EDISON Professional FIREFLY T3500 User manual

EDISON PROFESSIONAL
TRANSLUCENT Bluetooth Party Speaker
FIREFLY T3500
User Manual
Please read this manual carefully before operating the FIREFLY speaker. Please keep this
manual for future reference.

Introduction
Congratulations on your purchase!
We encourage you to take a few minutes to read this manual, which describes the
FIREFLY Speaker and includes step-by–step instructions to help you to enjoy the
product. Read all the safety instructions before using the product.
If you have any questions about this product, please contact customer service or your
retailer.
Important Safety Instructions
1. Read all warnings.
2. Follow all instructions.
3. The FIREFLY Speaker should not be exposed to water, rain, or any liquids.
4. Do not block any ventilation openings. Please keep at least a foot of distance
between the FIREFLY Speaker and any other objects.
5. Do not place the FIREFLY Speaker near any heat sources such as radiators, stoves, or
other appliances (including amplifiers) that produce heat.
6.Do not place candles or any objects with a flame on the FIREFLY Speaker.
7. Protect the power cord from being walked on or pinched, especially at the wall
outlet and where the cord attaches to the back of the FIREFLY speaker.
8. Use only attachments and accessories specified by the manufacturer.
9. Unplug the FIREFLY Speaker during lightning storms or when not in use.

PRODUCT OVERVIEW
Front View Rear Control Panel
1. Control Panel
a. SD CARD: Insert memory card to playback your stored music.
b. USB: Insert a USB storage device to play back your stored music.
c. MODE: Press to select LINE (Aux-in)/ BLUETOOTH /FM.
d. Repeat / EQ: Short press to repeat the track. Long Press to select EQ
modes. (EQ: modes：Normal/Classical/Jazz/POP/Rock).
e. /VOL-: Short press for previous song, long press for volume down.
f. /VOL+: Short press to skip to next song, long press to increase volume.
g. /TWS: In USB/SD/BT mode short press to Play & Pause the music. In
FM mode, press to auto search and store radio stations. Long press for
TWS pairing.
2. TREBLE: Rotate knob to adjust treble settings to your desired levels.
3. VOLUME: In USB/SD/FM/BT mode; rotate the knob to adjust volume to your
desired level.
4. AUX input: Connect to external device through 3.5mm AUX-IN cable.
5. BASS: Rotate the knob to adjust BASS to your desired level.
6. LINE OUT: Using balanced XLR cable (not supplied) connect the speaker to an
amplifier or other speaker.
7. MASTER: Controls the volume of the speaker.
8. LINE IN VOL: Rotate the knob to adjust volume to your desired level.
9. MIC IN VOL: Rotate the knob to adjust the MIC volume to your desired level.
10. RCA Line input: Connect the speaker to your analogue audio device using RCA
cable (not supplied).
11. MIC IN ¼” Jack Insert a microphone to sing along while listening to music.

12. Line IN: Using balanced XLR cable (not supplied) connect the speaker to an
audio source.
13. MIC IN: Plug your microphone into the appropriate XLR cable input to sing
along with the music.
14. AC Power: Connect the detachable power cord to speaker and plug in to the
main wall outlet.
15. POWER: Press to switch on /off the speaker.
16. LED Switch: Press to switch on /off the lights.
Remote control
1. POWER: When the Power switch on the unit is ON, press the Power button on
remote control and unit will go in STANDBY mode. Press power button again and
it will resume to normal mode.
2. STOP: In SD Card and USB mode press to stop the media being played.
3. MUTE: Press to mute music in any mode, press again to resume sound.
4. MODE: Press repeatedly to select the following modes LINE IN (AUX IN)/USB/TF
CARD / FM Radio/Wireless BT.
5. REPEAT: Press to repeat one song or repeat all songs.
In Wireless BT mode, this button has no function.
6. EQ: Press to switch between the different EQ modes. This works only in USB/SD
card mode. (EQ modes: Normal/Classical/Jazz/POP/Rock).
7. : In USB/ SD card and AUX mode press once to go back to the previous song;
press and hold for 3 seconds to rewind the current song.

In Bluetooth “BT” mode, press once to go back to the previous song.
In FM mode, press once to go back to the previous channel.
8. : In USB/SD card and AUX mode press once to go to the next song, press and
hold for 3 seconds to fast forward the current song.
In BT mode, press once to go next song.
In FM mode, press once to go to next channel.
9. In all modes, press to pause the music. Press again to resume play.
10. VOL -: Press to reduce the speaker master volume to your desired level.
11. VOL+: Press to increase the speaker master volume to your desired level.
12. Numeric Keys: In USB /SD mode, press the track number and your desired track will start
playing. 1-9 just press the number, 10 is 1+0,11 is 1+1,21 is 2+1
Basic Operation
TURNING THE UNIT ON/OFF
Press the power ON/OFF button on the back of the speaker to switch on/off the speaker.
If the power button is off, power button on the remote control will not be functional.
FRONT PANEL LIGHT
To turn on the Light short press RED switch on the rear panel. There are 5 lighting
modes to choose from.
Mode 1: Multi-color automatically when power on
Mode 2: Color conversion
Mode 3: Color run
Mode 4: Color flash
Mode 5: Turn off LED light.
TWS Mode

You can pair two FIREFLY speakers (sold separately) to enjoy your music in true stereo.
Press and hold the “TWS” button on the rear panel. The FIREFLY Speakers will pair
automatically.
Turn on the Bluetooth from your smartphone and search for the T3500. Select the
music you would like to hear. The FIREFLY Speaker will start playing music from your
Bluetooth device.
Notes:
1. TWS doesn't work in radio mode.
2.Press and hold the TWS button to disconnect TWS connection.
RF exposure statement
This equipment complies with the FCC radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.

SPECIFICATION
General
Power Requirement AC120V/60Hz
Power Consumption 7.5 W
Weight 21.5 Kgs
Dimension 47*44.2*100 cm
Operation temperature +5degree C -+ 35 degree C
Audio Section
Speaker size: 15" steel frame woofer 4 Ohm
Driver: 2X1” Titanium diaphragm 8 Ohm
Power 2000 Watts PMPO
Accessories
Remote Control x 1
AC Power cord
Instruction manual
Note: Specifications are subject to change for continuous improvement without prior notice.
