Efco EBC-3330 User manual

EBC-3330
SmartEC Embedded Box PC
User Manual
Version 1.1
Published January 2016
Copyright©2016 EFCO. All rights reserved.

i
SmartEC Embedded Box PC EBC-3330
Revision History
Revision
Date
Description
1.0
2015/07/30
First release
1.1
2016/02/24
Add revision history
1.2
2016/04/11
Change product name

ii
SmartEC Embedded Box PC EBC-3330
Copyright Notice
This document is copyrighted, 2016. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use, or
for any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, EFCO assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information contained herein.
EFCO reserves the right to make changes in the product design without notice to its
users.
Acknowledgement
All other products’ name or trademarks are properties of their respective owners.
Microsoft Windows® is a registered trademark of Microsoft Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines
Corporation.
Intel® and Pentium® are trademark of Intel Corp.
All other product names or trademarks are properties of their respective owners.

iii
SmartEC Embedded Box PC EBC-3330
Packing List
Before setting up your product, please ensure the following items have been shipped:
1 x EBC-3330
1 x Product DVD with User Manual(PDF) and Drivers
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.
About Manual
This User Manual contains all the essential information, such as detailed descriptions
and explanations on the product’s hardware and software features (if any), its
specifications, dimensions, jumper/connector settings/definitions, and driver
installation instructions (if any), to facilitate users in setting up their product.
Users may refer to http://www.efcotec.com for the latest version of this document.
Product Warranty (2 years)
EFCO warrants to you, the original purchaser, that each of its products will be free
from defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by EFCO, or which have been subject
to misuse, abuse, accident or improper installation. EFCO assumes no liability under
the terms of this warranty as a consequence of such events.
Because of EFCO’s high quality-control standards and rigorous testing, most of our
customers never need to use our repair service. If an EFCO product is defective, it will
be repaired or replaced at no charge during the warranty period. For out-of-warranty
repairs, you will be billed according to the cost of replacement materials, service

iv
SmartEC Embedded Box PC EBC-3330
time, and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, EFCO
product Spec, other software and hardware used, etc.) Note anything abnormal
and list any onscreen messages you get when the problem occurs.
2. If your product is diagnosed as defective, obtain an RMA (Return Merchandise
Authorization) number from your account sales or EFCO website. This allows us to
process your return more quickly.
3. Carefully pack the defective product, a fully-completed repair and replacement
order card and photocopy proof of purchase date (such as your sales receipt) in a
shippable container. A product returned without proof of the purchase date is not
eligible for warranty service.
4. Write the RMA number visibly on the outside of the package and ship it prepaid to
EFCO.
Warnings, Cautions and Notes
Warnings indicate conditions, which if not observed, can cause personal
injury!
Cautions are included to help you avoid damaging hardware or losing
data.
Notes provide optional additional information.

v
SmartEC Embedded Box PC EBC-3330
Safety Instructions
Please read the following safety instructions carefully. It is advised that you keep this
manual for future references.
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the device.
3. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
4. Always completely disconnect the power before working on the system’s
hardware. 5. No connections should be made when the system is powered as a
sudden rush of
power may damage sensitive electronic components.
6. If the device is not to be used for a long time, disconnect it from the power supply
to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray detergents.
9. Make sure the device is installed near a power outlet and is easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent falls.
12. Do not cover the openings on the device to ensure optimal heat dissipation.
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is running.
15. Never pour any liquid into the openings. This could cause fire or electric shock.
16. As most electronic components are sensitive to static electrical charge, be sure to
ground yourself to prevent static charge when installing the internal components.
Use a grounding wrist strap and contain all electronic components in any static-
shielded containers.
17. If any of the following situations arises, please contact our service personnel:
I. Damaged power cord or plug.
II. Liquid intrusion to the device.
III. Exposure to moisture.
IV. Device is not working as expected or in a manner as described in this
manual.
V. The device is dropped or damaged.
VI. Any obvious signs of damage displayed on the device.

vi
SmartEC Embedded Box PC EBC-3330
18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT WHERE THE
STORAGE TEMPERATURE IS BELOW 0° C (32°F) OR ABOVE 60°C (140°F) TO
PREVENT DAMAGE.
FCC Statement
FCC Class A:
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.

vii
SmartEC Embedded Box PC EBC-3330
Contents
Revision History.......................................................................................................................................i
Copyright Notice ....................................................................................................................................ii
Acknowledgement .................................................................................................................................ii
Packing List............................................................................................................................................ iii
About Manual ....................................................................................................................................... iii
Product Warranty (2 years) ................................................................................................................... iii
Warnings, Cautions and Notes.............................................................................................................. iv
Safety Instructions ................................................................................................................................. v
FCC Statement....................................................................................................................................... vi
Contents............................................................................................................................................... vii
Chapter 1................................................................................................................................................1
1.1 Introduction .............................................................................................................................2
1.2 Features....................................................................................................................................2
1.3 Specifications ...........................................................................................................................3
Chapter 2................................................................................................................................................6
2.1 Dimension ................................................................................................................................7
2.2 Standard I/O Indication............................................................................................................8
2.2.1 I/O Indication View .......................................................................................................8
2.2.2 Power ON/OFF Button ..................................................................................................8
2.2.3 Power Input Connector.................................................................................................8
2.2.4 Audio Connector ...........................................................................................................9
2.2.5 USB Connector ..............................................................................................................9
2.2.6 Ethernet Connector(LAN)............................................................................................10
2.2.7 VGA Connector............................................................................................................11
2.2.8 High definition video output Connector.....................................................................11
2.3 Jumpers of the Main Board....................................................................................................12
2.3.1 Jumper Description .....................................................................................................12
2.3.2 Jumper settings list and location ................................................................................13
2.4 Connectors of the Main Board...............................................................................................14
2.4.1 Connectors list and location........................................................................................14
2.4.2 DC-IN Connector .........................................................................................................14
2.4.3 CMOS Battery Connector(J3) ......................................................................................14
2.4.4 S/PDIF-OUT Connector................................................................................................15
2.4.5 MIC Connector ............................................................................................................15

viii
SmartEC Embedded Box PC EBC-3330
2.4.6 GPIO(J22) Connector...................................................................................................15
2.4.7 COM A(J23) & COM B(J24) Connector ........................................................................16
2.4.8 Front Header(J25) Connector .....................................................................................16
2.4.9 PCI Express Mini Card .................................................................................................16
2.4.10 SATA 1 Connector......................................................................................................18
2.4.11 SATA_PWR(CN3) Connector......................................................................................18
2.4.12 EPORT Connector......................................................................................................18
2.4.13 LVDS Connector.........................................................................................................19
2.4.14 SO-DIMM Connector.................................................................................................20
2.4.15 Micro SD Slot.............................................................................................................20
2.5 Peripheral Installation ............................................................................................................20
2.5.1 Memory Installation....................................................................................................20
2.5.2 Full-Size PCI Express Mini Card Installation ................................................................22
2.5.3 Half-Size PCI Express Mini Card Installation................................................................23
2.5.4 Micro SD Card Installation...........................................................................................23
Chapter 3..............................................................................................................................................25
3.1 BIOS Introduction...................................................................................................................26
3.2 Continue.................................................................................................................................27
3.3 Boot Manager ........................................................................................................................27
3.4 Device Management ..............................................................................................................28
3.5 Boot From File........................................................................................................................29
3.6 Secure Boot Option................................................................................................................30
3.7 SCU (System Control Unit) .....................................................................................................32
3.7.1 Main ............................................................................................................................32
3.7.2 Advanced.....................................................................................................................33
3.7.3 Security .......................................................................................................................56
3.7.4 Power ..........................................................................................................................57
3.7.5 Boot.............................................................................................................................62
3.7.6 Exit...............................................................................................................................67
Chapter 4..............................................................................................................................................68
4.1 Driver Installation...................................................................................................................69
Chapter A .............................................................................................................................................71
A.1 Option Accessories I/O Indication .........................................................................................72
A.1.1 COM Port I/O (P/N: EFCP1169X1-L)............................................................................72
4.1.2 Ethernet Port I/O (P/N: EFCP1168X1-L) ......................................................................73
4.1.3 GPIO Port I/O (P/N: EFCP1170X1-L) ............................................................................74
4.1.4 USB 3.0 Port I/O (P/N: EFCP1171X1-L)........................................................................74
Chapter B..............................................................................................................................................76

ix
SmartEC Embedded Box PC EBC-3330
B.1 Watchdog Timer Initial Program............................................................................................77
B.2 Watchdog Sample Program ...................................................................................................79
Chapter C..............................................................................................................................................82
C.1 I/O Address Map ....................................................................................................................83
C.2 IRQ Mapping Chart ................................................................................................................84
C.3 Memory Address Map ...........................................................................................................87

1
SmartEC Embedded Box PC EBC-3330
Chapter 1
GENERAL INTRODUCTION

2
SmartEC Embedded Box PC EBC-3330
1.1 Introduction
The Fanless Embedded Box PC with multi I/O interfaces.
The SmartEC series devices are designed in compact sizes and using the latest energy-
efficient Intel® Bay Trail platform. The fanless architecture ensures silent operation
with maximum reliability and minimum dust intake, making the SmartEC ideal to use
in various environments. For enhanced flexibility, the system supports dual display
capability and storage expansion availability. Additionally, the device supports High-
Definition video format to provide the ultimate video experience.
The SmartEC is compatible with various applications, such as Thin Client, Factory
Automation, and Digital Signage with limited space. Multiple I/O interfaces provide
the connection to the most common peripherals. With its smart design, low energy
consumption and great connectivity, the SmartEC is definitely the best choice for your
diverse applications.
Applications.
Industrial Controller
Digital Signage
Kiosk Engine
Factory Automation
POS PC
Remote Terminal Unit (RTU)
IoT Gateway
1.2 Features
•Fanless design with low power consumption
•Supports Intel® Bay Trail platform
•1 x 204 pin DDR3L SO-DIMM 1333 max up to 8GB
•Supports VESA mount
•Standard I/O:
1 x USB3.0, 1x USB2.0
Dual display for 1 VGA & 1 High definition video output
1 x mSATA supported

3
SmartEC Embedded Box PC EBC-3330
12V Power input (Optional for 5V ~ 55V)
1 x Line-out
1.3 Specifications
System
CPU
♦Intel® Bay Trail platform
System Memory
♦1 x 204 pin DDR3L SO-DIMM 1333 max up to 8GB
Chipset
♦SoC integrated
Storage
♦1 x mSATA supported
Watchdog Timer
♦255 levels, 255 sec.
External I/O
♦1 x VGA, 1 x High definition video output
♦1 x USB 2.0
♦1 x USB 3.0
♦2 x 10/100/1000Mbps Ethernet
♦1 x power on/off button

4
SmartEC Embedded Box PC EBC-3330
♦1 x Audio (Line-Out)
WiFi
♦Optional for 802.11 b/g/n
Power Supply
♦12V DC Power input (Optional for 5V ~ 55V)
Expansion Slot
♦1 x full-size PCI Express Mini card (for mSATA)
♦1 x half-size PCI Express Mini card with USB signal (for optional Wireless module)
Mechanical
Dimension
♦190(W) x 115.5(D) x42.2(H) mm
Weight
♦2.5kg / 4kg

5
SmartEC Embedded Box PC EBC-3330
Mounting Type
♦VESA
Environmental
Operation Temperature
♦0~+60°C, (32F –140 F)
Relative Humidity
♦10%-90% (non-condensing)
Certificate Software Support
Certification
♦CE, FCC Class A
OS Information
♦Windows 7 Professional 64bit, Windows Embedded standard 7 64bit, Linux Ubuntu
14.04.3 LTS 64bit

6
SmartEC Embedded Box PC EBC-3330
Chapter 2
HARDWARE INFORMATION

7
SmartEC Embedded Box PC EBC-3330
2.1 Dimension
Unit: mm
Photo_1 – EBC-3330 mechanical dimension drawing-1
Photo_2 – EBC-3330 mechanical dimension drawing-2
Photo_3 – EBC-3330 mechanical dimension drawing-3

8
SmartEC Embedded Box PC EBC-3330
2.2 Standard I/O Indication
2.2.1 I/O Indication View
Phot_ 4 – EBC-3330 I/O View
2.2.2 Power ON/OFF Button
The EBC-3330 has a Power On/Off button with LED indicator. Using the Power button,
the device can be switched on, suspended, shut down immediately, or shut down
with the delay of 4 seconds.
Photo_5 – Power Button
2.2.3 Power Input Connector
The EBC-3330 has 2 external DC power input connectors: DC 12V Power Jack and DC

9
SmartEC Embedded Box PC EBC-3330
5V - 55V 2-pin terminal block connector as shown in the following images.
Photo_6 – Power Input Connector_12V Photo_7 – Power Input Connector_5~55V
2.2.4 Audio Connector
EBC-3330 provides a single 3.5mm ear phone jack connector with Line-out function.
Photo_8 – Ear Phone Jack Connector
2.2.5 USB Connector
EBC-3330 provides two (1 x USB 2.0 & 1 x USB 3.0) USB interface connectors. The
interface is compliant with USB UHCI, Rev. 2.0 & 3.0. Both connectors are Plug and
Play compatible, allowing you to connect or disconnect a device whenever you want,
without turning off the computer.
Pin
Signal Name
Pin
Signal Name
1
+5VSB
2
USB0_D-
3
USB0_D+
4
GND
5
USB1_SSRX-
6
USB1_SSRX+
7
GND
8
USB1_SSTX-
9
USB1_SSTX+
10
+5VSB
11
USB1_D-
12
USB1_D+
13
GND

10
SmartEC Embedded Box PC EBC-3330
Table_1 – USB Pin Assignments Photo_9 – USB Connector
When Insertion USB device, please check device's direction.
2.2.6 Ethernet Connector(LAN)
EBC-3330 provides two RJ-45 LAN interface connectors which are fully compliant with
IEEE 802.3u 10/100/1000 Mbps CSMA/CD standards. It is equipped with Intel I210
and supports Wake-On-LAN function. The Ethernet port uses a standard RJ-45 jack
connector with LED indicators on the front side to show Active/Link status and Speed
status.
Pin
Signal Name
Pin
Signal Name
1
TX+, MDI0+
2
TX-, MDI0-
3
RX+, MDI1+
4
MDI2+
5
MDI2-
6
RX-, MDI1-
7
MDI3+
8
MDI3-
Table_2 – LAN Pin Assignments Photo_10 – Ethernet Connector
LAN1 LED State Table
LAN LED Status
LED1 (Link)
LED2 (SPEED)
Network link is not established or system
power off
Amber/ Blinking
OFF
10 Mbps (10 Base-T)
10 Full Duplex
Amber
OFF
Link/Active
Blinking
OFF
100 Mbps (100 Base-TX)
100 Full Duplex
Amber
Green
Link/Active
Blinking
ON
1000 Mbps (1000 Base-T)
1000 Full Duplex
Amber
Orange
Link/Active
Blinking
ON
Table_3 – LAN1 LED State
LAN2 Intel i210-AT LED State Table
