effegibi effe AQUASTEAM SMART 30 User manual

AQUASTEAM SMART
EASYSTEAM SMART
Assembly instructions

AQUASTEAM / EASYSTEAM
2
MAHA000371
SYMBOLS
Whenever you see one of these symbols in the manual you must read the information given
alongside as it is vital to ensure correct use of your steam generator. Failure to read and
take into account the information could seriously compromise the safety of both objects and
people.
DANGER - ATTENTION
This indicates situations of grave danger which, if ignored, could
seriously compromise the health and safety of the persons concerned.
CAUTION - PRECAUTION
This indicates you need to take all necessary measures and precautions
to prevent accidents and/or damage to objects and/or harm to people
NOTE
This indicates technical information of particular importance and
which must not be overlooked.
1.1 INTENDED USE
The AQUASTEAM SMART/EASYSTEAM SMART Generator produces non-pressurized
steam by means of
heating elements immersed in the water contained in the boiler; the steam produced in this
way is used to ‘humidify’ the Turkish Bath area, using special diffusers.
The quality of the water used does not affect the evaporation process, so it is possible to use
untreated water, as long as it is potable, or water treated by a water softener; the evaporated
water is automatically re-integrated by means of a ller valve.
This appliance is designed solely for the production of steam. It is for this purpose only, so
all installation, use and maintenance must be executed in conformity with the instructions in
this manual and the information on the labels placed on and inside the appliance.
The ambient conditions and supply voltage must be as specied.
The steam generator must be put to the sole purpose for which it
was intended; any other use is improper and therefore dangerous
Any other use and any changes not expressly authorized by the manufacturer are deemed
improper.
The Manufacturer cannot assume any liability for lesions or
damage due to improper use of the appliance.
As the appliance contains live electrical components and hot surfaces, all servicing and/or
maintenance must be executed by an experienced and qualied technician taking all the
necessary precautions.
1 INTRODUCTION
DO NOT
Tells you not to do certain things that could cause accidents and/or
damage property and/or harm people.

012 000 767
Serial number
AQUASTEAM / EASYSTEAM 3MAHA000371
1.2 SCOPE OF THE MANUAL
This manual provides all the information required to ensure correct use and proper
maintenance of the AQUASTEAM SMART/EASYSTEAM SMART generator.
You must read this user and maintenance manual carefully before starting up the appliance
for the rst time; only then can you learn how to use our Steam Generator properly and in a
short time.
The good working order of the generator depends largely on good maintenance and
cleaning. It is therefore very important to know how to clean and execute the maintenance.
We therefore advise you to consult the user and maintenance manual, which also
describes start-up, shutdown and good, safe operation.
The generator was designed in conformity with the safety provisions of the following
directives:
• Low voltage directive 2014/35/EU
• RED Directive 2014/53/EU
We constantly seek to improve upon our products, so please note that the generator in your
possession may not be exactly the same as described in this manual. Any differences are
in any case marginal and not substantial.
The Manufacturer reserves the right to take legal action against
all persons who make unauthorized changes to its steam generators.
1.3 IDENTIFICATION OF THE AQUASTEAM SMART/
EASYSTEAM SMART COLUMN
The plate attached to the left side of the column provides all the information required to identify
your generator – the type of product, the model, its power consumption, voltage, serial number,
the year of manufacture, the name of the manufacturer and the CE mark of conformity.
Models:
AQUASTEAM SMART 30 3000W cod: HA CM AS 0009
AQUASTEAM SMART 45 4500W cod: HA CM AS 0010
EASYSTEAM SMART 30 3000W cod: HA CM ES 0013
EASYSTEAM SMART 45 4500W cod: HA CM ES 0014
Models

AQUASTEAM / EASYSTEAM
4
MAHA000371
2. SAFETY INSTRUCTIONS
Use of the steam generator for any purposes other than those for
which it has been specically designed is strictly prohibited.
The Hammam/Turkish bath must not be used by anyone suffering
from serious heart disorders, internal inammation, contagious
diseases, epilepsy or who wears a pacemaker.
People taking medications should consult a medical practitioner
before use, since some medications can cause drowsiness
and other may affect the cardiac rhythm, blood pressure and
circulation. The use of alcohol, drugs or other pharmaceuticals
may dramatically increase the risk of hyperthermia.
This manual is an integral part of the product, keep it carefully in
an accessible place. Read this manual carefully before using the
Hammam/Turkish bath.
We recommend seeking medical advice before using the
Hammam/Turkish bath.
The equipment must not be used by children under the age
of 8 and by people with reduced physical, sensorial or mental
capabilities or those lacking the necessary experience or
knowledge, other than under supervision, or if they have been
given instructions for the safe use of the equipment and therefore
understand the risks involved in its use. Do not allow children to
play with the equipment.
Any cleaning and maintenance to be done by the user must not
be done by children without supervision.
Be careful when using the equipment because of the release of
hot water steam (IEC 60335-2-98).
High temperatures have the potential to damage to the foetus
in the early months of pregnancy. Women who are pregnant or
who suspect they may be pregnant should consult a medical
practitioner regarding any exposure. People who are obese
or who have cardiac problems, high or low blood pressure,
cardiovascular conditions or diabetes should consult a medical
practitioner before use.
Carefully follow all the safety instructions and hazard warnings
issued by the authorities of individual countries.
Use of the Hammam/Turkish bath by people (adults or children)
with impaired physical, sensorial or mental capacities that may
prevent the Hammam/Turkish bath being used in total safety
must be supervised or given special instructions.
Always carry out the prescribed checks, inspections and
scheduled maintenance.
Do not introduce other electrical appliances into the steam
generator or bring them into the Hammam/Turkish bath cubicle.

AQUASTEAM / EASYSTEAM 5MAHA000371
Prolonged use of the Turkish bath may raise the inner body temperature excessively
and weaken its self-regulation capacity (hyperthermia). We recommend staying in the
Turkish bath for a maximum of 15 minutes. Enter the Turkish bath cubicle once it is
full of steam. All users must be informed and given instructions about how to use it.
Take great care using the Turkish bath. The steam diffuser emits hot steam. Do not
touch the steam diffuser.
Label xed to the steam diffuser: warning very hot surfaces. Do not remove it.
Label xed to the steam diffuser: Do not cover. Do not remove it.
The steam diffuser has a front panel made of toughened glass, therefore during installa-
tion and use, normal care should be taken with the glass.
Do not bring into or install in the steam room:
- Animals
- Electrical appliances
- Non-electrical items not suitable for such an environment
The manufacturer accepts no liability for items or animals brought into the steam room.
Do not, for any reason, remove the adhesive labels xed to the generator. If these dete-
riorate, order replacements.
Enter the Turkish bath cubicle once it is full of steam.
All users must be informed and given instructions about how to use it.
Do not cover or place anything on the steam diffuser because this could prevent it work-
ing properly.
The optional LED light is safe and does not carry any risks, in compliance with the stand-
ard IEC/TR 62471-2: 2009.
Be careful when using the equipment because of the release of hot water steam (IEC
60335-2-98).
Disconnect the equipment during relling and cleaning (IEC 60335-2-98).

255 137
134
137 575
255 137
137 575
134
AQUASTEAM / EASYSTEAM
6
MAHA000371
3 OVERALL DIMENSIONS
Aquasteam
Easysteam

3
1
2
4
N°4
N°1 N°1
N°4 N°4 N°1 N°1 N°1
AQUASTEAM / EASYSTEAM 7MAHA000371
3.1 PACK CONTENTS
2 BAG OF ACCESSORIES
1 Installation frame
2 AQUASTEAM SMART /EASYSTEAM SMART with bag of accessories
3 Polystyrene head protections
4 Bowl in white resin (only for AQUASTEAM SMART)

535
210
AQUASTEAM / EASYSTEAM
8
MAHA000371
4 INSTALLATION
4.1. CHECKING THE ROOM FOR THE
AQUASTEAM SMART /EASYSTEAM SMART COLUMN
Put a complete strip of sili-
cone (without gaps) around
the base, between the box
and the coating.
Box
Check the height is
210mm x 535mm
and check all around the
appliance to make sure
that the coating does not
protrude; remove any
excess.
Silicone
Coating

7/8
7/8
AQUASTEAM / EASYSTEAM 9MAHA000371
4.2. SILICONE COATING ON THE FINISHING FRAME
Put a complete strip of silicone (without gaps) around the entire inner layer of the frame to
be brought in contact with the coating.
ATTENTION!
DO NOT REMOVE
THE CONTAINMENT
TEMPLATE IN
ORDER TO AVOID
DEFORMATIONS

1
2
x4
AQUASTEAM / EASYSTEAM
10
MAHA000371
4.3. INSERTING THE FINISHING FRAME
Insert the frame, putting the slots on the
respective threaded steel pins.
Be careful not to reverse the top/
bottom position of the frame.
Keep the hooks down.
Once the silicone-coated frame has been positioned,
tighten with the 4 anged nuts in correspondence
to the slots, taking care to keep it well against the
coating and without deforming it.

AQUASTEAM / EASYSTEAM 11 MAHA000371
4.4. CLEANING THE SILICONE
Remove any silicone smears and check there are no gaps between the frame and the coat-
ing: ll in any gaps with new silicone.
Ensure that the outlet tube
is not blocked.
The xing nuts and the external
surface of the frame must be clean
and free of silicone residues and/or
residues of masonry, glues and dust
resulting from the installation.

x4
AQUASTEAM / EASYSTEAM
12
MAHA000371
After the silicone has dried, remove the 4 xing screws of the containment template and
remove it from the frame.
4.5 DISASSEMBLING THE FRAME TEMPLATE

1
2
3
AQUASTEAM / EASYSTEAM 13 MAHA000371
5 CONNECTION TO THE MAINS SUPPLY (WATER - ELECTRICITY)
Remove the caps from the Aquasteam and outer casing
5.1 WATER SYSTEM CONNECTION (LOADING)
Insert pipe + JG curve in the JG water inlet
tting of the outer casing and lock with the clip
supplied.

AQUASTEAM / EASYSTEAM
14
MAHA000371
Put the AQUASTEAM SMART / EASYSTEAM SMART column near where it is to be in-
stalled.
Insert the tube + JG curve
into the lling connection of
the AQUASTEAM SMART /
EASYSTEAM SMART column.
Push the tube fully and make
sure it does not come off.

1
2
AQUASTEAM / EASYSTEAM 15 MAHA000371
5.2 COLUMN POSITION
Place the column on the lower supports
ensuring that it is held upright and not let-
ting it touch the covering below.
While installing, the column should be supported by securing it as follows:
Attach the steel cable on the column to
the hook at the bottom of the outer casing.
Ensure that the column is stable then
continue with the next installation
steps.

AQUASTEAM / EASYSTEAM
16
MAHA000371
5.3 CONNECTION TO THE ELECTRICAL MAINS
The installation must be carried out only by qualied personnel in compliance with all the provisions
contained in this manual and with IEC 64-8 and the respective electrical installation regulations of
the local authorities.
Follow the wiring diagrams.
A circuit breaker permitting complete disconnection in accordance with overvoltage category III
must be installed on the power line upstream of the appliance.
For example: a circuit breaker ( d > 3 mm + differential + fuse ).
The appliance must be permanently connected to the mains with a differential protection device
that has a rated differential current no greater than 30 mA.
The electrical connection, the position of the main switch with differential, control switch, and
transformer must comply with IEC 64-8 and the respective electrical installation regulations of the
local authorities.
The electrical connection, the position of the main switch with differential and fuse, of the control
switch, must be positioned in compliance with IEC 64-8 and the respective electrical installation
regulations of the local authorities.
The cable should be installed and replaced, when necessary, by a qualied technician.
Connect the wires of the power cable to the terminal marked L3-L2- L1- N-E , in accordance
with the wiring diagram and the type, single-phase. Put the cable in the cable gland
A connection must be made to the main earth terminal marked . Use the earth wire (yellow/
green), longer than the active wires (L3-L2- L1- N-E).
Always take into account all the danger warnings and safety rules issued by domestic authorities.
All maintenance and repairs must be executed by a qualied technician.
SYSTEM’S EQUIPOTENTIAL
It is mandatory to connect the AQUASTEAM SMART / EASYSTEAM SMART column to the
equipotential bonding point of the system in compliance with IEC 64-8 and the respective electrical
installation regulations of the local authorities. Connect the yellow/green cable to the respective
terminal marked
Equipotential
bonding point

AQUASTEAM / EASYSTEAM 17 MAHA000371
5.4 ELECTRIC POWER SUPPLY

AQUASTEAM / EASYSTEAM
18
MAHA000371
OPTIONAL REMOTE
Connector for the lamp
and extra panel
Remote connector
WARNING: in order for the remote sensor to function the cable must be con-
nected to a switch or a relay.
The contact must be clean and must not share connections with any other
devices.
No connection must be made with the system safety earth, therefore DO NOT
USE the digital inputs and outputs of other electronic devices.
MAXIMUM DISTANCE FOR LAMP OR ADDITIONAL PANEL: 8m
WARNING: Use only the cable supplied with the extra lamp.
DO NOT use other cables. If you need one, ask the manufacturer for a spare.
Use the cable clamp to lock
the lamp cable in place to
avoid problems if it is pulled
accidentally during installation
or maintenance.
DO NOT use the main power
cable clamp.

L3 L2 L1
L
N
N
E
EQUIPOT.
EQUIPOT.
PANEL
Remote
Signal
Common Open Door
Signal
REMOTE
(OPTIONAL)
DOOR
(OPTIONAL)
CROMO
AQUASTEAM / EASYSTEAM 19
220-240 V ~
Power Ampere SEZ Fuse
3000 W 13.6 2.5 mm220A
4500 W 20.5 4 mm230A
MAHA000371
POWER SUPPLY SINGLE-PHASE BLOCK DIAGRAM - OPTIONAL - REMOTE
OPTIONAL - REMOTE POWER SUPPLY

L3
L3
L2
L2
L1
L1
N
N
E
EQUIPOT.
EQUIPOT.
PANEL
REMOTE
(OPTIONAL)
DOOR
(OPTIONAL)
CROMO
Remote
Signal
Common Open Door
Signal
AQUASTEAM / EASYSTEAM
20
380-415 V 3N ~
Power Ampere SEZ Fuse
3000 W 4 1.5 mm23x16A
4500 W 6 1.5 mm23x20A
MAHA000371
POWER SUPPLY THREE-PHASE BLOCK DIAGRAM - OPTIONAL - REMOTE
OPTIONAL - REMOTE POWER SUPPLY
