EFE Rail Class J94 Locomotive Technical manual

Class J94 Locomotive
Owner’s Information
Thank you for purchasing this EFE Rail Class J94 model locomotive. This highly detailed working replica
will give you years of pleasure and reliable operation if it is handled with care and regularly serviced.
This locomotive is a carefully engineered scale model, and will require a short period of running in time
before operating at its best. Run for about half an hour at a moderate speed in each direction to allow
the gears in the mechanism to bed in for smooth operation.
Motor: Coreless
Decoder: Next18 DCC Decoder
After every 24 hours of operation,
your locomotive will require
light lubrication to keep it in top
operating condition. Use a plastic
compatible lubricant suitable for
models carefully applied to the
gear train and connector rods.
Please take care when removing your model from its packaging, as EFE models incorporate many small
parts.
Run your model on track laid on a rm surface - not on carpet – to avoid dust and bres entering the
working parts of your model.
Care must be taken to clean and maintain your model for optimum performance. When required, wipe
the rails and exposed portions of your locomotive’s wheels with a soft, lint-free cloth or cotton swab
to ensure good electrical contact. Do not use steel wool to clean your track. Take care to avoid scenic
material from the layout entering the mechanism.
Welcome
Running In
Model Spec.
Cleaning and Maintenance
Lubrication

Your EFE Rail Class J94 model comes ready to be
adapted for Digital Command Control (DCC). The
conversion of this locomotive to DCC operation is
a simple task.
The Next18 DCC Decoder Socket has been
cleaverly hidden behind the locomotive smokebox
door. This is held in place with magnets and can be
removed by gently pulling it away.
DCC Decoder Fitting
Fig.1 Smokebox Door Fig.2 Gently remove the Smokebox Door
Fig.3 Pull out the PCB and Remove the Next18
DCC Blanking Plate.
Fig.4 Fit the Next18 DCC Decoder, return PCB
to boiler and replace Smokebox Door.
It is important to retain your packaging and associated information for future reference and storage.
Storage

This product has a Warranty for 12 months from the date of purchase against faulty materials or
workmanship subject to the following conditions. During this period such defects that occur will be
repaired or defective parts replaced free of charge.
1. This Warranty applies only if the item was purchased from an authorised retailer of Bachmann Europe
plc (‘Bachmann’) within the United Kingdom, European Union & European Economic Area. This Warranty
does not confer any rights other than those expressly set out above and does not cover any claims for
consequential loss or damage. The Warranty is oered as an additional benet and does not aect your
statutory rights as a consumer.
2. For claims under this Warranty, in the rst instance the product must be returned to the retailer with
evidence of the purchase date in the form of retailer receipt/invoice accompanied by a letter setting out
the date and place of purchase, giving a brief explanation of the problem that has led to the claim. It is
essential that the claim reach the retailer on or before the last day of this Warranty period. Late claims will
not be considered.
3. This Warranty is only available to the original retail purchaser of this product and is non-transferable.
4. The Warranty does not extend to cover damage resulting from misuse or careless handling, accidental
damage, wear and tear, or use on a voltage supply other than that stamped on the product.
5. The Warranty may be considered void if repairs have been attempted other than by Heljan sta.
6. The Warranty is on the original product in its entirety and does not extend to individual components
removed from the product. In respect of train sets the warranty applies to motorized units and controllers
only.
7. If Bachmann chooses to replace a product it will be with the nearest appropriate model of its choice.
8. Bachmann reserves the right to decline service to any model that has been tted with a decoder after
manufacture.
9. Bachmann will not be held responsible for damage to or loss of an after market decoder tted to a
model submitted for service under the Warranty.
10. The tting of a Bachmann decoder with a current Warranty shall not be deemed to change the position
regarding a product that is otherwise outside its own Warranty. It may be necessary to change decoder
settings during service.
11. Bachmann’s liability under this Warranty will in no case exceed the price paid for the product as
originally manufactured.
Warranty
Bachmann Europe PLC
Moat Way,
Barwell,
Leicestershire,
LE9 8EY
www.bachmann.co.uk

Class J94 / Austerity 0-6-0ST
