Eaelec BB-157 User manual

Assembly Instructions For Z-Scale
Ford Model BB-157 1 ½ ton Trucks
Page 1
This is a scale model kit of the 1934 BB series truck. The BB series was in production
from 1932 to 1934. It was equipped with either the standard four cylinder or the optional
“flathead” V-8 (this kit depicts the V-8). The BB-157 indicates the longer wheelbase version
(157”) rather than the shorter wheelbase version (131.5”). The kit is available with several
different cargo beds and loads, this first sheet of instructions is common and the second sheet
is specific to the type of bed/load, such as stake bed with beer kegs or flat bed with lumber,
etc..
Parts Included in the kit:
A. 3D printed chassis.
B. 3D printed cab
C. 3D printed cargo bed
E. 3D printed load - on some versions of the kit
D. One decal sheet
Required to complete the kit:
Paint - Flat black, silver, brown, wood, gloss coat
- and cab color (see page 4 for painting guide).
Glue - Slow setting CA is best.
Tools Required:
1. X-acto knife with a sharp #11 blade.
2. #400 and #600 sandpaper.
www.eaelec.com
Made in Canada
WARNING: CHOKING HAZARD
Keep out of reach of small
children!
Note that these ARE NOT TOYS,
AND ARE NOT INTENDED FOR
USE BY CHILDREN UNDER
AGE OF 14. These products are
model railroad equipment and
accessories intended for use by
adults.
ROYCE
LUMBER
R
Panther
BREWERY
CO.
Beer Truck
Lumber Truck

The 3D printing process requires a supporting frame during printing, see below
left. The printed part is cut from the frame using flush cutters and this sometimes
leaves small bumps on the part. Use a knife with a sharp new blade to cut away the
bumps. When trimming bumps off the wheels you should place the wheel on a flat
surface as shown below on the right. Putting too much stress on the wheel can cause
the axle to break. For bumps on the cab body, sanding is recommended.
After cleaning up the bumps, paint the cab, cargo bed, chassis and the load as
shown on the painting guide on page 4. The sign boards where the decals are placed
should painted with a gloss paint or clear gloss before the decals are applied. Decals
don’t set properly on a flat finish. Cut out decals as shown on page 3 before applying.
After the decals are completely dry, it is a good idea to apply a coat of gloss over the
decals to preserve them.
When everything is dry, proceed to final assembly. Follow the steps below
using CAglue.
Page 2
www.eaelec.com
When gluing the cab to chassis, the front
of the grill should extend to red line
Glue the cab to chassis.
Final Assembly - Step 1

Panther
BREWERY
CO.
Page 3
www.eaelec.com
When gluing the cargo bed to chassis, this part
of the bed hooks over the end of the chassis
Glue the beer kegs to the cargo bed
Glue the cargo bed to chassis.
Final Assembly - Step 2
Final Assembly - Step 3
Panther
BREWERY
CO.
Cut out decals on dotted lines:
Note on Decals
Panther
BREWERY
CO.
Panther
BREWERY
CO.

Ford BB-157 Beer Truck Painting and Decal Placement
Decal
Decal
Flat Black
Flat Black
Brown
Flat Black
Flat Black
Silver Silver
Red
Red
Red
Wood
Left View
Right View
Front View Barrel Load
Panther
BREWERY
CO.
Panther
BREWERY
CO.
Page 4
