enable Link Pass Through.
OFF: Disable Link Pass Through.
ON
1234

Description of Hardware
6
LED Indicators
The CPE includes seven LED status indicators on the top panel. The LEDs are
detailed in the following figure and table.
LED Color Description
PWR Green ON: Power is on.
OFF: Power is off.
OPT Green ON: Fiber link is up.
OFF: Fiber link down.
TEST Orange ON: Loopback test in progress.
OFF: No loopback test (normal mode).
PC Green ON: UTP port link is up.
OFF: UTP portlink isdown.
DATA Green ON/Flashing: UTP port is transmitting or receiving data.
OFF: No activity on the UTP port.
100M Green ON: UTP port is operating as 100BASE-TX.
OFF: UTP port is operating as 10BASE-T.
FULL Green ON: UTP port is operating in full-duplex mode.
OFF: UTP port is operating in half-duplex mode.

Package Contents
7
Installing the FTTH CPE
Before installing the CPE, verify that you have all the items listed under “Package
Contents.” If any of the items are missing or damaged,contact your service provider.
Also, be sure you have all the necessary tools and cabling before installing the CPE.
Package Contents
The package includes the following items:
• One EC3002 FTTH media converter CPE
• Four rubber foot pads
• AC power adapter
• This Installation Guide
Please inform your service provider if there are any incorrect, missing or damaged
parts. If possible, retain the carton, including the original packing materials. Use
them again to repack the product in case there is a need to return it for repair.
System Requirements
The CPE requires the following computer features to operate:
• A PC or Macintosh with a 10/100 Mbps Ethernet adapter card installed
• For Internet access, the computer must be configured for TCP/IP

Installing the FTTH CPE
8
Mounting the CPE
Caution: The EC3002 CPE is for indoor mounting only. Do not mount the unit on the
outside of a building.
The CPE includes rubber feet for desktop mounting.
Before you start installing the CPE, make sure you can provide the right operating
environment. Verify the following installation requirements:
• Power requirements: 12 VDC via the included AC power adapter. Make sure that
a properly grounded power outlet is within 1.8 m (6 ft) of the CPE.
• The CPE should be located in a cool dry place, with at least 5 cm (2 in.) of space
on all sides for proper air flow.
• Place the CPE out of direct sunlight, and away from heat sources or areas with a
highamountofelectromagneticinterference.Thetemperatureandhumidityshould
be within the ranges listed in the specifications.
• Make sure the fiber line is carefully routed to the CPE in a way that does not incur
a bending radius in the cable of less than 30 mm.
• Be sure that the CPE is accessible for the UTP Ethernet connection.
• Make sure UTP cable is always routed away from power lines, fluorescent lighting
fixtures and other sources of electrical interference such as radios, transmitters,
etc.
• The status LEDs are clearly visible.
Wall mounting using the
wall-mounting slots
Desktop Mounting
Horizontal mounting using
rubber feet
Wall Mounting

Mounting the CPE
9
Desktop Mounting
The CPE can be mounted horizontally on any flat surface, such as a desktop or
shelf.
For horizontal mounting, simply stick the self-adhesive rubber foot pads (that come
with this package) on each of the four concave spaces located on the bottom of the
CPE. Then, place the CPE on the flat surface where it is to be installed.
Wall Mounting
The CPE can also be mounted on a wall. Two mounting slots are provided on the
bottom of the unit for this purpose. Be sure to position the CPE so that the front
panel LEDs can be viewed when the unit is operating.
Note: Wall mounting screws and wall plugs are not provided in the CPE package.
To mount the CPE on a plastered brick or concrete wall, follow these steps:
1. Mark the position of the mounting screws on the wall so they line up with the two
mounting slots on the bottom of the CPE.
2. Drill two holes of appropriate size for the wall plugs and screws (recommended
size T3 x 15L). Press the plugs firmly into the drilled holes until they are flush
with the surface of the wall.
3. Insert the screws into the wall plugs leaving about 3 mm (0.12 in.) clearance
from the wall.
4. Position the CPE over the mounting screws, then slide it down onto the screws.
To mount the CPE on a wood wall, follow these steps:
1. Mark the position of the mounting screws on the wall so they line up with the two
mounting slots on the bottom of the CPE.
2. Insert the screws into the wall leaving about 3 mm (0.12 in.) clearance from the
wall.
3. Position the CPE over the mounting screws, then slide it down onto the screws.
Rubber feet
Bottom surface

Installing the FTTH CPE
10
Connecting to the CPE
Caution: The CPE fiber line should be connected to the unit by a qualified technician
only. Do not attempt to remove the fiber cable from the CPE. If there are any
problems with the fiber cable connection, contact your service provider.
You can connect any computer with an Ethernet network interface card, a LAN
switch, hub, or other network device to the CPE’s UTP port.
Making a Connection to the UTP Port
The UTP port on the CPE supports both MDI and MDI-X operation via DIP-switch
selection. This allows you to use standard straight-through twisted-pair cables to
connect to any other network device (computers, switches, routers, or hubs).
See “Port and Cable Assignments” on page 16 for more information on connecting
straight-through or crossover UTP cables to MDI or MDI-X ports.
Caution: Do not plug a phone jack connector into any RJ-45 port. This may damage the
CPE. Instead, use only twisted-pair cable with RJ-45 connectors that conform
with FCC standards.
To connect the CPE’s UTP port directly to a computer, carry out the following steps:
1. Prepare the computer you wish to connect. Make sure you have installed a
10BASE-T or 100BASE-TX network interface card for connecting to the CPE’s
UTP port.
2. Check that the CPE’s UTP port has auto-negotiation enabled by setting the
“Auto” DIP-switch to ON. If you manually set the speed and duplex mode, be
sure that the CPE and computer’s network interface card settings match.
3. Check that the CPE’s UTP port has MDI-X enabled by setting the “MDI-X”
DIP-switch to ON. Prepare straight-through shielded or unshielded twisted-pair
cable with RJ-45 plugs at both ends (not included in the CPE package). Use
100-ohm Category 3, 4 or 5 cable for 10 Mbps Ethernet connections, or
100-ohm Category 5 cable for 100 Mbps Fast Ethernet connections.
AC Power Adapter
FTTH Link
Category 5 UTP cable to
Ethernet port on computer
DC Power Cord
UTP
Port
Computer
Fiber Line AC Power Outlet
EC3002

Powering On the CPE
11
4. Connect one end of the cable to the RJ-45 port of the computer’s network
interface card, and the other end to the UTP port on the CPE. When inserting an
RJ-45 plug, be sure the tab on the plug clicks into position to ensure that it is
properly seated.
Notes: 1. Make sure each twisted-pair cable does not exceed 100 meters (328 feet).
2. We advise using Category 5 cable for all network connections to avoid any
confusion or inconvenience in the future when you upgrade devices to Fast
Ethernet.
Powering On the CPE
Plug the AC power adapter directly into a power outlet. Check the LED marked
“Power” on the front panel to be sure it is on.

Installing the FTTH CPE
12
Configuring the TCP/IP Protocol
To connect to the Internet through the CPE’s Ethernet port, a computer must have
an Ethernet network interface card installed, and be configured for the TCP/IP
protocol. Many service providers will configure TCP/IP for client computers
automatically using a networking technology known as Dynamic Host Configuration
Protocol (DHCP). Other serviceproviders may specify an IP configuration(known as
a static IP address), which must be entered manually.
Carry out the following steps to check that the computer’s Ethernet port is correctly
configured for DHCP.
Windows 95/98/NT
1. Select Start/Settings/Control Panel.
2. Click on the Network icon.
3. For Windows NT, click the Protocols tab.
4. Select TCP/IP from the list of network protocols, this may include details of
adapters installed in your computer.
5. Click on “Properties.”
6. Select the option “Obtain an IP Address.”
Windows 2000
1. Select Start/Settings/Network and Dial-up Connections.
2. Click on “Local Area Connections.”
3. Select “TCP/IP” from the list of network protocols, this may include details of
adapters installed in your computer.
4. Click on “Properties.”
5. Select the option “Obtain an IP Address.”
Windows XP
1. Select Start/Settings/Control Panel.
2. Click on the Network and Internet Connections icon.
3. Double click “LAN or High-Speed Internet.”
4. Click on “Properties.”
5. Double click “Internet Protocol (TCP/IP).”
6. Select the option “Obtain an IP Address automatically.”

13
Mac OS Systems
1. Pull down the Apple Menu. Click “Control Panels” and select “TCP/IP.”
2. In the TCP/IP dialog box, make sure that “Ethernet” is selected in the “Connect
via:” field.
3. If “Using DHCP Server” is already selected in the “Configure” field, your
computer is already configured for DHCP. Otherwise, select “Using DHCP
Server” in the “Configure” field and close the window.
4. Another box will appear asking whether you want to save your TCP/IP settings.
Click Save.
Your service provider will now be able to automatically assign an IP address to your
computer.

Product Specifications
14
Product Specifications
Standards Conformance IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX and
100BASE-FX, IEEE 802.3x flow control
TTC Standard TS-1000 class S
Fiber Specifications
Fiber Cable ITU-T G.652 single-fiber single-mode (WDM)
Connector SC and splice (internal)
Wavelengths 1310 nm transmit, 1550 nm receive
Data Rate 100 Mbps full duplex
Transmit Power -14 to -8 dBm
Receive Power -30 to -8 dBm
Optical Power Budget 16 dB
Range Up to 15km (max)
Ports 1 RJ-45 10/100BASE-TX
Media Connection 10BASE-T: Cat 3, 4, or 5 UTP cable
100BASE-TX: Cat 5 UTP cable
LEDs Power, Test, OPT (Fiber), PC (LAN), Data (LAN
Activity), 100 (LAN speed), FULL (LAN mode)
Dimensions 18 x 11 x 3.5 cm (7.09 x 4.33 x 1.38 in.)
Weight
Media Converter 250 g (8.82 oz.) maximum
AC Adapter 160 g (5.64 oz.) maximum
Input Power 12 VDC, 1A (via AC power adapter)
Available Adapters: Europe - DVE / DV-0151A-12A(U)
Japan and USA - DVW / DV-0151A-12
Power Consumption 4 Watts maximum
Environmental
Temperature Operating: 0~40 °C / 32~122 °F
Storage: -10~70 °C / -40~158 °F
Humidity 10 - 90% (non-condensing)
Certification
Immunity IEC 61000-4-2
Emissions FCC Class B
