Edimax PS-2207SU User manual

Shares USB Storages or Printers for each USB Port
This product provides two USB 2.0 ports. Users can connect the USB
mass storage or printer to each USB port. When the USB mass storage
is connected, the device can be a NAS (Network Attached Storage)
system allowing user to share files in the storage. When the printer is
connected, the device can be a print server allowing user to share
printer through the network.
Supports 10/100Mbps Wired
The device can support 10/100Mbps wired. Users can share the USB
storages or printers through Fast Ethernet network.
Supports File Sharing
This product let users to share files in the storage through Windows
Neighborhood or Samba in Linux/Unix/MAC. You can set the user
authorization for each folder. In addition, with the built-in FTP server,
user can access the files in the storages via Internet.
Provides Completed Printing Methods
The product provides LPR, IPP and Raw Printing methods. You can
choose the best printing method according to your environment to share
the printers.
Supports Major Operating Systems
The product is compatible with all major operating systems like
Windows 98SE/Me/2000/XP, MAC OS and Unix/Linux environments.
2 USB 2.0 Port
2 USB 2.0 Port
Fast Ethernet Print Server &
Fast Ethernet Print Server &
Storage Server (NAS)
Storage Server (NAS)
IEEE 802.3/802.3u Compatible
IEEE 802.3/802.3u Compatible
Fast Ethernet Print Server with Storage Server (NAS)
Fast Ethernet Print Server with Storage Server (NAS)
Taiwan / Headquarters
Edimax Technology Co., LTD.
TEL:[phone]
FAX:[phone]
[e-mail]
Europe
Edimax Technology Europe B.V.
TEL:[phone]
FAX:[phone]
[e-mail]
U.K.
Edimax Technology (UK) Ltd.
TEL:[phone]
FAX:[phone]
[e-mail]
Poland
Edimax Technology Europe
B.V. SP. Z O.O.
Tel: [phone]
Fax: [phone]
[e-mail]
U.S.A.
Edimax Computer Company
TEL:[phone]
FAX:[phone]
[e-mail]
Latin America
TEL:[phone]
FAX:[phone]
sales_latinameri[email protected]
China
TEL:[phone]
FAX:[phone]
Russia
Edimax Technology Russia
Tel./Fax: [phone]
[e-mail]
PS-2207SU

Main Features
•Complies with IEEE 802.3, IEEE 802.3u Fast Ethernet.
•Shares USB storages or printer to all PCs through network.
•Compatible with all major operating systems (Windows
98SE/Me/2000/XP, MAC OS and Unix/Linux).
•Easy to configure through the setup wizard and web-based
management.
NAS
•Shares USB storages or flash drive to the network users.
•Supports FAT16, FAT 32, Ext2, Ext3 and NTFS (Read Only for
NTFS) file systems.
•Built-in FTP Server.
•Supports file sharing through Windows Neighborhood or Samba in
Linux/Unix/MAC.
•Supports account management and user authorization for file
folders.
•Release USB storage through hardware buttons.
Print Server
•Supports LPR, IPP and Raw Printing printing protocols.
•Compatible with the popular brands of printers. (Please refer to
the compatible list)
Model NO. PS-2207SU
CPU RISC CPU
Flash 4MB NOR Flash
RAM 32MB SDRAM
USB Port USB 2.0 x 2
LAN Port 10/100M UTP Port x 1
(Auto-MDI/MDI-X)
Output Power 16dBm-18dBm
Power 12V DC, 1.25A Power Adaptor
Dimension 30(H) x 128(W) x 90(D) mm
Temperature 0~50°C
Humidity 10~90% (Non-Condensing)
Certification FCC, CE
