Edimax EW-7612PIn User manual

1
Multi-Language QIG in Driver CD
================================================
Český: Českého průvodce rychlou instalací naleznete na
přiloženém CD s ovladači
Deutsch: Finden Sie bitte das deutsche QIG beiliegend in der
Treiber CD
Español: Incluido en el CD el QIG en Español
Français: Veuillez trouver l’français QIG ci-joint dans le CD
Italiano: Incluso nel CD il QIG in Italiano
Magyar: A magyar telepítési útmutató megtalálható a mellékelt
CD-n
Nederlands: De nederlandse QIG treft u aan op de bijgesloten
CD
Polski: Skrócona instrukcja instalacji w języku polskim znajduje
sięna załączonej płycie CD
Português: Incluído no CD o QIG em Portugues
Русский: Найдите QIG на pусскoмязыке на приложеном CD
Romana: Cd-ul cuprinde Ghid de instalare rapida in limba
romana
Slovensky: Anglického sprievodcu rýchlou inštaláciou nájdete
na priloženom CD s ovládačmi.
Türkçe: Ürün ile beraber gelen CD içinde Türkçe Hızlı Kurulum
Kılavuzu'nu bulabilirsiniz
简体中文
简体中文简体中文
简体中文: 产品包装 CD 光盘中含有简体中文版快速安装手冊
繁體中文
繁體中文繁體中文
繁體中文: 產品包裝隨附 CD 中含有繁體中文版之快速安裝指南

2
Copyrightby Edimax Technology Co, LTD. all rights reserved. No part of
this publication may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, without the prior written permission of this
company.
This company makes no representations or warranties, either expressed
or implied, with respect to the contents hereof and specifically disclaims
any warranties, merchantability or fitness for any particular purpose. Any
software described in this manual is sold or licensed "as is". Should the
programs prove defective following their purchase, the buyer (and not this
company, its distributor, or its dealer) assumes the entire cost of all
necessary servicing, repair, and any incidental or consequential damages
resulting from any defect in the software. Further, this company reserves
the right to revise this publication and to make changes from time to time
in the contents hereof without obligation to notify any person of such
revision or changes.
The product you have purchased and the setup screen may appear
slightly different from those shown in this QIG. For more detailed
information about this product, please refer to the User's Manual on the
CD-ROM. The software and specifications are subject to change without
notice. Please visit our web site www.edimax.com for the update. All right
reserved including all brand and product names mentioned in this manual
are trademarks and/or registered trademarks of their respective holders.

3
Product Information
Main Features
 Complies with 802.11n, 802.11g and 802.11b standards.
 Supports PCI Express base specification Rev. 1.0a
 Supports WMM, WMM-PS (IEEE 802.11e QoS standard).
 Supports 64/128-bit WEP, WPA (TKIP with IEEE 802.1x),WPA2 (AES
with IEEE 802.1x) for high security level.
 Supports operating system: Windows OS XP/Vista/7, and Linux
1. Package Contents
Before you starting to use this wireless network card, please check if
there's anything missing in the package, and contact your dealer of
purchase to claim for missing items:
EW-7612PIn
□Wireless PCI-e Adapter x1
□3dBi Antenna x 2
□Quick Installation Guide x1
□CD (EZmax Wizard / Utility, Multi-language Quick Installation Guide &
User Manual) x1

4
2. Network Card Installation
Please follow the following instructions to install your new wireless
network card:
2.1 Hardware Installation
1. SWITCH THE COMPUTER OFF, remove the cover and insert the
wireless network card into an empty PCI Express slot of your
computer.
2. Fasten the antennas to the antenna connectors on the network card by
clockwise direction.
3. You can bend the antenna to fit actual needs.
4. Switch the computer on, the following message will appear on your
computer, please click ‘cancel’.

5
2.2 Software Installation
This wizard can be run in Windows XP/Vista/7.
You can install the Wireless Adapter by EZMAX Setup Wizard in the
CD-ROM including in the package. The wizard is an easy and quick
configuration tool for internet connection with series process. When you
start EZMAX Setup Wizard, you will get the following welcome screen.
Please choose the language to start the configuration. The wizard will
guide you to finish your network connection. We will not provide any
instruction for the EZMAX Setup Wizard here.
If you lose the CD ROM or you prefer the traditional setup procedure,
please follow the instruction as following step in this quick
installation guide.

6
2.2.1 Please execute ‘ Utility \ Setup.exe ’ program to install your wireless
adapter.

7
2.2.2 When you see this message, please click ‘Finish’ to complete the
driver installation process.

8
3. Connect to Wireless Access Point
Using Configuration Utility to Connect to Wireless Access Point
3.1 After installation is complete, wireless configuration utility will be
shown as an icon at the lower-right corner of your windows desktop.
Please click the icon by right mouse key, and select ‘Open Config
Utility’
Configuration utility will scan for wireless access points
automatically, and all found access points will be displayed. Please
select an access point you wish to connect, and click ‘Connect’.
If the wireless access point you want to connect does not show here,
please click ‘Rescan’

9
3.2 If the wireless access point uses encryption, you have to input WEP
passphrase or WPA preshared key. Please ask the owner of the
wireless access point you want to connect, and input the correct
passphrase / preshared key here, then click ‘OK’. If the value you
inputted here is wrong, you will not be able to connect to wireless
access point.
Authentication type is selected automatically, please don’t change
it.
