Ego Power+ PAD1800 User manual

WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
POWER INVERTER
OPERATOR’S MANUAL
56-VOLT
POWER INVERTER
MODEL NUMBER PAD1800/PAD1800-FC
180W
120V-1.5A
PURE SINE WAVE
Español p. 43
Français p. 21

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC2
READ ALL INSTRUCTIONS!
READ & UNDERSTAND
OPERATOR’S MANUAL
TABLE OF CONTENTS
Safety Symbols ..........................................3
Symbols................................................4
Safety Instructions for Power Inverter.......................5-7
FCC Statement ..........................................8
Introduction ............................................9
Specifications ..........................................10
Packing List ...........................................10
Description ............................................11
Operation ..........................................12-16
Maintenance ...........................................17
Troubleshooting ........................................18
EGO Limited Warranty .................................19-20

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC 3
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper accident prevention
measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER”, “WARNING”,
and “CAUTION” before using this machine. Failure to follow all instructions listed below
may result in electric shock, fire, and/or serious personal injury.
The definitions below describe the level of severity for each signal word. Please read
the manual and pay attention to these symbols.
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
DANGER DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION CAUTION, used with the safety alert symbol, indicates a
hazardous situation which, if not avoided, will result in minor or
moderate injury.
DAMAGE PREVENTION AND INFORMATION MESSAGES
These inform the user of important information and/or instructions that could lead
to equipment or other property damage if they are not followed. Each message is
preceded by the word “NOTICE”, as in the example below:
NOTICE: Equipment and/or property damage may result if these instructions are not
followed.

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC4
SYMBOLS
This page depicts and describes symbols that may appear on this product. Read,
understand, and follow all instructions on the product before attempting to assemble
and operate.
Safety Alert Indicates a potential personal injury hazard.
Read & Understand
Operator’s Manual
To reduce the risk of injury, user must read
and understand the operator’s manual
before using this product.
Alternating Current Type or a characteristic of current
Direct Current Type or a characteristic of current
V Volt Voltage
A Amperes Current
kg Kilogram Weight
lb Pound Weight
°C Degrees Celsius Temperature
°F Degrees Fahrenheit Temperature

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC 5
SAFETY INSTRUCTIONS FOR POWER INVERTER
WARNING: When using this product, basic precautions should always be
followed, including the following:
 Read all the instructions before using the product.
 To reduce the risk of injury, close supervision is necessary when the product is
used near children.
 Do not put fingers or hands into the product.
 Use of an attachment not recommended or sold by power pack (inverter)
manufacturer may result in a risk of fire, electric shock, or injury to persons.
 To reduce risk of damage to the electric plug and cord, pull the plug rather than
the cord when disconnecting the power pack (inverter).
 Do not use a battery pack or appliance that is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire, explosion,
or risk of injury.
 Do not operate the power pack (inverter) with a damaged cord or plug, or a
damaged output cable.
 Do not disassemble the power pack (inverter), take it to a qualified service person
when service or repair is required. Incorrect reassembly may result in a risk of fire
or electric shock.
 To reduce the risk of electric shock, unplug the power pack (inverter) form the
outlet before attempting any instructed servicing.
 When charging the internal battery, work in a well ventilated area and do not
restrict ventilation in any way.
 Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may cause irritation or burns.
 Do not expose a power pack (inverter) to fire or excessive temperature. Exposure
to fire or temperature above 265 °F (130 °C) may cause explosion.
 Have servicing performed by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the product is maintained.

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC6
WARNING: Read all safety warnings and instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
 Risk of fire and electric shock. Dry location use only. Do not expose the
power inverter to rain or wet conditions. Water entering the power inverter will
increase the risk of electric shock.
 For household use only.
 Do not allow the power inverter to be used as a toy. Close attention is
necessary when used by or near children.
 The power inverter is not intended for any use other than charging small
USB electronics or small AC devices specified in SPECIFICATIONS in this
manual. Any other use may result in damage.
 Switch off the power inverter when not in use.
 Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to battery pack, picking up or carrying the power inverter.
Carrying the power inverter with your finger on the switch or energizing power
inverter that has the switch on invites accidents.
 Disconnect the battery pack from the power inverter before making
any adjustments, changing accessories, or storing power inverter. Such
preventive safety measures reduce the risk of starting the power inverter
accidentally.
 Recharge only with the charger specified by the manufacturer. A charger that
is suitable for one type of battery pack may create a risk of fire when used with
another battery pack.
 Use power inverter only with specifically designated battery packs. Use of
any other battery packs may create a risk of injury and fire.
 Use only with the battery packs and chargers listed below:

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC 7
BATTERY PACK CHARGER
BA1400, BA1400-FC,BA2800, BA2800-FC,
BA4200, BA4200-FC, BA1400T, BA1400T-FC,
BA2242T, BA2242T-FC, BA2800T, BA2800T-FC,
BA4200T, BA4200T-FC, BA3360T, BA3360T-FC,
BA4480T, BA4480T-FC, BA5600T, BA5600T-FC,
BA6720T, BA6720T-FC
CH2100, CH2100-FC,
CH3200, CH3200-FC
CH5500, CH5500-FC,
CH2800D, CH2800D-FC
CH7000, CH7000-FC
 When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects, that
can make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
 Follow all charging instructions and do not charge the battery pack or
appliance outside of the temperature range specified in the instructions.
Charging improperly or at temperatures outside of the specified range may
damage the battery and increase the risk of fire.
 Do not modify or attempt to repair the power inverter or the battery pack
except as indicated in the instructions for use and care.
 Store idle power inverter out of the reach of children and do not allow
persons unfamiliar with the power inverter or these instructions to operate
the power inverter. Power inverters are dangerous in the hands of untrained
users.
 Maintain power inverter and accessories. Check for misalignment or
breakage of parts and any other condition that may affect the power
inverter’s operation. If damaged, have the power inverter repaired before
use. Many accidents are caused by poorly maintained power inverter.

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC8
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTICE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures: Reorient or relocate the receiving antenna. Increase
the separation between the equipment and receiver. Connect the equipment into an
outlet on a circuit different from that to which the receiver is connected. Consult the
dealer or an experienced radio/TV technician for help.
Save these instructions. Refer to them frequently and use them to instruct others
who may use this product. If you lend this product to someone else, also lend these
instructions to them to prevent misuse of the product and possibly injury.
SAVE THESE INSTRUCTIONS!

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC 9
INTRODUCTION
Congratulations on your selection of the 56V Lithium-ion Power Inverter. It has been
designed, engineered and manufactured to give you the best possible dependability
and performance.
Should you experience any problem you cannot easily remedy, please contact EGO
customer service center 1-855-EGO-5656.
This manual contains important information on to the safe assembly, operation and
maintenance of your product. Read it carefully before using the product. Keep this
manual handy so you can refer to it at any time.
SERIAL NUMBER _____________________ DATE OF PURCHASE _________________
YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP IN A SAFE
PLACE FOR FUTURE REFERENCE

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC10
SPECIFICATIONS
Voltage 56V
Output Wave Form Pure Sine Wave
USB-A Output 5V 2.4A
USB-C Output 5V 3A, 9V 3A, 12V 3A,
20V Max. 5A, Max.100W
AC Output (Receptacle) 120V ~ 60Hz, 180W Continuous, 250W Peak
more than 3 seconds
Weight (Without battery pack) 1.5 lb (0.68 kg)
Recommended Ambient
Temperature Range for Operation 41°F - 104°F (5°C - 40°C)
Recommended Ambient
Temperature Range for Storage -4°F - 158°F (-20°C - 70°C)
PACKING LIST
PART NAME QUANTITY
Power Inverter 1
Operator’s Manual 1

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC 11
DESCRIPTION
KNOW YOUR POWER INVERTER (Fig. 1)
The safe use of this product requires an understanding of the information on the
product and in this operator’s manual, as well as knowledge of the project you are
attempting. Before use of this product, familiarize yourself with all operating features
and safety rules.
180W
120V-1.5A
PURE SINE WAVE
Electric ContactsLED Button
LED Light
AC Output Port
USB-C Output
Port
Handle
Power
Button
USB-A Output Port
1
Latch
Power Button (with built-in LED Indicator)
To switch the power inverter on/off and indicate the power inverter status.
AC and USB Output Ports
To connect with AC and USB devices.
LED Button
Turns the LED light ON and OFF.
LED Light
Provides light in low light conditions or serves as an emergency light beacon.
Handle
Allows the user to carry the power inverter.

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC12
OPERATION
WARNING: Do not allow familiarity with this product to make you careless.
Remember that a careless fraction of a second is sufficient to inflict serious injury.
WARNING: Do not modify or attempt to repair the product except as indicated in
the instructions for use and care.
WARNING: This product is intended to be used indoors only. Do not use outdoors
under any conditions.
APPLICATION
You may use this product for the purposes listed below:
 Supplying power for small AC devices via AC output port.
 Supplying power for compatible small USB electronics via USB-A or USB-C output
ports.
 Providing light in low light conditions or serve as an emergency light beacon.
INSTALLING/REMOVING BATTERY
PACK (Fig. 2)
NOTE: Fully charge the battery pack
before first use.
To install battery pack
Align the mounting slots on the power
inverter with the ribs on the battery pack,
then move the power inverter towards the
battery pack until it snaps into position.
WARNING: Make sure that the latch on the power inverter snaps into place and
the battery pack is secured to the power inverter before beginning operation. Failure
to securely seat the battery pack could cause the battery pack to fall out, resulting in
serious personal injury.
2
Rib
Mounting Slot

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC 13
To remove battery pack
Hold the battery pack with one hand and pull the power inverter with the other hand to
separate them.
WARNING: Always be aware of location of your feet and children or pets around
you when separating the battery pack from the power inverter. Serious injury could
result if the battery pack fails. NEVER remove the battery pack at a high location.
WARNING: Always remove the battery when the power inverter is not in use.
TURNING POWER INVERTER ON/
OFF (Fig. 3)
1. Install the battery pack.
2. To turn the power inverter on, press
the power button and the button will
illuminate green, which indicates the
power inverter is activated.
3. To turn the power inverter off, press
the power button again and the green light will turn off, which indicates the power
inverter is deactivated.
NOTE:
If there is no device connected, the power inverter will shut off automatically in 2
hours.
If devices are connected but the USB output current is not more than 2W and the
AC output power is less than 5W, the power inverter will shut off automatically in 2
hours.
LED LIGHT (Fig. 3)
The power inverter is equipped with one LED light located on the top of the unit. The
light provides light in low light conditions or serves as an emergency light beacon.
The LED light could be turned on whenever the power inverter is activated or
deactivated.
3Power Button
LED Button
LED Light

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC14
To turn on the LED light, press the LED button. The light will turn on in low brightness
mode.
Press the LED button again to switch to high brightness mode.
Press the LED button the third time to switch LED light off.
In any mode, press and hold the LED button for more than 1 second and the light will
switch into flashing, “EMERGENCY” mode. Press the LED button again, the light will
shut off.
POWERING EXTERNAL DEVICES
1. Install a battery pack onto the power inverter.
2. Press the power button to turn on the power inverter. The LED in the power button
will glow solid green, which means the power inverter is ready for supplying power.
3. Connect devices into the power inverter’s USB ports and/or 120V AC output port. The
inverter will begin powering the devices automatically.
4. When the power inverter is not in use, disconnect devices from the power inverter,
then press the power button to turn off the power inverter.
5. Remove the battery pack from the power inverter.

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC 15
STATUS INDICATOR
Power Button LED Indicator Working Condition Action
Solid green
Standby
Normal operation. The
power inverter will shut
off automatically in 2
hours if there is no device
connected.
The connected USB device(s)
draw(s) no more than 2W
and the connected AC device
draws less than 5W.
The power inverter could
still power the devices but
will shut off automatically
in 2 hours.
If this happens, turn the
power inverter back on.
Powering connected devices Normal operation.
Flashing green (1Hz) for 1
minute, then shuts off Low battery voltage
Charge the battery. See
“LOW BATTERY PACK
CHARGE PROTECTION”
below.
Solid red for 1 min, then
shuts off
The power inverter or battery
pack is overheated.
Allow the unit to cool
down, then restart the
power inverter. See
“OVER TEMPERATURE
PROTECTION” below.
Flashing red quickly (2Hz)
for 1 minute, then shuts off
The power inverter may be
overloaded or short circuited.
Disconnect device from
the AC output port, see
“OVERLOAD OR SHORT
CIRCUIT PROTECTION”
below.
Flashing red slowly (1Hz)
for 1 minute, then shuts off Other electronics error.
Disconnect your device and
reconnect it again, if the
same fault reoccurs, please
contact EGO customer
service center.

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC16
OVER TEMPERATURE PROTECTION
If the battery or power inverter temperature exceeds 158 °F (70 °C) during
operation, the power button LED indicator will glow solid red for 1 minute, and
then the temperature-protection circuit will shut off the power inverter to protect
from overheating damage. Allow the battery and the power inverter to cool until the
temperature drops below 152 °F (67 °C) before restarting.
LOW BATTERY PACK CHARGE PROTECTION
When the battery pack charge reaches a low level, the power button LED indicator will
flash for 1 minute and then the power inverter will automatically shut down.
Charge the battery pack.
OVERLOAD OR SHORT CIRCUIT PROTECTION
When the connected AC device draws more than the rated power of the port, the power
button LED indicator will flash red quickly for 1 minute, and then the power inverter will
automatically shut down.
Disconnect the AC device.

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC 17
MAINTENANCE
WARNING: To avoid serious personal injury, always remove the battery pack
from the power inverter when cleaning or performing any maintenance.
WARNING: When servicing, use only identical replacement parts. Use of any
parts may create a hazard or cause product damage. To ensure safety and reliability, all
repairs should be performed by a qualified service technician.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to
damage from various types of commercial solvents and may be damaged by their use.
Use clean cloth to remove dirt, dust, oil, grease, etc.
WARNING: Do not at any time let brake fluids, gasoline, petroleum-based
products, penetrating oils, etc., come in contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which may result in serious personal injury.
STORING THE POWER INVERTER
1. Remove the battery pack from the power inverter.
2. Clean the power inverter thoroughly before storing it.
3. Store the power inverter in a dry, well-ventilated area, locked-up or up high, out of
the reach of children. Do not store the power inverter on or adjacent to fertilizers,
gasoline, or other chemicals.

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC18
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The power inverter
cannot be turned on.
The Battery pack
capacity is depleted.
Charge the battery pack.
The battery pack is too
hot.
Cool the battery pack until
its temperature drops below
152 °F (67 °C).
Other electronics error. Contact EGO customer
service center for repair.

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC 19
EGO LIMITED WARRANTY
WARRANTY POLICY TERMS AND DURATION
Chervon North America, Inc. (“Chervon North America”) provides the following Limited
Warranty for EGO products to the original purchaser of EGO products.
The detailed warranty period for each EGO product can be found online at
http://egopowerplus.com/warranty-policy.
Please contact EGO Customer Service Toll-Free at 1-855-EGO-5656 any time you
have questions or warranty claims or would like a hard copy of the warranty.
LIMITED SERVICE WARRANTY
EGO products are warranted against defects in material or workmanship from the date
of original retail purchase for the applicable warranty period. For any properly and
timely submitted warranty claim, if Chervon North America determines a product to be
defective during the warranty period, the product will receive free repair or replacement
as determined by Chervon North America.
HOW TO OBTAIN SERVICE
For warranty service, within the applicable warranty period, please contact EGO
customer service toll-free at 1-855-EGO-5656. When requesting warranty service,
you must present the original dated sales receipt. An authorized service center will
be selected to evaluate and repair the product if defective according to the stated
warranty terms. When bringing your product to the authorized service center, there may
be a small deposit that will be required when dropping off your tool. This deposit is
refundable when the repair service is deemed to be covered under warranty.
ADDITIONAL LIMITATIONS & EXCLUSIONS
This limited warranty applies only to the original purchaser from an authorized EGO
retailer and is not transferable. EGO products shall not be considered defective, and this
warranty will not apply, where the claimed defect is attributable to any cause other than
the above-defined defects. This warranty shall be void if the product has been used for
rental purposes. This warranty shall not apply to damage caused by accident, abuse,
misuse, alteration, modification, unauthorized repair, liquid contact, fire, earthquake or
other external cause; operating the product outside EGO’s instructions, specifications

56-VOLT POWER INVERTER — PAD1800/PAD1800-FC20
or guidelines; or failure to properly service of maintain the product. This warranty also
does not apply to cosmetic damage, including but not limited to scratches or dents;
defects caused by normal wear and tear or otherwise due to the normal aging of the
product.
THIS EXPRESS WARRANTY IS GIVEN IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR PARTICULAR PURPOSE OR USE, WHICH ARE DISCLAIMED. Any implied
warranties, including warranties of merchantability or fitness for a particular purpose,
that cannot be disclaimed under state law are limited to the applicable warranty period
defined at the beginning of this article. The sole and exclusive remedy in connection
with the purchase, installation, use, and/or performance of the EGO products is repair
or replacement of the product as determined by Chervon North America. Chervon North
America’s maximum liability shall not in any case exceed the purchase price paid for
the product. CHERVON NORTH AMERICA SHALL NOT BE LIABLE TO THE USER OR TO
ANYONE ELSE FOR CONSEQUENTIAL, INCIDENTAL, SPECIAL, EXEMPLARY, INDIRECT,
OR PUNITIVE DAMAGES ARISING FROM USE OF THE PRODUCTS, INCLUDING BUT NOT
LIMITED TO PERSONAL INJURY, DEATH, PROPERTY DAMAGE, LOST PROFITS, OR OTHER
ECONOMIC INJURY. This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state. Some states do not allow limitations on how
long an implied warranty lasts, the exclusion or limitation of incidental or consequential
damages, or the limitations on time to bring certain actions, so such limitations
contained herein do not apply to individual consumers in those states.
This warranty is subject to and shall be interpreted according to Michigan law without
regard to principles of conflicts of laws. No legal action shall be brought against
Chervon North America unless filed within one (1) year after the basis for such legal
action becomes known, or with the exercise of reasonable diligence should have
become known. Any action not timely filed shall be deemed waived.
For customer service contact us toll-free at: 1-855-EGO-5656 or
EGOPOWERPLUS.COM.
EGO Customer Service
769 Seward Ave. NW, Suite 102
Grand Rapids, Michigan 49504.
