Edsyn FUMINATOR FXF15 User manual

Instructions
for
FXF15
FUMINATORTM
Fume Extractor Fan
Form.996
Rev D
Color
FXF15 (Black)
FXF15W (White)
FXF15B (Blue)
Power Supply
Standard (U.S.A.)
-1 (No Transformer)
-100 (Japan)
-230 (Europe)
-230B (U.K.)
Create a healthy environment
(Design, colors and materials subject to change without notice)

XF01 Filter Set with 1 - XF02
and 1 - XF03
XF02 Primary Rotating Filter
(set of 5)
XF03 Charcoal Impregnated
Stationary Filter
(set of 5)
XF01
Filter Set
XF02
Primary Rotating Filter
XF03
Charcoal Impregrated
Stationary Filter
XF02
Primary Rotating Filter
The XF02 lter element rotates at the same
speed as the fan blades. Fumes and nail resi-
dues are evenly distributed.
(set of 5)
XF03
Charcoal Impregnated Stationary Filter
(set of 5)
power supply
SR571 for 100V (Japan)
SR538 for 115V (U.S.A.)
SR572 for 230V (Europe)
SR821 for 230B (U.K.)
FXF15
exploded view
SR638
SR642*
SR868*
SR867
SR866
SR639
(washer placed between fan and post)
SR640*
SR480
FXF10-1
PowerSupply
*Black is the standard color. For color selections,specify W, B, G, or R after the
part nmber. Example FXF10-1R for red fan assembly.

1. XF03 Charcoal Impregnated
Stationary Filter
2. SR489 Cage
3. SR474 Fan Motor
4. XF02 Primary Rotating Filter
5. SR475 Circuit Board Assembly
Items 2, 3 & 5 are Serviced at the
Factory
For Drying Nails
While fan assembly is turned to face the
opposite direction, remove both lters
for drying clients nails.
The XF02 and XF03 lter elements can be
used separately. For maximum ltration, install
both lters.
Front View
(air input)
Rear View
(air output)
Green LED
(indicates air ow
towards fan)
Yellow LED
(indicates air ow
away from fan)
Universal 12VDC Input
Jack Type: J4 Female 2.1
mm x 5.5 mm. Rec-
ommended 12VDC, 500mA
Power Supply
Filter Replacement
1. Pull out dirty lter
from hub when fan
is off.
2. Replace with new
XF02 Primary
Rotating Filter
Variable Positioning
when extracting nail residue
from the air
Louvres
1
2
3
4
5
2
FXF10-1
exploded view

features
•
•
Powerful 12V fan motor removes unwanted fumes, powder
residues and odors from the air
• Can be used to either lter or blow dry clients nails
• Ultra-quiet operation
• R o t a t i n g f r o n t fi l te r p r o v i d e s f i l t ra t i o n e i g h t t i m e s
better than a stationary lter
• Bright front (green) and rear (yellow) LED’s to indicate power
and air ow direction
• Adjustable to almost any working angle
• Quick lter replacement
• Internal safety grills
breathe clean
Phone (sales): 800.910.1101 • Phone (service): 818.989.2324
Email: inf[email protected] • Internet: www.edsyn.com
©Copyright 2002 by EDSYN®, Inc.
patented made in U.S.A.
specications
Power
Requirements 12 V DC
Overall
Dimension 4”W x 9”H x 4”D
Weight 1.09 lbs (.49 kg)
Design, color and material subject to change
without notice
102 mm x 229 mm x 102 mm
