Edimax 3G-6218n User manual

150Mbps Wireless 3G Portable Router
with Battery
* Please check the 3G/3.5G USB modem card compatibility list for details.
** Please check the smart phone compatibility list for details.
3G-6218n
Compactness and a Built-in Rechargeable Li-ion Battery for True Mobility
If you often need to share your Internet connection where a power outlet isn’t available, the 3G-6218n 3G router
is the best choice for you. Not only is the 3G-6218n currently the smallest 3G router around, the built-in
rechargeable Li-ion battery allows this miniature 3G router to be used virtually anywhere. Multiple users can
enjoy up to 4 hours of wireless connectivity in a park, on a train, or even in the desert on battery power alone.
Supports Both 3G/3.5G and Cable/xDSL Modems*
Simply connect a 3G/3.5G USB modem card to the built-in USB port and this little broadband router will share
your Internet connection with others at speeds of up to 14.4Mbps. When 3G/3.5G Internet access is not
available, you also have the option of connecting a cable/xDSL modem to this device via the built-in Ethernet
port. The 3G-6218n is capable of switching to your wired Internet connection automatically.
Supports iPhone, HTC, Blackberry, Nokia, Sony Ericsson, and Other Smart Phones**
Besides supporting both 3G/3.5G and Cable/xDSL modems, the 3G-6218n 3G router also supports Internet
tethering via many major smart phones on the market—like iPhone, HTC, Blackberry, Nokia, Sony Ericsson, and
other smart phones.
Designed with the Latest Green Ethernet Technology
With the latest green Ethernet technology, the 3G-6218n is able to adjust its power supply according to Ethernet
activity and the length of the cable used. By using only the amount of power needed, this 3G router allows for
high performance while maintaining minimum power consumption.
Impressive Data Transmission Rates via IEEE 802.11n
The Edimax 3G-6218n complies with IEEE 802.11b/g/n standards. Its wireless data transmission rate can reach up
to 150Mbps and its signal coverage is 3 times greater than standard 802.11g/b routers.

FEATURES AND TECHNICAL SPECIFICATIONS
HARDWARE INTERFACE MANAGEMENT POWER ADAPTER & Battery
One 10/100Mbps Ethernet Port for WAN or LAN Connection
One USB 2.0 for 3G/3.5G USB Modem
One Mini USB Power Adapter
LED Indicators: PWR, CHG, WLAN, ETHERNET, INTERNET
WPS/Reset Button
Switch 1 for LAN/WAN (Ethernet Port)
Switch 2 for Power ON/OFF
Supports Remote Management
Supports 3G Limit Control
Multi-language user interface
System Status and Security Log (Web Interface)
Firmware Upgradeable
Battery 3.7V, 1880mAh
DC 5V, 2A Switching Mini
USB Type Power Adapter
WAN INSTALLATION MEMORY
Supports 3G/3.5G (UMTS/HSDPA/CDMA)
Supports cable/xDSL modem
WAN protocol: PPPoE/Static IP/PPTP/Dynamic IP /L2TP
16-language EZmax Setup Wizard to setup
Internet connection, SSID, wireless security
and firmware upgrade
8 MB NOR Flash
32 MB SDRAM
SECURITY ANTENNA & OUTPUT POWER HUMIDITY & TEMPERATURE
NAT/NAPT IP Sharing
64/128-bit WEP Encryption and WPA-PSK, WPA2-PSK security
DHCP Server
MAC/IP Filter and URL Blocking
Anti-Dos Firewall
Internal Printed Antenna
11n:13±1.5dBm
11g: 14±1.5dBm
11b: 17±1.5dBm
10-90%
(Non-condensing)
0oC ~40oC
FUNCTIONS DIMENSIONS CERTIFICATIONS
Supports 3G and xDSL connection Fail Over
Port Triggering for Special Applications
Supports iPhone Internet tethering
Supports Green WLAN
DDNS, WMM and QoS
Virtual Server and DMZ
Supports UPnP
VPN Pass Through (IPSec/PPTP)
102 (W) x 69 (D) x 16 (H) mm CE, FCC
NETWORK SETUP DIAGRAM AND RELATED PRODUCTS
An example of how the 3G-6218n can be setup:
• Connect the 3G/3.5G USB modem card to 3G-6218n router USB port.
• Connect a computer to the Ethernet port and setup the Internet connection by running the multi-language setup wizard.
• Share the Internet connection by connecting wired or wireless computers.
** You can switch Ethernet port as a WAN port, and connect 3G-6218n router Ethernet port to your cable/xDSL modem as a backup.
* Product features and specifications are subject to change without notice.
