EdilKamin GORA 22 Quick start guide

GORA 22
GORA 26
GORA 29
EN Installation, use and maintenance pag. 2
PELLET BOILER

2
ENGLISH
The undersigned company, with registered office in
Via Vincenzo Monti 47 - 20123 Milan (Italy) - Italian Tax
Code 00192220192
Hereby declares, under its sole responsibility, that:
The pellet boiler described below conforms to
European Directive 2006/42/EC (Machinery Directive)
and to the harmonised European standard
EN 303-5:2012
PELLET BOILER, tradename Edilkamin,
GORA 22 - GORA 26 - GORA 29
SERIAL NO.: Data plates
Declaration of Conformity
Rating plate reference
Moreover, the company hereby declares that:
the GORA 22 - GORA 26 - GORA 29 wood
pellet stove satisfy the requirements of the following
European directives:
2014/35/UE - Low Voltage Directive
2014/30/UE - Electromagnetic Compatibility Directive
CONTENTS
Safety information
Safety information 4
Technical data
Technical data 5
Dimensions
Dimensions 6
Water circuit installation
Water circuit installation 13
Installation
Installation 16
Instructions for use
Instructions for use 21
Maintenance
Maintenance 34
Troubleshooting
Troubleshooting 38

3
ENGLISH
Dear Sir/Madam
Congratulations on choosing our product. Before you
use it, please read this manual carefully, to ensure you
get the best performance from your new appliance in
total safety.
This manual is an integral part of the product. We ask
that you keep it for the entire lifetime of the product. If
you lose it, you can request a copy or download it from
www.Edilkamin.it
After unpacking the product, check the condition and
completeness of the contents.
In the event of error, immediately contact the retailer
where the purchase was made, providing him with a
copy of the warranty booklet and the sales receipt.
The product must be installed and used in compliance
with all applicable local, national and European
regulations. For the installation and other aspects
not covered explicitly in this manual, refer to the local
regulations of your country.
The diagrams provided in this manual are for illustration
purposes only: they do not always strictly refer to your
specific model, and are not binding in any way.
The product is uniquely identified by a number, the
“counterfoil”, which is on the warranty certificate.
Please keep:
• the warranty certificate accompanying the product
• the purchase receipt given to you by the retailer
• the declaration of conformity given to you by the
installer.
The warranty conditions are given in the warranty
certificate accompanying the product.
In Italy, commissioning by an authorised technician
is required by UNI 10683, and is recommended in all
countries to ensure best results from the product.
This consists in:
• checking the installation documents (declaration
of conformity) and the quality of the installation
itself;
• calibrating the product to suit its actual application
• explanation to the end user and issue of
complementary documentation (commissioning
certificate)
Having the appliance commissioned properly ensures
that it will operate to best effect and in complete safety.
Proper commissioning is required for activation of the
Edilkamin warranty. The warranty is only valid in the
country of sale of the product.
If the appliance is not commissioned by an authorised
technician, Edilkamin will not provide warranty service.
See the warranty booklet for details. The above terms
do not affect the reseller’s legal responsibility for the
legal warranty.
The warranty covers only demonstrable manufacturing
defects and not, for instance, problems resulting from
improper installation or calibration.
MEANING OF SYMBOLS
In some parts of the manual the following symbols are
used:
INFORMATION:
failure to comply with these requirements
will compromise product use.
PLEASE NOTE:
carefully read and understand the
message in question, since failure to
follow the instructions in it could cause
serious damage to the product and put
the safety of those using it at risk.
OPERATING SEQUENCE:
follow the instructions for the operations
described

4
ENGLISH
SAFETY INFORMATION
• The product is not designed for use by
people, including children, with limited
physical, sensory and mental abilities.
• The appliance is designed for cooking
purposes.
• The appliance is designed to burn UNI EN
ISO 17225-2 category A1 wood pellets, in
the amounts and manner described in
this manual.
• The appliance is designed for indoor use
and for environments with normal humidity
conditions.
• Keep the product in a dry place out of the
weather.
• For the legal and company warranties,
refer to the warranty certificate inside the
product: specifically, neither Edilkamin nor
the reseller are liable for damage resulting
from incorrect installation or maintenance.
Safety risks may be caused by:
• installation in unsuitable areas. In
conditions where there is a particular risk
of fire hazard. DO NOT INSTALL THE
PRODUCT IN AREAS SUBJECT TO THE
RISK OF FIRE.
• contact with fire and hot parts (e.g. glass
panel and pipes). DO NOT TOUCH HOT
PARTS and, when switched off and still
hot, always wear the gloves.
• contact with live electrical equipment
(internal). DO NOT ACCESS THE
INTERNAL ELECTRICAL EQUIPMENT
WHILE THE APPLIANCE IS POWERED
ON. Electrocution hazard.
• the use of unsuitable ignition aids (e.g.
alcohol). DO NOT IGNITE OR BOOST
THE FLAME WITH FLUID SPRAYS OR
A FLAME TORCH. Serious risk of burns,
damage and injury.
• the use of fuel other than wood pellets. DO
NOT BURN WASTE MATTER, PLASTICS
OR ANY MATERIALS OTHER THAN
WOOD PELLETS IN THE HEARTH. Risk.
The product may be soiled, the flue may
catch fire, and could cause damage to
the environment.
• cleaning the hearth when hot. NEVER
VACUUM WHEN HOT. This risks damage
to the vacuum cleaner and smoke in the
room.
• cleaning the fumes duct with cleaning
products. DO NOT CLEAN THE
PRODUCT BY HAND WITH FLAMMABLE
PRODUCTS. Risk of fire or blowback.
• cleaning the hot glass pane with unsuitable
cleaning products. DO NOT CLEAN
HOT GLASS WITH WATER. ONLY USE
RECOMMENDED GLASS CLEANING
PRODUCTS Risk of cracking as well as
irreparable damage to the glass.
• the storage of flammable materials at
a distance which is less than the safe
distances listed in this manual. DO NOT
REST LAUNDRY ON THE PRODUCT.
DO NOT PLACE DRYING RACKS AT A
DISTANCE WHICH IS LESS THAN THE
SAFETY DISTANCES. Keep flammable
fluids away from the product. Risk of fire.
• blocking air ventilation openings or air
inlets in the room. DO NOT BLOCK THE
AIR VENTILATION OPENINGS, OR THE
FLUE. Risk of smoke returning into the
room with consequent damage and injury.
• use of the product as a support or ladder.
DO NOT CLIMB ONTO THE PRODUCT
OR USE IT AS A SUPPORT. Risk of
damage and injury
• use of the boiler with the hearth open.
DO NOT USE THE PRODUCT WITH ITS
DOOR OPEN.
• incandescent material escaping from the
open door. DO NOT throw incandescent
material outside the appliance. Risk of fire.
• use of water in case of fire. CALL THE
AUTHORITIES in the event of fire.
• If you have doubts, please do not take
any action, but contact the retailer or the
installer.
• NEVER OPERATE THE BOILER WITHOUT
WATER IN THE CIRCUIT.
• A “DRY” IGNITION COULD RESULT IN
DAMAGE TO THE BOILER.
• For reasons of safety, read the user
instructions included in this manual.

5
ENGLISH
TECHNICAL DATA
The manufacturer reserves the right to modify the product without notification in the interests of improve-
ment.
TECHNICAL DATA FOR RATING THE FLUE
which must in any case satisfy the requirements of this sheet and the installation instructions for the product
GORA 22 GORA 26 GORA 29
Nominal power
Fumes temperature at outlet 106 112 116 °C
Minimum draw 0,01 Pa
Fumes flow rate 11,7 13 13,7 g/s
ELECTRICAL SPECIFICATIONS
Power 230Vac +/- 10% 50 Hz
Power consumption in stand by 4 W
Mean absorbed power 73/20 W 90/20 W 90/20 W
Power absorption during ignition 400 W
Protection on mains power supply Fuse 4 AT, 250 Vac 5x20
Logic board protection Fuse 4 AF, 250 Vac 5x20
TECHNICAL CHARACTERISTICS in accord. with EN 303-5
GORA 22 GORA 26 GORA 29 GORA
22-26-29
Nominal
power
Nominal
power
Nominal
power
Reduced
power
Heat input 21,5 25,8 29,2 6 kW
Available power 20,1 24 27 6 kW
Efficiency 93,5 92,9 92,5 94,3 %
CO emissions at 10% O20,002 0,006 0,009 0,026 %
Fumes temperature 88 93 97 54 °C
Fuel consumption * 4,5 5,4 6,1 1,4 kg/h
Tank capacity 60 kg
Draw 12 11 11 11 Pa
Water content 40 Litri
Maximum operating water pressure 2 bar
Maximum operating water temperature 90 °C
Autonomy 13-43 11-43 10-43 -- h
Heatable volume ** 525 625 705 -- m3
Fumes outlet diameter 80 mm
Combustion air diameter 50 mm
Weight including packaging 302 335 328 -- kg
Product class (EN 303-5/2012) 5 --
EU 2015/1187 A+ --
*A calorific value of 4.8 kW/Kg has been used to calculate consumption.
** The heatable volume is calculated based on the assumption of a heating demand of 33 Kcal/m³ hour.

6
ENGLISH
DIMENSIONS
GORA 22 - GORA 26 - GORA 29 (dimensions cm)
55 78
131 131
78
97,1
27,5
17,1
16 Smoke outlet
Ø 8 cm
42,7
24,6
27,5
Combustion
air Ø 5 cm
A
AHydraulic connections depend on the
optional kits R-FX, R2-FX o RW-FX.
You can find further information in the
paragraph “water circuit installation”

7
ENGLISH
TECHNICAL DATA
Pag. 1 of 2

ECODESIGN REQUIREMENTS FOR SOLID FUEL BOILERS
ACCORDING TO COMMISSION REGULATION (EU) 2015/1189
AND ECOLABEL REQUIREMENTS FOR SOLID FUEL BOILERS
ACCORDING TO COMMISSION REGULATION (EU) 2015/1187
The present document cancels and supersedes document issued November 29, 2018.
EDILKAMIN –GORA 22
Stoking mode: Automatic: it is recommended that the boiler be operated with a hot water storage tank of a
volume of at least 400 litres (**)
Condensing boiler: no
Solid fuel cogeneration boiler: no
Combination boiler: no
Fuel
Preferred
fuel (only
one):
Other
suitable
fuel(s):
ηs
[%]:
Seasonal space heating
emissions
PM
OGC
CO
NOx
mg/m3at 10%O2
Log wood, moisture content ≤25 %
no
no
Chipped wood, moisture content 15-35 %
no
no
Chipped wood, moisture content > 35 %
no
no
Compressed wood in the form of pellets
or briquettes
yes
no
84
16
4
281
122
Sawdust, moisture content ≤50 %
no
no
Other woody biomass
no
no
Non-woody biomass
no
no
Bituminous coal
no
no
Brown coal (including briquettes)
no
no
Coke
no
no
Anthracite
no
no
Blended fossil fuel briquettes
no
no
Other fossil fuel
no
no
Blended biomass (30-70 %)/fossil fuel
briquettes
no
no
Other blend of biomass and fossil fuel
no
no
(**) Tank volume = 20 x Prwith Prindicated in kW

8
ENGLISH
TECHNICAL DATA
Characteristics when operating with the preferred fuel only:
Seasonal space heating energy efficiency ηs [%]: 84
Energy efficiency index EEI: 124
Item
Symbol
Value
Unit
Item
Symbol
Value
Unit
Useful heat output
Useful efficiency (GCV as received)
At rated heat output
Pn
20,1
kW
At rated heat output
ηn
87.5
%
At [30 %/50 %] of
rated heat output, if
applicable
Pp
6,0
kW
At [30 %/50 %] of
rated heat output, if
applicable
ηp
88.2
%
For solid fuel cogeneration boilers: Electrical
efficiency
Auxiliary electricity consumption
At rated heat output
elmax
0,073
kW
At rated heat output
ηel,n
N.A.
%
At [30 %/50 %] of
rated heat output, if
applicable
elmin
0,020
kW
Of incorporated secondary
emission abatement
equipment, if applicable
N.A.
kW
In standby mode
PSB
0,004
kW
Contact details
Name and address of the manufacturer or its authorized representative.
Tel. [phone]
www.edilkamin.it
[e-mail]
Manufacturer: EDILKAMIN SPA
Via Mascagni 7
20020 Lainate (MI) –ITALY

9
ENGLISH
TECHNICAL DATA
Pag. 1 of 2

ECODESIGN REQUIREMENTS FOR SOLID FUEL BOILERS
ACCORDING TO COMMISSION REGULATION (EU) 2015/1189
AND ECOLABEL REQUIREMENTS FOR SOLID FUEL BOILERS
ACCORDING TO COMMISSION REGULATION (EU) 2015/1187
The present document cancels and supersedes document issued November 29, 2018.
EDILKAMIN –GORA 26
Stoking mode: Automatic: it is recommended that the boiler be operated with a hot water storage tank of a
volume of at least 480 litres (**)
Condensing boiler: no
Solid fuel cogeneration boiler: no
Combination boiler: no
Fuel
Preferred
fuel (only
one):
Other
suitable
fuel(s):
ηs
[%]:
Seasonal space heating
emissions
PM
OGC
CO
NOx
mg/m3at 10%O2
Log wood, moisture content ≤25 %
no
no
Chipped wood, moisture content 15-35 %
no
no
Chipped wood, moisture content > 35 %
no
no
Compressed wood in the form of pellets
or briquettes
yes
no
84
16
4
288
121
Sawdust, moisture content ≤50 %
no
no
Other woody biomass
no
no
Non-woody biomass
no
no
Bituminous coal
no
no
Brown coal (including briquettes)
no
no
Coke
no
no
Anthracite
no
no
Blended fossil fuel briquettes
no
no
Other fossil fuel
no
no
Blended biomass (30-70 %)/fossil fuel
briquettes
no
no
Other blend of biomass and fossil fuel
no
no
(**) Tank volume = 20 x Prwith Prindicated in kW

10
ENGLISH
TECHNICAL DATA
Characteristics when operating with the preferred fuel only:
Seasonal space heating energy efficiency ηs [%]: 84
Energy efficiency index EEI: 124
Item
Symbol
Value
Unit
Item
Symbol
Value
Unit
Useful heat output
Useful efficiency (GCV as received)
At rated heat output
Pn
24,0
kW
At rated heat output
ηn
86,9
%
At [30 %/50 %] of
rated heat output, if
applicable
Pp
6,0
kW
At [30 %/50 %] of
rated heat output, if
applicable
ηp
88.2
%
For solid fuel cogeneration boilers: Electrical
efficiency
Auxiliary electricity consumption
At rated heat output
elmax
0,090
kW
At rated heat output
ηel,n
N.A.
%
At [30 %/50 %] of
rated heat output, if
applicable
elmin
0,020
kW
Of incorporated secondary
emission abatement
equipment, if applicable
N.A.
kW
In standby mode
PSB
0,004
kW
Contact details
Name and address of the manufacturer or its authorized representative.
Tel. [phone]
www.edilkamin.it
[e-mail]
Manufacturer: EDILKAMIN SPA
Via Mascagni 7
20020 Lainate (MI) –ITALY

11
ENGLISH
TECHNICAL DATA
Pag. 1 of 2

ECODESIGN REQUIREMENTS FOR SOLID FUEL BOILERS
ACCORDING TO COMMISSION REGULATION (EU) 2015/1189
AND ECOLABEL REQUIREMENTS FOR SOLID FUEL BOILERS
ACCORDING TO COMMISSION REGULATION (EU) 2015/1187
The present document cancels and supersedes document issued November 29, 2018.
EDILKAMIN –GORA 29
Stoking mode: Automatic: it is recommended that the boiler be operated with a hot water storage tank of a
volume of at least 540 litres (**)
Condensing boiler: no
Solid fuel cogeneration boiler: no
Combination boiler: no
Fuel
Preferred
fuel (only
one):
Other
suitable
fuel(s):
ηs
[%]:
Seasonal space heating
emissions
PM
OGC
CO
NOx
mg/m3at 10%O2
Log wood, moisture content ≤25 %
no
no
Chipped wood, moisture content 15-35 %
no
no
Chipped wood, moisture content > 35 %
no
no
Compressed wood in the form of pellets
or briquettes
yes
no
84
16
4
293
120
Sawdust, moisture content ≤50 %
no
no
Other woody biomass
no
no
Non-woody biomass
no
no
Bituminous coal
no
no
Brown coal (including briquettes)
no
no
Coke
no
no
Anthracite
no
no
Blended fossil fuel briquettes
no
no
Other fossil fuel
no
no
Blended biomass (30-70 %)/fossil fuel
briquettes
no
no
Other blend of biomass and fossil fuel
no
no
(**) Tank volume = 20 x Prwith Prindicated in kW

12
ENGLISH
TECHNICAL DATA
Characteristics when operating with the preferred fuel only:
Seasonal space heating energy efficiency ηs [%]: 84
Energy efficiency index EEI: 124
Item
Symbol
Value
Unit
Item
Symbol
Value
Unit
Useful heat output
Useful efficiency (GCV as received)
At rated heat output
Pn
27.0
kW
At rated heat output
ηn
86,5
%
At [30 %/50 %] of
rated heat output, if
applicable
Pp
6,0
kW
At [30 %/50 %] of
rated heat output, if
applicable
ηp
88.2
%
For solid fuel cogeneration boilers: Electrical
efficiency
Auxiliary electricity consumption
At rated heat output
elmax
0,090
kW
At rated heat output
ηel,n
N.A.
%
At [30 %/50 %] of
rated heat output, if
applicable
elmin
0,020
kW
Of incorporated secondary
emission abatement
equipment, if applicable
N.A.
kW
In standby mode
PSB
0,004
kW
Contact details
Name and address of the manufacturer or its authorized representative.
Tel. [phone]
www.edilkamin.it
[e-mail]
Manufacturer: EDILKAMIN SPA
Via Mascagni 7
20020 Lainate (MI) –ITALY

13
ENGLISH
WATER CIRCUIT INSTALLATION
PLUMBING
The products are equipped with closed expansion
tanks.
If the expansion tank is built into the product, this
does NOT ensure proper protection against thermal
expansion caused by water in the entire system.
Therefore, installers should assess whether an
additional expansion tank is needed, depending on the
type of system.
ALL OTHER HYDRAULIC COMPONENTS MAY BE
INSTALLED WITHIN THE Boiler stove BY PURCHASING
A KIT OR IF PREPARED BY THE INSTALLER.
• Plumbing depends on the type of system.
• However, there are some “general rules”:
• The hydraulic system must operate at a pressure
between 1 and 1.5-2 bars at running temperature
(hot) in a closed vessel circuit.
• N.B.: The boiler stove SHOULD NOT be installed
in place of, for example, an open vessel installed
kitchen range without adjusting the expansion
system to closed vessel.
• The presence of an accumulator (tank) is
recommended but not mandatory. Its advantage
is that it releases the boiler stove from “sudden”
requests from the system and can be integrated
with other heat sources. It reduces fuel consumption
and increases the efficiency of the system. A puffer
of at least 20 l/kW is recommended.
• The return temperature of water to the boiler stove
must be higher than 50-55° C to prevent the forming
of condensation.
• An accumulator (tank) is needed to heat
lowtemperature radiant panels and must be installed
according to the panel manufacturer’s instructions.
• The material used in the circuit must be suitable to
withstand overheating.
• The installer must determine whether or not to use
conditioned products. In Italy, refer to UNI 8065-1989
(Water treatment in heating systems for civil use).
• Direct plumbing to the radiators prevents proper
operation, owing to the small diameter of their pipes.
We offer four internal kits (optional)
KIT R-FX
for installation without instant DHW production.
KIT R2-FX
For installation without instant DHW production with
system separator.
KIT RW-FX
for installation with instant DHW production Suggested
for 22 kW models only.
PRESS URE GAUGE
The boiler stoves have an electronic water pressure
gauge. There are no analogue pressure gauges.
The water pressure is shown on the display, (*) as
shown
in the diagram. An analogue pressure gauges can be
fitted as an optional extra.
VENT
During normal operation the stove is
vented automatically. The need for manual
venting can only be assessed at initial
start-up by the technician
make sure that the swivel (nut)
on the two boiler stove outlet
pipes is closed
The product looks like the image below without any
kits.
(*)
Real size templates are available for technicians.

14
ENGLISH
WATER CIRCUIT INSTALLATION
PIPE KIT Measurements in mm
left side left side
floor
48(672%25'2,'(17,),&$,/3$9,0(172
7+,6('*(,'(17,),(67+()/225
5,725125,6&$/'$0(172

+($7,1*5(7851
0$1'$7$5,6&$/'$0(172

+($7,1*'(/,9(5<
6&$5,&26,&85(==$

6(&85,7<',6&+$5*(
5

144 mm
73 mm
R2-FX
48(672%25'2,'(17,),&$,/3$9,0(172
7+,6('*(,'(17,),(67+()/225
+

2)5(''$

&2/'+

2
+

2&$/'$

+27+

2
62/23(5 21/<)25
.,75:
5,725125,6&$/'$0(172

+($7,1*5(7851
0$1'$7$5,6&$/'$0(172

+($7,1*'(/,9(5<
6&$5,&26,&85(==$

6(&85,7<',6&+$5*(
55:

144 mm
floor
73 mm
R-FX - RW-FX
To assemble the kits, move the probe (S) from point Ato point B
A
B

15
ENGLISH
HEATING AND DHW BOILER
Compatible kits are:
• KIT R-FX
The heat demand may arise from:
the environmental probe input (if the detected temperature falls 1 °C below the set temperature);
the demand for DHW from the thermostat/boiler probe.
With a DHW demand, the boiler stove pump is switched on if the temperature in the boiler stove is 5 °C higher than
the boiler temperature and the three-way valve diverts to DHW. The distribution pump is off.
OPTIONAL HYDRAULIC KITS All kits are supplied with instructions for their connection to the boiler stove.
The technicians have a dedicated paper template for each product. Make sure to use the correct template for the
model being installed.
Position the template flush with the floor and aligned with the left hand side of the outer edge boiler stove.
Remember to always observe the minimum installation distances, both from flammable materials and for maintenance.
WATER CIRCUIT INSTALLATION
HEATING AND INSTANT DHW
Compatible kits are:
• KIT R-FX
• KIT RW-FX
• KIT R2-FX
The heat demand may arise from:
the environmental probe input (if the detected temperature falls 1 °C below the set temperature);
the flow switch, when the DHW tap is opened.
The heat demand is shown on the display by a radiator or a tap symbol.
COMBINATION WITH ACCUMULATOR TANK
The Kits combinable with the accumulator are:
• KIT R-FX
The accumulation probe must be set as accumulator tank probe
The demand for heating can be made:
by the thermostat/probe of the accumulator tank.
The pump of the boiler stove ensures the heat transfer from the boiler stove to the accumulator tank.
The (secondary) booster pump provides heat transfer from the accumulator tank to the system.
The timer programming on the display applies to the (secondary) booster pump.
These pages only include indications of possible installations and uses which must be
defined together with the installer and the Technical Assistance Centre during first ignition.
HYDRAULIC INSTALLATION EXAMPLES
N.B.: These diagrams are indicative, correct installation is the responsibility of the plumber
and the associated parameters should be set by the Technical Assistance Centre during
first ignition.
HEATING ONLY
Compatible kits are:
• KIT R-FX
• KIT R2-FX
The heat demand may arise from:
the environmental probe input (if the detected temperature falls 1 °C below the set temperature);
The heat demand is shown on the display by a radiator symbol.

16
ENGLISH
INSTALLATION
fig. 4
A
F
D
fig. 6
B
C
Fig. 2
M
N
Fig. 1
Fig. 3
fig. 5
D
fig. 7
E
E
ADAPTATION FOR PNEUMATIC PELLET
LOADING SYSTEM (optional)
The boiler is designed for pellet loading by means of a
pneumatic feeding system.
The user must activate loading manually.
To install the system, proceed as follows:
N.B.:
before starting, turn the boiler off and discon-
nect the electricity supply wire.
Fig. 4:
Remove the steel cover (A) by dismantling the two hinges
(B) and the compass type rod (C).
Fig. 5-6:
Position the plate (D), contained in the system packaging
and fix it with three screws (E) provided.
Fig. 7:
The external unit for drawing pellets must be fixed to the
plate (D) (see system technical diagram).
ADAPTATION FOR PELLET LOADING SCREW
SYSTEM (optional)
The boiler is designed for pellet loading by means of a
screw feeding system.
ATTENTION: the boiler must be positioned
at least 30 cm from the wall behind it
To install the system, proceed as follows:
N.B.:
before starting, turn the boiler off and di-
sconnect the electricity supply wire.
Fig 1 - 2
• Remove the cover screwed onto the back of the boiler
(fig. 1), and replace it with the flexible pipe connection
flange contained in the system packaging (M -fig. 2).
• The flexible pellet feeding pipe must be connected to
the flange (N) (see system technical diagram).
Fig 3
• Insert the level sensor in the special seat on the rear
of the boiler, removing the cap fixed with two screws.

17
ENGLISH
INSTALLATION
500 500
400
1000
mm
REMARKS ON INSTALLATION
REMARKS ON INSTALLATION
Note that:
Note that:
•
•
installation must be carried out by authorised
installation must be carried out by authorised
technical personnel.
technical personnel.
•
•
all local and national laws and European standards
all local and national laws and European standards
must be met in the installation and use of the
must be met in the installation and use of the
product. In Italy, the standard of reference is UNI
product. In Italy, the standard of reference is UNI
10683
10683
•
•
If installed in a condominium, the appliance must
If installed in a condominium, the appliance must
be approved by the administrator.
be approved by the administrator.
We give some general instructions below, however
We give some general instructions below, however
these do not obviate the need to comply with local
these do not obviate the need to comply with local
regulations and do not affect the installer’s liability for
regulations and do not affect the installer’s liability for
the installation.
the installation.
Checking the suitability of the installation
space
• The floor must be able to bear the weight of the
product and its accessories.
• Level the appliance
• The product may not be installed in bedrooms,
bathrooms or in a room with any other product
which draws air for combustion in the room itself,
or in any area with an explosive atmosphere. Any
extraction fans operating in the same room or area
in which the product has been installed, may affect
its draught.
In Italy, check the compatibility pursuant to UNI 10683
and UNI 7129 in the presence of gas fired products.
Protection from heat and safety clearances
safety
The surfaces of the building adjacent to the product
must be protected against overheating.
The insulation to be used will depend on the type of
surface in question.
When positioning the product, remember to leave
adequate space for the performance of maintenance
and the loading of pellets
We remind you to observe the distances (in mm)
shown in the diagram, also to facilitate maintenance
and loading of the pellets into the tank.

18
ENGLISH
INSTALLATION
THE FLUE
THE FLUE:
Further to the general prescriptions for the fumes duct
and flue, the flue
:
:
• must serve solely to exhaust fumes
• must be correctly sized to satisfy the requirements
of fumes exhaust (EN 13384-1)
• should preferably be insulated, in steel with a
circular internal section. If rectangular, the corners
must have a radius of not less than 20 mm, with a
ratio of the internal dimensions of <1.5
• must normally be at least 1.5 metres in vertical
length
• must have a constant cross section
• must be waterproof and thermally insulated to
ensure a good draw
• preferably provide a collection chamber for
unburnt fuel and condensates.
• If pre-existing, must be clean, to prevent the fire
hazard.
• in general, we recommend fitting a tube inside the
existing masonry chimney if its diameter is greater
than 150 mm.
INTUBATED SYSTEM
INTUBATED SYSTEM:
Further to the general prescriptions for the fumes duct
and flue, the intubated system:
• must operate in negative pressure;
• must be open to inspection
• must observe local regulations.
THE CHIMNEY POT
THE CHIMNEY POT
• must be windproof
• must have an internal cross section equivalent to
that of the flue and a fumes outlet at least double
that of the interior of the flue
• for dual flues (which should be spaced at least 2
m apart) the chimney pot receiving the fumes from
the solid fuel appliance or that from the higher
storey, must be at least 50 cm higher than the other
• it must extend beyond the back flow zone (in Italy,
refer to UNI 10683 point 6.5.8.)
• it must allow for maintenance of the chimney
EXTERNAL AIR INTAKE
In general, we suggest two ways to ensure a proper
flow of combustion air.
Indirect air intake
Install an air outlet at floor level with an effective surface
area (net of the screen or other protections) of at least
80 cm2(10 cm in diameter).
To prevent draughts, we recommend installing the
intake behind the stove or behind a radiator.
Installing it in front of the appliance will create
unpleasant draughts.
Direct air intake
Install an air intake of effective area ((net of the mesh
or other protective equipment) at least equal to that of
the air intake at the back of the product.
Connect the air intake to the appliance’s air intake with
a tube (which may also be flexible).
A maximum length of 3 metres is recommended, with
no more than 3 bends depending on the draft of the
flue.
The air maybe drawn from an adjacent room only if:
• the flow is taken from permanent and unobstructed
openings communicating with the outdoors;
• the air pressure in the adjacent room is never
lower than that of the outdoor pressure;
• the adjacent room is not a garage. subject to fire
hazard, a bathroom or bedroom
• the adjacent room is not a shared room in the
condominium
In Italy, UNI 10683 requires that ventilation is sufficient
even if it is guaranteed that the difference in pressure
between the outdoor and indoor environment is equal
to or less than 4 PA (UNI EN 13384-1). The installer
who issues the declaration of conformity is responsible
for ensuring these conditions are met..

19
ENGLISH
INSTALLATION
THE FUMES DUCT
THE FUMES DUCT
Further to the general requirements for the fumes duct
and flue, the fumes duct
:
:
• may not be made of flexible metal material
• must be insulated, if routed through unheated
areas or outdoors
• must not be routed through rooms where the
installation of combustion heat generators is
prohibited, there is risk of fire, or which cannot be
inspected.
• must enable the recovery of soot and be open for
inspection
• have at most 3 bends with a maximum angle of
90°
• have a single horizontal section with a maximum
length of 3 metres, depending on the draw. In any
event, consider that long sections promote the
accumulation of dirt and are harder to clean.
Positioning the product
The product is designed to operate in all climatic
conditions. In the event of special circumstances, such
as strong wind, the product may be switched OFF
through the intervention of the safety systems.
Contact the authorised Edilkamin Technical Assistance
Centre.
FLUE SYSTEM
FLUE SYSTEM
(
(
Fumes duct, flue and chimney pot
Fumes duct, flue and chimney pot
)
)
This section has been drafted pursuant to European
regulations EN 13384, EN 1443, EN 1856 and EN
1457. The installer must observe both these and any
other local regulations. This manual should not in
any way be considered as a replacement for existing
regulations.
The product must be connected to a flue system which
ensures that the fumes produced by combustion are
exhausted in complete safety.
Before positioning the product, the installer must
check that the flue is suitable.
FUMES DUCT, FLUE
FUMES DUCT, FLUE
The fumes duct
(which connects the hearth’s fumes
(which connects the hearth’s fumes
outlet with the flue)
outlet with the flue) and the flue itself must, among
other regulatory requirements:
• receive the fumes from a single product (the outlets
of multiple appliances may not be conveyed into
a single flue)
• be routed vertically for the most part
• have no downwards sloping sections
• preferably have a circular internal cross section, or
with a ratio of the sides of less than 1.5
• terminate at roof level with a proper chimney pot:
the flue may not discharge directly on the wall
or into an enclosed space, even if the space in
question is open to the sky
• be made of material rated fire reaction class A1 per
UNI EN 13501 or analogous national regulations.
• be certified, with a chimney plate if metal
• be of uniform cross section or vary in cross section
only immediately after the outlet, not at some mid
point of its length

20
ENGLISH
TERMINAL BOARD
TERMINAL BOARD
There is a bracket with a terminal board and
5 cableways* on the back (remove the protective
cover fixed by two screws).
Examples of possible connection configurations are
given below.
* The cableways are provided in the pack above the
product structure. Based on the connections required
at the terminal board, break the knockout panel in the
terminal board cover for the cable to be wired and
secure it with the cable gland.
The poles are numbered on the product as below.
low voltage terminal board
high voltage terminal board
No.
POLES POSSIBLE CONNECTIONS NOTES
1/2 NTC analogue input e.g. for a second probe for accumulator tank or boiler for domestic hot water or for an external
probe for climatic curve
3/4 NTC probe/accumulator tank thermostat
5/6 NTC probe/room thermostat the room probe is supplied already wired as
standard
7/8
Home Automation Input.
This is an input which receives all home automation
contacts
A telephone dialler, for example
9/10 NTC probe/ Hot water boiler thermostat
for domestic hot water boiler
No.
POLES POSSIBLE CONNECTIONS NOTES
1/2/3 Electrical connection for booster/secondary pump
(Earth, Neutral/Phase)
4/5/6
EXTERNAL SOLENOID VALVE (Common, Normally
Closed, Normally Open)
4 = Common
5 = Normally Closed
6 = Normally Open
During First Ignition, the technician can set up,
into parameters, the connection setting on points
4 and 5, of an external boiler contact or remore
alarm.
