EemaX PA018208T2T User manual

ELECTRIC INSTANTANEOUS WATER HEATER
INSTALLATION GUIDEAND OWNERS MANUAL
EEMAX
PROADVANTAGE
MODELS COVERED
Triple Module Models PA018208T2T,
PA024208T2T, PA018277T2T, PA024277T2T,
PA032277T2T Single Phase Model PA028240T2T
WARNING
BEFORE ATTEMPTING INSTALLATION OF THIS UNIT OR MAKING ANY ADJUSTMENTS
TO THE UNITALWAYS BE SURE MAIN CIRCUIT BREAKER IS OFF TO PREVENT DANGER
OF SERIOUS ELECTRIC SHOCK.
MODEL :
SERIAL NO :
INSTALLATION DATE :
ELEMENT RESISTANCE: OHMS
SWITCH ON FLOW RATE: GPM
OPERATING TEMPERATURE
MIN MAX
INSTALLER/ CONSUMER RESPONSIBILITIES
PLEASE TAKE THE TIME TO READ NOT ONLY THIS MANUAL BUT ALSO THE
WARRANTY CARD ENCLOSED. WARRANTY OF THIS HEATER WILL DEPEND ON PROPER
INSTALLATIONAND OPERATION. THE WARRANTYSHALL BE VOID IF THE DESIGN OR
STRUCTURE OF THE WATER HEATER HAS BEEN ALTERED IN ANY WAY WHATSOEVER. THE
MANUFACTURER OF THIS WATER HEATER WILL NOT BE LIABLE FOR ANY DAMAGES
BECAUSE OF FAILURE TO COMPLY WITH THE INSTALLATIONAND OPERATING
INSTRUCTIONS OUTLINED ON THE FOLLOWING PAGES.
IF YOU REQUIRE ANY HELP OR HAVE ANY QUESTIONS RELATING TO THE
INSTALLATION OR PERFORMANCE OF THIS HEATER, PLEASE CALL OUR TECHNICAL
SERVICE DEPARTMENT TOLL-FREE:
1-800-543-6163
HAVE THE INFORMATION LISTED BELOW BEFORE CALLING

GENERAL SAFETY
The “Eemax ProAdvantage” heater is specifically designed to take in hot or cold water and
heat it to temperatures suitable for normal domestic usage up to a maximum of 140 F(60 C).
To obtain optimum performance and energy savings, the unit should be located as
near as possible to the point of use. “Thermostatic” models indicated by the letters T2T after
the model number, these models and only these, can be fed with pre-heated water and be
used to boost temperature
Also, ensure that the pipes are clear of installation debris before fitting the heater.
THIS HEATER MUST HAVE DEDICATED INDEPENDENT 208V 3 PHASE,
240V 3 PHASE , 480/277V 3 PHASE CIRCUITS, USING CORRECTLY
RATED WIRES AND CIRCUIT BREAKERS. PER UL 499, 18.4 THE RATING
OF THE BRANCH-CIRCUIT OVERCURRENT PROTECTIVE DEVICE
SHALL BE 150% OF THE RATING OF THE PRODUCT.
DO NOT USE SPACE SAVING BREAKERS.
WARNING
IMPROPER INSTALLATION,ADJUSTMENT,ALTERATION, SERVICE OR MAINTENANCE
CAN CAUSE DEATH, SERIOUS BODILY INJURY OR PROPERTY DAMAGE. REFER TO
THIS MANUAL FOR ASSISTANCE OR CONSULT THE LOCAL ELECTRIC UTILITY FOR
FURTHER INFORMATION.
FAILURE TO GROUND THE SYSTEM MAY RESULT IN DEATH OR SERIOUS INJURY.
WARNING
WARNING
HAZARD OF ELECTRICAL SHOCK! BEFORE REMOVING THE COVER OR SERVICING THE
WATER HEATER, MAKE SURE THE ELECTRICAL SUPPLY TO THE WATER HEATER IS
TURNED “OFF”. FAILURE TO DO THIS COULD RESULT IN DEATH, SERIOUS BODILY INJURY,
OR PROPERTY DAMAGE. NOTE: UNIT HAS MULTIPLE ELECTRICAL CONNECTIONS.
ENSURE TO DISCONNECT ALL POWER SUPPLIES BEFORE SERVICING
When removing and re-installing the cover make sure to use the ground screw provided. There are a total of 5
screws that affix the cover to the unit. If you are missing any call technical support at 1-800-543-6163.

I. MOUNTING THE UNIT
1) The unit should be mounted as close to the point of use as possible.
Do not install the heater above a faucet or “point of use” because the siphoning effect may
drain the heater which can cause premature element burn out. If the unit must be installed at
a higher elevation, you must install spring loaded check valves on both the inlet and outlet of
the water heater.
2) This unit must only be mounted in a vertical position with the water fittings positioned at
the bottom of the unit. Mounting other than in the vertical position will cause element burn
out and permanent damage to the water heater.
3) The cold water inlet is on the right hand side and the hot water outlet is on the left hand side
as marked by the fittings of the unit. Under NO circumstances can these be reversed.
4) Leave a minimum of 8” above the unit for easy replacement of the element.
5) The heater should be fixed to the wall using all four mounting holes of the backplate.
Use an appropriate fastener for the weight. For the unit to be mounted against hollow walls,
we suggest using steel wall anchors with the correct grip range, and #10-32 screws at a
minimum.
NOTE: The heater should be installed below the level of all hot water outlets serviced by this
heater. Otherwise install spring loaded check valves on both the inlet and outlet.
NOTE: PRESSURE AND TEMPERATURE RELIEF VALVE
These units are not required by UL to have a Pressure and Temperature Relief
Valve (PTRV). You should check with local codes to find out if one is required in your
area. If local codes require the use of a temperature and pressure relief valve it
should be installed on the outlet hot water pipe before the outlet ball valve.
Requirements:
Max Output: 18.0 kW @ 208 volts
24.0 kW @ 208 volts
18.0 kW @ 277 volts
24.0 kW @ 277 volts
32.0 kW @ 277 volts
28.0 kW @ 240 volts
About 0.70-4.0 GPM at showering temperature.
MODELS:
PA 208 - * 3Φ 208V - Series 3
PA 240 - * 1Φ240V - Series 3
PA 277 - * 3Φ277/480V - Series 3
Eemax
Lavatory Shower
Kitchen
Hot outlet Cold inlet

TRIAC
PART# EX18
DISPLAY BOARD
PART# EX309-240V
208/240V
PART# EX309-277V
277V
CONTROL BOARD
PART# EX284E-309-240V
208/240V
PART# EX309-284-277V
277V
PART# EX256
208V
PART# EX257B
277V
PART# EX255B
240V
Replacement Elements
PA018208T2T- EX720
PA024208T2T- EX560
PA018277T2T- EX1280
PA024277T2T- EX960
PA032277T2T- EX720
PA028240T2T- EX630

II. PLUMBING HOOK-UP
1) The unit is supplied with ¾’’ NPT fittings (Figure 3), USE THESE. DO NOT USE
PIPE DOPE AND DO NOT SOLDER TO THE INLET OR OUTLET.
2) Take care to ensure that the pipes are correctly aligned with the inlet and outlet bosses
in order to avoid excessive stress on the heater body molding.
NOTE: When soldering pipe joints remove heater from the wall. Serious damage can occur
if any soldering is done while pipes are connected to the heater.
When tighten the fittings make sure to secure the fitting inside the heater to make
a tight connection.
Run water through the supply pipe to remove all debris from the pipe before connecting
the heater. Failure to do so could cause damage to the flow switch.
3) Install isolating valves (full flow ball valve type) on both inlet and outlet pipes. This allows unit
to be isolated for maintenance purposes. (Fig. 1B)
4) When all plumbing is complete, fully check the system for water leaks at all the plumbing
connections. If a leak is present take corrective action. Fully open both inlet and outlet
BALL VALVES.
Run all the hot water outlets fed by this heater one at a time, for a minute or two, until the water
flow is continuous, free from “gulping” and from all visible air pockets.
HOT OUTLET
¾’’ NPT
FITTING
DO NOT SOLDER
COLD INLET
¾’’ NPT
FITTING
DO NOT SOLDER
NOTE:
ALL MOUNTING AND PLUMBING MUST BE COMPLETE BEFORE YOU
PROCEED WITH ELECTRICAL HOOK-UP.
TEST THE INSTALLATION FOR LEAKS BEFORE CONNECTING THE
ELECTRICAL SUPPLY.
9.962”
Figure 3

III. ELECTRICAL HOOK-UP
WARNING
THIS UNIT HAS MULTIPLE POWER SUPPLIES. ENSURE TO DISCONNECT
ALL POWER SUPPLIES BEFORE SERVICING THE WATER HEATER.
“Eemax ProAdvantage” heaters are manufactured to the following specifications:
This unit must have its own independent circuits, using 3 SETS of UL listed 2 conductor and
ground core copper wire cable of the appropriate size protected by 3 separate and
independent correctly rated Double Pole Breakers. (240 V, see Figure 5). Three phase models
shall utilize UL listed 3 conductor and ground core copper wire cable of the appropriate size
protected by correctly rated Triple Pole Breaker. Wire entry into the unit must be made through
the hole(s) provided in the flange on the backplate. Ensure to check national and local
building codes.
The Rating of the branch-circuit over current protective device shall be 150% of the rating of
the unit (see chart above) per UL 499 18.4.
The “live” wires should be connected to the slots in the terminal block marked L1, L2 and L3.
The ground lead must be connected to the slot marked GND. GROUND MUST BE BROUGHT
TO THE “GROUND” AT THE CIRCUIT BREAKER PANEL.
DANGER
FAILURE TO GROUND THE SYSTEM MAY RESULT IN DEATH OR SERIOUS INJURY.
MODEL TYPE Voltage kW output AMPERAGE
PA 018208T2T 208 18 50A /PHASE
PA 024208T2T 208 24 67A/PHASE
PA 018277T2T 277 18 22A/PHASE
PA 024277T2T 277 24 29A/PHASE
PA 032277T2T 277 32 39A/PHASE
PA 028240T2T 240 28 120(3x40)A
3 Separate and independent
correctly rated Double pole
breakers (240/208 Volts)
Figure 4
Figure 5 Circuit Breaker Panel
ONON
OFF
OF F
ON
OFF
ON
OFF
ONON
OFF
OF F

IMPORTANT
BEFORE SWITCHING “ON” THE POWER AT THE MAIN CIRCUIT BREAKER PANEL
MAKE SURE THAT THE HOT WATER CIRCUIT IS FREE OF AIR POCKETS OR ELSE
PREMATURE FAILURE OF THE ELEMENT WILLOCCUR. TO DO THIS OPEN ALL HOT
WATER OUTLETS ONE AT ATIME FOR A MINUTE OR TWO UNTIL THE WATER FLOW
IS CONTINUOUS AND FREE FROM “GULPING” AND FREE FROM VISIBLE AIR POCKETS.
1) Open fully both inlet and outlet valves at the heater.
2) Open any hot water outlet in the system. If the outlet is a “single lever” mixer type turn to the
hottest position. Run for one minute to clear all the air from the system.
3) Slowly close OUTLET ball valve until the water flow from the faucet just starts to reduce.
NOTE: This process has two effects. One, any air in the system will be purged out. Two, the
heater units will be pressurized at the supply pressure. This will prevent the elements free from
air pockets while energized
4)At this point you may energize the hot water heater. (Note: Unit has 3 separate circuit
breakers). Once energized the Thermostatic control touch pad display on the front cover will
illuminate. This is where and when you will program your desired temperature. (figure 6 below)
NOTE
Unit will display the programmed temperature, not the actual outlet temperature
IV COMMISSIONING YOUR HEATER
F/C
140 F
Increase temperature Decrease temperature Fahrenheit / Celsius
To trouble shoot the display board, shut off power to the unit. Press and hold all three buttons.
While buttons are depressed, re-energize the unit. If display board is working properly, the word
“Yes” will display. If the board has a fault it will display “No”. Call technical support for a
replacement.

TROUBLESHOOTING
SYMPTOM “A”: NO HEAT, INDICATOR LIGHT OFF
1) ELECTRIC SUPPLY IS OFF
Turn on the Three main circuit breakers. Ensure the breakers are properly connected to the
relay. L1/L2 from one breaker must correspond with the same relay. You must be able to get
240V across each relay when powered up independently. Do not use space saving breakers.
2) NO OR LOW WATER FLOW
Ensure that the minimum flow rate to switch on your heater is met. “T2T” Models minimum
flow rate = 0.7 gallons per minute. Also check that the inlet filter screen is clear from any
debris. This is located in the brass inlet boss.
3) WATER CONNECTIONS ARE REVERSED
Cold water inlet = right side, hot water outlet = left side.
4) ELEMENT BURNED OUT
TURN OFF THE FOUR MAIN CIRCUIT BREAKERS!
Using an ohmmeter test the resistance of the heating element
across the two threaded termination rods on top of the element.
The resistance reading should be roughly 6.0 ohms. If the resistance
is much greater than this value, call Eemax for a replacement element.
5) ECO TRIPPED (High Limit Thermostat)
TURN OFF THE FOUR MAIN CIRCUIT BREAKERS!
Reset by pushing in red button on each heater module. If the Eco was tripped it will re-engage.
SYMPTOM “B”: NO HEAT OR LOW TEMPERATURE WITH INDICATOR LIGHT ON
1) WATER FLOW TOO HIGH
Reduce the water flow by using an outlet ball valve. See specification sheet for temperature rise.
2) INCORRECT POWER SUPPLY
Make sure that the unit is connected to the voltage supply specified on the rating label on the front
cover of the unit and no other.
3) ELEMENT BURNED OUT
TURN OFF THE FOUR MAIN CIRCUIT BREAKERS!
Repeat the steps from paragraph 4 above.
4) ECO TRIPPED (High Limit Thermostat)
TURN OFF THE FOUR MAIN CIRCUIT BREAKERS!
Reset by pushing in red button on each heater module.
