Edimax Wireless USB Adapter 11g & 11n User manual




1EdimaxTechnology(UK)Limited|QuickInstallationGuide(USBWirelessv1.0‐MacOS)
www.edimax.co.uk









EdimaxWirelessUSBAdapter
11g&11n



QuickInstallationGuide
MacOS













2EdimaxTechnology(UK)Limited|QuickInstallationGuide(USBWirelessv1.0‐MacOS)
www.edimax.co.uk


A)InstallthedriverandConnecttoyourWireless
Network

1. InstallthedriverintoyourMacfromtheCD.(PleaseusethelatestMac’sdriverfrom
EdimaxWebsite).YoucandownloaditfromEdimaxwebsite.

2. RestartyourMac.

3. InsertyourwirelessUSBadapterinafreeUSBslot.

4. InthemainApplicationsfolder,youwillseethe"USBWirelessUtility".(Itmayor
maynotopenautomaticallyafterinsertingyourwirelessUSBadapter).Itshowsthe
detailsinformationaboutthewirelessUSBadapter.


5. OpentheWirelessUtility>SiteSurveytabandselectyourwirelessrouterandclick
"ADDPROFILE".(It'llaskyoutoenterdetailsaccordingly.Ifyouhavesecuritylike
WEP/WPAturnedon,putthatinformationinoryouwon'tbeabletoconnect.)




3EdimaxTechnology(UK)Limited|QuickInstallationGuide(USBWirelessv1.0‐MacOS)
www.edimax.co.uk



Select‘Authentication&Security’andenteryourWEP/WPAkey.

PROF1willappearintheProfiletab,selectPROF1andclick“ACTIVATE”.Youwillsee
agreentickshowingit’sconnected.GotoStep6.
NOTE:Aredtickisshowingit’snotconnected.Inthiscase,youmayhaveentered
incorrectWEP/WPAkey.










4EdimaxTechnology(UK)Limited|QuickInstallationGuide(USBWirelessv1.0‐MacOS)
www.edimax.co.uk


6. GotoMenu>SystemPreferences>Network.



Itwillshowanewport,whichisthewirelessUSBadapter.ClickOKandgotoStep10.
IfyourMacdoesn’tautomaticallydetectthe‘EthernetAdaptor(en1)’,pleasefollow
Step7‐9.



7. Fromthe"Show"popupmenu,select"NetworkPortConfigurations".

8. Click"New".

9. Click"Port".You'llseeeg:"EthernetAdaptor(en1)".Giveitaname,andclick"OK".





5EdimaxTechnology(UK)Limited|QuickInstallationGuide(USBWirelessv1.0‐MacOS)
www.edimax.co.uk



10. Theportwillshowupinthelist.(Draggedittothetoptogiveitthehighestpriority
whentryingtoconnect.)



11. From"Show",selectthatEthernetadaptorport.







6EdimaxTechnology(UK)Limited|QuickInstallationGuide(USBWirelessv1.0‐MacOS)
www.edimax.co.uk


12. Underthe"TCP/IP"tab,"ConfigureIPv4",use"UsingDHCP".

13. Click"ApplyNow".Shortly,itshouldrefreshandshowyournumbersfor"IPAddress",
"SubnetMask"and"Router".Ifitdoesn'tupdate,youmayneedtoclick"Renew
DHCPLease".

14. AfterOKandwaitforfewseconds,youshouldseethatyou'reconnected.Youcan
nowaccesstotheInternet.


B) Can’tConnecttoyourWirelessNetwork
IfyouhavedonetheaboveStep1‐14butyouarenotconnectedtotheInternet.Please
dothefollowing:
15. Underthe"TCP/IP"tab,"ConfigureIPv4",use"Manually".



16. EnteryourIPAddress,SubnetMask,RouterandDNSServermanually.
‐TheaboveexampleisbasedonrouterIPAddress192.168.12.253.Your
route’sIPAddresswillbedifferent.PleaseuseyourownIP’srangeandyour
router’sIPAddress.
‐DNSServersisthesameasyourrouter’sIPAddress.
‐Click“ApplyNow”tosavethesetting.

17. Afterwaitforfewseconds,youshouldseethatyou'reconnected.Youcannow
accesstotheInternet.Ifyouarestillunabletoopenwebpage,pleasegotoStep18.
192.168.12.253




7EdimaxTechnology(UK)Limited|QuickInstallationGuide(USBWirelessv1.0‐MacOS)
www.edimax.co.uk


C) Can’tConnecttoyourWirelessNetwork

18. Inthiscase,youneedtousetheDNSServersprovidedbyyourISP.Ifyoudon’thave
theDNSServersaddress,pleasecontactyourISP.

Then,entertheDNSServersintotheTCP/IPsettingasfollows:


19. Afterwaitforfewseconds,youshouldseethatyou'reconnected.Youcannow
accesstotheInternet.
UseyourISP’sDNSServers.
