Edimax EW-7611UCB User manual

EW-7611UCB
Quick Installation Guide
04-2018 / v1.0

Content
IProduct Information .............................................................................. 1
I-1 Package Content............................................................................................ 1
I-2 LED Indicator ................................................................................................. 1
I-3 System Requirements ...................................................................................1
I-4 Safety Information ........................................................................................ 2
II Installation............................................................................................ 3
III Windows............................................................................................... 4
III-1 Driver Installation / CD Information ............................................................. 4
III-2 Driver Uninstallation .....................................................................................8
IV Mac OS ................................................................................................11
IV-1 Driver Installation........................................................................................ 11
IV-2 Driver Uninstallation ................................................................................... 16
VDisabling Network Adapters.................................................................17
V-1 Windows 7................................................................................................... 17
V-2 Windows 8................................................................................................... 18
V-3 Windows 10................................................................................................. 19
V-4 Mac.............................................................................................................. 20
VI Using the Adapter ................................................................................21
VI-1 Windows –Wi-Fi ......................................................................................... 21
VI-2 Windows –Bluetooth.................................................................................. 23
VI-3 Mac –Wi-Fi.................................................................................................. 27
VI-4 WPS ............................................................................................................. 28

M
Me eh hr rs sp pr ra ac ch hi ig ge e S Sc ch hn ne el ll la an nl le ei it tu un ng g a au uf f C CD D
Če eš št ti in na a: Českého průvodce rychlou instalací naleznete na přiloženém CD s ovladači
D
De eu ut ts sc ch h: : Die deutsche Schnellanleitung befindet sich auf der Treiber-CD
E
Es sp pa añ ño ol l: Incluido en el CD el G.R.I. en Español.
F
Fr ra an nç ça ai is s: :Veuillez trouver l’français G.I.R ci-joint dans le CD
I
It ta al li ia an no o: : Incluso nel CD il Q.I.G. in Italiano.
U
Un ng ga ar ri is sc ch h: : A magyar telepítési útmutató megtalálható a mellékelt CD-n
N
Ne ed de er rl la an nd ds s: De nederlandse Q.I.G. treft u aan op de bijgesloten CD
P
Po ol ls sk ki i: Skrócona instrukcja instalacji w języku polskim znajduje się na załączonej płycie
CD
P
Po or rt tu ug gu uê ês s: Incluído no CD o G.I.R. em Portugues
Р
Ру ус сс ск ки ий й: : Найдите Q.I.G. на pусскoм языке на приложеном CD
T
Tü ür rk ki is sc ch h: :Ürün ile beraber gelen CD içinde Türkçe Hızlı Kurulum Kılavuzu'nu bulabilirsiniz
У
Ук кр ра аї їн нс сь ьк ка а: : Для швидкого налаштування Вашого пристрою, будь ласка, ознайомтесь
з інструкцією на CD

1
IProduct Information
I-1 Package Content
EW7611UCB
Quick Installation Guide
CD
I-2 LED Indicator
LED Color
LED Status
Description
Blue
On
Bluetooth function ON.
Off
Bluetooth function Off.
Green
Slow Flash
Wireless turned on, waiting to be connected.
Quick Flash
Wireless connection established / wireless activity.
The green LED is only visible if Bluetooth feature is turned off (blue LED
off).
I-3 System Requirements
-Windows 7 - 10, Mac OS X 10.9 –10.12
-USB 2.0 Port
-Hard Disk: 100MB
-CD-ROM Drive
Dual Color LED

2
I-4 Safety Information
In order to ensure the safe operation of the device and its users, please read
and act in accordance with the following safety instructions.
1. The wireless adapter is designed for indoor use only; do not place the
wireless adapter outdoors.
2. Do not place the wireless adapter in or near hot/humid places, such as a
kitchen or bathroom.
3. The wireless adapter contains small parts which are a danger to small
children under 3 years old. Please keep the wireless adapter out of reach
of children.
4. There are no user-serviceable parts inside the wireless adapter. If you
experience problems with the wireless adapter, please contact your dealer
of purchase and ask for help.
5. The wireless adapter is an electrical device and as such, if it becomes wet
for any reason, stop using it immediately. Contact an experienced
electrical technician for further help.

3
II Installation
1. Switch on your computer and insert the USB adapter into an available
USB port of your computer.
Never use force to insert the USB adapter.
2. Insert the included CD-ROM into the CD drive of your computer.
The setup wizard is also available for download from the Edimax website.
3. For Windows users the setup wizard will open. For Mac users the CD’s
“Mac” folder will open.
If the CD does not auto-run or if you downloaded the setup wizard, please
browse the “Autorun” or “Mac” folder of the CD for Windows or Mac
users respectively.
Please follow the instructions in the appropriate chapter for your
operating system.

4
III Windows
The screenshots below were captured under Windows 10 environment.
III-1 Driver Installation / CD Information
If the CD did not auto-run, please execute the
“Autorun.exe” file to start the setup wizard.
1. Click the image of the wireless USB adapter to continue.
Install Wi-Fi Driver
2. Click “Install Wi-Fi Driver” to install the Wi-Fi drivers.

5
3. Click “Next” to continue and follow the instructions on-screen until
installation is complete.
4. You need to install the Bluetooth drivers next, so select restart your
computer later and click “Finish”.

6
Install Bluetooth Driver
5. Click “Install Bluetooth Driver” to install the Bluetooth drivers.
6. Click “Next” to continue and follow the instructions on-screen until
installation is complete.

7
7. You need to restart your computer before using the adapter. Choose
whether to restart now or later and click “Finish” to continue.
8. Click “Exit” to close the setup wizard.
Multi-language QIG
The multi-language QIG is also included on the CD-ROM. To open it click
“Multi-language QIG”.

8
III-2 Driver Uninstallation
To uninstall drivers for your adapter, use the Windows Control Panel built-in
Programs and Features, Uninstall a Program or Add or Remove Programs
feature. An example is shown below:
1. Go to Windows settings by clicking followed by .
2. Click “Apps”for “Apps & Features”. Scroll down to locate and select the
driver you wish to remove (Edimax Wi-Fi AC600 Bluetooth 4.0 USB
Adapter, Edimax Bluetooh 4.0 or similar) and click Uninstall.

9
3. Click “Uninstall”again.
4. Windows will ask if you wish to make this change to the system, click
“Yes”to continue.
5. Windows will ask you to confirm the removal, click “Yes”to continue.

10
The system will uninstall the driver itself.
6. Click “Finish”to complete the procedure.

11
IV Mac OS
IV-1 Driver Installation
Bluetooth connectivity is Windows only.
1. Open the “RTLWLANU_MacOS..” folder and double click the
“Installer.pkg” file to open the driver installation wizard.
2. Click “Continue” to proceed to the next step.
3. The next screen displays important information, please read it carefully.
Click “Continue” when you are ready to continue.

12
4. Select a language (the default language is English) and click “Continue”
to install the driver.
5. To read the software license click “Read License” and then click “Agree”
to confirm you agree to the terms. You must agree to the terms to
continue installing the software.

13
6. If prompted, select which user to install the software for and click
“Continue”.
7. Click “Install” to install the driver.

14
8. You may be prompted to enter your system/administrative password
before the installation can begin. Enter them and click “Install Software”.
9. You will be prompted that you must restart your computer when the
installation is complete. Click “Continue Installation” to proceed.

15
Please wait while the driver is installing.
10. When the installation is complete, you will see the following screen
informing you that “The installation was successful”. Click “Restart” to
restart your computer.

16
IV-2 Driver Uninstallation
1. Open the “RTLWLANU_MacOS..” folder.
2. Double click the “Uninstall.pkg” file and follow the on-screen
instructions.

17
VDisabling Network Adapters
To ensure that your USB wireless adapter can function correctly, it is
recommended that you disable any other existing wireless network and
Bluetooth adapters installed on your computer. If you are unsure how to do
so, you can refer to the user manual for your computer, or follow the
examples below.
V-1 Windows 7
1. Go to Start > Control Panel.
2. Click View network status and tasks.
3. Click Wireless Network Connection (outlined in red below) for a
properties window and click Disable.
